Shuttle Spacewalker AV30 User manual

AV30
FC-PGA/PPGA Celeron
and FC-PGA Pentium III Processor
Based DDR Main Board
User's Manual

Shuttle®SpacewalkerTM AV30
PPGA/FC-PGA Celeron and FC-PGA Pentium III processor
based DDR AGPset Mainboard
Manual Version 1.1
Copyright
Copyright©2001 by Shuttle®Inc. All Rights Reserved.
No part of this publication may be reproduced, transcribed, stored in a retrieval system,
translated into any language, or transmitted in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without
prior written permission from Shuttle®Inc.
Disclaimer
Shuttle®Inc. shall not be liable for any incidental or consequential damages resulting from the
performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual.
Information in this manual has been carefully checked for reliability; however, no guarantee is
given as to the correctness of the contents. In the interest of continued product improvement,
this company reserves the right to revise the manual or include changes in the specifications
of the product described within it at any time without notice and without obligation to notify any
person of such revision or changes. The information contained in this manual is provided for
general use by the customers.
Trademarks
Spacewalker is a registered trademark of Shuttle Inc.
VIA is a registered trademark of VIA Corporation.
Intel, Pentium is a registered trademarks of Intel Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other brand and product names used herein are for identification
purposes only and may be trademarks of their respective owners.
M420

- 1 -
WHAT’S IN THE MANUAL .....................................................................5
Quick Reference................................................................................................5
About This Manual ............................................................................................5
1 INTRODUCTION .................................................................................6
1.1 TO DIFFERENT USERS ..............................................................................6
First-TimeDIYSystemBuilder ..................................................................6
ExperiencedDIYUser ..............................................................................6
SystemIntegrator .....................................................................................6
1.2 ITEM CHECKLIST........................................................................................7
2 FEATURES..........................................................................................8
2.1 SPECIFICATIONS ........................................................................................8
3 HARDWARE INSTALLATION ...........................................................11
3.1 STEP-BY-STEP INSTALLATION ............................................................... 11
STEP1InstalltheCPU...........................................................................12
STEP 2 Set Jumpers..............................................................................13
STEP3InstallDDRSDRAMSystemMemory ........................................13
STEP4InstallInternalPeripherals in System Case.................................14
STEP5MounttheMainboardontheComputerChassis ........................15
STEP6ConnectFront-panelSwitches/LEDs/Speaker/USB ..................16
STEP 7 Connect IDE & Floppy Disk Drives............................................18
STEP8ConnectOther Internal Peripherals ............................................18
STEP9ConnectPowerSupply..............................................................19
STEP10InstallAdd-onCardsinExpansionSlots ..................................19
STEP11ConnectExternalPeripheralstoBack-panel............................20
STEP 12 First Time System Boot Up......................................................22
STEP13InstallDriver&SoftwareComponents......................................23
TABLE OF CONTENTS

- 2 -
3.2 JUMPER SETTINGS ..................................................................................24
JUMPER&CONNECTORGUIDE .........................................................25
Jumpers
FSB Speed Auto Configuration Setting (JP3).........................................28
DDR SDRAM Voltage Setting (JP11) .....................................................29
BIOSWriteProtection(JP6)...................................................................30
Clear CMOS (JP2).................................................................................30
Back-Panel Connectors
PS/2 Keyboard & PS/2 Mouse Connectors ............................................31
LANConnector.......................................................................................31
USB1/USB2PortConnectors.................................................................31
COM1/2Connector ................................................................................31
ParallelPortConnector...........................................................................32
Line-Out .................................................................................................32
Line-In ....................................................................................................32
Mic-In .....................................................................................................32
MIDI/GAMEPort.....................................................................................32
Front-Panel Connectors
ATXPowerOn/OffSwitchConnector(PWON)........................................33
EPMIConnector(EPMI) .........................................................................33
GreenLEDConnector(GLED)...............................................................33
HDD LED Connector (HDLED) ..............................................................34
PWR LED Connector (PWR LED)..........................................................34
HardwareResetConnector(RST) ..........................................................34
Speaker Connector (SPEAK).................................................................35
ExtendedfourUSBConnectorHeader(JP7/JP8)...................................35

- 3 -
Internal Peripherals Connectors
EnhancedIDEPortsandFloppyConnectors ..........................................36
Other Connectors
ATXPowerSupplyConnector(CN10) ....................................................37
Cooling FAN Connectors for CPU FAN (FAN1), SYSTEM FAN (FAN2) &
AGP FAN (FAN3) ...................................................................................37
SIR/CIRConnector(JP5)........................................................................38
Wake-On-LANConnector (CN1).............................................................38
AudioConnectorCD_In(CN6) ...............................................................39
AudioConnectorAUX_In(CN7) .............................................................39
AudioConnectorTAD_In(CN8)..............................................................39
FactoryReserved(JP4)..........................................................................40
3.3 SYSTEM MEMORY CONFIGURATION ......................................................41
InstallMemory.........................................................................................41
UpgradeMemory ...................................................................................41
4 SOFTWARE UTILITY .......................................................................42
4.1 Mainboard CD Overview ..........................................................................42
4.2 Install VIA 4 in 1 Driver .............................................................................43
4.3 Install Audio Device Software..................................................................44
4.4 Install LAN Software.................................................................................45
InstallWIN98LANdrivers .......................................................................45
InstallWIN2000LANdrivers ...................................................................48
InstallWINNTLAN drivers .......................................................................52
4.5 View the User's Manual............................................................................54

- 4 -
5 BIOS SETUP.....................................................................................55
5.1 ENTER THE BIOS......................................................................................55
5.2 THE MAIN MENU .......................................................................................56
STANDARD CMOS FEATURES ................................................................58
ADVANCED BIOS FEATURES..................................................................62
ADVANCED CHIPSET FEATURES...........................................................66
INTEGRATEDPERIPHERALS...................................................................70
POWERMANAGEMENTSETUP ..............................................................75
PNP/PCICONFIGURATION .......................................................................79
PC HEALTH STATUS.................................................................................81
FREQUENCY/VOLTAGECONTROL..........................................................83
LOAD FAIL-SAFE DEFAULTS...................................................................85
LOADOPTIMIZEDDEFAULTS ..................................................................85
SET SUPERVISOR PASSWORD ..............................................................86
SET USER PASSWORD ...........................................................................86
SAVE & EXIT SETUP.................................................................................87
EXITWITHOUTSAVING.............................................................................87

- 5 -
Quick Reference
Hardware Installation >> Step-by-Step ................................................ Page 11
Jumper Settings >> A Closer Look ...................................................... Page 24
Software Utility >> How to Install ......................................................... Page 42
BIOS Setup >> How to Configure ........................................................ Page 55
About This Manual
For First-Time DIY System Builder......................................................... Page 6
For Experienced DIY User ...................................................................... Page 6
For System Integrator ............................................................................. Page 6
WHAT’S IN THE MANUAL

- 6 -
1INTRODUCTION
1.1 To Different Users
First-Time DIY System Builder
Welcome to the DIY world! Building your own computer system is not as
difficult as you may think. To make your first computer DIY experience
successful, right from the start, we have designed the Chapter 3 Hardware
Installation section in a step-by-step fashion for all the first-time DIY system
builders. Prior to installation, we also suggest you to read the whole manual
carefully to gain a complete understanding of your new Shuttle AV30
mainboard.
Experienced DIY User
Congratulate on your purchase of the Shuttle AV30 mainboard. You will find
thatinstallingyournewShuttleAV30mainboardisjusteasy. Bundledwithan
array of onboard functions, the highly-integrated AV30 mainboard provides
you with a total solution to build the most stable and reliable system. Refer to
sections3.2 Jumper Settings and Chapter 4 Software Utility to find outhowto
get the best out of your new mainboard. Chapter 5 BIOS Setup also contains
therelevantinformationonhowtotuneupyoursystemto achieve higher per-
formance.
System Integrator
YouhavewiselychosenShuttleAV30toconstructyoursystem. Shuttle AV30
incorporatesallthestate-of-the-arttechnology of the VT8633chipsetfromVIA.
It integrates the most advanced functions you can find to date in a compact
ATX board. Refer to sections 3.2 Jumper Settings and Chapter 4 Software
Utility foranin-depthviewofsystemconstruction.

- 7 -
1.2 Item Checklist
Check all items with you AV30 mainboard to make sure nothing is missing.
The complete package should include:
!One piece of Shuttle AV30 Mainboard
!One piece of ATA100/66/33 Ribbon Cable
!One piece of Floppy Ribbon Cable
!One piece of twin ports USB Cable(optional)
!AV30 User’s Manual
!One piece of Bundled CD-ROM with containing:
"AV30 user’s manual on PDF format
"VIA4-IN-1driver
"VIA Audio driver
"VIALANdriver(optional)
"AwardFlashingUtility
KB1
USB
CON1PRINT
AUDIO1
TADI/O
CD_IN
AUX_IN
USB5&6 USB3&4
DDRAM3DDRAM2DDRAM1
IDE2 IDE1
FLOPPY
WOL
F
O
R
S
Y
S
TEM
FORAGP
FORCPU
ATXPWRCON
PCI1 PCI2 PCI3 PCI4 PCI5 PCI6 CNR
IR
UJ4B8802C
0031
93711AF
ICS
Panasonic
CR2032
3V
JAPAN1
CN8
CN6
CN7
AGP1
JP8
JP7
JP11
JP3
JP5
CNR1
JP4
JP101
11
1
12 78
BSELO BSEL1
FS1 FS0
RST PWRLED+- SPEAK
1
11
1
11
1
1
1
1
JP2
JP6
FAN2
FAN3
FAN1
DIM3DIM2DIM1
CN10
FDD1
IDE2IDE1
GLED +-+- EPMI PWON
1 1
1
PG A3 70
AWARD
PCI/PNP686 169332966
1998
C
C
N1 1
in bond
L
80
22
5/
B
T0030 W
JC
2
9080
KOREA

- 8 -
AV30 mainboard is carefully designed for the demanding PC user who wants high perfor-
mance and maximum intelligent features in a compact package.
2.1 Specifications
!!
!!
!CPU Support
Support Socket370 package CPU with 66/100/133 MHz FSB.
Intel PPGA/FC-PGA Celeron processors: 300 ~ 800+ MHz.
IntelPentiumIII FC-PGAprocessors:500MHz~1.13+GHz.
VIACyrixIIIprocessors.
!!
!!
!Chipset
Features VIA Apollo Pro 266, VT8633/VT8233 chipset.
VT8633,Integratedhighperformance DDR DRAM controller.
!!
!!
!Jumperless CPU Configuration
Soft-configurationFSB(TheFSBspeedissoftware configurable from 66MHz
to 166MHz by 1MHz step in the Frequency/Voltage Control of BIOS setup
program.)
!!
!!
!10/100 Mb Fast Ethernet (optional)
VT8233 integrated fast Ethernet controller. Support 10/100 Mb full and half
duplexoperation.
!!
!!
!AC'97 Link for Audio and Telephony CODEC
AC'97 2.1 compliant
Spread independent PCI functions for Audio and Modem
!!
!!
!Versatile Memory Support
Three 184-pin DIMM slots to support up to 3GB of PC1600 or PC2100
compliantDDR SDRAMmodule.
!!
!!
!PCI Expansion Slots
Providessix32-bitPCIslots.
!!
!!
!CNR Expansion Slot
ProvidesoneCNR(Communication/NetworkRiser)slot.
!!
!!
!AGP Expansion Slot
Provides one 32-bit AGP slot which supports up to 4X AGP device.
2FEATURES

- 9 -
!!
!!
!I/O Interface
ProvidesavarietyofI/Ointerfaces:
"1 × Floppy interface for 3.5-inch FDD with 720KB, 1.44MB, or 2.88MB
formatorfor5.25-inch FDD with 360K or 1.2MB format.
"1 × PS/2 mouse connector.
"1 × PS/2 Keyboard connector.
"1 × RJ45 LAN connector.
"2 × DB9 Serial connectors 16550 UART compatible.
"1×Infrared communication port.
(Serial port COM2 can also be redirected to an external IrDA Adapter
forwirelessconnection.)
"1 × DB25 Parallel port supporting Standard Parallel Port (SPP),
Enhanced Parallel Port (EPP), and Extended Capabilities Port (ECP)
datatransmissionschemes.
"1×Line-Outport.
"1×Line-Inport.
"1×Mic-Inport.
"1×MIDI/GAMEport.
!!
!!
!6 USB Supported Onboard
"2 × USB connectors on back-panel and two 10-pin header for optional
USB cable to extend another 4 USB ports .
!!
!!
!PCI Bus Master IDE Controller Onboard
TwoUltraDMA 100/66/33 BusMasterDual-channelIDE portsprovidesupport
to a maximum of four IDE devices (one Master and one Slave per channel).
The IDE Bus implements the data transfer speed up to 100/66/33 MB/sec and
also supports Enhanced PIO Modes 0~4.
80-pin Cable Backward Compatible Legacy ATAPI Devices, ATAPI IDE CD-
ROM, CD-R, CD-RW, and LS-120 Supports.
!!
!!
!ATX Power Supply Connector
ATX power supply unit can be connect to the onboard 20-pin ATX power
connector,supportingSuspend and Soft-On/Off by dual-function power
button.

- 10 -
!!
!!
!Advanced Configuration and Power Interface
Features four power saving modes: Snoop, Suspend to RAM, Suspend to
Disk,andSoft-Off.ACPIprovidesmoreefficientEnergySavingsFeatures
controlled by your operating system that supports OS Direct Power Manage-
ment(OSPM)functionality.
!!
!!
!System BIOS
Provides licensed Award BIOS V6.0 PG on 2Mb Flash EEPROM and
supportsGreenPC,DesktopManagementInterface(DMI).
!!
!!
!ATX Form Factor
System board conforms to the ATX specification.
Board dimension: 305mm × 245mm.
!!
!!
!Advanced Features
"Dual Function Power Button - The system can be in one of two states;
one is Suspend mode and the other is Soft-Off mode. Pushing the power
button for less than 4 seconds places the system into Suspend mode.
When the power button is pressed for longer than 4 seconds, the system
enterstheSoft-Offmode.
"Wake-on-LAN (WOL) - The onboard WOL connector can be attached to
a network card that supports this function to wake up the system via LAN.
"Modem Ring Power-On - The system can be powered on automatically
by the activation of modem ring.
"CPU Clock Setting-Thisitemallows userstoadjustCPUHostClockinBIOS.
"CPU Vcore Setting- This item allows users to adjust CPU Vcore in BIOS.
!!
!!
!Intelligent Features
"Voltage Monitoring - Monitorsvarious voltages of key elements, such as
theCPU, and other critical systemvoltage levels to ensure stablecurrent
passing through mainboard components. System voltages include Vcore
on CPU, and +5V, +12V, -5V, -12V on system etc.
"Fan Status Monitoring - To prevent CPU from overheating, the CPU fan is
monitored for RPM and failure. (CPU Cooling FAN with RPM sensor is
required.)
"Temperature Monitoring -Thisitemallowsuserstomakesurewhether
the CPU or system runs in a suitable temperature.

- 11 -
3HARDWAREINSTALLATION
Before removing or installing any of these devices including CPU, DIMMs, Add-On
Cards, Cables, please make sure to unplug the onboard power connector.
This section outlines how to install and configure your AV30 mainboard. Refer to the
followingmainboardlayouttohelpyouidentifyvariousjumpers, connectors, slots, and
ports. Then follow these steps to guide you through a quick and correct installation of
yoursystem.
3.1 Step-by-Step Installation
Accessories Of AV30
KB1
USB
CON1PRINT
AUDIO1
TAD I/O
CD_IN
AUX_IN
USB5&6 USB3&4
DDRAM3DDRAM2DDRAM1
IDE 2 IDE1
FLOPPY
WOL
FORSYSTEM
FO R AGP
FO R CPU
ATX PWRCON
PCI1
PCI2
PCI3
PCI4
PCI5
PCI6
CNR
IR
U J4B8 802C 0031 93711A F
ICS
Panasonic
CR2032
3V
JAPAN1
CN8
CN6
CN7
AG P1
JP8
JP7
JP11
JP3
JP5
C NR1
JP4
JP10
1
11
1
1 2
7 8
BSE LO
BSE L1
FS1
FS0
RST
PWR LED
+ - SPE AK
1
11
1
11
1
1
1
1
JP2
JP6
FAN2
FAN3
FAN1
DIM3DIM2DIM1
CN10
FDD 1
IDE 2 IDE 1
GLED
+ -
+ - EPM I PWO N
1
1
1
PGA370
AWARD
PCI/PNP686
169332966
1998 C
CN1
1
inbond
L8022 5/B
T 00 30
W JC29 080
KOREA
PS/2 Keyboard/Mouse
Connectors
ATX Power Connector
Parallel Connector
Serial Port
Connector (COM2)
Serial Port
Connector (COM1)
Line-In/Line-Out/Mic-In
Game/MIDI Connectors
DDR Voltage -
JP11
System Clock - JP3
Floppy Connector
BIOS Write Protection - JP6
Front Panel Connector - JP10
Two E-IDE Connectors
FAN2
FAN3
Socket 370
FAN1
Six PCI Slots
One CNR Slot
One AGP Slot
VIA VT8633 Chipset
USB/LAN Connectors
IR Connector -
JP5
Factory Reserved - JP4
Clear CMOS - JP2
I/OController
Onboard MII interface compliant PHY
CD Audio Connectors
Onboard CODEC
Wake-On-LAN Connector -
CN1
Programmable 2Mb Flash EEPROM
Front Panel USBConnectors
header -
JP7/JP8
Three 184-pin DDR DIMM Slots

- 12 -
Step 1
Install the CPU:
1. Locate the CPU ZIF (Zero Insertion Force) socket on the upper-right
sector of your mainboard (between the back-panel connectors and the
DIMMmemoryslots).
2. Pull the CPU ZIF socket lever slightly sideways away from the socket
to unlock the lever, and then bring it to an upwardly vertical position.
3. Place your PPGA/FC-PGA370 processor in the ZIF socket. Note that the
CPU’s edges have been purposely designed non-symmetrically to prevent
from insertingtheprocessorinthewrongdirection. Thefollowing diagram
demonstrates the correct placement of the CPU in the ZIF socket. You can
seethat the two blunt-edged corners should face towards thesocket-lever.
4. Slightlypush the PPGA/FC-PGA370 processor intothe socket without
applying excessive force while making sure there is no gap between CPU
and socket. Then lower the socket-lever all the way down to its horizontal
position and lock it to secure the CPU in place.
5. The PPGA/FC-PGA370 processor requires a set of heatsink/fan to ensure
proper cooling of the processor. If heatsink/fan having not been already
mounted on your CPU, you must purchase the heatsink/fan separately
and have it installed. Plug the cable throught the heatsink/fan in the CPU
fan power connector located nearby. Note that there are several types of
CPU fan connectors. Normally, if your mainboard supports the hardware
monitoringfunction,a3-pinfanpower connector should allowyoursystem
to detect the CPU fan’s speed . The CPU fan can also run with a 2-pin fan
power connector, however, detection of CPU fan’s speed is not supported.
Another type of CPU fan may feature a large 4-pin fan power connector,
which does not support CPU fan's speed detection and must be directly
connectedto the system’s power supply unit. Please referto the following
diagram.
PGA370 PGA370
Lever BlankBlank Notch Notch
PPGA CPU
PGA370
Penti um MALAY
RB80526PY550256
Q944A036-0393 SL3R3
®
FC-PGA CPU

- 13 -
Step 2.
Set Jumpers
This mainboard is jumperless! The default jumper settings have been set for
the common usage standard of this mainboard. Therefore, you do not need
to reset the jumpers unless you require special adjustments as in any of the
followingcases:
1. Over-clock your CPU
2. Clear CMOS
3.SettingDDRVoltage
Forfirst-time DIY system builders, we recommend thatyou do not change the
defaultjumpersettingsifyouarenottotallyfamiliarwithmainboardconfigu-
rationprocedures. Thefactory-setdefaultsettingsaretunedforoptimum
system performance. For the advanced users who wish to customize their
system,section 3.2 Jumper Settingswillprovidedetailedinformationonhow
to configure your mainboard manually.
Step 3.
Install DDR SDRAM System Memory
Toinstallmemory,insertDDRSDRAMmemory module(s) in DIMMslot(s).
Note that DDR SDRAM modules are directional and will not go in the DIMM
slotsunlessproperlyoriented. Afterthemoduleisfullyinsertedintothe
DIMMslots,lifttheclipsofbothsidesoftheDIMMslottolockthemodulein
place.
DDR SDRAM

- 14 -
Step 4
Install Internal Peripherals in System Case
Before you install and connect the mainboard into your system case, we
recommendthatyoufirstassemblealltheinternal peripheral devices into the
computerhousing, including but not limited to thehard disk drive (IDE
/HDD),floppydiskdrive(FDD),CD-ROMdrive,andATXpowersupplyunit.
Thiswill greatly facilitate in making the connections tothe mainboard de-
scribedbelow.
ToinstallIDE&FDDdrives,followthisprocedure:
1. Set the required jumpers on board each device according to the
instructionsprovidedbythemanufacturer.(IDEdevices,HDD,and
CD-ROM have to set jumpers on Master or Slave mode depending
on your willing to install more than one device for each kind.)
2. Connect IDE cable and FDD cable on the back-panel of the internal
peripheral devices to the corresponding headers on board. Note that the
cable should be oriented with its colored stripe (usually in red or magenta)
connected to pin#1 both on the mainboard IDE or FDD connector and on
thedeviceaswell.
3. Connect an available power cable through your system power supply unit
to the back-panel of each peripheral device. Note that the power cable
isdirectional and cannot fit in if not properlypositioned.

- 15 -
Step 5
Mount the Mainboard on the Computer Chassis
1. You may find that there are a lot of different mounting hole positions
both on your computer chassis and on the mainboard. To choose a
correct mounting hole, the key point is to keep the back-panel of the
mainboard in a close fit with your system case, as shown below.
2. After deciding on the proper mounting holes, position the studs between
the frame of chassis and the mainboard. The studs are used to fix the
mainboard and to keep a certain distance between the system chassis
and the mainboard, in order to avoid any electrical short between the
board and the metal frame of chassis. (If your computer case is
alreadyequipped with mounting studs, you willneed to tighten screws to
attachthe mainboard.)
Note: In most computer housings, you will be able to find 4 or more
attachmentpointsto install mounting studs and fix the mainboard.
If there aren’t enough matching holes, then make sure to install at
least 4 mounting studs to ensure proper attachment of the
mainboard.

- 16 -
Step 6
Connect Front-Panel Switches/LEDs/Speaker/USB connectors
You can find there are several different cables already existing in the system
caseandoriginatingfromthecomputer’sfront-paneldevices(HDDLED,
Power LED, Reset Switch, PC Speaker, or USB devices etc.) These cables
serve to connect the front-panel switches, LEDs, and USB connectors to the
mainboard’s front-panel connectors group (JP10, JP7, and JP8), as shown
below.
1. ATXSoftPowerOn/Off(PWON)
2. EPMI
(HardwareSystemManagement
Interface)
3. Green_LED(GLED)
JP101RST
PWR LED
+ - SPEAK
GLED
+ -+ - EPMI PWON
JP101RST
PWR LED
+ - SPEAK
GLED
+ -+ - EPMI PWON
JP101RST
PWR LED
+ - SPEAK
GLED
+ -+ - EPMI PWON
JP101RST
PWRLED
+ - SPEAK
GLED
+ -+ - EPMI PWON
USB5&6 USB3&4
JP8
JP7
11

- 17 -
4. HDD_LED(HDLED)
5. Power-LED(PWRLED)
6. HardwareResetSwitch(RST)
7. PC Speaker (SPEAK)
8. Extended four USB Connector Header
JP101RST
PWR LED
+ - SPEAK
GLED
+ -+ - EPMI PWON
JP101RST
PWR LED
+ - SPEAK
GLED
+ -+ - EPMI PWON
JP101RST
PWR LED
+ - SPEAK
GLED
+ -+ - EPMI PWON
JP101RST
PWR LED
+ - SPEAK
GLED
+ -+ - EPMI PWON
GROUND GROUND USBD3+ USBD3- +5V
+5V
USBD2-
USBD2+
GROUND GROUND
USB3
(
USB5
)
USB4
(
USB6
)
JP7 (JP8) 1

- 18 -
Step 7
Connect IDE & Floppy Disk Drives
1. IDE cable connector
2. FDD cable connector
Step 8
Connect Other Internal Peripherals
1. CD_IN,AUX_IN,andTAD_INconnectors
2. IR connector
IDE2 IDE1
11
IDE2 IDE1
FLOPPY
1
FDD1
TAD I/O
CD_IN
AUX_IN
CN8
CN6
CN7
1
1
1
IR
JP5 1
