Server 85783 User manual

Remote
Dispensing System
Remote Pump with 36" Hose
SINGLE POUCH SYSTEM
85783
Remote Pump with 36" Hose
TWIN POUCH SYSTEM
85784
...for purchasing our Remote Dispensing System.
This manually operated system simplifies
high-volume dispensing, eliminating the
hassle of a CO2driven dispenser.
HIGH VOLUME—HIGHLY CONVENIENT
Thank You
Use with pouches up to 3 gallons
with either 16mm fitment
or 38mm connector.

Page 2
REMOTE SYSTEM PARTS
PUMP
85951
MOUNTING
BRACKET
85791
TURN-KEY
CLAMPS (2)
85877
16MM ADAPTER
85264
DISPENSING CAP
85754
COUPLING
85753
52" BRUSH
85206
36" HOSE
85255
SINGLE POUCH
SYSTEM
85783
TWIN POUCH
SYSTEM
85784
EVACUATION
PLATE
07814
(2) EVACUATION
PLATES
07814
TORSION
SPRING
07813
(2) TORSION
SPRINGS
07813
POUCH
SUPPORT
07811
(2) POUCH
SUPPORTS
07811
WIREWISE RACK
88643
Twin system includes
(2) DISPENSING CAPS
85754
&
(2) 16MM ADAPTERS
85264
HOSE ASSEMBLY
85758

Page 3
LOOSEN SCREW
PULL HERE TO
RELEASE PUMP
SAFETY
According to food and safety regulations,
most foods must be stored and/or served at
certain temperatures or they could become
hazardous. Check with local food and safety
regulators for specific guidelines.
Be aware of the product you are serving
and the temperature the product is required
to maintain. Server Products, Inc. cannot
be responsible for the serving of potentially
hazardous product.
IMPORTANT
Clean, rinse, sanitize, and dry parts daily or regularly
to comply with local sanitization requirements.
NSF International lists this pump as:
“Not acceptable for dispensing potentially
hazardous foods.”
MOUNTING BRACKET DETAILS
MOUNTING BRACKET
85791
Side View
Assembled View
LATCH
ASSEMBLY
PLATE
85787
THUMB
SCREW,
10-32 X 3/4
86691
LEVER ASSEMBLY
85789
#10 PUSHNUT
86676
COTTERLESS HINGE PIN
81105
TORSION SPRING
85395
Tighten or Loosen
Thumb Screw to
Lock or Release Lever

Page 4
QUICK START
INSTALL THE COUNTERTOP BRACKET
1
• Choose a location with easy access and
convenient height for pump.
• Allow room for slack in hose during set-up,
pouch replacement and take-down.
• Use cutout template included to mark,
cut and drill holes.
• Secure the bracket with four screws.
YOU WILL NEED:
• A qualified person to install the countertop bracket
• Screwdriver, (4) screws, router and/or saw equipment
ATTACH HOSE TO PUMP
• Slide hose onto valve connector at bottom
end of pump.
• Rotate hose clamp turn-key clockwise to
secure hose.
3
TIP: Hose may be trimmed
if length is excessive.
Always clean pump first.
Refer to separate instructions for the pump.
• Insert pin on rear of bracket into hole on
rear of lid.
•
Pull the under-counter lever forward to allow
front pin of bracket into front hole of lid.
• Release lever to secure front bracket pin.
• Tighten thumbscrew to lock lever.
INSERT THE PUMP INTO BRACKET
2
IMPORTANT
TIP:
Do not locate
countertop
hole directly
above pouch
support(s).
Offset the hole
to leave space
for pump and
hose below.

Page 5
PREPARE POUCH(ES)
4
Place condiment pouch on flat surface with pouch connector or fitment facing upward.
If pouch has
38MM EXTERNAL CONNECTOR
If pouch has
16MM INTERNAL FITMENT
• Remove pouch cap.
• Screw dispensing cap onto connector.
• Screw dispensing cap onto adapter.
• Position adapter directly
over center of pouch fitment.
• Press adapter down to pierce
through film in pouch fitment.
Pump is fully engaged when
top surface of pouch fitment
touches adapter rim.
CONNECT HOSE TO POUCH
Snap hose end onto dispensing cap.
7
PRIME PUMP
8
Repeatedly press pump knob until condiment
is drawn up from pouch and hose below.
PLACE POUCH(ES)
INTO POUCH SUPPORT(S)
5
Locate dispensing cap in front slot directed
downward for best evacuation of condiment.
PLACE SUPPORT(S)
BENEATH COUNTER
Twin pouch system includes
wire rack for pouch supports.
6

Page 6
SWITCHING POUCHES
DISCONNECT HOSE
FROM EMPTY POUCH
1
Press button on side of hose coupling to release.
SNAP HOSE COUPLING ONTO
DISPENSING CAP ON NEW POUCH
2
See page 5 for how to prepare pouch(es).
WHEN A CONDIMENT POUCH BECOMES EMPTY...
DID YOU KNOW?
The hose coupler and dispensing cap
prevent leaks when hose is disconnected.

Page 7
DISASSEMBLY
DISCONNECT HOSE FROM PUMP
1
Turn hose clamp turn-key counter-clockwise
to loosen the hose.
DISCONNECT HOSE FROM
POUCH
2
Press button on side of hose coupling to release.
REMOVE PART(S) FROM POUCH
3
Unscrew dispensing cap from pouch.
IF USED: Remove adapter from 16mm pouch fitment.
REMOVE PUMP FROM COUNTER
BRACKET
4
• Loosen thumbscrew on bracket.
• Pull lever under counter to release front hole
of lid from front pin of bracket.
• Lift pump free from pin in back of bracket.
IMPORTANT: Only throw away empty pouch.
Keep any dispensing cap and adapter fitment.

Page 8 Manual 01898-RevD 052219
NEED HELP?
Please be prepared with your Part Numbers,
as shown on pages 2 & 3.
262.628.5600 | 800.558.8722
[email protected]
Server Products Inc.
3601 Pleasant Hill Road
Richfield, WI 53076 USA
SERVER PRODUCTS
LIMITED WARRANTY
GENERAL SERVICE,
REPAIR OR RETURNS
Server Products equipment is backed by a
two-year limited warranty against defects in
materials and workmanship.
For complete warranty information go to:
www.Server-Products.com
Before sending any item to Server Products
for service, repair, or return, contact Server
Products customer service to request a Return
Authorization Number. Merchandise must be
sent to Server Products with this number. Service
is extremely prompt. Typically, units are repaired
and ship out within 48 hours.
Merchandise being returned for credit must be in
new and unused condition and not more than 90
days old and will be subject to a 20% restocking
charge.
CLEANING
Use dishwashing
soap and hot water.
Use supplied brush to clean inside hose.
YES!
RINSE fully with clear water.
2
AIR DRY all parts fully.
4
CLEAN
1
After disassembling, thoroughly clean all
washable parts with soap and hot water.
• External surfaces may be wiped clean
with a clean damp cloth.
• Glass and surface cleaners approved for
use in food contact areas may be used.
• Do not use abrasive, caustic or ammonia
based cleansers.
• Do not use metal scrapers or cleaning
pads that could scratch surfaces.
SANITIZE
3
all parts according to local sanitization
requirements. All parts in contact with
food must be sanitized.
Refer to separate instruction manual
for pump cleaning.

5.625 C-C REF (NEW PATTERN)
3.000 C-C REF (NEW PATTERN)
4.000 C-C REF (EXISTING HOLES)
3.500 C-C REF (EXISTING HOLES)
ACCESS END
2.50
6.00 .31
3.000 C-C TYP
5.625 C-C TYP
MOUNTING HOLE PATTERN
CUTOUT TeMPLATe Full Scale 1:1
