Shuttle FX83 User manual

FX83
Socket 754
AMDAthlonTM 64Processor
Based DDR MAINBOARD
User's Manual

Shuttle®FX83
Socket 754
AMD Athlon TM 64 Processor
Based DDR Mainboard
Manual Version 1.0
Copyright
Copyright©2004 by Shuttle®Inc. All Rights Reserved.
No part of this publication may be reproduced, transcribed, stored in a retrieval system,
translated into any language, or transmitted in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without
prior written permission from Shuttle®Inc.
Disclaimer
Shuttle®Inc. shall not be liable for any incidental or consequential damages resulting from the
performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual.
Information in this manual has been carefully checked for reliability; however, no guarantee is
given as to the correctness of the contents. In the interest of continued product improvement,
this company reserves the right to revise the manual or include changes in the specifications
of the product described within it at any time without notice and without obligation to notify any
person of such revision or changes. The information contained in this manual is provided for
general use by the customers.
Trademarks
Shuttle is a registered trademark of Shuttle Inc.
Intel, Pentium is a registered trademarks of Intel Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other product names used in this manual are ascribed to their respective
owners and acknowledged.
M847

Thermalissueishighlyessentialforprocessorswithaspeedof600MHz and above.
Hence,we recommend you to usetheCPU fan qualified byAMDormotherboard
manufacturer.Meanwhile, pleasemake sureCPU andfanare securelyfastened well.
Otherwise,improper faninstallation notonly getssystemunstable butalso could
damageboth CPU and motherboardbecause insufficient thermal dissipation.
Ifyou would like toknowmore about thermal topicpleasesee AMD website for
detailedthermal requirementthrough theaddress:
http://www.amd.com
WARNING

Ifyou’ve changed your CPU or overclockedyoursystem, the system may fail tobootup,
even with a Clear CMOS jumper physically resetted. The reason is that NVIDIA’s new
nForce2 chipset introduces a way to reset a Clear CMOS jumper without removing a
chassis.Please follow the stepslisted below:
1. Turnoff yourcomputer andunplugthe powercable. Reconnectitafter 30seconds;
2. Press<Insert>andthenpress yourcomputer’sstart button.Continueholding <Insert>
untilthe systembegins thePOST (Power-OnSelfTest);
3. Immediatelypress <Del>to enter theBIOS;
4. Select‘Load Optimized Defaults’to return yoursystemto a bootablecondition; then
select ‘SAVE to CMOS and EXIT’;
5. Rebootyour system.
Moreover, if your system fails to boot up after you reset the CPU FSB, select “SAVE to
CMOS and EXIT” in the BIOS.After the system restarts, there is on screen a message
warningyounot toreset orturn offyour computer:
Warning! New setting is updating now
Do not Reset or Shutdown the system
Yoursystem works aftertheBIOS is updated.
NOTICE

Statement of Shuttle Mainboard via the EMI Test
Shuttle mainboards have been via the EMI test in terms of series of regulations: EN55022/
CISPR22/AS/NZS3548Class B, EN55024 (1998/AS/NZS), EN4252.1(1994), EN61000,ANSI
C63.4 (1992), CFR47 Part 15 Subpart B, and CNS13438 (1997). The items tested are illus-
trated as follows:
(A)Voltage:AC110V/60HZ &AC230V/50HZ
(B) Tested Product Information:
Product Name: PC Mainboard
Status: Sample
ModelName:FX83
S/N:N/A
CPU: ExternalFrequency: 200 MHz AMDK83400+
Keyboard Port: one port with 6 pins
Mouse Port: one port with 6 pins
USB 2.0 Port: six ports with 4 pins
Parallel Port: one port with 9 pins
LAN Port: one port with 8 pins
1394 Port: one port with 6 pins respectively
1394 Port: one port with 4 pins respectively
VGA Port: one port with 15 pins
LAN Port: one port wiht 8 pins
Mic-Out & Line-In & Headphones Ports: one port for each
SPDIF_In/ Out: one port for each
DDR Memory: DDR 400 128 MB *2
Power Cable: Detachable and Shielded (with a GND pin)
Monitor:CRT
Maximum Resolution: 1280 X 1024 V:60Hz
All CPUs have completely been tested, and values offered by the worst EMI combination of
CPU external frequency are listed as follows:
Test Mode External Frequency CPU Open/Close
1 200MHz 200 MHzAMD K8 3400+ Close
2 200MHz 200 MHz AMD K8 3400+ Open
(C) Remedy for the Tested Product & Its EMI Interference:
Remedy:N/A
EMIInterference:
Crystal:14.318MHz(Y2)/14.318MHz(Y3)/24.576MHz(X4)/24.576MHz(X5)/
25.00 KHz(Y4)/32.768 MHz(X1)/25.00 MHz(X1)
ClockGenerator:U11

(D) Supported Host Peripherals:
(E) Notices for Assembling Computers:
1. Cases should be made of iron or other metal that has good electric conductivity.
2. Cylinders in a case should be made of metal, and as having a mainboard mounted
in a case, make sure screws are all utilized and fastened on a mainboard.
3. An I/O shielding should be contacted with I/O metallic parts of a mainboard.
4. Cables should appropriately be arranged and fixed in a case. Follow instructions:
Ø Leave IDE cables not crossed upon CPU and SDRAM;
Ø Leave power cables minimum in length, and not crossed upon a mainboard;
Ø Leave CPU fan cables minimum in length, and not near CPU;
Ø Leave cables on panels and other spare cables tied in a computer case.
5. Make sure an EMI shielding attached to a case has properly been installed.
6. Make sure a 5.25" or 3.5" FDD and screws are fastened to an EMI shielding.
7. Make sure a case is closely in contact with EMI connected points.
8. Make sure there is no cleft in a case which is not deformed.
9. Make sure a PCI orAGP door is bound to a case.
10. Make sure cables of other devices (fans or some others) are fixed in a case.
Host Peripheral Product Name Model Name
#1 Case FX83
#2 Shuttle Power Supply PC35I2402
#3 IBM HDD (82.3GB) IC35L080AVVA07-0
#4 CODE DVD Player DVD-116
#5 Panasonic FDD JU-257A606P

- 1 -
TABLE OF CONTENTS
WHAT'S IN THE MANUAL.................................................................... 5
Quick Reference............................................................................................... 5
About This Manual............................................................................................ 5
1 INTRODUCTION................................................................................ 6
1.1 TO DIFFERENT USERS ............................................................................. 6
FIRST-TIMEDIYSYSTEMBUILDER............................................................ 6
EXPERIENCEDDIY USER......................................................................... 6
SYSTEMINTEGRATOR............................................................................... 6
1.2 ITEM CHECKLIST....................................................................................... 7
2 FEATURES ........................................................................................ 8
2.1 SPECIFICATIONS ....................................................................................... 8
3 HARDWARE INSTALLATION .......................................................... 11
3.1 STEP BY STEP INSTALLATION................................................................11
Accessories of FX83.............................................................................11
STEP1 CPU Installation ........................................................................ 12
STEP 2 Set Jumpers............................................................................. 13
STEP3 Install DDR SDRAMSystem Memory........................................ 13
STEP4 InstallInternalPeripherals in SystemCase ................................ 14
STEP5 MounttheMainboard ontheComputer Chassis ........................ 15
STEP6 Connect Front Panel Switches/LEDs ........................................ 16
STEP7ConnectIDE,FloppyandSerialATA Disk Drives....................... 17
STEP8 ConnectOther InternalPeripherals............................................ 18
STEP9 Connect the Power Supply........................................................ 20
STEP10InstallAdd-on Cards in ExpansionSlots .................................. 20
STEP11Connect External PeripheralstoBack-Panel ........................... 21
STEP 12 First Time System Boot Up ..................................................... 22
STEP13 InstallDrivers & SoftwareComponents ................................... 23

- 2 -
3.2 JUMPER SETTINGS ................................................................................. 24
JUMPERS& CONNECTORS GUIDE.................................................... 25
Jumpers
Clear CMOS Setting (JP1) ................................................................... 27
Back-Panel Connectors
COM1Port Connector ........................................................................... 28
VGAPort Connector .............................................................................. 28
TV-OutConnector .................................................................................. 28
ClearCMOSButton............................................................................... 28
10/100base-T LAN Port Connector....................................................... 28
IEEE1394aPortConnector .................................................................. 28
USB0/1/2/3 Port Connectors................................................................. 28
PS/2Keyboard&PS/2MouseConnectors............................................ 29
Center/BassPort Connector.................................................................. 29
Rear-OutPortConnector ...................................................................... .29
Line-OutPort Connector ........................................................................ 29
Front-Panel Connectors
ATXPower On/Off Switch Header (PWON)........................................... 30
HDD LED Header (HLED).................................................................... 30
Green LED/Power LED Header (GLED/PLED) .................................... 31
HardwareReset Header (RST) ............................................................. 31
FrontPanel I/OConnector (JP3) ............................................................ 32
Internal Peripherals Connectors
EnhancedIDE andFloppyConnectors................................................... 33
SerialATA Connectors........................................................................... 33
Other Connectors
ATXPower SupplyConnectors (PWR1 and CN13)................................ 34
CPU,System and Chipset Fan Connectors (FAN1/2/3).......................... 35
AudioCD_IN Connector (CN11) (Black) ................................................ 35

- 3 -
AudioAUX_IN Connector (CN12)(White) .............................................. 36
WirelessKeyboard and Mouse Connector (CN2)................................... 36
SMBUSConnector(JP5)....................................................................... 36
IRHeader (JP6)..................................................................................... 37
ParallelPortHeader-EXT.Print Port (JP7)............................................. 37
SPDIF_In/OutHeader (JP8)................................................................... 38
USB Headers (USB3/ USB4) ................................................................ 38
3.3 SYSTEM MEMORY CONFIGURATION ..................................................... 39
INSTALLMEMORY............................................................................... 39
UPGRADEMEMORY............................................................................ 39
4 SOFTWARE UTILITY ......................................................................40
4.1 Mainboard CD Overview ......................................................................... 40
4.2 Install Mainboard Software ..................................................................... 40
4.2.A Install VIA 4in1 Chipset Driver ............................................................. 41
4.2.B Install VIA VGA Driver........................................................................... 41
4.2.C Install VIA LAN Driver........................................................................... 42
4.2.D Install Realtek Audio Driver ................................................................. 42
4.2.E Install VIA RAID Driver.......................................................................... 43
4.2.F Install VIA USB 2.0 Driver ..................................................................... 43
4.3 View the User's Manual........................................................................... 44
5 BIOS SETUP ................................................................................... 45
5.1 ENTER BIOS ............................................................................................. 45
5.2 THE MAIN MENU ...................................................................................... 46
STANDARD CMOS FEATURES ............................................................... 48
ADVANCED BIOS FEATURES................................................................. 51
ADVANCED CHIPSET FEATURES .......................................................... 55
INTEGRATEDPERIPHERALS .................................................................. 60

- 4 -
POWERMANAGEMENT SETUP.............................................................. 64
PNP/PCICONFIGURATIONS .................................................................... 68
PCHEALTH STATUS ................................................................................ 70
FREQUENCY/VOLTAGECONTROL ......................................................... 72
LOAD FAIL-SAFE DEFAULTS .................................................................. 73
LOADOPTIMIZED DEFAULTS ................................................................. 73
SETSUPERVISOR/USERPASSWORD................................................... 74
SAVE & EXIT SETUP................................................................................ 75
EXITWITHOUTSAVING ............................................................................ 75

- 5 -
WHAT'S IN THE MANUAL
Quick Reference
Hardware Installation >> Step-by-Step ................................................ Page 11
Jumper Settings >> A Closer Look.......................................................Page 24
Drivers/Software Utilities >> How to Install .........................................Page 40
BIOS Setup >> How to Configure.........................................................Page 45
About This Manual
For First-Time DIY System Builder.........................................................Page 6
For Experienced DIY User ......................................................................Page 6
For System Integrator .............................................................................Page 6

- 6 -
1INTRODUCTION
1.1 To Different Users
First-Time DIY System Builder
Welcome to the DIY world! Building your own computer system is not as diffi-
cult as you may think. To make your first computer DIY experience successful,
right from the start, we have designed the 3.1 Hardware Installation section
in a step-by-step fashion for all the first-time DIY system builders. Prior to instal-
lation, we also suggest you to read the whole manual carefully to gain a com-
plete understanding of your new Shuttle FX83 mainboard.
Experienced DIY User
Congratulate on your purchase of the Shuttle FX83 mainboard. You will find
that installing your new Shuttle FX83 mainboard is just easy. Bundled with an
array of onboard functions, the highly-integrated FX83 mainboard provides you
with a total solution to build the most stable and reliable system. Refer to sec-
tions 3.2 Jumper Settings and Chapter 4 Drivers/Software Utilities to
find out how to get the best out of your new mainboard. Chapter 5 BIOS
Setup also contains the relevant information on how to tune up your system to
achieve higher performance.
System Integrator
You have wisely chosen Shuttle FX83 to construct your system. Shuttle FX83
incorporates all the state-of-the-art technology of the VIA K8M800+VT8237
chipset from VIA. It integrates the most advanced functions you can find to
date in a compact Small Form Factor ATX board.

- 7 -
1.2 Item Checklist
Check all items with your FX83 mainboard to make sure nothing is missing.
The complete package should include:
-One piece of Shuttle FX83 Mainboard
-One piece of ATA 133/100/66/33 Ribbon Cable
-One CD-ROM Cable
-One TV-Out Cable
-One piece of Serial ATA Cable
-FX83 User's Manual
-One piece of Bundled CD-ROM with containing:
ØFX83 user's manual saved in PDF format.
ØInstall VIA 4in1 driver.
ØInstall VIA VGA driver.
ØInstall VIA LAN driver.
ØInstall Realtek Audio driver.
ØInstall VIA RAID driver.
ØInstall VIA USB 2.0 driver.
ØAward Flashing Utility.
SERIAL
ATA
V
S
O
S
O
C
K
E
T
7
5
4
1
F
A
N
2
1
34333T1326F
ALC650
M
C
C
N
1
3
1
1
PWR1
IDE1
IDE2
1
1
1
F
D
C
1
AMIC
A290021TL-70 0122T B3X5A
JP5
1
J
P
9
1
U
S
B
3
JP1
1
J
P
7
1
1
JP2
CN1
1
CD_IN
AUX_IN
FAN3
1
1
1
JP8
DIMM1 DIMM2
SATA1
J
P
6
1
1
USB4
BA
T1
J
P
3
1
CN1
2
CH1CH0

- 8 -
2 FEATURES
FX83 mainboard is carefully designed for the demanding PC user who wants high perfor-
mance and maximum intelligent features in a compact package.
2.1 Specifications
-CPU Support
Supports AMD Althon TM 64, 754 pin processor with 200 MHz FSB.
-Chipset
Features VIA K8M800 N.B. and VT8237 S.B..
Integrated Graphics/Video Accelerator.
8X AGP3.0 interface at 533MHz.
Processor interface via Hyper Transport bus.
-Jumperless CPU Configuration
Soft-configuration FSB (The FSB speed is software configurable from 200MHz
to 232MHz in the Frequency / Voltage Control of BIOS setup program.)
-On Board 5.1 Channel AC97 Audio
Realtek ALC650 compliant with AC'97 2.2 specifications.
5.1 channel slot selectable DAC Output for multi-channel applications.
-Versatile Memory Support
Two 184-pin DIMM slots to support up to 2GB of PC1600, PC2100,
PC2700 or PC3200 compliant DDR SDRAM module.
-AGP Expansion Slot
Supports AGP3.0 0.8V signaling for 8X and 4X modes.
Suooprts AGP2.0 1.5V signaling for 4X and 2X modes.
-PCI Expansion Slots
PCI 2.2 specification compliance.
Provides one 32-bit PCI slot.
-8 USB 2.0/1.1 Complaint Interface Onboard
Ø4 x USB 2.0 connectors on back-panel.
Ø2 x USB 2.0 connectors on front-panel.
Ø2 x USB port headers on mid-board.

- 9 -
-I/O Interface
Provides a variety of I/O interfaces:
Ø1 x Floppy interface for 3.5-inch FDD with 720KB, 1.44MB, or 2.88MB
format or for 5.25-inch FDD with 360K or 1.2MB format.
Ø1 x DB9 Serial connector 16550 UART compatible.
Ø1 x VGA connector.
Ø1 x TV-OUT connector.
Ø4 x USB2.0 ports.
Ø1 x RJ45 LAN connector.
Ø1 x IEEE 1394a connector.
Ø1 x PS/2 Mouse connector.
Ø1 x PS/2 Keyboard connector.
Ø1 x Center/Bass port.
Ø1 x Rear-Out port.
Ø1 x Line-Out port.
-PCI Bus Master IDE Controller Onboard
Two Ultra DMA 133/100/66/33 Bus Master Dual-channel IDE ports provide
support to a maximum of four IDE devices (one Master and one Slave per chan-
nel). The IDE Bus implements data transfer speeds of up to 133/100/66/33
MB/sec and also supports Enhanced PIO Modes.
80-pin Cable Backward Compatible Legacy ATAPI Devices, DVD-ROM, DVD
Dual, ATAPI IDE CD-ROM, CD-R, CD-RW, and LS-120 Supports.
-ATX Power Supply Connector
ATX power supply unit can connect to the onboard 20-pin Pentium 4 stan-
dard ATX power connectors, supporting Suspend and Soft-On/Off by dual-
function power button.
The Pentium 4 ATX power include other 4-pin +12V ATX power connector.
-Advanced Configuration and Power Interface
Features four power saving modes: S1 (Snoop), S3 (Suspend to RAM), S4
(Suspend to DISK), and S5 (Soft-Off). ACPI provides more efficient Energy
Saving Features controlled by your operating system that supports OS Direct
Power Management (OSPM) functionality.

- 10 -
-System BIOS
Provides licensed Award BIOS V6.0 PG on 4Mb Flash core and supports
Green PC, Desktop Management Interface (DMI).
-Form Factor
System board conforms to Shuttle specification.
Board dimension: 254mm x 185mm.
-Advanced Features
ØLow EMI - Built in spread spectrum and automatic clock shut-off of
unused PCI/SDRAMS slots to reduce EMI.
ØDual Function Power Button - The system can be in one of two states,
one is Suspend mode and the other is Soft-Off mode. Pushing the
power button for less than 4 seconds places the system into Suspend
mode. When the power button is pressed for longer than 4 seconds, the
system enters Soft-Off mode.
ØModem Ring Power-On - The system can be powered on automatically
by the activation of modem ringing.
-Intelligent Features
ØVoltage Monitoring - Monitors various voltages of key elements, such
as the CPU, and other critical system voltage levels to ensure stable
current passing through mainboard components.
ØFan Status Monitoring -To prevent CPU from overheating, the CPU fan
is monitored for RPM and failure. (CPU Cooling FAN with RPM sensor is
required.)
ØTemperature Monitoring -This item allows users to make sure whether
the CPU or system runs in a suitable temperature.
ØCPU Fan Speed Control -This SMART Bios enabled 4 phase Variable
Fan Speed and CPU temperature Control feature.

- 11 -
3HARDWARE INSTALLATION
Before removing or installing any of these devices including CPU, DIMMs,
Add-On Cards, Cables, please make sure to unplug the onboard power
connector.
This section outlines how to install and configure your mainboard. Refer to the following
mainboard layout to help you to identify various jumpers, connectors, slots, and ports.
Then follow these steps designed to guide you through a quick and correct installation of
your system.
3.1 Step-by-Step Installation
Accessories Of FX83
S
O
C
K
E
T
7
5
4
1
F
A
N
2
1
34333T1326F
ALC650
M
C
C
N
1
3
1
1
PWR1
IDE1
IDE2
1
1
1
F
D
C
1
AMIC
A290021 TL-70 0122T B3X5A
JP5
1
J
P
9
1
U
S
B
3
JP1
1
JP7
1
1
JP2
CN11
CD_IN
AUX_IN
FAN3
1
1
1
JP8
DIMM1 DIMM2
SATA1
J
P
6
1
1
USB4
BAT1
J
P
3
1
CN12
CH1CH0
ATXPower
F
l
o
p
p
y
C
o
n
n
e
c
t
o
r
-
F
D
C
1
Two IDE Slots
Front Panel Connector-JP9
SMBUS Connector
-JP5
USB Header-USB3
Clear CMOS-JP1
K8M800 Chipset
VT8237 Chipset
One AGP Slot
One PCI Slot
AUX_IN Connector
CD_IN Connector
IR Connector-JP6
LAN & Dual USB
Ports
Wireless KB/MS
Connector-JP2
1394 & Dual USB
Ports
Socket 754
Clear CMOS Button
TV-OUT Connector
VGA & COM Ports
PS/2 K/B & M/S
Connectors
Center/Bass
Rear-out/Line-out
Port Connectors
SPDIF IN/OUT
Connectors-JP8
FAN1 & FAN3
Front Panel I/O
Connector-JP3
EXT.PrintPort
-JP7
FAN2
EXT+12V
TwoDIMM Slots
USB Header-USB4
Dual Channel
SERIAL ATA-SATA1

- 12 -
Step 1
Install the CPU:
1. Locate the CPU ZIF (Zero Insertion Force) socket on the upper-right sector
of your mainboard (between the back panel connectors and the DIMM
memory slots).
2. Pull the CPU ZIF socket lever slightly sideways away from the socket to
unlock the lever, and then bring it to an upwardly vertical position.
3. Place your AMD Athlon TM 64 processor in the socket . Note that the CPU's
edges have been purposely designed non-symmetrically to prevent from in
serting the processor in the wrong direction. The following diagram demon
strates the correct placement of the CPU in the ZIF socket.
4. Slightly push the AMD Athlon TM 64 processor into the socket without apply
ing excessive force while making sure there is no gap between CPU and
socket. Then lower the socket-lever all the way down to its horizontal posi-
tion and lock it to secure the CPU in place.
5. The AMD Athlon TM 64 processor requires a set of heatsink/fan to ensure
proper cooling of the processor. If heatsink/fan have not been already
mounted on your CPU, you must purchase the heatsink/fan separately and
have it in stalled. Plug the cable throught the heatsink/fan in the CPU fan
power connector located nearby. Note that there are several types of CPU
fan connectors. Normally, if your mainboard supports the hardware moni
toring function, a 3-pin fan power connector should allow your system to
detect the CPU fan's speed. The CPU fan can also run with a 2-pin fan power
connector, however, detection of CPU fan's speed is not supported. An
other type of CPU fan may feature a large 4-pin fan power connector, which
does not support CPU fan's speed detection and must be directly connected
to the system's power supply unit. Please refer to the following diagram.
Lever
A Triangle
Mark
Lever
AMD CPU
Z
A
D
A
3
1
0
0
A
E
P
5
A
J
A
A
A
I
C
0
3
1
9
P
A
W
F
3
5
8
1
9
7
2
4
0
0
2
5

- 13 -
Step 2
Set Jumpers
This mainboard is jumperless! The default jumper settings have been set for
the common usage standard of this mainboard. Therefore, you do not need
to reset the jumpers unless you require special adjustments as any of the
following cases:
1. Clear CMOS
For first-time DIY system builders, we recommend that you do not change the
default jumper settings if you are not totally familiar with the mainboard
configuration procedures. The factory-set default settings are tuned for opti-
mum system performance. For the advanced users who wish to customize
their system, section 3.2 Jumper Settings will provide detailed information
on how to configure your mainboard manually.
Step 3
Install DDR SDRAM System Memory
To install memory, insert DDR SDRAM memory module(s) in DIMM slot(s).
Note that DDR SDRAM modules are directional and will not go in the DIMM
slots unless properly oriented. After the module is fully inserted into the
DIMM slots, lift the clips of both sides of the DIMM slot to lock the module in
place.
DDR SDRAM

- 14 -
Step 4
Install Internal Peripherals in System Case
Before you install and connect the mainboard into your system case, we
recommend that you first assemble all the internal peripheral devices into the
computer housing, including but not limited to the hard disk drive (IDE
HDD), floppy disk drive (FDD), CD-ROM drive, and ATX power supply unit.
This will greatly facilitate in making the connections to the mainboard de-
scribed below.
To install IDE & FDD drives, follow this procedure:
1. Set the required jumpers on each device according to the instructions
provided by the manufacturer. (IDE devices, HDD and CD-ROM, have to
set jumpers to Master or Slave mode depending on whether you install
more than one device of each kind.)
2. Connect IDE cable and FDD cable on the back-panel of the internal
peripheral devices to the corresponding headers on board. Note that the
cable should be oriented with its colored stripe (usually red or magenta)
connected to pin#1 both on the mainboard IDE or FDD connector and on
the device as well.
3. Connect an available power cable from your system power supply unit
to the back-panel of each peripheral device. Note that the power cable is
directional and cannot fit in if not properly positioned.
