SINAMICS G120 Input Choke Installation Instructions
Ground
Frame Size A B C
Tightening Torque (Nm) 1.1 1.5 2.25
Tightening Torque (lbf.in) 10 13.3 20
Recommended Minimum
Cable Cross Section (mm
2
) 1 1.5 2.5
Maximum Cable Cross
Section (mm
2
) 2.5 6 10
Recommended Minimum
Cable Cross Section (AWG) 18 AWG 16 AWG 14 AWG
Maximum Cable Cross
Section (AWG) 14 AWG 10 AWG 8 AWG
Wire Size and Terminal Torques - Field Wiring Connectors
1
2
D
E
F
H
G
A B C D E F G H I J
6SE6400-3CC00-2AD3 FSA 200 - 480 1.9 3 200 75.5 49.5 200 75.5 216.4 - 160 56 187 M4 (2) 1.31
6SE6400-3CC00-4AD3 FSA 200 - 480 3.5 3 200 75.5 49.5 200 75.5 216.4 - 160 56 187 M4 (2) 1.35
6SE6400-3CC00-6AD3 FSA 200 - 480 4.8 3 200 75.5 49.5 200 75.5 216.4 - 160 56 187 M4 (2) 1.41
6SL3203-0CD21-0AA0 FSB 200 - 480 9 3 270 153 70 270 153 235.25 133 258 133 258 M4 (4) 3.4
6SL3203-0CD21-4AA0 FSB 200 - 480 12.1 3 270 153 70 270 153 235.25 133 258 133 258 M4 (4) 3.4
6SL3203-0CD22-2AA0 FSC 200 - 480 20.5 3 336 189 50 336 189 235 167 323 167 323 M5 (4) 5.82
6SL3203-0CD23-5AA0 FSC 200 - 480 29.3 3 336 189 50 336 189 235 167 323 167 323 M5 (4) 5.82
Fixing Size
Input Choke Identification
Electrical Characteristics
Overall Dimensions (mm)
Fixing Dimensions (mm)
Weight
(kg) of
Unit
MLFB Frame size Voltage Current Phase
Input choke
Drive Envelope
Drive
Choke
*A5E01209802A*
OPTIONS COMBINATIONS EXAMPLES
53 mm
83.5 mm
280 mm
Fixing Centres: 264 mm
Fixing Centres: 272 mm
Frame Size C Input Choke
Side-mounting Bracket (2 sizes)
Fixing Centres: 220 mm
Frame Size B Input Choke
Side-mounting Dimensions
Mains input
Filter
Filter cable
Mains input
Choke cable
Input
choke
Choke cable
Output choke
Motor cable
Filter cable
Input choke (Reversed)
Input
filter
Mains cable
Output choke cable
Filter cable Motor cable
Output
Choke
Mains input
Input
filter
Mains input
Input choke
cable
Input
choke
Output choke
cable
Motor cable
Output
Choke
Output choke cable
Filter cable Motor cable
Output
Choke
Input
filter
Mains input
Input choke
(reversed)
