Sena 10s User manual

Quick Start Guide
Motorcycle Bluetooth®
Communication System
INTERCOM
Pairing with Other Headsets
Headset A Headset B
“Intercom pairing”
Follow the steps above to pair with two or more headsets.
Using the Intercom
After Pairing…
1
2
3
You can start or end a two-way intercom
conversation with each headset.
RADIO
Turning On/O the FM Radio
1You will hear a double beep sound.
“FM on” or “FM o”
Seeking Stations
Rotate While Pressing
Saving or Deleting Stations
To Save To Delete
“Preset (#)” “(#)” “Save preset
(#)”
“Delete preset
(#)”
Listening to Preset
Stations
SETTING
Method1) Using the headset
You will hear a double beep sound.
“Conguration menu”
Method2) Using the Sena Device Manager
Connect the headset to your computer via a USB cable. Launch the Sena
Device Manager and click DEVICE SETTING to congure the headset
settings.
For details about downloading the Sena Device Manager, refer to the
leaet included in the package.
Method3) Using the Sena Smartphone App
1. On your smartphone, download the Sena Smartphone App for Android
or iPhone from Google Play or App Store.
Refer to www.sena.com/headset-app/ for more details.
2. Pair your smartphone with the headset.
3. Run the Sena Smartphone App. Swipe the screen to the right and tap
Setting to congure the headset settings.
TROUBLESHOOTING
Factory Reset
If you want to restore the 10S to factory default settings, press and hold the
Phone Button for 10 seconds. Tap the Jog Dial. The headset automatically
restores the default settings and turns o.
Fault Reset
If the 10S is not working properly for any
reason, push the pin-hole reset button
located on the back of the headset.
Sena Technologies, Inc.
www.sena.com
Customer Support: support.sena.com
E-mail: [email protected]
16.Feb
You can download the full version of the manual and view other
Sena products at the Sena website: www.sena.com.
Using the Speed Dial
You will hear a beep.
“Speed dial”
Voice Menu
• Last number redial
• Speed dial 1
• Speed dial 2
• Speed dial 3
• Cancel
Listening to Music
1
After Pairing…
Playing or Pausing Music Tracking Forward or Backward
until you hear
a double beep
Rotate While
Pressing

PREPARATION
Knowing the Headset Layout
Headset
Charging LED
Status LED
Phone Button
Jog Dial
DC Power Charging &
Firmware Upgrade Port
Clamp Unit
Microphone
Connector
MP3 Port
Left Speaker
Connector
Earbud Port Right Speaker
Connector
BASIC OPERATION
Operating the Buttons
5
Tap the
button
Double tap the
button
Press and hold
the button for
5 seconds
Press the two
buttons at the
same time
Rotate the
Jog Dial
Turning On/O the Headset
1
ON You will hear ascending
beeps.
“Hello”
OFF You will hear descending
beeps.
“Good bye”
Simultaneously press and hold the Jog Dial and the Phone Button
for 1 second to turn on or o the headset.
Adjusting the Volume
You will hear a beep when the volume
reaches the maximum or minimum
level.
PAIRING
Pairing with Mobile Devices - Phone, Music
“Phone pairing”
Bluetooth
Bluetooth
Sena10S
“Your headset is paired”
Checking the Battery Level
Blinking
70~100%
Blinking
30~70%
Blinking
0~30%
Turn on the headset and check the battery level via the Status LED.
3
“High” 70~100%
“Medium” 30~70%
“Low” 0~30%
Or, press and hold the Jog Dial and the Phone Button for 3 more
seconds when the headset turns on. You will hear a triple beep
and a voice prompt.
Charging the Battery
Charging
Fully charged
AC adapter
or
Using Phone Features
After Pairing…
Answering Calls
Ending Calls Rejecting Calls
or
or
or
“Hello”
until you hear a beep until you hear a beep
Making Calls
Using the Phone Keypad Using the Voice Dialer
Installing the Headset
1
2
1
3
2
12
1
2
1
2
Clamp Unit
Speaker
Microphone
Headset
Left
