Described product
W4F
WTB4FP MultiSwitch
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is
only permissible within the limits of the legal determination of Copyright Law. Any modi‐
fication, abridgment or translation of this document is prohibited without the express
written permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
2006/42/EC
NO
SAFETY
8025665.1C7L/2021-09-03 | SICK O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 3
Subject to change without notice
en

Contents
1 General safety notes................................................................................ 5
2 Notes on UL approval............................................................................... 5
3 Product description.................................................................................. 5
3.1 Intended use............................................................................ 5
3.2 Operating elements and status indicators............................. 5
4 Mounting................................................................................................... 6
5 Electrical installation................................................................................ 6
6 Commissioning......................................................................................... 7
6.1 Alignment................................................................................. 7
6.2 Check the application conditions:.......................................... 8
6.3 Setting...................................................................................... 10
6.4 Process data structure............................................................ 12
7 Troubleshooting........................................................................................ 12
8 Disassembly and disposal....................................................................... 13
9 Maintenance............................................................................................. 13
10 Technical specifications........................................................................... 13
10.1 Dimensional drawings............................................................. 14
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 8025665.1C7L/2021-09-03 | SICK
Subject to change without notice
en

1 General safety notes
■Read the operating instructions before commissioning.
■
Connection, mounting, and configuration may only be performed by trained
specialists.
■
2006/42/EC
NO
SAFETY
Not a safety component in accordance with the EU Machinery Directive.
■
Do not install the sensor at locations that are exposed to direct UV radiation
(sunlight) or other weather influences, unless this is expressly permitted in the
operating instructions.
■When commissioning, protect the device from moisture and contamination.
■These operating instructions contain information required during the life cycle of
the sensor.
2 Notes on UL approval
The device shall be supplied from an isolating transformer having a secondary overcur‐
rent protective device that complies with UL 248 to be installed in the field rated either:
a) max 5 amps for voltages 0 ~ 20 V (0 ~ 28.3 V peak), or
b) 100 / Vp for voltages of 20 ~ 30 V (28.3 ~ 42.4 V peak).
Alternatively, they can be supplied from a Class 2 power supply.
UL Environmental Rating: Enclosure type 1
3 Product description
3.1 Intended use
The WTB4F is an opto-electronic photoelectric background suppression proximity sen‐
sor (referred to as “sensor” in the following) for the optical, non-contact detection of
objects, animals, and persons. If the product is used for any other purpose or modified
in any way, any warranty claim against SICK AG shall become void.
3.2 Operating elements and status indicators
Photoelectric proximity sensor with background suppression.
1
34
2
1BluePilot blue: operating mode, Switching state QL1, QL2
2Teach-Button: adjusting the sensing range
3LED indicator yellow: status of received light beam
GENERAL SAFETY NOTES 1
8025665.1C7L/2021-09-03 | SICK O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 5
Subject to change without notice
en

4LED indicator green: supply voltage active
4 Mounting
Mount the sensor using a suitable mounting bracket (see the SICK range of accesso‐
ries).
Figure 1: Alignment of the sensor relative to the object direction
Note the sensor’s maximum permissible tightening torque of < 0,4 Nm.
Note the preferred direction of the object relative to the sensor, cf. see figure 1, page 6.
5 Electrical installation
Operation in standard I/O mode:
The sensors must be connected in a voltage-free state. The following information must
be observed, depending on the connection type:
– Male connector connection: Pin assignment
– Cable: Wire color
Only apply voltage/switch on the voltage supply once all electrical connections have
been established.
Operation in IO-Link mode: Connect the device to a suitable IO-Link master and inte‐
grate in the master or control via IODD/function block. The green LED flashes on the
sensor. IODD and function block are available to download from www.sick.com under
the part number.
Explanations on connection diagram.
BN = brown
WH = white
BU = blue
BK = black
MF (pin 2 configuration) = external input, teach-in, switching signal
QL1/C = switching output, IO-Link communication
Test = Test input
UB: 10 ... 30 V DC
4 MOUNTING
6O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 8025665.1C7L/2021-09-03 | SICK
Subject to change without notice
en

Table 1: Electrical connection
WTB4Fx- x4 x2 xH
1 = BN
2 = WH
3 = BU
4 = BK
12
4 3
2
1
4
3
0.14 mm2
AWG26
Table 2: DC
WTx4Fx-
Push-pull xx16DxxxA00 xx16RxxxA00 xx16xxxxA01-A99
PNP xx86DxxxA00 xx86RxxxA00 xx86xxxxA01-A99
1 = BN + (L+)
2 = WH MF
3 = BU - (M)
4 = BK QL1 / C
Default: MF QL2 QL2 www.sick.com
8022709
Default: QL1 / C QL1 QL1 www.sick.com
8022709
Table 3: Push-pull, PNP, NPN
QL1 QL2
Push-pull
PNP
NPN
+ (L+)
Q ≤ 100 mA
‒ (M)
Push-pull
PNP
NPN
+ (L+)
Q ≤ 100 mA
‒ (M)
Push-pull
PNP
NPN
+ (L+)
Q ≤ 100 mA
‒ (M)
Push-pull
PNP
NPN
+ (L+)
Q≤ 100 mA
‒ (M)
Push-pull
PNP
NPN
+ (L+)
Q≤ 100 mA
‒ (M)
Push-pull
PNP
NPN
+ (L+)
Q≤ 100 mA
‒ (M)
6 Commissioning
6.1 Alignment
Align the sensor with the object. Select the position so that the red emitted light beam
hits the center of the object. You must ensure that the optical opening (front screen) of
the sensor is completely clear [see figure 2].
ELECTRICAL INSTALLATION 5
8025665.1C7L/2021-09-03 | SICK O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 7
Subject to change without notice
en

Figure 2: Alignment
Figure 3: Alignment
6.2 Check the application conditions:
Sensing range
WTB4F are photoelectric proximity sensors with background suppression. Depending
on the remission of the object to be detected, and perhaps the background behind it,
a minimum distance (y) between the set sensing range (x) and the background is to be
maintained.
Check the application conditions:
Schaltabstand und Distanz zum Objekt bzw. Hintergrund sowie Remissionsvermögen
des Objekts mit dem zugehörigen Diagramm abgleichen (x = Schaltabstand, y = Mind‐
estabstand zwischen eingestelltem Schaltabstand und Hintergrund (weiß, 90%)) Remis‐
sion: 6 % = schwarz 1, 18 % = grau 2, 90 % = weiß 3 (bezogen auf Standardweiß
nach DIN 5033). Wir empfehlen, die Einstellung mit einem Objekt von niedriger Remis‐
sion vorzunehmen.
Die minimale Distanz (= y) für die Hintergrundausblendung kann aus der Abbildung
figure 4 wie folgt ermittelt werden:
Beispiel: x = 100 mm, y = 4 mm. D. h. der Hintergrund (weiß, 90%) wird ab einer
Distanz von > 4 mm vom Sensor ausgeblendet.
WTB4FP-xx6x15X:
6 COMMISSIONING
8O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 8025665.1C7L/2021-09-03 | SICK
Subject to change without notice
en

0
20
(0.79)
10
(0.39)
40
(1.57)
30
(1.18)
50
(1.97)
80
(3.15)
40
(1.57)
120
(4.72)
160
(6.30)
200
(7.87)
240
(9.45)
0
y
x
y
x
Minimum distance in mm (y) between the set sensing
range and white background (90 % remission)
Example:
Safe suppression of the background
White background (90 %)
Black object (6 % remission)
Set sensing range x = 120 mm
Needed minimum distance to white
background y = 7 mm
Distance in mm (inch)
Recommended sensing range for
the best performance
60
(2.36)
90%/90%
18%/90%
1
6%/90%
33
2
Figure 4: Characteristic line
0
815
715
4 220
Distance in mm (inch)
210
215
1
2
3
80
(3.15)
40
(1.57)
120
(4.72)
160
(6.30)
200
(7.87)
240
(9.45)
15
D
C
A B
Figure 5: bar graph
0
Distance in mm (inch)
Dimensions in mm (inch)
4
(0.16)
6
(0.24)
–6
(–0.24)
–4
(–0.16)
0
2
(0.08)
–2
(–0.08)
10
(0.39)
220
(8.66)
80
(3.15)
40
(1.57)
120
(4.72)
160
(6.30)
200
(7.87)
240
(9.45)
130
(5.12)
Recommended sensing range for
the best performance
Figure 6: Light spot size
WTB4FP-xx6x25X:
0
40
(1.57)
20
(0.79)
60
(2.36)
80
(3.15)
100
(3.94)
0
WTB4FP
y
x
y
x
Minimum distance in mm (y) between the set sensing
range and white background (90 % remission)
Example:
Safe suppression of the background
White background (90 %)
Black object (6 % remission)
Set sensing range x = 40 mm
Needed minimum distance to white
background y = 2 mm
Distance in mm (inch)
Recommended sensing range for
the best performance
20
(0.79)
16
(0.63)
90%/90%
12
(0.47)
8
(0.31)
4
(0.16)
2
6%/90%
3
1
1%/90%
18%/90%
4
Figure 7: Characteristic line
4
1
2
10
6515
59515
515
415
398
100
0 80
(3.15)
20
(0.79)
40
(1.57)
60
(2.36)
100
(3.94)
Distance in mm (inch)
D
C
A B
Figure 8: bar graph
0
Distance in mm (inch)
Dimensions in mm (inch)
4
(0.16)
6
(0.24)
–6
(–0.24)
–4
(–0.16)
0
2
(0.08)
–2
(–0.08)
10
(0.39)
100
(3.94)
20
(0.79)
40
(1.57)
60
(2.36)
80
(3.15)
100
(3.94)
50
(1.97)
Recommended sensing range for
the best performance
Figure 9: Light spot size
ASensing range min. in mm
BSensing range max. in mm
CViewing range
DSetting range switching threshold for background suppression
ESensing range indicator
FTeach-Turn adjustment
blue Recommended sensing range for the best performance
COMMISSIONING 6
8025665.1C7L/2021-09-03 | SICK O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 9
Subject to change without notice
en

6.3 Setting
Sensing range adjustment
WTB4FP-xxxxxx50A00
1 7
26
3 4 5
BluePilot LED #4: Operating mode 2 switching points
1 - 3 QL1 active
5 - 7 QL2 active
BluePilot LED #7: Operating mode distance value via IO-Link
1 - 6 off
6 COMMISSIONING
10 O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 8025665.1C7L/2021-09-03 | SICK
Subject to change without notice
en

1...3 sec.
QL1
1...3 sec.
QL2
Q
L1
+Q
L2
Figure 10: WTB4F, adjustment of the sensing range using a teach-turn adjustment
Please refer to the enclosed operating instructions for the IO-Link photoelectric sensor
for information about adjusting the IO-Link sensing range.
COMMISSIONING 6
8025665.1C7L/2021-09-03 | SICK O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 11
Subject to change without notice
en

The sensor is adjusted and ready for operation.
WTx4Fx-xxxxxxA0Zxx:
6.4 Process data structure
WTB4FP-xxxxxxxxAxx:
A00 A70 A71 A72 A73 A75
IO-Link V1.1
Process
data
2 bytes 4 bytes
Byte 0: bits 15... 8
Byte 1: bits 7... 0
Byte 0: bits 31...
24
Byte 1: bits 13...
16
Byte 2: bits 15...
8
Byte 3: bits 7... 0
Bit 0 / Data
type
QL1 / Boolean
Bit 1 / Data
type
QL2 / Boolean Qint.1 /
Boolean
QL2 / Boo‐
lean
Qint.1 / Boolean
Bit... /
Descrip‐
tion / Data
type
2 ...15 /
[empty]
2 ...15 /
[time
measure‐
ment
value] /
UInt 14
2 … 15 /
[counter
value] /
UInt 14
2 … 15 /
[length /
speed
measure‐
ment] /
SInt14
2 /
Qint.1 /
Boolean
2 … 7 / [empty]
Bit... /
Descrip‐
tion / Data
type
3 … 15 /
[time
measure‐
ment
value] /
UInt13
8 … 31 / [carrier
load] / UInt 24
7 Troubleshooting
The Troubleshooting table indicates measures to be taken if the sensor stops working.
Table 4: Troubleshooting
LED indicator/fault pattern Cause Measures
Green LED flashes IO-Link communication None
Switching outputs do not
behave in accordance with
table 3
1. IO-Link communication
2. Change of the configuration
3. Short-circuit
1. None
2. Adjustment of the configura‐
tion
3. Check electrical connections
Yellow LED lights up, no object
in the path of the beam
The sensing range distance is
too large
Reduce the sensing range
Object is in the path of the
beam, yellow LED does not
light up
Distance between the sensor
and the object is too long or
sensing range is set too short
Increase the sensing range
6 COMMISSIONING
12 O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 8025665.1C7L/2021-09-03 | SICK
Subject to change without notice
en

LED indicator/fault pattern Cause Measures
No object in beam path, no
output signal
Test input (Test) is not con‐
nected properly
Check connection of the test
input. When using female cable
connectors with LED indicators,
make sure the test input is
assigned correspondingly.
8 Disassembly and disposal
The sensor must be disposed of according to the applicable country-specific regula‐
tions. Efforts should be made during the disposal process to recycle the constituent
materials (particularly precious metals).
NOTE
Disposal of batteries, electric and electronic devices
•According to international directives, batteries, accumulators and electrical or
electronic devices must not be disposed of in general waste.
•The owner is obliged by law to return this devices at the end of their life to the
respective public collection points.
•
WEEE: This symbol on the product, its package or in this document,
indicates that a product is subject to these regulations.
9 Maintenance
SICK sensors are maintenance-free.
We recommend doing the following regularly:
•Clean the external lens surfaces
•Check the screw connections and plug-in connections
No modifications may be made to devices.
Subject to change without notice. Specified product properties and technical data are
not written guarantees.
10 Technical specifications
WTB4FP-xxxxx1 WTB4FP-xxxxx2
Recommended sensing range for the best performance 40 mm … 140 mm 30 mm ... 60 mm
Sensing range max. 4 mm … 220 mm
(Typ)1)
4 mm ... 100 mm (Typ)
Light spot diameter/distance Ø 5 mm (50 mm) (Typ) ,
Ø 4 mm (100 mm) (Typ)
Ø 2 mm (50 mm) (Typ)
Supply voltage UBDC 10 ... 30 V2) DC 10 ... 30 V2)
Ripple ≤ 5 Vss ≤ 5 Vss
Output current Imax. ≤ 100 mA ≤ 100 mA
Current consumption 25 mA 25 mA
Communication mode COM2 COM2
IO-Link 1.1 1.1
DISASSEMBLY AND DISPOSAL 8
8025665.1C7L/2021-09-03 | SICK O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 13
Subject to change without notice
en

WTB4FP-xxxxx1 WTB4FP-xxxxx2
Switching frequency 500 Hz3) 500 Hz3)
Max. response time 1000 µs4) 1000 µs4)
Enclosure rating IP66, IP67 IP66, IP67
Protection class III5) III5)
Circuit protection A, B, D6) A, B, D6)
Ambient operating temperature –40 °C ... +60 °C –40 °C ... +60 °C
1) Object with 90 % remission (based on standard white DIN 5033)
2) Limit values. UB connections reverse-polarity protected. Residual ripple max 5 VPP
3) With light / dark ratio 1:1
4) Signal transit time with resistive load
5) Reference voltage DC 50 V
6) A = UB-connections reverse polarity protected
B = inputs and output reverse-polarity protected
D = outputs overcurrent and short-circuit protected
10.1 Dimensional drawings
8
67
4
5
3
1
2
16 (0.63) 12.1 (0.48)
9 (0.35) Ø 6.8
(0.27)
5.6 (0.22)
Ø 6.2 (0.24)
8 (0.32)
8.1 (0.32)
3.5 (0.14)
37.2 (1.46)
4.7 (0.18)
3.4 (0.13)
6.7 (0.26)
9 (0.35) 8 (0.31)
Figure 11: Dimensional drawing 1, cable
1Preferred direction of the target
object
2Center of optical axis, sender
3Center of optical axis, receiver
4M3 threaded mounting hole
5Connection
6LED indicator green: supply voltage
active
7LED indicator yellow: status of
received light beam
8Press-turn element / Potentiome‐
ter / Teach-Button: adjusting the
sensing range
3
1
2
8
67
4
5
16 (0.63) 12.1 (0.48)
9 (0.35) M8
(0.31)
5.6 (0.22)
Ø 6.2 (0.24)
8 (0.32)
11 (0.43)
3.5 (0.14) 9 (0.35) 8 (0.31)
40.1 (1.58)
7.6 (0.3)
3.4 (0.13)
6.7 (0.26)
Figure 12: Dimensional drawing 2, male
connector
10 TECHNICAL SPECIFICATIONS
14 O P E R A T I N G I N S T R U C T I O N S | WTB4FP MultiSwitch 8025665.1C7L/2021-09-03 | SICK
Subject to change without notice
en

BETRIEBSANLEITUNG
WTB4FP MultiSwitch
Miniatur-Lichtschranken
de
en
es
fr
it
ja
pl
pt
ru
zh

Beschriebenes Produkt
W4F
WTB4FP MultiSwitch
Hersteller
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Deutschland
Rechtliche Hinweise
Dieses Werk ist urheberrechtlich geschützt. Die dadurch begründeten Rechte bleiben
bei der Firma SICK AG. Die Vervielfältigung des Werks oder von Teilen dieses Werks
ist nur in den Grenzen der gesetzlichen Bestimmungen des Urheberrechtsgesetzes
zulässig. Jede Änderung, Kürzung oder Übersetzung des Werks ohne ausdrückliche
schriftliche Zustimmung der Firma SICK AG ist untersagt.
Die in diesem Dokument genannten Marken sind Eigentum ihrer jeweiligen Inhaber.
© SICK AG. Alle Rechte vorbehalten.
Originaldokument
Dieses Dokument ist ein Originaldokument der SICK AG.
2006/42/EC
NO
SAFETY
16 B E T R I E B S A N L E I T U N G | WTB4FP MultiSwitch 8025665.1C7L/2021-09-03 | SICK
Irrtümer und Änderungen vorbehalten
de

Inhalt
1 Allgemeine Sicherheitshinweise.............................................................. 18
2 Hinweise zur UL Zulassung...................................................................... 18
3 Produktbeschreibung............................................................................... 18
3.1 Bestimmungsgemäße Verwendung........................................ 18
3.2 Bedien- und Anzeigeelemente................................................ 18
4 Montage.................................................................................................... 19
5 Elektrische Installation............................................................................. 19
6 Inbetriebnahme........................................................................................ 20
6.1 Ausrichtung.............................................................................. 20
6.2 Die Einsatzbedingungen prüfen:............................................. 21
6.3 Einstellung................................................................................ 23
6.4 Prozessdatenstruktur.............................................................. 25
7 Störungsbehebung................................................................................... 25
8 Demontage und Entsorgung.................................................................... 26
9 Wartung..................................................................................................... 26
10 Technische Daten..................................................................................... 26
10.1 Maßzeichnungen..................................................................... 27
INHALT
8025665.1C7L/2021-09-03 | SICK B E T R I E B S A N L E I T U N G | WTB4FP MultiSwitch 17
Irrtümer und Änderungen vorbehalten
de

1 Allgemeine Sicherheitshinweise
■Lesen Sie vor der Inbetriebnahme des Geräts die Betriebsanleitung.
■
Der Anschluss, die Montage und die Konfiguration des Geräts dürfen nur
von geschultem Fachpersonal vorgenommen werden.
■
2006/42/EC
NO
SAFETY
Bei diesem Gerät handelt es sich um kein sicherheitsgerichtetes Bauteil im
Sinne der EU-Maschinenrichtlinie.
■
Installieren Sie den Sensor nicht an Orten, die direkter UV-Strahlung (Son‐
nenlicht) oder sonstigen Wettereinflüssen ausgesetzt sind, ausser dies ist in der
Betriebsanleitung ausdrücklich erlaubt.
■Bei der Inbetriebnahme ist das Gerät ausreichend vor Feuchtigkeit und Verschmut‐
zung zu schützen.
■Die vorliegende Betriebsanleitung enthält Informationen, die während des Lebens‐
zyklus der Lichtschranke benötigt werden.
2 Hinweise zur UL Zulassung
The device shall be supplied from an isolating transformer having a secondary overcur‐
rent protective device that complies with UL 248 to be installed in the field rated either:
a) max 5 amps for voltages 0 ~ 20 V (0 ~ 28.3 V peak), or
b) 100 / Vp for voltages of 20 ~ 30 V (28.3 ~ 42.4 V peak).
Alternatively, they can be supplied from a Class 2 power supply.
UL Environmental Rating: Enclosure type 1
3 Produktbeschreibung
3.1 Bestimmungsgemäße Verwendung
Die WTB4F ist ein optoelektronischer Reflexions-Lichttaster mit Hintergrundausblen‐
dung (im Folgenden Sensor genannt) und wird zum optischen, berührungslosen Erfas‐
sen von Sachen, Tieren und Personen eingesetzt. Bei jeder anderen Verwendung und
bei Veränderungen am Produkt verfällt jeglicher Gewährleistungsanspruch gegenüber
der SICK AG.
3.2 Bedien- und Anzeigeelemente
Reflexionslichttaster mit Hintergrundausblendung.
1
34
2
1 ALLGEMEINE SICHERHEITSHINWEISE
18 B E T R I E B S A N L E I T U N G | WTB4FP MultiSwitch 8025665.1C7L/2021-09-03 | SICK
Irrtümer und Änderungen vorbehalten
de

1BluePilot blau: Betriebsart, Schaltzustände QL1, QL2
2Teach-Taste: Einstellung des Schaltabstands
3Anzeige-LED gelb: Status Lichtempfang
4Anzeige-LED grün: Betriebsspannung aktiv
4 Montage
Den Sensor an einen geeigneten Befestigungswinkel montieren (siehe SICK-Zube‐
hör-Programm).
Abbildung 13: Ausrichtung des Sensors relativ zur Objektrichtung
Maximal zulässiges Anzugsdrehmoment des Sensors von < 0,4 Nm beachten.
Vorzugsrichtung des Objektes zum Sensor beachten, vgl. siehe Abbildung 13, Seite 19.
5 Elektrische Installation
Betrieb im Standard-I/O-Modus:
Anschluss der Sensoren muss spannungsfrei erfolgen. Je nach Anschlussart sind die
folgenden Informationen zu beachten:
– Steckeranschluss: Pinbelegung
– Leitung: Adernfarbe
Erst nach Anschluss aller elektrischen Verbindungen die Spannungsversorgung anlegen
bzw. einschalten.
Betrieb im IO-Link-Modus: Gerät an geeigneten IO-Link-Master anschließen und per
IODD / Funktionsblock im Master, bzw. in der Steuerung integrieren. Am Sensor blinkt
die grüne Anzeige-LED. IODD und Funktionsblock stehen unter www.sick.com unter der
Bestellnummer zum Download bereit.
Erläuterungen zum Anschlussschema.
BN = braun
WH = weiß
BU = blau
BK = schwarz
MF (Pin-2-Konfiguration) = Externer Eingang, Teach-in, Schaltsignal
QL1/C = Schaltausgang, IO-Link Kommunikation
Test = Test-Eingang
MONTAGE 4
8025665.1C7L/2021-09-03 | SICK B E T R I E B S A N L E I T U N G | WTB4FP MultiSwitch 19
Irrtümer und Änderungen vorbehalten
de

UB: 10 ... 30 V DC
Tabelle 5: elektrischer Anschluss
WTB4Fx- x4 x2 xH
1 = BN
2 = WH
3 = BU
4 = BK
12
4 3
2
1
4
3
0.14 mm2
AWG26
Tabelle 6: DC
WTx4Fx-
Push-pull xx16DxxxA00 xx16RxxxA00 xx16xxxxA01-A99
PNP xx86DxxxA00 xx86RxxxA00 xx86xxxxA01-A99
1 = BN + (L+)
2 = WH MF
3 = BU - (M)
4 = BK QL1/C
Default: MF QL2 QL2 www.sick.com
8022709
Default: QL1/C QL1 QL1 www.sick.com
8022709
Tabelle 7: Push-pull, PNP, NPN
QL1 QL2
Push-pull
PNP
NPN
+ (L+)
Q ≤ 100 mA
‒ (M)
Push-pull
PNP
NPN
+ (L+)
Q ≤ 100 mA
‒ (M)
Push-pull
PNP
NPN
+ (L+)
Q ≤ 100 mA
‒ (M)
Push-pull
PNP
NPN
+ (L+)
Q≤ 100 mA
‒ (M)
Push-pull
PNP
NPN
+ (L+)
Q≤ 100 mA
‒ (M)
Push-pull
PNP
NPN
+ (L+)
Q≤ 100 mA
‒ (M)
6 Inbetriebnahme
6.1 Ausrichtung
Sensor auf Objekt ausrichten. Positionierung so wählen, dass der rote Sendelichtstrahl
in der Mitte des Objekts auftrifft. Es ist darauf zu achten, dass die optische Öffnung
(Frontscheibe) des Sensors vollständig frei ist [siehe Abbildung 14].
5 ELEKTRISCHE INSTALLATION
20 B E T R I E B S A N L E I T U N G | WTB4FP MultiSwitch 8025665.1C7L/2021-09-03 | SICK
Irrtümer und Änderungen vorbehalten
de
