Siemens MCP 398C User manual

SINUMERIK
SINUMERIK 840D sl
Machine control panel: MCP 398C
Manual
Valid for:
Control system
SINUMERIK 840D sl / 840DE sl
12/2017
A5E43199783B AA
Fundamental safety
instructions 1
Description 2
Operator control and display
elements 3
Dimension drawings 4
Mounting 5
Connecting 6
Service and maintenance 7
Diagnostics 8
Technical data 9
Spare parts/accessories 10
Safety symbols 11

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be
used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property
damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions. Qualified
personnel are those who, based on their training and experience, are capable of identifying risks and avoiding
potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described.
Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the information in
this publication is reviewed regularly and any necessary corrections are included in subsequent editions.
Siemens AG
Division Digital Factory
Postfach 48 48
90026 NÜRNBERG
GERMANY
Document order number: A5E43199783B AA
Ⓟ 01/2018 Subject to change
Copyright © Siemens AG 2017.
All rights reserved

Table of contents
1 Fundamental safety instructions...................................................................................................................5
1.1 General safety instructions.......................................................................................................5
1.2 Equipment damage due to electric fields or electrostatic discharge........................................8
1.3 Warranty and liability for application examples........................................................................8
1.4 Industrial security.....................................................................................................................9
1.5 Residual risks of power drive systems...................................................................................10
2 Description..................................................................................................................................................11
2.1 Overview................................................................................................................................11
2.2 System features.....................................................................................................................12
2.3 Interfaces...............................................................................................................................13
2.3.1 Overview................................................................................................................................13
2.3.2 Description.............................................................................................................................15
2.3.3 Input / output images..............................................................................................................18
2.4 Rating plate............................................................................................................................22
3 Operator control and display elements.......................................................................................................25
3.1 Front side...............................................................................................................................25
3.2 Rear side................................................................................................................................28
4 Dimension drawings...................................................................................................................................31
5 Mounting.....................................................................................................................................................33
5.1 Introduction............................................................................................................................33
5.2 Mounting................................................................................................................................34
6 Connecting.................................................................................................................................................37
6.1 Pin assignment of the interfaces............................................................................................37
6.1.1 Power supply..........................................................................................................................37
6.1.2 Ethernet ports X20, X21.........................................................................................................37
6.1.3 Axis override switches X30, X31, X32...................................................................................38
6.1.4 Universal inputs X51, X52, X55.............................................................................................39
6.1.5 Universal outputs X53, X54....................................................................................................41
6.1.6 Handwheels...........................................................................................................................41
7 Service and maintenance...........................................................................................................................43
8 Diagnostics.................................................................................................................................................45
8.1 LED displays..........................................................................................................................45
8.2 Output functions.....................................................................................................................45
8.3 Key test..................................................................................................................................49
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 3

9 Technical data............................................................................................................................................51
9.1 Supplementary electrical conditions.......................................................................................53
9.1.1 Power supply..........................................................................................................................53
9.1.2 Grounding concept.................................................................................................................54
9.1.3 RI suppression measures......................................................................................................55
9.1.4 SINUMERIK_SouthKorea_Note.............................................................................................56
9.2 Standards and approvals.......................................................................................................57
9.3 Recycling and disposal..........................................................................................................57
10 Spare parts/accessories.............................................................................................................................59
10.1 Overview................................................................................................................................59
10.2 Handwheel connection...........................................................................................................60
11 Safety symbols...........................................................................................................................................61
Index...........................................................................................................................................................63
Table of contents
Machine control panel: MCP 398C
4Manual, 12/2017, A5E43199783B AA

Fundamental safety instructions 1
1.1 General safety instructions
WARNING
Electric shock and danger to life due to other energy sources
Touching live components can result in death or severe injury.
● Only work on electrical devices when you are qualified for this job.
● Always observe the country-specific safety rules.
Generally, the following six steps apply when establishing safety:
1. Prepare for disconnection. Notify all those who will be affected by the procedure.
2. Isolate the drive system from the power supply and take measures to prevent it being
switched back on again.
3. Wait until the discharge time specified on the warning labels has elapsed.
4. Check that there is no voltage between any of the power connections, and between any
of the power connections and the protective conductor connection.
5. Check whether the existing auxiliary supply circuits are de-energized.
6. Ensure that the motors cannot move.
7. Identify all other dangerous energy sources, e.g. compressed air, hydraulic systems, or
water. Switch the energy sources to a safe state.
8. Check that the correct drive system is completely locked.
After you have completed the work, restore the operational readiness in the inverse sequence.
WARNING
Electric shock due to connection to an unsuitable power supply
When equipment is connected to an unsuitable power supply, exposed components may
carry a hazardous voltage that might result in serious injury or death.
● Only use power supplies that provide SELV (Safety Extra Low Voltage) or PELV-
(Protective Extra Low Voltage) output voltages for all connections and terminals of the
electronics modules.
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 5

WARNING
Electric shock due to equipment damage
Improper handling may cause damage to equipment. For damaged devices, hazardous
voltages can be present at the enclosure or at exposed components; if touched, this can
result in death or severe injury.
● Ensure compliance with the limit values specified in the technical data during transport,
storage and operation.
● Do not use any damaged devices.
WARNING
Electric shock due to unconnected cable shields
Hazardous touch voltages can occur through capacitive cross-coupling due to unconnected
cable shields.
● As a minimum, connect cable shields and the cores of cables that are not used at one end
at the grounded housing potential.
WARNING
Electric shock if there is no ground connection
For missing or incorrectly implemented protective conductor connection for devices with
protection class I, high voltages can be present at open, exposed parts, which when touched,
can result in death or severe injury.
● Ground the device in compliance with the applicable regulations.
WARNING
Spread of fire from built-in devices
In the event of fire outbreak, the enclosures of built-in devices cannot prevent the escape of
fire and smoke. This can result in serious personal injury or property damage.
● Install built-in units in a suitable metal cabinet in such a way that personnel are protected
against fire and smoke, or take other appropriate measures to protect personnel.
● Ensure that smoke can only escape via controlled and monitored paths.
Fundamental safety instructions
1.1 General safety instructions
Machine control panel: MCP 398C
6Manual, 12/2017, A5E43199783B AA

WARNING
Unexpected movement of machines caused by radio devices or mobile phones
When radio devices or mobile phones with a transmission power > 1 W are used in the
immediate vicinity of components, they may cause the equipment to malfunction.
Malfunctions may impair the functional safety of machines and can therefore put people in
danger or lead to property damage.
● If you come closer than around 2 m to such components, switch off any radios or mobile
phones.
● Use the "SIEMENS Industry Online Support App" only on equipment that has already been
switched off.
WARNING
Fire due to inadequate ventilation clearances
Inadequate ventilation clearances can cause overheating of components with subsequent
fire and smoke. This can cause severe injury or even death. This can also result in increased
downtime and reduced service lives for devices/systems.
● Ensure compliance with the specified minimum clearance as ventilation clearance for the
respective component.
WARNING
Unexpected movement of machines caused by inactive safety functions
Inactive or non-adapted safety functions can trigger unexpected machine movements that
may result in serious injury or death.
● Observe the information in the appropriate product documentation before commissioning.
● Carry out a safety inspection for functions relevant to safety on the entire system, including
all safety-related components.
● Ensure that the safety functions used in your drives and automation tasks are adjusted
and activated through appropriate parameterizing.
● Perform a function test.
● Only put your plant into live operation once you have guaranteed that the functions relevant
to safety are running correctly.
Note
Important safety notices for Safety Integrated functions
If you want to use Safety Integrated functions, you must observe the safety notices in the Safety
Integrated manuals.
Fundamental safety instructions
1.1 General safety instructions
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 7

1.2 Equipment damage due to electric fields or electrostatic discharge
Electrostatic sensitive devices (ESD) are individual components, integrated circuits, modules
or devices that may be damaged by either electric fields or electrostatic discharge.
NOTICE
Equipment damage due to electric fields or electrostatic discharge
Electric fields or electrostatic discharge can cause malfunctions through damaged individual
components, integrated circuits, modules or devices.
● Only pack, store, transport and send electronic components, modules or devices in their
original packaging or in other suitable materials, e.g conductive foam rubber of aluminum
foil.
● Only touch components, modules and devices when you are grounded by one of the
following methods:
– Wearing an ESD wrist strap
– Wearing ESD shoes or ESD grounding straps in ESD areas with conductive flooring
● Only place electronic components, modules or devices on conductive surfaces (table with
ESD surface, conductive ESD foam, ESD packaging, ESD transport container).
1.3 Warranty and liability for application examples
The application examples are not binding and do not claim to be complete regarding
configuration, equipment or any eventuality which may arise. The application examples do not
represent specific customer solutions, but are only intended to provide support for typical tasks.
You are responsible for the proper operation of the described products. These application
examples do not relieve you of your responsibility for safe handling when using, installing,
operating and maintaining the equipment.
Fundamental safety instructions
1.3 Warranty and liability for application examples
Machine control panel: MCP 398C
8Manual, 12/2017, A5E43199783B AA

1.4 Industrial security
Note
Industrial security
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens products and solutions only represent one component of such a
concept.
The customer is responsible for preventing unauthorized access to its plants, systems,
machines and networks. Systems, machines and components should only be connected to
the enterprise network or the internet if and to the extent necessary and with appropriate
security measures (e.g. use of firewalls and network segmentation) in place.
Additionally, Siemens’ guidance on appropriate security measures should be taken into
account. For more information about industrial security, please visit:
Industrial security (http://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more secure.
Siemens strongly recommends to apply product updates as soon as available and to always
use the latest product versions. Use of product versions that are no longer supported, and
failure to apply latest updates may increase customer’s exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed at:
Industrial security (http://www.siemens.com/industrialsecurity).
WARNING
Unsafe operating states resulting from software manipulation
Software manipulations (e.g. viruses, trojans, malware or worms) can cause unsafe operating
states in your system that may lead to death, serious injury, and property damage.
● Keep the software up to date.
● Incorporate the automation and drive components into a holistic, state-of-the-art industrial
security concept for the installation or machine.
● Make sure that you include all installed products into the holistic industrial security concept.
● Protect files stored on exchangeable storage media from malicious software by with
suitable protection measures, e.g. virus scanners.
Fundamental safety instructions
1.4 Industrial security
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 9

1.5 Residual risks of power drive systems
When assessing the machine- or system-related risk in accordance with the respective local
regulations (e.g., EC Machinery Directive), the machine manufacturer or system installer must
take into account the following residual risks emanating from the control and drive components
of a drive system:
1. Unintentional movements of driven machine or system components during commissioning,
operation, maintenance, and repairs caused by, for example,
– Hardware and/or software errors in the sensors, control system, actuators, and cables
and connections
– Response times of the control system and of the drive
– Operation and/or environmental conditions outside the specification
– Condensation/conductive contamination
– Parameterization, programming, cabling, and installation errors
– Use of wireless devices/mobile phones in the immediate vicinity of electronic
components
– External influences/damage
– X-ray, ionizing radiation and cosmic radiation
2. Unusually high temperatures, including open flames, as well as emissions of light, noise,
particles, gases, etc., can occur inside and outside the components under fault conditions
caused by, for example:
– Component failure
– Software errors
– Operation and/or environmental conditions outside the specification
– External influences/damage
3. Hazardous shock voltages caused by, for example:
– Component failure
– Influence during electrostatic charging
– Induction of voltages in moving motors
– Operation and/or environmental conditions outside the specification
– Condensation/conductive contamination
– External influences/damage
4. Electrical, magnetic and electromagnetic fields generated in operation that can pose a risk
to people with a pacemaker, implants or metal replacement joints, etc., if they are too close
5. Release of environmental pollutants or emissions as a result of improper operation of the
system and/or failure to dispose of components safely and correctly
6. Influence of network-connected communication systems, e.g. ripple-control transmitters or
data communication via the network
For more information about the residual risks of the drive system components, see the relevant
sections in the technical user documentation.
Fundamental safety instructions
1.5 Residual risks of power drive systems
Machine control panel: MCP 398C
10 Manual, 12/2017, A5E43199783B AA

Description 2
2.1 Overview
The MCP 398C enables user-friendly operation of the machine functions on complex
machining stations. It is suitable for machine-level operation of milling, turning, grinding and
special machines.
Note
The IE functionality (IE = Industrial Ethernet) is still included and preset.
Please note the switch position of S2.
In addition to the standard elements for machine control, freely assignable slots can be
integrated with the EM 66 and EM 131 for connecting further control devices, e.g. for
pushbuttons, USB interface, Ethernet interface. The EM 131 also has space for a third override
switch, a handwheel or other operator controls.
The function of the MCP 398C can be extended considerably by installing additional keys.
All keys are designed with replaceable caps for machine-specific adaptations. The key caps
can be freely inscribed using a laser. Clear key caps can be used as an alternative.
The machine control panel is easy to mount on the rear using special tension jacks.
The MCP 398C is available as a standard version and with expansion modules.
Validity
The following description applies to the following machine control panels and expansion
modules:
Table 2-1 Standard version
Designation Features Article number
MCP 398C 6FC5303-0AF25-0AA0
Table 2-2 Expansion modules
Designation Features Article number
EM 66 Space for four slots (d = 16 mm) or for three slots (d = 22 mm) 6FC5303-0AF30-0AA0
EM 131 Space for six slots (depending on the size of the switching ele‐
ments) as well as space for a third override switch, a handwheel or
other operator controls.
6FC5303-0AF31-0AA0
The safety-related accessories / spare parts are marked in Section "Accessories and spare
parts (Page 59)" with an *).
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 11

2.2 System features
Configuration
Operator controls:
● Mechanical short-stroke keys
● Operating mode and function keys:
– 50 keys with assigned LEDs, of which 17 freely assignable customer keys in the
standard assignment
– Direction keys for milling machines with rapid traverse override
(The key covers for the direction keys for turning machines are supplied, see Section
Front side (Page 25))
● Spindle control with spindle override (rotary switch with 16 positions)
● Feed control with feed rate / rapid traverse override (rotary switch with 23 positions)
● Keyswitch (four positions and three different keys)
● Emergency stop button, two contact blocks (one NO contact + one NC contact each)
Interfaces:
● Two Ethernet interfaces (transmission rate: 10/100 Mbit/s; for IE and PN)
● Nine customer-specific inputs (e.g. for illuminated pushbuttons)
● Six customer-specific outputs
● Connection for two handwheels (Sub-D)
Velocity input and contour handwheel are only possible when connecting via the MCP PN
interface 6FC5303-0AF03-0AA0.
● Connection for one additional electronic override rotary switch
Expansion modules:
EM 66:
● When installed next to the MCP 398C, this results in a total width of 464 mm. The EM 66
is therefore suitable for use with the TOP 1900.
● Four 16 mm or three 22 mm slots (depending on the size of the switching elements).
● Space for the integration, for example, of pushbuttons, USB interface or other operator
controls.
EM 131:
● When installed next to the MCP 398C, this results in a total width of 529 mm. The EM 131
is therefore suitable for use with the TOP 2200.
● Six 16 mm or 22 mm slots (depending on the size of the switching elements).
● Space for the integration, for example, of pushbuttons, a USB interface, an Ethernet
interface, a handwheel, an additional override switch or other operator controls.
Description
2.2 System features
Machine control panel: MCP 398C
12 Manual, 12/2017, A5E43199783B AA

Note
No built-in elements are equipped in the delivery state.
2.3 Interfaces
2.3.1 Overview
Interface Designation Max. cable length: Type
X10 24 V power supply interface 10 m Terminal block, 3-
pin
X20 Ethernet 1 100 m RJ45
X21 Ethernet 2 100 m RJ45
X30 Interface for feedrate override rotary switch 0.6 m 10-pin male con‐
nector
X31 Interface for spindle override rotary switch 0.6 m 10-pin male con‐
nector
X32 Interface for additional override switch 0.6 m 10-pin male con‐
nector
X51 /
X52 / X55
Interfaces for customer-specific inputs 0.6 m 4-pin male connec‐
tor
X53 / X54 Interfaces for customer-specific outputs 0.6 m 4-pin male connec‐
tor
X60 / X61 Connections for two handwheels (TTL / differen‐
tial - can be set with switch S1)
5 m 15-pin Sub-D male
connector
Protective conductor connection Length and cross
section in accord‐
ance with the na‐
tional regulations
M5 screw
The following special requirements apply for the connection cables:
● The 24 VDC cable must be approved for temperatures up to 70° C.
● Select the permitted conductor cross-section in accordance with the national regulations
(NEC, VDE, etc.) and the "Power supply connectors for MCP 398C" table below. The line
protection in accordance with the national regulations (NEC, VDE,...) must be guarantied
as appropriate for the selected conductor cross-section.
● Strip the cables (7 mm) for connection to the 24 VDC connector.
● Flame resistance of the 24 VDC cable in accordance with UL 2556 VW-1 / or tested in
accordance with IEC 60332-1-2.
● Observe the permissible bending radius of the cables.
Description
2.3 Interfaces
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 13

● Only rotate the panel in a way that does not cause pinching of the cables.
● Route all of the cables in such a way that they do not come into contact with chafing edges.
Note
Warning for areas subject to NEC or CEC:
Safety notice for connectors with Ethernet marking:
A Ethernet or Ethernet segment, with all its associated interconnected equipment, shall be
entirely contained within a single low-voltage power distribution and within a single building.
The Ethernet is considered to be in an "environment A" according IEEE802.3 or "environment
0" according IEC TR 62102, respectively.
Never make direct electrical connection to TNV-circuits (Telephone Network) or WAN (Wide
Area Network).
Pin assignment
The pin assignments of the interfaces are described in Section "Connect" > "Pin assignment
of the interfaces" (Page 37).
Power supply connector for MCP 398C
Connection type Strain-relief clamp connection
Connection screw M2.5 screw with cross-slot
Operating tool Screwdriver blade 0.6x3.5, PH0, PZ0 (DIN
5264, ISO 8764/2-PH, ISO 8764/2-PZ)
Specified tightening torque Nm 0.4 ... 0.5
Conductor cross-section min./max.
Solid mm² 1.3 … 3.3
Finely stranded mm² 1.3 … 3.3
With ferrule with collar DIN46228/4 mm² 1.3 … 2.5
With ferrule DIN46228/1 mm² 1.3 … 3.3
AWG cables, solid or stranded AWG 12 … 16
Description
2.3 Interfaces
Machine control panel: MCP 398C
14 Manual, 12/2017, A5E43199783B AA

2.3.2 Description
Switch S1
MCP set up as PN
Table 2-3 General switch S1 setting
1-8 9 10 Meaning
See Table "Settings of switch S1" on on PN
off off IE (default)
The two switches S1-9 and S1-10 must be set to "on" for the PN functionality.
The switches S1-1 to S1-8 define the default device name.
Up to 128 default device names are possible. If these default device names are used, there is
no need for initialization of the MCP.
Note
Reconfiguration of preset device names not possible
You cannot reconfigure preset device names, for example, with STEP 7 "Device initialization".
Note
SINUMERIK control must support the PN functionality of the MCP
When you connect the MCP to a SINUMERIK control as a PROFINET component, make sure
that this functionality is supported by the relevant control.
DCP mode:
No default device name is available in this mode. You must set the device name by means of
an initialization. This newly created name is saved on the MCP. To delete the device name,
you must reset the MCP to the factory setting, e.g. with STEP 7.
Table 2-4 Settings of switch S1
1 2 3 4 5 6 7 8 9 10 Meaning
on on
on on on on on on on on DCP mode
on on on on on on on off Default device name: mcp-pn127
off on on on on on on off Default device name: mcp-pn126
on off on on on on on off Default device name: mcp-pn125
off off on on on on on off Default device name: mcp-pn124
on on off on on on on off Default device name: mcp-pn123
off on off on on on on off Default device name: mcp-pn122
on off off on on on on off Default device name: mcp-pn121
off off off on on on on off Default device name: mcp-pn120
Description
2.3 Interfaces
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 15

1 2 3 4 5 6 7 8 9 10 Meaning
on on on off on on on off Default device name: mcp-pn119
off on on off on on on off Default device name: mcp-pn118
on off on off on on on off Default device name: mcp-pn117
off off on off on on on off Default device name: mcp-pn116
on on off off on on on off Default device name: mcp-pn115
off on off off on on on off Default device name: mcp-pn114
on off off off on on on off Default device name: mcp-pn113
off off off off on on on off Default device name: mcp-pn112
x x x x x x x x "
on on on on off off off off Default device name: mcp-pn15
off on on on off off off off Default device name: mcp-pn14
on off on on off off off off Default device name: mcp-pn13
off off on on off off off off Default device name: mcp-pn12
on on off on off off off off Default device name: mcp-pn11
off on off on off off off off Default device name: mcp-pn10
on off off on off off off off Default device name: mcp-pn9
off off off on off off off off Default device name: mcp-pn8
on on on off off off off off Default device name: mcp-pn7
off on on off off off off off Default device name: mcp-pn6
on off on off off off off off Default device name: mcp-pn5
off off on off off off off off Default device name: mcp-pn4
on on off off off off off off Default device name: mcp-pn3
off on off off off off off off Default device name: mcp-pn2
on off off off off off off off Default device name: mcp-pn1
off off off off off off off off Default device name: mcp-pn
MCP set up as IE
You can assign a logical address to the MCP for communication via Ethernet with the 10-bit
switch S1.
Table 2-5 Setting of switch S1 as delivered
1 2 3 4 5 6 7 8 9 10 Meaning
off off off off off off on on off off MCP address 192
The two switches S1-9 and S1-10 must be set to "off" (IE functionality).
The switches S1-1 to S1-8 define the MCP address in the range of 0 to 255.
The addresses from 192 to 223 count as the default range.
Description
2.3 Interfaces
Machine control panel: MCP 398C
16 Manual, 12/2017, A5E43199783B AA

The MCP address is used as a reference for addressing an MCP during the PLC parameter
assignment.
Table 2-6 Settings of switch S1
1 2 3 4 5 6 7 8 9 10 Meaning
off off
on on on on on on on on MCP address 255
x x x x x x x x "
on on on on on off on on MCP address 223
off on on on on off on on MCP address 222
on off on on on off on on MCP address 221
off off on on on off on on MCP address 220
on on off on on off on on MCP address 219
off on off on on off on on MCP address 218
on off off on on off on on MCP address 217
off off off on on off on on MCP address 216
on on on off on off on on MCP address 215
off on on off on off on on MCP address 214
on off on off on off on on MCP address 213
off off on off on off on on MCP address 212
on on off off on off on on MCP address 211
off on off off on off on on MCP address 210
on off off off on off on on MCP address 209
off off off off on off on on MCP address 208
on on on on off off on on MCP address 207
off on on on off off on on MCP address 206
on off on on off off on on MCP address 205
off off on on off off on on MCP address 204
on on off on off off on on MCP address 203
off on off on off off on on MCP address 202
on off off on off off on on MCP address 201
off off off on off off on on MCP address 200
on on on off off off on on MCP address 199
off on on off off off on on MCP address 198
on off on off off off on on MCP address 197
off off on off off off on on MCP address 196
on on off off off off on on MCP address 195
off on off off off off on on MCP address 194
on off off off off off on on MCP address 193
Description
2.3 Interfaces
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 17

1 2 3 4 5 6 7 8 9 10 Meaning
off off off off off off on on MCP address 192
x x x x x x x x "
on off off off off off off off MCP address 001
off off off off off off off off MCP address 000
You can find the settings for the basic PLC program in:
Function Manual, Basic Functions (P3 sl)
Switch S2
The handwheel signal type is set with switch S2-1.
Table 2-7 Settings of switch S2
S2-1 po‐
sition
Meaning
on Differential connection
off TTL connection
Switch S2-1 is set to "on" when delivered from the factory.
Note
S2-2 position
Switch S2-2 is reserved for test purposes.
See also
Pin assignment of the interfaces (Page 37)
2.3.3 Input / output images
Standard + two handwheels
The specifications for assigning input and output bytes listed in the tables can be changed in
the PLC via parameter assignment.
Note
The following applies in respect of the process input and output images in the tables: n is
defined by means of FB1 parameters in OB100 of the PLC.
Description
2.3 Interfaces
Machine control panel: MCP 398C
18 Manual, 12/2017, A5E43199783B AA

Table 2-8 MCP 398C input image
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
EB n + 0 Spindle override Mode
D (23) C (22) B (21) A (20) JOG TEACH IN MDA AUTO
EB n + 1 Machine function
REPOS REF. Var. INC 10000 INC 1000 INC 100 INC 10 INC 1 INC
EB n + 2 Key-operated switch Spindle
start
* Spindle
stop
Feed
start
* Feed
stop
NC
start
* NC
stop
Position 0 Position 2
EB n + 3 RESET Key-operat‐
ed
switch
position 1
Single
block
Feed override
E (24) D (23) C (22) B (21) A (20)
EB n + 4 Arrow keys Key-operat‐
ed
switch
position 3
Axis selection
+
R15
-
R13
Rapid tra‐
verse
R14
X
R1
4th axis
R4
7th axis
R7 R10
EB n + 5 Axis selection
Y
R2
Z
R3
5th axis
R5
Motion
command
in
MCS/WCS
R11
9th axis
R9
8th axis
R8
6th axis
R6
EB n + 6 Unassigned customer keys
T9 T10 T11 T12 T13 T14 T15 -
EB n + 7 Unassigned customer keys
T1 T2 T3 T4 T5 T6 T7 T8
EB n + 8 - - - - - - - -
EB n + 9 - - - - - - - -
EB n + 10 KT-IN8
X55.2
KT-IN7
X55.1
KT-IN6
X52.3
KT-IN5
X52.2
KT-IN4
X52.1
KT-IN3
X51.3
KT-IN2
X51.2
KT-IN1
X51.1
EB n + 11 - - - - - - - KT-IN9
X55.3
EB n + 12 - - - X32
pin 61)
X32
pin 71)
X32
pin 81)
X32
pin 91)
X32
pin 101)
EB n + 13 - - - X31
pin 6 1)
X31
pin 7 1)
X31
pin 8 1)
X31
pin 9 1)
X31
pin 10 1)
Signals marked with * are inverse signals.
1) If the 4-stage rotary spindle override switch on X31 is replaced by a 5-stage rotary switch, the input information here
can be measured in five stages.
Table 2-9 Input image for handwheel data
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
EB n + 14 Handwheel 1 counter status
(16-bit signed, low-order byte equals byte n+14)
EB n + 15
EB n + 16 Handwheel 2 counter status
(16-bit signed, low-order byte equals byte n+16)
EB n + 17
Description
2.3 Interfaces
Machine control panel: MCP 398C
Manual, 12/2017, A5E43199783B AA 19

Within the SINUMERIK control, the handwheel data is processed directly by the NCK and is
not available to the PLC.
Table 2-10 MCP 398C output image
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
AB n + 0 Machine function Mode
1000 INC 100 INC 10 INC 1 INC JOG TEACH IN MDA AUTO
AB n + 1 Feed
start
* Feed
stop
NC
start
* NC
stop
Machine function
REPOS REF. Var. INC 10000 INC
AB n + 2 Arrow
key -
R13
Axis selection Single
block
Spindle
Start
*Spindle
Stop
X
R1
4th axis
R4
7th axis
R7 R10
AB n + 3 Axis selection Arrow
key +
R15
Z
R3
5th axis
R5
Motion
command
in
MCS/WCS
R11
9th axis
R9
8th axis
R8
6th axis
R6
AB n + 4 Unassigned customer keys
T9 T10 T11 T12 T13 T14 T15 Y
R2
AB n + 5 Unassigned customer keys
T1 T2 T3 T4 T5 T6 T7 T8
AB n + 6 - - - - - - RESET R14
AB n + 7 - - KT-OUT6
X54.3
KT-OUT5
X54.2
KT-OUT4
X54.1
KT-OUT3
X53.3
KT-OUT2
X53.2
KT-OUT1
X53.1
Signals marked with * are inverse signals
Default key assignment
,QSXWVLQYHUWHG77 XQODEHOHGNH\VREP REF
TCH INC
VAR
INC
1
MDA INC
10
AUT
RESET
(T1)
-2*INC
100
INC
1000
INC
10000
Einzel-
satz
NC-
STOP
NC-
START
(T2) (T3)
(T4) (T5) (T6)
(T7) (T8) (T9)
(T10) (T11) (T12)
(T13) (T14) (T15)
X
(R1)
Y
(R2)
Z
(R3)
4
(R4)
5
(R5)
6
(R6)
7
(R7)
8
(R8)
9
(R9)
(R10) (R11)
WKS
(R12)
+
(R13)
Eilg.
(R14)
-
(R15)
Sp.-
STOP
Sp.-
START
VS-
STOP
VS-
START
Figure 2-1 MCP 398C default key assignment
Description
2.3 Interfaces
Machine control panel: MCP 398C
20 Manual, 12/2017, A5E43199783B AA
