Fiber network module FN2006 / FN2007
1 Description
4
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
1Fiber network module FN2006 / FN2007
1.1 Description
The fiber network module multi-mode (MM) and the fiber network module single-mode
(SM) can be used to network fire detection panels to the system bus
FCnet/SAFEDLINK or C-WEB/SAFEDLINK over large distances using glass fiber optic
cable.
The fiber network modules have the following features:
 Fiber network module (SM) FN2006: Single-mode transmission up to 131000 ft
 Fiber network module (MM) FN2007: Multi-mode transmission up to 13100 ft
 Two independent, electrically isolated channels
 SC connections for fiber optic cable
 Ground fault detection
 Trouble signaling via LED and potential-free relay contact
 Installation in panel

Fiber network module FN2006 / FN2007
Installation 1
5
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
1.2 Installation
The fiber network module is installed on the far left of the back box of the enclosure
(2HU), beside the power supply. Installation is identical for the following modules:
 Fiber network module (SM) FN2006
 Fiber network module (MM) FN2007
Each fiber network module is supplied with a set of plugs.
4
1
2
3
Installing the fiber network module FN2006 or FN2007 in the enclosure (2HU)
1 3x fixing screw
2 Fiber network module
3 3x fastening tab on enclosure underside of fiber network module
4 3x threaded sleeve in back box
1. Position the fiber network module (2) on the back box of the enclosure as shown.
2. Screw the fiber network module (2) on the three fastening tabs (3) with three
fastening screws (1) to the threaded sleeves (4) in the back box.
3. Wire up the fiber network module according to the following pin assignment.

Fiber network module FN2006 / FN2007
1 Views
6
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
1.3 Views
Fail1
RX1
LNK1
EF1
LNK2
PowerA
Fail2
RX2
PowerB
Line 1
Line 2
EF2
5
5
4
5
6
123
83
7
Views of the fiber network module from above and the side
1 Fiber optic SC connection for circuit 1
2 Fiber optic SC connection for circuit 2
3 10 LED indicators for data transmission, errors and power supply for both channels
4 Power B socket, redundant power supply and error contact
5 Fastening tab for enclosure installation
6 Power A socket, power supply and error contact
7 Socket A2/B2, FCnet/C-WEB circuit 2
8 Socket A1/B1, FCnet/C-WEB circuit 1

Fiber network module FN2006 / FN2007
Pin assignments 1
7
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
1.4 Pin assignments
1.4.1 Wiring
Power supply wiring
 If the fiber network module is installed in the panel, the supply does not have to be
routed redundantly.
 If the fiber network module is installed in the panel, the relay contacts for supply
supervision do not have to be connected because the panel's power supply is
already supervised.
 'Power A' and 'Power B' inputs can only be supplied by UL 864 approved regulated
power sources.
– Periphery board FCI2016/FCI2017, X1001 DC 24 V AUX
– PAD-3/4
FN2006/FN2007
A1
B1
A2
B2
Line 1
Line 2
Power A
Power B
Circuit 1
+
NC
NO
C
-
+
NC
NO
C
-
+
-
+
-
X1001
24 V
AUX
Fire control panel
Periphery board
FCI2016 / FCI2017
11
1
A1
-
B1
1
Circuit 1
A2
-
B2
1
Wiring of fiber network module, installed in fire control panel

Fiber network module FN2006 / FN2007
1 Pin assignments
8
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
Fiber optic cable wiring
 The accessible laser radiation is safe. It corresponds to laser class 1 in accordance
with IEC 60825/ANSI Z136.
 The fiber optic cable is wired crosswise:
– The optical transmitter (TX) of one device must always be connected with
the optical receiver (RX) of the other device.
– Circuit 1 must always be connected with circuit 2.
 The bending radius of the fiber optic cable must not be less than that specified by
the manufacturer (e.g. 10 x outer diameter).
Class A, style 7 circuit:
FN2006/FN2007 FN2006/FN2007
FN2006/FN2007
Line 1
Line 2
A1
B1
A2
B2
A1
B1
A2
B2
A
1
A
1
A2
B2
A1
B1
A
1
3
3
3
Line 2
Line 1
Line 1
Line 2
Power A
Power B
Power A
Power B
Power A
Power B
A1
B1
A2
B2
A1
B1
A2
B2
A2
B2
A1
B1
FN2006/FN2007
A2
B2
A1
B1
1
3
Line 2
Line 1
Power A
Power B
A2
B2
A1
B1
A
Class A optical network
3
Wiring example of optical network, class A with four fiber network modules

Fiber network module FN2006 / FN2007
Pin assignments 1
9
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
Class B, style 4 circuit:
FN2006/FN2007 FN2006/FN2007
FN2006/FN2007
Line 1
Line 2
A1
B1
A2
B2
A1
B1
A2
B2
A
1
A
1
A2
B2
A1
B1
A
1
3
3
3
Line 2
Line 1
Line 1
Line 2
Power A
Power B
Power A
Power B
Power A
Power B
A1
B1
A2
B2
A1
B1
A2
B2
A2
B2
A1
B1
FN2006/FN2007
A2
B2
A1
B1
1
3
Line 2
Line 1
Power A
Power B
A2
B2
A1
B1
A
Class B optical network
Class B optical network
Wiring example of optical network, class B with four fiber network modules
Designation Description
A Panel with installed fiber network module
1 Network module (SAFEDLINK), main module
3 'Power A', supply input A to fiber network module
A1/B1 Electric FCnet/C-WEB connection for circuit '1'
A2/B2 Electric FCnet/C-WEB connection for circuit '2'
Fiber optic connection (RX), optical receiver
Fiber optic connection (TX), optical transmitter

Fiber network module FN2006 / FN2007
1 Pin assignments
10
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
FCnet/C-WEB wiring
You will find detailed information about FCnetC-WEB wiring and the network module
(SAFEDLINK) FN2001 in the corresponding description.
 Electrical FCnet/C-WEB supply line, shielded or unshielded. If the supply line is
shielded, cable glands must be used for the network module (SAFEDLINK). You
will find information about this in the description of the network module
(SAFEDLINK).
 Ground faults detected at <1 kΩ
 Total length of electrical FCnet/C-WEB wiring: Max. 3300 ft
 Each pair individually supervised

Fiber network module FN2006 / FN2007
Pin assignments 1
11
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
1.4.2 Power supply sockets (4, 6)
The 5-pole connectors for the power supply are supplied with the fiber network module.
Pin Designation Description
1 DC 24 V+ Supply input + of DC 24 V AUX from periphery board
2 DC 24 V- Supply input - of DC 24 V AUX from periphery board
3 COM Common contact
4 NO Normally open
5 NC Normally closed
Admissible cable cross-section: 16...28 AWG
 When installing in the fire control panel, the power supply does not have to be
supervised or routed redundantly.
 The supply line for a remote network module must be shielded.
 In the event of an error, relay contacts COM and NC are connected.
Terminal Plug
without housing
Connector
Cover cap (open)
12345
+-
CNO NC
Terminal Plug
with housing
360º shielding
Connector power A (B)

Fiber network module FN2006 / FN2007
1 Pin assignments
12
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
1.4.3 Sockets for FCnet/C-WEB circuits (7, 8)
The 3-pole connectors for the FCnet/C-WEB connection are supplied with the fiber
network module.
The total cable length of the electrical FCnet/C-WEB connections (copper cable) in
the optical network must not exceed 3300 ft.
Connection bush A1/B1
Pin Designation Description
3 B1 FCnet/C-WEB circuit 1 (-)
2 NC Do not use
1 A1 FCnet/C-WEB circuit 1 (+)
Admissible cable cross-section: 16...28 AWG
Connection bush A2/B2 (7, 8)
Pin Designation Description
3 B2 FCnet/C-WEB circuit 2 (-)
2 NC Do not use
1 A2 FCnet/C-WEB circuit 2 (+)
Admissible cable cross-section: 16...28 AWG

Fiber network module FN2006 / FN2007
Indicators 1
13
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
Terminal Plug
without housing
Connector
Cover cap (open)
123
A1
A2 B1
B2
Terminal Plug
with housing
360º shieldin
g
Connector EF1/EF2, FCnet/C-WEB A1/B1 (A2/B2)
1.5 Indicators
LED Colour Function Condition Meaning
RX1 Green Receipt of data from fiber optic circuit '1' Lit up Data is being received from circuit '1'
Fail1 Yellow Fault on fiber optic circuit '1' Lit up Weakly receiving data from circuit '1'
Fail2 Yellow Fault on fiber optic circuit '2' Lit up Weakly receiving data from circuit '2'.
RX2 Green Receiving data from fiber optic circuit '2' Lit up Data is being received from circuit '2'
On Normal operation (feeding voltage available) Power B Green Supervision of feeding voltage for
'Power B' Off No feeding voltage or voltage below minimum
input voltage (9 V)
On Normal operation (feeding voltage available) Power A Green Supervision of feeding voltage for
'Power A' Off No feeding voltage or voltage below minimum
input voltage (9 V)
LNK1 Green Data transmission for FCnet/C-WEB
circuit '1'
Flashes Data is being transmitted via A1/B1
EF1 Yellow Ground fault supervision on
FCnet/C-WEB circuit '1'
Lit up Ground fault on A1/B1
EF2 Yellow Creation of ground fault on
FCnet/C-WEB circuit '2'
Flashes Ground fault on A1/B1 mirrored on A2/B2
LNK2 Green Data transmission for FCnet/C-WEB
circuit '2'
Flashes Data is being transmitted via A2/B2

Fiber network module FN2006 / FN2007
1 Technical data
14
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
1.6 Technical data
Supply input Input voltage DC 24 V
Decentralized installation Shielded supply cable (not in scope of supply)
Operating current Max. 132 mA @ DC 24 V
Supervision contact Ohmic load:
 Maximum switching voltage DC 30 V
 Maximum switching current DC 1 A
Fibre optic cable Type of connection SC connector
Wavelength 1310 nm (for MM and SM)
Multi-mode
Range:
 Fiber type 62.5/125 µm 13,100 ft
 Fiber type 50/125 µm 6550 ft
Optical budget:
 Fiber type 62.5/125 µm 11 dBm
 Fiber type 50/125 µm 7.5 dBm
Single mode
Range:
 Fiber type 9/125 µm 131,000 ft
Optical budget:
 Fiber type 9/125 µm 29 dBm
 Minimum optical attenuation
(corresponds to a minimum fiber length
of 13100 ft
3 dBm
FCnet/C-WEB Total length of line 3300 ft at 312 kbit/s
Impedance 120 Ω
Transmission mode Half-duplex
Cable type Shielded and unshielded cables

FCC Statement 2
15
Siemens Industry, Inc. A6V10315048_b_en_US
Building Technologies Division 01/13/2012
2FCC Statement
WARNING
Installation and usage of equipment is not in accordance with instructions manual
Radiation of radio frequency energy
Interference to radio communications
● Install and use equipment in accordance with instructions manual.
● Read the following information.
This equipment generates, uses, and can radiate radio frequency energy and if not
installed and used in accordance with the instructions manual, may cause interference
to radio communications.
It has been tested and found to comply with the limits for a Class A computing device
pursuant to Part 15 of FCC Rules, which are designed to provide reasonable protection
against such interference when operated in a commercial environment.
Operation of this equipment in a residential area is likely to cause interference in which
case the user at his own expense will be required to take whatever measures may be
required to correct the interference.

Issued by
Siemens Industry, Inc.
Building Technologies Division
8 Fernwood Road
Florham Park, NJ 07932
Tel. [phone]
www.sbt.siemens.com/FIS
© 2011 Siemens Industry, Inc.
Technical specifications and availability subject to change without notice.
Document ID A6V10315048_b_en_US SAP order no.: A5Q00050754
Edition 01/13/2012
