Sena MESHPORT RED User manual

1.2.0
QUICK START GUIDE
ENGLISH
MESHPORT
RED
BLUETOOTH TO MESH INTERCOM ADAPTER FOR
PHONE OR TABLET PC

2
PRODUCT FEATURES
The easy-to-use MeshPort Red will turn any
Smartphones or Tablet PCs into a more advanced
and flexible communication device with the
simple push of a button.
Bluetooth®4.1
Mesh Intercom™
up to 0.8 km (0.5 mi)*
* in open terrain

3
GETTING STARTED
1. Update this product for free with the latest
firmware to fully enjoy the new advanced
features built into this product. Visit
senaindustrial.com to see how to update
your product.
2. Users can follow Sena on Facebook, YouTube,
Twitter and Instagram to receive the most up
to date information on products, helpful tips
and all other announcements regarding Sena
products.
SENA Technologies, Inc.
Customer Support: senaindustrial.com

4
TABLE OF CONTENTS
1. ABOUT THE MESHPORT RED 6
1.1 Product Details 6
1.2 Package Contents 6
1.3 Installing the MeshPort Red 7
1.3.1 Using the Belt Clip Mount 7
1.3.2 Using the Rubber Strap Mount 8
1.3.3 Attaching the Flat Surface Mount 8
2. GETTING STARTED 9
2.1 Downloadable Sena Software 9
2.1.1 Sena MeshPort App 9
2.1.2 Running the Sena MeshPort App 9
2.1.3 Sena Device Manager 10
2.2 Powering On and Off 10
2.3 Charging 10
2.4 Checking the Battery Level 11
3. MESH INTERCOM 12
3.1 What is Mesh Intercom 12
3.1.1 Open Mesh 12

5
4. USING THE MESHPORT RED 13
4.1 About the MeshPort Red 13
4.2 Bluetooth Pairing 14
4.2.1 Initially Bluetooth Pairing the
MeshPort Red 15
4.2.2 Bluetooth Pairing When the MeshPort
Red is Turned Off 15
4.2.3 Bluetooth Pairing When the MeshPort
Red is Turned On 16
4.3 Starting Mesh Intercom 16
4.3.1 Mesh Intercom On and Off 16
4.3.2 Phone Call and Answering 17
4.3.3 Mesh Intercom Reconnection 17
4.4 Muting the Microphone (Default: Unmute) 18
4.5 Mesh Intercom Repeater Mode 19
5. TROUBLESHOOTING 20
5.1 Firmware Upgrade 20
5.2 Fault Reset 20
5.3 Factory Reset 20
QUICK REFERENCE 21

6
1. ABOUT THE MESHPORT RED
1.1 Product Details
Mesh Intercom
Antenna
Status LED
Multi-function Button
DC Power Charging &
Firmware Upgrade Port
1.2 Package Contents
Main Unit Mesh Intercom
Antenna
Belt Clip
Mount
Rubber Strap
Mount
Flat Surface
Mount
USB Power &
Data Cable

7
ABOUT THE MESHPORT RED
1.3 Installing the MeshPort Red
Install the MeshPort Red where the antenna is not blocked
by the human body as much as possible.
When the human body is blocking the antenna, the Mesh
Intercom signal strength will be weakened.
1.3.1 Using the Belt Clip Mount
1. Attach the belt clip mount to the
back of the unit along the guide
rail, as shown in the illustration,
until you hear a click.
2. Mount the assembled unit in a
convenient location, such as on
your belt, with the antenna
upwards.
3. Angle the antenna away from
you to prevent it from interfering
with your movement.

8
ABOUT THE MESHPORT RED
1.3.2 Using the Rubber Strap Mount
1. Place the rubber strap mount on the object, wind the
rubber band around the object, and hang it on the hook.
2. Attach the rubber strap mount on the back of the main
unit along the guide rail until you hear a click.
1.3.3 Attaching the Flat Surface Mount
1. Locate an appropriate surface for attaching the flat
surface mount, clean the mounting surface with a
moistened towel, and allow it to dry thoroughly.
2. Peel off the cover of the adhesive tape of the flat surface
mount and attach it to the surface.
3. Attach the flat surface mount on the back of the main unit
along the guide rail until you hear a click.
Note: Make sure that the main unit sticks on the surface
firmly. Maximum adhesion occurs after 24 hours.

9
2.1 Downloadable Sena Software
2.1.1 Sena MeshPort App
You can use the Sena MeshPort App without pairing your
Smartphone to the MeshPort Red.
• Download
– Android: Google Play Store > ‘Sena MeshPort’
– iOS: App Store > ‘Sena MeshPort’
2.1.2 Running the Sena MeshPort App
1. Turn on the product.
2. Launch the Sena MeshPort App on your Smartphone.
3. Scan the product in the app.
• When you launch the app, the product is automatically
scanned.
• Tap the Scan icon ( ) to manually scan the product.
4. After scanning is complete, select the scanned product in
the app.
Note:
• If the product has not been scanned in the app, please
update the product to the latest firmware.
• How to identify the scanned product in the app
You can identify the product by the
six-letter code on the label on the
back of your product. XXXX
XXXX
XXXXXX
XXXXX
2. GETTING STARTED

10
GETTING STARTED
2.1.3 Sena Device Manager
The Sena Device Manager allows you to upgrade the
firmware from your PC or Apple computer. Download the
Sena Device Manager from senaindustrial.com.
2.2 Powering On and Off
To power on the MeshPort Red, press and hold the
Multi-functionButton for 1 second. The LED flashes blue.
To power off the MeshPort Red, press and hold the
Multi-functionButton for 1 second. The LED flashes red
once.
2.3 Charging
The MeshPort Red can be charged using many common
methods via the supplied USB power & data cable. The LED
turns red while the MeshPort Red is charging and turns
blue when it is fully charged. Depending upon the charging
method, the MeshPort Red will be fully charged in about 2
hours.
Note:
• Any 3rd party USB charger can be used with Sena
products if the charger is approved by either the FCC,
CE, IC or other locally approved agencies that Sena
accepts.
• The MeshPort Red is compatible with 5 V input USB-
charged devices only.
