Siemens SPC5000 Instruction sheet

Building Technologies
Fire Safety & Security Products
Intrusion Control Panel
SPC5000/6000
Installation&Configuration
Manual

Technical Data
16
Siemens Building Technologies
Fire Safety & Security Products 09.2008
3 Technical Data
3.1 SPC5000/6000 Controller
Mains voltage 230 V AC, +10 to -15 %, 50 Hz
Fuse 250 mA T
Power consumption SPC5220/5230: 160 mA at 230 V AC
SPC6320/6330: 200 mA at 230 V AC
Auxiliary power (nominal) 1) Max. 750 mA at 12 V DC
Battery Optional
Battery type Sealed cell valve-regulated
Battery capacity SPC5220/6320: Max. 7 AH / 12 V
SPC5230/6330: Max. 17 AH / 12 V
Battery charger Max. 24h for 80 % of battery capacity
Current consumption 1) SPC5220/5230: Max. 160 mA at 12 V DC
SPC5320/5330: Max. 200 mA at 12 V DC
Number of on-board zones 8
EOL resistor Dual 4K7 (default), other resistor combinations configurable
Number of on-board open
collector outputs.
1 internal bell (max. 400 mA resistive),
1 external bell (max. 400 mA resistive),
3 general outputs (each max. 400 mA resistive, supplied via auxiliary output)
Number of on-board relays 1 strobe, 30 V / 1 A (resistive switching current)
Field bus 2) X-BUS on RS-485 (307 kb/s)
Interfaces
SPC5220/5230 and SPC6320/6330: 2 X-BUS (2 spurs or 1 loop),
2 RS232 (RJ45 ports, for X-10 or external communication)
1 USB (PC for browser programming / terminal program),
1 SPC Fast Programmer,
Additional on the SPC6320/6330: 1 Ethernet (RJ45)
Tamper contact On-board front cabinet spring tamper
+ 2 auxiliary tamper inputs
Operating temperature 5 - 40 °C
Relative humidity Max. 90 % (no condensation)
Housing protection IP30
Colour RAL 9003
Housing protection class Class II Indoor General
Mounting Surface, wall-mounted
Housing material Steel > 1.2 mm
Housing SPC5220/6320: Metal enclosure
SPC5230/6330: Hinged metal enclosure
Housing can contain up to SPC5220/6320: 1 additional Expander (size 150 mm x 82 mm)
SPC5230/6330: 4 additional Expanders (size 150 mm x 82 mm)
Standards
SPC5220/6320: Designed to meet EN50131-1:2006 (Grade 2) TS50131-3:2003
(Grade 2) EN50131-6:2008 (Grade 2)
SPC5230/6330: Designed to meet EN50131-1:2006 (Grade 3), TS50131-3:2003

Technical Data
17
Siemens Building Technologies
Fire Safety & Security Products 09.2008
(Grade 3) EN50131-6:2008 (Grade 3)
1) For EN compliance the supplied current needs to be supported by the battery for required stand by time
2) Max. 400m between devices with cable types IYSTY 2 x 2 x Ø 0,6 mm (min.), UTP cat5 (solid core) or Belden 9829
3.2 Keypad
LC-display 2 x 16 characters
Special function keys Multi dimensional navigation key and 2 soft keys
Status LEDs 3
Card reader SPCK421: 125 kHz, EM 4102 or compatible (e.g. SiPASS)
Card read distance SPCK421: 10 mm
Operating voltage 9.5 – 14 V DC
Current consumption 2) SPCK420: Min: 60 mA at 12 V DC, Max. 70 mA at 12 V DC
SPCK421: Min. 90 mA at 12 V DC, Max. 110 mA at 12 V DC
Field bus 3) X-BUS on RS-485 (307 kb/s)
Tamper contact Front/rear spring tamper
Operating temperature 5 - 40 °C
Relative humidity Max. 90 % (no condensation)
Housing protection IP30
Housing protection class Class II Indoor General
Housing material ABS
Colour RAL 9003
Mounting Surface, wall-mounted, height of 1.30 - 1-50 m
Standards
Designed to meet
EN50131-1:2006 (Grade 3),
TS50131-3:2003 (Grade 3)
1) For EN compliance the supplied current needs to be supported by the battery for required stand by time
2) Max. 400m between devices with cable types IYSTY 2 x 2 x Ø 0,6 mm (min.), UTP cat5 (solid core) or Belden 9829
