SICK FLOWSIC30 User manual

O P E R A T I N G I N S T R U C T I O N S
Installation
Operation
Maintenance
Title Page
FLOWSIC30
Gas Meter
for Wellhead Applications

2 FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH
Document information
Product
Product name: FLOWSIC30
Document ID
Title: Operating Instructions FLOWSIC30
Part No.: 8020999/173B
Version: 1-4
Release: 2020-02
Manufacturer
SICK Engineering GmbH
Bergener Ring 27 · D-01458 Ottendorf-Okrilla · Germany
Phone: [phone]
Fax: [phone]
E-mail: i[email protected]
Original documents
The English version 8020999/173B of this document is an original
document of SICK Engineering GmbH.
SICK Engineering GmbH assumes no liability for the correctness of
an unauthorized translation.
Please contact SICK Engineering GmbH or your local representative
in case of doubt.
Legal information
Subject to change without notice.
© SICK Engineering GmbH. All rights reserved.
Glossary
AGA 8 American Gas Association Report 8
ATEX Atmosphères Explosifs: Abbreviation for European
standards that govern safety in potentially explosive
atmospheres
EVC Electronic Volume Converter
a. c. actual condition
IEC International Electrotechnical Comission
IECEx IEC system for certification in accordance with
standards for devices for use in potentially explosive
atmospheres
s. c. standard condition
IPxy Ingress Protection: Degree of protection of a device
according to IEC/DIN EN 60529; x designates
protection against contact and impurities, y protec-
tion against moisture.
LVF Liquid Volume Fraction
SPU Signal Processing Unit
SOS Speed of Sound

FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH 3
Warning symbols
Warning levels / signal words
DANGER
Risk or hazardous situation which will result in severe personal
injury or death.
WARNING
Risk or hazardous situation which could result in severe personal
injury or death.
CAUTION
Hazard or unsafe practice which could result in personal injury or
property damage.
NOTICE
Hazards which could result in property damage
Information symbols
IMMEDIATE HAZARD
of severe injuries or death
Hazard (general)
Hazards by electrical voltage
Hazard in potentially explosive atmospheres
Hazard by explosive substances/mixtures
Hazard by unhealthy substances
Hazards by toxic substances
Information on product condition with regard to
protection against explosions (general)
Information on product characteristics related to
European Directive ATEX
Information on product characteristics related to
explosion protection in accordance with the IECEx
scheme.
Important technical information for this product
Important information on electric or electronic
functions
Nice to know
Supplementary information
Link referring to information at another place

Co n t en ts
4 FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH
1 Important information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 About this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 Main hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3.1 Purpose of the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3.2 Product identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3.3 Operation in potentially explosive atmospheres . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.3.4 Operation in pressure applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.3.5 Operation in applications with wet gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.3.6 Restrictions of use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.4 Responsibility of user . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2 Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.1 Functional principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.2 Calculations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.2.1 Determining the gas velocity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.2.2 Determining the sound velocity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2.3 Calculating the volume flow rate a. c. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2.4 Calculating the methane content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2.5 Volume conversion (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.2.6 Energy flow rate (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.3 System overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.4 Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.4.1 Analog output 4..20mA (passive) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.4.2 HART® compatible interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.4.3 RS485 interface (passive, option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.5 Wet gas detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.6 Data processing in FLOWSIC30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.6.1 Event logbook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.6.2 Diagnostic archive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.7 Display and operating elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.8 FLOWgateTM operating software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.8.1 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.8.2 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.1 Hazards during installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.2 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.2.1 Delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.2.2 Transport and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.3 Mechanical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.3.1 Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.3.2 Meter orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.3.3 Inlet and outlet piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.3.4 Choosing flanges, gaskets and other components . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.3.5 Fitting the FLOWSIC30 in the pipeline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.3.6 SPU alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.3.7 Sun shade for electronics (accessory) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Contents

Co n t en ts
FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH 5
3.4 Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.4.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.4.2 Cable specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.4.3 Maximum resistance for analog loop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3.4.4 Terminal compartment on the SPU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.4.5 Operating the FLOWSIC30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3.4.6 Requirements for use in hazardous areas with potentially explosive
atmospheres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4 Commissioning and operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.2 Commissioning via HART® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.2.1 Required tools and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.2.2 Establish the connection to FLOWSIC30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.2.3 Login procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.2.4 Meter installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4.2.5 Pressure value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4.2.6 HART® dynamic variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4.2.7 Analog out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
4.2.8 Electronic volume conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
4.3 Commissioning with the FLOWgateTM operating software . . . . . . . . . . . . . . . . . . . . . . . 54
4.3.1 Required tools and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4.3.2 Connecting to the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4.3.3 Connecting the FLOWSIC30 with a laptop or PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
4.3.4 Closing the FLOWSIC30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
4.3.5 User rights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
4.3.6 Commissioning wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
4.3.6.1 Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
4.3.6.2 System/User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
4.3.6.3 Archive/Logbook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
4.3.6.4 Analog output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
4.3.6.5 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
4.3.6.6 Pressure/Temperature Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
4.3.6.7 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
4.3.6.8 Electronic Volume Conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
4.3.6.9 Finalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
5 Maintenance and repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
5.1 Routine checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
5.1.1 Comparing theoretical and measured Speed of Sound (SOS) . . . . . . . . . . . . . . . . . . 66
5.1.2 Checking the meter health . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
5.1.3 Creating a parameter report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
5.2 Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Co n t en ts
6 FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH
6 Decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
6.1 Return delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6.1.1 Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6.1.2 Clearance certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6.1.3 Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6.2 Disposal Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6.2.1 Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6.2.2 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
7 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
7.1 General troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
7.2 System alarms and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
7.3 Checking the meter values via FLOWgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
7.4 Creating a diagnosis session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
8 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
8.1 Conformities and technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.1.1 Conformities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.1.2 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
8.2 Application limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
8.3 Type plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
8.4 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
8.5 Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Important information
FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH 7
Subject to change without notice
FLOWSIC30
1Important information
About this document
Main hazards
Intended use
Responsibility of user

8 FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH
Important information
Subject to change without notice
1.1 About this document
These Operating Instructions contain essential information on the function, installation,
start-up and maintenance of the FLOWSIC30.
1.2 Main hazards
The FLOWSIC30 is directly integrated into gas-carrying pipelines.
The operating company is responsible for safe operation and for complying with additional
national and company-specific regulations.
WARNING: Hazards through the gas in the system
The following conditions can increase the risk:
● Toxic gas or gas dangerous to health
● Chemically aggressive gas
● Explosive gas
● High gas pressure
● High gas temperature
▸ Only carry out installation work when the system is out of operation and
does not contain dangerous gas.
Otherwise escaping gas can possibly be dangerous to health and cause
injuries (e.g. poisoning, burns).
WARNING: Hazards through leaks
Operation in leaky condition is not allowed and possibly dangerous.
▸ Check leak tightness of equipment regularly.

Important information
FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH 9
Subject to change without notice
1.3 Intended use
1.3.1 Purpose of the device
The FLOWSIC30 serves measuring the gas volume, volume flow, gas temperature, gas
pressure (optional), speed of sound and methane content of gases in pipelines.
The FLOWSIC30 may only be used as specified by the manufacturer and as set forth below.
Make sure the use of the equipment complies with the technical data, information about
the permitted use as well as assembly, installation, ambient and operating conditions.
Relevant information is provided in the order documentation, type plate, certification
documents and this manual.
1.3.2 Product identification
For identification use the information on the main type plate.
For detailed information on the type plates and examples, please refer to → p. 79, §8.3.
Fig. 1 Location of type plates
Product name: FLOWSIC30
Manufacturer
SICK Engineering GmbH
Bergener Ring 27
D-01458 Ottendorf-Okrilla
Germany
1 Main type plate on the SPU
2 Type plate on the meter body
3 Flange designation
1
3
2

10 FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH
Important information
Subject to change without notice
1.3.3 Operation in potentially explosive atmospheres
1.3.4 Operation in pressure applications
Design, manufacture and inspection of the FLOWSIC30 measuring system is performed in
compliance with the safety requirements set forth in the ASME standard B31.3.
1.3.5 Operation in applications with wet gas
FLOWSIC30 has been designed for robust and reliable operation in challenging gas produc-
tion applications. In these applications, wet gas may also be existent in the gas stream.
However, FLOWSIC30 is a gas meter. All specifications of the gas meter apply for dry gas
only. Any wet gas in the gas stream may adversely affect the certainty of the measured
values and meter function.
→ Fig. 2 shows the gas meter's operating range at low pressure in horizontal and in vertical
meter orientation. Horizontal installation of the gas meter is recommended for wet gas
applications.
Since the effects of 2-phase streams with mixtures of liquid and gas are very complex, a
general operation guarantee cannot be given for the gas meter in these conditions.
Fig. 2 Wet gas operation
The FLOWSIC30 is suitable for use in potentially explosive atmospheres:
IECEx: Ex db eb ia [ia] IIA T4 Gb
ATEX: II 2G Ex db eb ia [ia] IIA T4 Gb
Further information on potentially explosive atmospheres, see → p. 39, §3.4.6.
0
200
400
600
800
1000
1200
1400
1600
012345
Max. flow rate [m³/h]
Liquid volume fraction [%]
Vertical meter orientation Horizontal meter orientation

Important information
FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH 11
Subject to change without notice
1.3.6 Restrictions of use
▸ Refer to the type plate for the configuration of your FLOWSIC30.
▸ Check that the FLOWSIC30 is suitably equipped for your application (e.g. gas condi-
tions).
1.4 Responsibility of user
▸
Only put the FLOWSIC30 into operation after reading the Operating Instructions.
▸ Observe all safety information.
▸ If anything is not clear: Please contact SICK Customer Service.
Designated users
The FLOWSIC30 may only be operated by skilled technicians who, based on their technical
training and knowledge as well as knowledge of the relevant regulations, can assess the
tasks given and recognize the hazards involved.
Correct use
▸ Only use the FLOWSIC30 as described in these Operating Instructions. The manufac-
turer bears no responsibility for any other use.
▸ Do not carry out any work or repairs on the FLOWSIC30 not described in this manual.
▸ Do not remove, add or modify any components to or on the FLOWSIC30 unless
described and specified in the official manufacturer information.
Otherwise
– any warranty by the manufacturer becomes void,
– the device may become dangerous,
– the approval for use in potentially explosive atmospheres is no longer valid,
– the approval for use in lines pressurized above 0.5 bar (7.25 psi) bar is no longer
valid.
Special local conditions
▸ Follow all local laws, regulations and company-internal operating directives applicable at
the installation location.
Retention of documents
▸ Keep these Operating Instructions and all associated documents available for refer-
ence.
▸ Pass the documents on to a new owner.
NOTICE:
Skilled persons are persons in accordance with DIN VDE 0105 or IEC 364, or
directly comparable standards.
These persons must have exact knowledge on hazards arising from operation,
e.g. through hot, toxic, explosive gases or gases under pressure, gas-liquid
mixtures or other media as well as adequate knowledge of the measuring
system gained through training.

12 FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH
Important information
Subject to change without notice

Product description
FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH 13
Subject to change without notice
FLOWSIC30
2Product description
Functional principle
Volume conversion (option)
System overview
Interfaces
FLOWgateTM operating software

14 FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH
Product description
Subject to change without notice
2.1 Functional principle
The FLOWSIC30 works according to the principle of ultrasonic transit time difference
measurement. Measured signal travel times tAB and tBA are defined by the current sound
and flow velocity of the gas.
Gas velocity v is determined from the difference between the signal travel times. Therefore
changes in the sound velocity caused by pressure or temperature fluctuations do not affect
the calculated gas flow rate with this method of measurement.
Fig. 3 Measuring principle FLOWSIC30
2.2 Calculations
2.2.1 Determining the gas velocity
Measuring path L is equal to the active measuring path, that is, the area through which the
gas flows. Given measuring path L, sound velocity c, and angle of inclination α between the
sound and flow direction, the sound transit time in the direction of the gas flow (forward
direction) when the signal is transmitted can be expressed as:
i.e. a relation in which, except for the two transit times measured, only the active measuring
path and the path angle exist as constants.
Ultrasonic transducer B
Ultrasonic transducer A
tBA
v
Meter body
LtAB 
v = Gas velocity in m/s
L = Measuring path in m
= Angle of inclination in °
tAB = Sound transit time in flow direction
tBA = Sound transit time against the flow
direction
Valid against the flow is:
After the resolution to v:
v = · ( )
tBA =
tAB =
L 1 1
2 · cos α tAB tBA
L
c - v · cos α
L
c + v · cos α (2.1)
(2.2)
(2.3)

Product description
FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH 15
Subject to change without notice
2.2.2 Determining the sound velocity
Sound velocity c can be calculated by resolving formulas 2.1 and 2.2.
2.2.3 Calculating the volume flow rate a. c.
The volume flow rate in actual condition (a. c.) is calculated from the gas velocity and the
geometric dimensions of the meter body diameter D.
2.2.4 Calculating the methane content
The calculation of the methane content is made by a simple model based on the measured
speed of sound in the medium. It can be used to identify changes in the gas composition
that may require appropriate action by the plant operator. The underlying model has been
created primarily for unconventional natural gas with high contents of methane.
The algorithm is based on the following assumptions:
● The main components are N2, CO2 and CH4, all other components exist only in
negligible amounts.
● The portion of N2 is roughly twice the portion of CO2.
● Significant amounts of other substances may lead to deviations.
Application limits of the methane algorithm
-10 °C < T < 85 °C
1 bar (a) < p < 20 bar (a)
The output value is without unit and refers to 1, uncertainty < 0.5%.
L tAB + tBA
2 tAB · tBA (2.4)
c = · ( )
Q = · ( )
D2 · π
4 (2.5)
v

16 FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH
Product description
Subject to change without notice
2.2.5 Volume conversion (option)
As an option, FLOWSIC30 can be ordered with electronic volume conversion.
The optional Electronic Volume Converter (EVC) provides the capability to convert the
measured values in actual condition (a. c.) to standard condition (s. c.). Various standard
conditions can be defined.
Table 1 Measured values
The gas compressibility calculation is made acc. to AGA 8 Gross method 1 or 2. It requires
input of certain process values such as gas pressure and temperature. Settings can be
made in the FLOWgateTM operating software or via HART® protocol.
Prerequisites for volume conversion
● Actual process pressure is fed into FLOWSIC30 by one of the methods below:
– The process pressure is set to a fix value in FLOWSIC30.
– The process pressure is read in from an external HART® pressure sensor connected
to the HART® bus. The p sensor is then loop powered.
– The process pressure is read in from an internal pressure sensor.
● The p sensor and the FLOWSIC30 are configured as follows:
– The p sensor and the FLOWSIC30 are in multidrop mode.
– The p sensor is in burst mode or must be polled periodically by HART® master.
● The p sensor has been fully configured in FLOWSIC30.
Table 2 AGA8, ranges of applicability
In actual condition In standard condition
Gas volume a. c. Gas volume s. c.
Error volume a. c. Error volume s. c.
Volumetric flow a. c. Volumetric flow s. c.
Quantity Gross calculation
Relative Density (Gr) 0.56 to 0.87
Gross Heating Value 477 to 1150 Btu/scf (16.8 - 40.5 MJ/m³)
Mol Percent Methane 45.0 to 100.0
Mol Percent Nitrogen 0.0 to 50.0
Mol Percent Carbon Dioxide 0.0 to 30.0
Mol Percent Ethane 0.0 to 10.0
Mol Percent Propane 0.0 to 4.0
Mol Percent Butanes 0.0 to 1.0
Mol Percent Pentanes 0.0 to 0.3
Mol Percent Hexanes Plus 0.0 to 0.2
Mol Percent Helium 0.0 to 0.2
Mol Percent Hydrogen Assumed 0.0
Mol Percent Carbon Monoxide Assumed 0.0
MolPercent Argon Assumed 0.0
Mol Percent Oxygen Assumed 0.0
Mol Percent Water 0.0 to 0.05
Mol Percent Hydrogen Sulfide 0.0 to 0.02
Flowing Pressure 1200 psia (8.3 MPa)
Flowing Temperature 32 to 130 Deg F (0 to 55 Deg C)

Product description
FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH 17
Subject to change without notice
2.2.6 Energy flow rate (option)
Based on standardized volume flow rate and heating value, the energy flow rate is
calculated as follows:
The energy flow rate can be visualized on the device display and in the FLOWgateTM
operating software.
Prerequisites for energy flow rate
● Fully configured volume conversion (option), → p. 16, §2.2.5
● Heating value set by user via HART® or RS485 (option)
● Heating value and volume conversion need to refer to the same reference conditions
E
t(2.6)
Et = = Qref. · HVref.

18 FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH
Product description
Subject to change without notice
2.3 System overview
The FLOWSIC30 is designed for use in natural gas production applications for gases such
as coal bed methane. The dual-path meter comes with a robust carbon steel meter body
and full-titanium transducers.
The ultrasonic measurement technology has no moving parts and is virtually maintenance
free. The rugged design with integrated wires protects the gas meter from harsh ambient
conditions while the large turn-down ratio covers all well flow rates. FLOWSIC30 is equipped
with integrated diagnostics that monitor the meter status and indicate the presence of
liquids in the gas stream.
With integrated temperature and pressure measurement and optional volume conversion
according to AGA 8, the gas meter calculates the volumetric flow s. c. and reduces installa-
tion efforts. Power consumption of only 65 mW and the two-wire loop powered concept
make integration easy while HART® and Modbus communication provide versatility in data
transfer.
FLOWSIC30 is available as wet-gas robust or wet-gas tolerant design.
Wet-gas robust design
The wet-gas robust design was designed specifically for wet gas applications in natural gas
production with installation upstream of separators. The device is also suitable for
continuous wet gas operation with a high liquid loading.
Wet-gas tolerant design
The wet-gas tolerant device design was designed for installation behind separators. The
device can measure in continuous wet gas operation with low liquid loading. Temporary
high liquid loads can lead to limited measuring availability. As the liquid load decreases, the
gas meter recovers completely, e.g. in case of temporarily reduced separator performance.
The lower wet gas robustness enables improved measurement accuracy.
System components
The FLOWSIC30 measuring system comprises the following hardware components:
● Meter body
● Ultrasonic transducers
● Temperature sensor (option)
● Internal pressure sensor (optional)
● Signal processing unit (SPU)

Product description
FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH 19
Subject to change without notice
Fig. 4 System components
2.4 Interfaces
As a standard, FLOWSIC30 comes with loop-powered 4..20 mA output. The current loop
supports digital HART® communication for setup and diagnosis of the gas meter. The inter-
face can be used also to transmit additional measurement data. Optionally, FLOWSIC30
can be ordered with an additional Modbus RS485 interface.
2.4.1 Analog output 4..20mA (passive)
The following measurement values can be assigned. The same value is used as primary
variable of the HART® interface.
1Volumetric flow, a. c. (default)
2Volumetric flow s. c.
3Pressure
4Temperature
5Velocity of sound
6Velocity of gas
7Methane content
1 Transducer cover with internal wiring
2 Flange, full ANSI #150
3 Pressure tap
4 Two-wire loop power
5 SPU (Signal Processing Unit)
6 HART® and Modbus interface
7 Integrated temperature and pressure sensor (both optional)
8 Marking for direction of flow (forward)
9 Meter body
1
2
3
4
5
6
7
8
9

20 FLOWSIC30 · Operating Instructions · 8020999/173B/V1-4/2020-02 · © SICK Engineering GmbH
Product description
Subject to change without notice
2.4.2 HART® compatible interface
Impedance value of the HART® interface
Rx = 160 kΩ
Cx = 10 nF
Conformities
The FLOWSIC30 complies with the following specifications:
● HCF_SPEC-127, revision 5.0
● HCF_SPEC-301, revision 6.0
● HCF_SPEC-151, revision 8.0
● HCF_SPEC-99, revision 8.0
● HCF_SPEC-183, revision 13.0
● HCF_SPEC-81, revision 8.0
The device type code of the FLOWSIC30 gas meter is 0xC782 (FieldComm/HART® Founda-
tion registration pending) .
Point to point wiring
The device supports point-to-point connections. A host and/or a field communicator can be
integrated into the bus as communication master(s). Communication may run through Ex
isolators according to the HART® specification. Any polling address in the HART® address
range can be used to address the device. The polling address must be configured by the
software using the command #6 (default: 0).
Network (Multidrop)
The device can also be integrated into a network. Polling addresses must not be used more
than once in the network. If the device is integrated into a network, its polling address must
be greater than zero. In this mode the signal of the analog loop does not represent a
quantity measured by the device. A host and/or a field communicator can be integrated
into the bus as communication master(s). The number of devices in the network is limited
by the number of possible device addresses.
