ASSEMBLY INSTRUCTIONS
GC10/12
Heavy Duty Workbench
Model: CWB1630R
Part No: 7637825

2
Parts & Service: 020 8988 7400/E-mail:[email protected] or [email protected]
INTRODUCTION
Thank you for purchasing this CLARKE product. Before assembling the
workbench, be sure to read these instructions thoroughly. In doing so you will
ensure the safety of yourself and of others around you, and you can look
forward to the product giving you long and satisfactory service.
CONTENTS
CWB1630R (with 1 half shelf)
4
1
1
Posts (917mm long)
A
4
Plastic Post Caps C
Plastic Feet B
Centre Support D
Long Beams (with holes) E2
4
Long Beams (without holes) F
1
Upper End Beams H
2
2
2
1
1
Lower End Beams I
Shelf Clips J
Small Board K
Large Board L
Shelf Support Beam G
Safe Working Load 300kg (full shelf) /100kg (half shelf) UDL
Post
Upper End
Beam
Beam
Lower End
Long Beam
Shelf Support
Beam
Centre Support
A
E
Long Beam F
I
H
G
D

3
Parts & Service: 020 8988 7400/E-mail:Part[email protected] or [email protected]
ASSEMBLY
The tabs of the beams will often enter the slots fully using just firm hand
pressure but if they are too tight, you may require a rubber mallet or hammer
to assist. If so, always use a cloth to
protect the product paint finish.
1. Decide how high you want the
shelf to be, relative to the floor.
3. Repeat this again for the other
end of the assembly, making sure
that the corresponding end
beam is at the same height.
Note that the edge with the wider
flange should be installed
uppermost to touch the shelf. (the
face with open edges should face
the rear of the unit).
FIG 4
Shelf Support
Beam
Centre Support
Lower End Beam
FIG 3
FIG 1
Slots
FIG 2
Long Beam
Upper
End
Beam
•Only use the mallet to tap gently,
ensuring the tabs of the beams
are in line with the slots in the posts.
•When using a hammer or mallet,
always strike the edge closest to
the post and protect the paint with
a cloth.
2. Fit the upper end beams between
two posts as shown in Fig 1.
A
4. Now fit the long beams to match
the upper end beams as shown
in Fig 2.
E
H
5. Fit the centre support between
the lower end beams to support
the lower shelf as shown in Fig 3.
D
6. Slot the shelf support beam
between the long beams to carry
the large board.
G
E
L
E
H
D
I
G

7. Fix the shelf clips to the centre
support and place the small
board on the half shelf
8. Fit the plastic post capstop of each
post as shown in Fig 5.
SAFETY ADVICE
•Always place heavier items on the
shelf where possible.
•Always distribute your loads evenly
where possible.
GUARANTEE
Parts & Service: 0208 988 7400
E-mail: [email protected] or [email protected]
Clarke International Hemnall Street, Epping, Essex CM16 4LG
FIG 5
Plastic
Post
Cap C
J
D
K
9. Fix the plastic foot to end of
each post as in Fig 6.
A
B
Plastic
Foot
Post
FIG 6
A
B
This CLARKE product is guaranteed against
faulty manufacture for a period of 12 months from the date of purchase. Please
keep your receipt as proof of purchase. This guarantee is invalid if the product is
found to have been abused or tampered with in any way, or not used for its
intended purpose.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
