Seville Classics UltraHD 20213 User manual

TR201224
ASSEMBLY INSTRUCTIONS
UltraHD®2-Drawer Storage Cabinet (Model No. 20213)
20" W x 18" D x 34.7" H
(50.8 cm W x 45.7 cm D x 88.2 cm H)
Reference page 11 for special care
and maintenance of stainless steel

1

#20 Drawer
2

(#28) Front Frame X 1PC
(#29)Back Panel X 1PC
(#6)Door Panel X 1PC
(#5)Middle Shelf X 1PC
PARTS LIST
Please check the parts carefully according to the parts list. If you are missing any parts, please contact our
customer service department. (Please refer to page 12 of 13.)
(#3) Wood Top X 1PC
(#4)Bottom Panel X 1PC
(#1)Left Panel X 1PC
(#2)Right Panel X 1PC
3

(#20-1)Drawer Front Panel X 2PCS
(#20-2)Drawer Base Panel X 2PCS
(#24)Drawer Mat X 2PCS
(#20-3) Drawer Left Panel X 2PCS
(#20-5)Drawer Back Panel X 2PCS
(#10)3"x1"Wheel W/O Brake X 2PCS
PARTS LIST
Please check the parts carefully according to the parts list. If you are missing any parts, please contact our
customer service department. (Please refer to page 12 of 13.)
(#20-4)Drawer Right Panel X 2PCS
(#9) 3"x1"Wheel with Brake X 2PCS
4

(#23) Magnet x 2 PCS
PARTS LIST
Please check the parts carefully according to the parts list. If you are missing any parts, please contact our customer
service department. (please refer to page 12 of 13) .
(#21) Screw Driver x 1 PC
(#25-1) Wrench x 1 PC
(#14) Screw A (M4 x 10 ) X 37 PCS
(#15) Screw B (M4 X 8L) X 44PCS
5

TIP:
WARNING:
Step 1: Install Front Frame (#28) to Wood Top (#3)
Step 3: Install the Right Panel (#2)
Step 2: Install Left Panel (#1)
Attach Left Panel (#1) to Front Frame (#28), making
sure the "Top" of Left Panel (#1) is on the Wood Top
(#3). Use 5 pcs of Screw A (#14) to tighten.
UltraHD® 2-Drawer Storage Cabinet (Model No. 20213)
*NOTE: We recommend using TWO people to assemble the cabinet.
Some parts may have sharp edges. To avoid injury,
wearing gloves is recommended during assembly.
A magnetic screwdriver is included for your
convenience. If a power screwdriver is used, keep
on a low torque setting.
Attach the Right Panel (#2) to the Front Frame
(#28),make sure the "Top" of Right Panel (#2) is
close to the Wood Top (#3). Again, the “Top” is
indicated by a sticker on one of the vertical columns.
Use 5 pcs of Screw A (#14) to tighten.
Open both boxes, locate and remove the cardboard
box containing the Wood Top (#3). Set the other
parts to the side.
When assembling this item, place the Wood Top up
side down on the cardboard to avoid scratching the
top surface.
Place the Front Frame (#28) as the left picture
shows and use 2 pcs Screw A (#14) to tighten.
Attach the
"Top" of the Front Frame (#28), as indicated by the
attached sticker, to the Wood Top (#3).
(The Wood Top has set front or back end,
make sure to assemble on the front side of the
wood top).
Front
Back
Front
Back
#3
#14 #28
#1
#2
#14
#1
#14
6

Step 4: Install Bottom Panel (#4)
Step 5: Install Back Panel (#29)
Step 6: Install Wheels (#9 and #10)
Attach Bottom Panel (#4) to the Left and Right Panel
(#1 & #2) as the left picture shows. Use 6 pcs of
Screw A (#14) and Screw Driver (#21) to tighten.
Place the Back Panel (#29) as the left picture shows
and use 11 pcs Screw A (#14) to tighten.
Use Wrench (#25-1) to tighten the wheels (#9) &
(#10) on the Front Frame (#28) and Bottom Panel
(#4).
Note: The wheels with brake (#9) should be fixed on
the Front Frame (#28), and the wheels without brake
(#10) should be fixed on the Bottom Panel (#4).
Front
Back
#4
#14
#14
#29
#25-1
7
UltraHD® 2-Drawer Storage Cabinet (Model No. 20213)
*NOTE: We recommend using TWO people to assemble the cabinet.

Step 7:
Step 8:
Step 9: Install Drawer Right Panel (#20-4)
Step 10:
Install Drawer Back Panel (#20-5)
Attached the Drawer Back Panel (#20-5) to the
Drawer Left and Right Panel (#20-3 & #20-4) and
Drawer Base Panel (#20-2), lined up the screw
holes. Use 6 pcs of Screw B (#15) to
tighten, then tighten all screw B (#15) that are
not tightened in the above step.
Install Drawer Base Panel (#20-2)
Place the Drawer Base Panel (#20-2) to the
Drawer Left Panel (#20-3) and Drawer Front
Panel (#20-1) as the left photo shows.
Use 5 pcs Screw B (#15) to tighten.
Don't tighten screws completely.
Attached the Drawer Right Panel (#20-4) to the
Drawer Front Panel (#20-1) and the Drawer Base
Panel (#20-2) as the left photo shows.
Use 5 pcs Screw B (#15) to tighten.
Don't tighten screws completely.
Install Drawer Front Panel (#20-1) and Drawer
Left Panel (#20-3)
Attached the Drawer Left Panel (#20-3) to the
Drawer Front Panel (#20-1) as the left photo
shows. Use 2 pcs Screw B (#15) to tighten.
Don't tighten screws completely.
#20-5
#15
#15
#20-3
#20-1
#20-1
#15
#20-2
#20-3
#20-4
#15
8
UltraHD® 2-Drawer Storage Cabinet (Model No. 20213)
*NOTE: We recommend using TWO people to assemble the cabinet.

Step 7:
Step 8:
Install the Magnet (#23)
Place the Drawers (#20)
A. Pull out the sliders completely, then attach the
drawer to the sliders. Make sure the square holes
on the drawer side panels are line up, and the
drawer is hooked onto the sliders completely.
B. Use 4pcs Screw B (#15) to tighten the drawer to
the Slider.
Repeat above steps to place another drawer.
Note: Do not tighten any screws completely until
all the drawers are adjusted well.
The oval hole at the front of the slider allows for
the gaps between the drawers to be adjusted.
Make the adjustments once all the drawers are
installed.
Install the Magnet (#23) on the Front Frame
(#28)as the left photo shows, use 4 pcs Screw A
(#14) to tighten.
A
C
B
C
#20
#23
#14
9
UltraHD® 2-Drawer Storage Cabinet (Model No. 20213)
*NOTE: We recommend using TWO people to assemble the cabinet.

Step 9: Install the Middle Shelf (#5)
Step 10: Install Door Panel (#6)
Note:
Step 11: Place the Drawer Mat (#24) into the Drawer
`
Place the Middle Shelf (#5) in the unit at the
desired height and ensure that all four corners
are secured on the hooks on the front and back
frame.
Attached the Door Panel (#6) to the Front Frame
(#28) as the left photo show, use 4 pcs Screw A
(#14) to tighten.The door could be left or right
side assembled as your desire.
1. The OB hole on the door is able to adjust the
tolerance of the door.
2. The door panel can be installed on the left or
right side of the door frame
#5
#24
#6
#14
#6
#14
10
UltraHD® 2-Drawer Storage Cabinet (Model No. 20213)
*NOTE: We recommend using TWO people to assemble the cabinet.

How to pull the drawer out of the unit?
`
1). To pull the drawers out of the unit, pull the
black plastic clip on the right side of the
drawer up, then push on the black plastic clip
on the left side of the drawer down. Now you
can pull the drawer out.
2). You can also unscrew the 4pcs screws on the
side of the drawer to make the whole drawer up.
Pull
Push
Stainless Steel Maintenance:
These parts have an UltraGuard® fingerprint
resistant finish. Do not use traditional
stainless steel cleaners on this unit. Lightly
wipe off once a month with clean warm water
and a soft cloth (preferably a micro fiber
cloth). This is the safest formula to prevent
new stains from appearing over time and
manage unwanted fingerprints or grease
marks. Remember to always wipe in the
direction of the surface grain (NEVER ACROSS)
and always use a lint-free cloth. Once the
surface is clean,thoroughly wipe dry with a
soft absorbent cloth.
11
UltraHD® 2-Drawer Storage Cabinet (Model No. 20213)
*NOTE: We recommend using TWO people to assemble the cabinet.

Seville Classics, Inc.
19401 Harborgate Way Torrance, CA 90501 USA
Telephone: [phone] within USA
Fax: [phone]
Hours: 9:00am - 4:30pm (Pacific Standard Time)
E-mail: [email protected]
Website & Online Store: www.sevilleclassics.com
