Siemens SINAMICS DCM User manual

___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SINAMICS
DCM
SINAMICS DCM Control Module
Operating Instructions
Firmware Version V1.5
12/2018
A5E34888669A
Preface
Safety instructions
1
Ordering information
2
Description
3
Technical data
4
Transport, unpacking,
installation
5
Connecting
6
Additional system
components
7
Commissioning
8
Operation
9
Descriptions of functions
10
Maintenance
11
Applications
12
Functional safety
13
Appendix A
A
Appendix B
B

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E34888669A
Ⓟ
11/2018 Subject to change
Copyright © Siemens AG 2009 - 2018.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SINAMICS DCM Control Module
Operating Instructions, 12/2018, A5E34888669A 3
Preface
Product name
The SINAMICS DCM Control Module documentation also uses the following product names:
●SINAMICS DCM
●SINAMICS DC MASTER
These designations are often (frequently in circuit diagrams and topology arrangements)
used in these instructions as an alternative designation for the combination of SINAMICS
DCM Control Module and external converter power unit.
Device firmware version
As these Operating Instructions went to print, SINAMICS DCM Control Modules were being
supplied from the factory with firmware version specified on the inside front page.
However, these Operating Instructions can, in principle, also apply to other firmware
versions.
●
Older firmware versions:
It is possible that not all of the functions described here are actually available.
●
Newer firmware versions:
It is possible that SINAMICS DCM Control Modules may feature additional functions that
are not described in these Operating Instructions. Do not change any parameters that
you cannot find in the List Manual from their factory setting, and do not give parameters
any values that are not specified in the List Manual.
The firmware version is displayed using r50060[6].
Example:
01010203 displayed on the BOP20 means 01.01.02.03 → Version 1.1, Service Pack 2, Hotfix 3
When required, you can obtain the current firmware from your local Siemens sales office.
Download of the current firmware version for registered users
(https://support.industry.siemens.com/cs/ww/en/view/44029688)

Preface
SINAMICS DCM Control Module
4Operating Instructions, 12/2018, A5E34888669A
Note
Hardware/firmware compatibility
The hardware version of the Control Unit (CUD) must be taken into account when updating
the device firmware, see the following table.
The hardware version can be read from the label on the right
-hand side of the CUD.
CUD (print on label)
Executable firmware versions
C98043-A7100-
L1
-...
C98043-A7100-
L2
-...
C98043-A7100-
L100
-...
C98043-A7100-L200-...
1.1, 1.2, 1.3
C98043-A7100-
L3
-...
C98043-A7100-
L4
-...
C98043-A7100-
L103
-...
C98043-A7100-L204-...
All versions
A5E...
All versions
SINAMICS DCM documentation available
SINAMICS DCM DC Converters Operating Instructions
C
ontains all information on
ordering, installation, connecting, commissioning, maintaining, description of functions,
and service
SINAMICS DCM Control Modules Operating Instructions
C
ontains all information on
ordering, installation, connecting, commissioning, maintaining, description of functions,
and service
SINAMICS DCM List Manual (for DC converters and control modules)
Contains
parameter list, function diagrams, list of faults and alarms
SINAMICS free function blocks, function description
Includes a general description, list of parameters, the function block diagrams as well as
the list of faults and alarms.
Manuals and application notes on the Internet
The manuals and application documents are also available in the Internet:
Manuals (https://support.industry.siemens.com/cs/ww/en/ps/13298/man)
The list of general conditions available there include current supplements to the manuals.
The notes included in the general condition lists have a higher priority than the statements
made in the manuals.

Preface
SINAMICS DCM Control Module
Operating Instructions, 12/2018, A5E34888669A 5
FAQ in the Internet
FAQ (http://support.automation.siemens.com/WW/view/en/38157755/133000)
Service
You can find information on our services and regional contact persons in the Internet
(https://support.industry.siemens.com/sc/ww/en/sc)
Technical Support
Our technical support can provide you with technical assistance for products, systems, and
solutions:
Service (https://support.industry.siemens.com/sc/ww/en/sc)
Central hotlines for SINAMICS DCM technical support
European and African time
zone
Service Request
(https://support.industry.siemens.com/My/ww/en/request
s#createRequest)
America time zone
24-hour hotline: [phone]
Tel.: [phone]
Fax: [phone]
email
(mailto:[e-mail])
8:00 to 17:00
Eastern Standard Time
Asia/Australia time zone Tel.: [phone]
Fax: [phone]
email (mailto:[e-mail])
7:30 to 17:30
Beijing local time
Spare parts
You can find information on spare parts
●In catalog D23.1
●Via the electronic spare parts catalog Spares On Web, after entering the serial number
and article number of your SINAMICS DCM in the Internet (registration required).
Spares on Web (https://www.sow.siemens.com/)
Websites of third parties
This publication contains hyperlinks to websites of third parties. Siemens does not take any
responsibility for the contents of these websites or adopt any of these websites or their
contents as their own, because Siemens does not control the information on these websites
and is also not responsible for the contents and information provided there. Use of these
websites is at the risk of the person doing so.

Preface
SINAMICS DCM Control Module
6Operating Instructions, 12/2018, A5E34888669A
Use of OpenSSL
This product contains software that has been developed by the OpenSSL project for use in
the OpenSSL toolkit.
This product contains cryptographic software created by Eric Young.
This product contains software developed by Eric Young.
Compliance with the General Data Protection Regulation
Siemens respects the principles of data protection, in particular the data minimization rules
(privacy by design).
For this product, this means:
The product does not process neither store any person-related data, only technical function
data (e.g. time stamps). If the user links these data with other data (e.g. shift plans) or if he
stores person-related data on the same data medium (e.g. hard disk), thus personalizing
these data, he has to ensure compliance with the applicable data protection stipulations.
Further Internet links
Generic station description file (GSD) for
PROFIBUS (https://support.industry.siemens.com/cs/ww/en/view/98206128)
PROFINET (https://support.industry.siemens.com/cs/ww/en/view/98207877)

SINAMICS DCM Control Module
Operating Instructions, 12/2018, A5E34888669A 7
Table of contents
Preface ................................................................................................................................................... 3
1 Safety instructions................................................................................................................................. 17
1.1 General safety instructions .....................................................................................................17
1.2 ESD-sensitive components.....................................................................................................22
1.3 Industrial security ....................................................................................................................23
1.4 Residual risks of power drive systems....................................................................................24
2 Ordering information ............................................................................................................................. 25
2.1 Device article numbers ...........................................................................................................25
2.2 Rating plates, packaging label................................................................................................25
2.3 Ordering information for options and accessories ..................................................................26
3 Description............................................................................................................................................ 33
4 Technical data ...................................................................................................................................... 37
4.1 Environmental conditions........................................................................................................37
4.2 Unit data..................................................................................................................................38
5 Transport, unpacking, installation .......................................................................................................... 39
5.1 Transportation, unpacking ......................................................................................................39
5.2 Installation...............................................................................................................................39
5.2.1 Dimension drawings................................................................................................................40
5.2.2 Dividing the unit ......................................................................................................................43
5.2.3 Removal/Installation and division of modules.........................................................................45
5.2.3.1 Removing modules .................................................................................................................45
5.2.3.2 Firing pulse transformer module .............................................................................................47
5.2.3.3 Fuse monitoring and voltage measurement ...........................................................................50
5.2.4 Installing options and accessories ..........................................................................................52
5.2.4.1 AOP30 operator panel ............................................................................................................52
5.2.4.2 Fuse monitoring distributor .....................................................................................................52
5.2.4.3 Installing a second CUD .........................................................................................................52
6 Connecting ........................................................................................................................................... 55
6.1 Instructions for EMC-compliant drive installation....................................................................56
6.1.1 Basic information about EMC .................................................................................................56
6.1.2 EMC-compliant drive installation (installation instructions).....................................................59
6.1.3 Arranging components for converter units..............................................................................64
6.1.4 RFI suppression filter ..............................................................................................................65
6.1.5 Information on line-side harmonics produced by converter units in a fully-controlled
two-pulse bridge circuit configuration (B6C and (B6)A(B6)C) ................................................66
6.1.6 Data on the line-side harmonics from converter units in a fully-controlled AC bridge
circuit B2C...............................................................................................................................68

Table of contents
SINAMICS DCM Control Module
8Operating Instructions, 12/2018, A5E34888669A
6.2 Cable routing in the unit ......................................................................................................... 69
6.3 Block diagram with connection suggestion............................................................................ 73
6.4 Connecting the external power unit ....................................................................................... 76
6.5 Division options ...................................................................................................................... 83
6.6 Measurement of the armature current ................................................................................... 97
6.6.1 General information ............................................................................................................... 97
6.6.2 Current measurement with two current transformers on the line side ................................... 99
6.6.3 Current measurement via terminal block XB-1 to XB-4 with external measuring circuit ..... 101
6.6.3.1 External current transformers in V-circuit with +1 V at rated armature DC current ............. 101
6.6.3.2 External current transformers in V-circuit with +10 V at rated armature DC current ........... 102
6.6.3.3 Differential input for +/-10 V at rated armature DC current.................................................. 103
6.6.3.4 Input for +/-1 V at rated armature DC current ...................................................................... 104
6.6.4 External current measurement via X21A or X_I_IST ........................................................... 105
6.6.5 Offset correction via XN1 ..................................................................................................... 105
6.6.6 Information on the differential input, control limits, and grounding ...................................... 106
6.7 Connecting the firing pulse transformers ............................................................................. 107
6.7.1 General information ............................................................................................................. 107
6.7.2 Normal use (individual) ........................................................................................................ 107
6.7.3 Parallel connection of firing pulses ...................................................................................... 108
6.7.4 External amplification of firing pulses .................................................................................. 108
6.8 Connecting voltage measurement equipment ..................................................................... 109
6.9 Connecting fuse monitoring equipment ............................................................................... 110
6.10 Parallel connection of power units ....................................................................................... 111
6.11 Field supply .......................................................................................................................... 112
6.12 Line reactors ........................................................................................................................ 112
6.13 Fuses ................................................................................................................................... 116
6.14 Arrangement of printed circuit boards.................................................................................. 117
6.15 Arrangement of customer connections (connector terminals, Faston mounting tabs) ........ 118
6.16 Connector assignment (terminals, Faston mounting tabs, ribbon cables) .......................... 126
6.16.1 Connecting the protective conductor ................................................................................... 127
6.16.2 Field circuit ........................................................................................................................... 128
6.16.3 Electronic power supply ....................................................................................................... 128
6.16.4 Open-loop and closed-loop control section ......................................................................... 129
6.16.5 Voltage measurement equipment ........................................................................................ 142
6.16.6 Fuse monitoring equipment ................................................................................................. 143
6.16.7 Firing pulse transformers ..................................................................................................... 144
6.16.8 Firing pulse........................................................................................................................... 148
6.16.9 Ribbon cables ...................................................................................................................... 150
6.16.10 Assignment of the RS485 cable to the AOP30.................................................................... 155
6.16.11 Terminal assignment functional safety ................................................................................ 156

Table of contents
SINAMICS DCM Control Module
Operating Instructions, 12/2018, A5E34888669A 9
7 Additional system components............................................................................................................ 157
7.1 Option Board: CBE20 Communication Board Ethernet........................................................158
7.1.1 Description ............................................................................................................................158
7.1.2 Safety instructions.................................................................................................................158
7.1.3 Interface description..............................................................................................................159
7.1.3.1 Overview ...............................................................................................................................159
7.1.3.2 X1400 Ethernet interface ......................................................................................................160
7.1.4 Meaning of the LEDs ............................................................................................................161
7.1.5 Installation.............................................................................................................................163
7.1.6 Technical data.......................................................................................................................163
7.2 SMC10 Sensor Module Cabinet-Mounted............................................................................164
7.2.1 Description ............................................................................................................................164
7.2.2 Interface description..............................................................................................................164
7.2.2.1 Overview ...............................................................................................................................164
7.2.2.2 X500 DRIVE-CLiQ interface .................................................................................................165
7.2.2.3 X524 Electronics power supply.............................................................................................165
7.2.2.4 X520 encoder system interface ............................................................................................166
7.2.3 Connection example .............................................................................................................167
7.2.4 Meaning of the LED ..............................................................................................................167
7.2.4.1 Meaning of the LED on the Sensor Module Cabinet-Mounted SMC10................................167
7.2.4.2 Cause and rectification of faults............................................................................................168
7.2.5 Dimension drawing ...............................................................................................................168
7.2.6 Mounting ...............................................................................................................................169
7.2.7 Technical data.......................................................................................................................170
7.3 Sensor Module Cabinet-Mounted SMC30 ............................................................................172
7.3.1 Description ............................................................................................................................172
7.3.2 Safety instructions.................................................................................................................173
7.3.3 Interface description..............................................................................................................175
7.3.3.1 Overview ...............................................................................................................................175
7.3.3.2 X500 DRIVE-CLiQ interface .................................................................................................176
7.3.3.3 X524 electronic power supply...............................................................................................176
7.3.3.4 X520 encoder system interface ............................................................................................177
7.3.3.5 X521/X531 alternative encoder system interface .................................................................178
7.3.4 Connection examples ...........................................................................................................180
7.3.5 Meaning of the LEDs ............................................................................................................182
7.3.6 Dimension drawing ...............................................................................................................183
7.3.7 Mounting ...............................................................................................................................183
7.3.8 Protective conductor connection and shield support ............................................................185
7.3.9 Technical data.......................................................................................................................186
7.4 Terminal Module TM15 .........................................................................................................190
7.4.1 Description ............................................................................................................................190
7.4.2 Safety instructions.................................................................................................................190
7.4.3 Interface description..............................................................................................................191
7.4.3.1 Overview ...............................................................................................................................191
7.4.3.2 X500 and X501 DRIVE-CLiQ interface.................................................................................192
7.4.3.3 X524 electronic power supply...............................................................................................193
7.4.3.4 X520 bidirectional digital inputs/outputs ...............................................................................193
7.4.3.5 X521 bidirectional digital inputs/outputs ...............................................................................194
7.4.3.6 X522 bidirectional digital inputs/outputs ...............................................................................194
7.4.4 Connection example .............................................................................................................195

Table of contents
SINAMICS DCM Control Module
10 Operating Instructions, 12/2018, A5E34888669A
7.4.5 Meaning of the LEDs on the Terminal Module TM15 .......................................................... 196
7.4.6 Dimension drawing .............................................................................................................. 197
7.4.7 Installation ............................................................................................................................ 197
7.4.8 Protective conductor connection and shield support ........................................................... 199
7.4.9 Connector coding................................................................................................................. 200
7.4.10 Technical data...................................................................................................................... 201
7.5 Terminal Module TM31 ........................................................................................................ 203
7.5.1 Description ........................................................................................................................... 203
7.5.2 Safety instructions................................................................................................................ 204
7.5.3 Interface description............................................................................................................. 205
7.5.3.1 Overview .............................................................................................................................. 205
7.5.3.2 X500/X501 DRIVE-CLiQ interfaces ..................................................................................... 206
7.5.3.3 X524 electronic power supply .............................................................................................. 207
7.5.3.4 X520, X530 digital inputs ..................................................................................................... 208
7.5.3.5 X521 analog inputs .............................................................................................................. 209
7.5.3.6 Analog inputs current/voltage switch ................................................................................... 210
7.5.3.7 X522 analog outputs/temperature sensor............................................................................ 210
7.5.3.8 X540 auxiliary voltage for the digital inputs ......................................................................... 211
7.5.3.9 X541 bidirectional digital inputs/outputs .............................................................................. 212
7.5.3.10 X542 relay outputs ............................................................................................................... 213
7.5.4 Connection example ............................................................................................................ 214
7.5.5 Meanings of the LEDs on the Terminal Module TM31 ........................................................ 215
7.5.6 Dimension drawing .............................................................................................................. 216
7.5.7 Installation ............................................................................................................................ 217
7.5.8 Protective conductor connection and shield support ........................................................... 218
7.5.9 Connector coding................................................................................................................. 219
7.5.10 Technical data...................................................................................................................... 220
7.6 Terminal Module TM150 ...................................................................................................... 221
7.6.1 Description ........................................................................................................................... 221
7.6.2 Safety instructions................................................................................................................ 222
7.6.3 Interface description............................................................................................................. 223
7.6.3.1 Overview .............................................................................................................................. 223
7.6.3.2 X500 and X501 DRIVE-CLiQ interfaces .............................................................................. 224
7.6.3.3 X524 Electronics power supply............................................................................................ 225
7.6.3.4 X531-X536 temperature sensor inputs ................................................................................ 225
7.6.4 Connection examples .......................................................................................................... 227
7.6.5 Meaning of the LEDs on the Terminal Module TM150 ........................................................ 229
7.6.6 Dimension drawing .............................................................................................................. 230
7.6.7 Installation ............................................................................................................................ 231
7.6.8 Protective conductor connection and shield support ........................................................... 232
7.6.9 Technical data...................................................................................................................... 233
8 Commissioning ....................................................................................................................................235
8.1 Commissioning checklist...................................................................................................... 236
8.2 Switching on......................................................................................................................... 238
8.3 Commissioning using the BOP20 Operator Panel............................................................... 239
8.3.1 Preconditions ....................................................................................................................... 239
8.3.2 Commissioning steps........................................................................................................... 240
8.4 Commissioning using the AOP30 Operator Panel............................................................... 247
8.4.1 First commissioning ............................................................................................................. 247

Table of contents
SINAMICS DCM Control Module
Operating Instructions, 12/2018, A5E34888669A 11
8.4.1.1 First power-up .......................................................................................................................247
8.4.1.2 Full drive commissioning.......................................................................................................249
8.4.2 Status after commissioning...................................................................................................252
8.4.3 Resetting parameters to factory settings ..............................................................................253
8.5 Commissioning with the STARTER commissioning tool ......................................................253
8.5.1 STARTER commissioning tool .............................................................................................253
8.5.1.1 Installing the STARTER commissioning tool ........................................................................254
8.5.1.2 Layout of the STARTER user interface ................................................................................254
8.5.2 Procedure for commissioning with STARTER......................................................................255
8.5.2.1 Creating the project...............................................................................................................255
8.5.2.2 Configuring a drive unit.........................................................................................................264
8.5.2.3 Starting the drive project .......................................................................................................284
8.6 Activating function modules ..................................................................................................288
8.6.1 Activating offline with STARTER ..........................................................................................288
8.6.2 Activating online through parameters ...................................................................................290
8.7 Commissioning optional additional modules ........................................................................291
8.7.1 Terminal Modules (TM31, TM15, TM150) ............................................................................292
8.7.1.1 Commissioning with STARTER ............................................................................................292
8.7.1.2 Commissioning via parameter assignment...........................................................................295
8.7.2 Encoder evaluation (SMC10, SMC30)..................................................................................295
8.7.2.1 Add/commissioning (with STARTER) ...................................................................................296
8.7.2.2 Removal (with STARTER) ....................................................................................................300
8.7.3 CBE20 Communication Board Ethernet ...............................................................................300
8.7.3.1 Adding online into the drive ..................................................................................................300
8.7.3.2 Adding offline in STARTER ..................................................................................................301
8.7.3.3 Deleting from the drive online ...............................................................................................302
8.7.3.4 Deleting offline with STARTER.............................................................................................302
8.8 Drive optimization .................................................................................................................303
8.9 Manual optimization ..............................................................................................................311
8.9.1 Optimization of closed-loop armature current control...........................................................311
8.9.2 Optimization of closed-loop field-current control ..................................................................313
8.9.3 Optimizing the speed controller ............................................................................................314
9 Operation............................................................................................................................................ 317
9.1 Basic information ..................................................................................................................317
9.1.1 Parameter .............................................................................................................................317
9.1.2 Data sets...............................................................................................................................321
9.1.2.1 Function diagrams and parameters ......................................................................................323
9.1.2.2 Using data sets .....................................................................................................................324
9.1.3 Drive objects .........................................................................................................................325
9.1.4 Memory card functions..........................................................................................................327
9.1.5 BICO technology: Interconnecting signals............................................................................332
9.1.5.1 Binectors, connectors ...........................................................................................................333
9.1.5.2 Interconnecting signals using BICO technology ...................................................................334
9.1.5.3 Internal encoding of the binector/connector output parameters ...........................................335
9.1.5.4 Example: Interconnecting digital signals...............................................................................335
9.1.5.5 Information on BICO technology...........................................................................................336
9.2 Parameterizing using the BOP20 (Basic Operator Panel 20)...............................................336
9.2.1 General information about the BOP20..................................................................................336

Table of contents
SINAMICS DCM Control Module
12 Operating Instructions, 12/2018, A5E34888669A
9.2.2 Displays and using the BOP20 ............................................................................................ 341
9.2.3 Displaying faults and alarms ................................................................................................ 346
9.2.4 Controlling the drive using the BOP20................................................................................. 347
9.3 Controlling via the AOP30 operator panel ........................................................................... 348
9.3.1 Overview and menu structure .............................................................................................. 349
9.3.2 Menu: Operation screen ...................................................................................................... 351
9.3.3 Parameterization menu........................................................................................................ 352
9.3.4 Menu: Fault/alarm memory .................................................................................................. 353
9.3.5 Menu: Commissioning/Service ............................................................................................ 354
9.3.5.1 Drive commissioning............................................................................................................ 354
9.3.5.2 Device commissioning ......................................................................................................... 355
9.3.5.3 AOP settings ........................................................................................................................ 355
9.3.5.4 Lists of signals for the operation screen .............................................................................. 357
9.3.5.5 AOP30 diagnostics .............................................................................................................. 360
9.3.6 Sprachauswahl/Language selection .................................................................................... 361
9.3.7 Operation via the operator panel (LOCAL mode) ................................................................ 361
9.3.7.1 LOCAL/REMOTE key .......................................................................................................... 361
9.3.7.2 ON key/OFF key .................................................................................................................. 362
9.3.7.3 CCW/CW changeover.......................................................................................................... 363
9.3.7.4 Jogging................................................................................................................................. 363
9.3.7.5 Increase setpoint/Decrease setpoint ................................................................................... 363
9.3.7.6 AOP setpoint ........................................................................................................................ 364
9.3.7.7 Inhibiting AOP LOCAL mode ............................................................................................... 364
9.3.7.8 Acknowledging errors via the AOP ...................................................................................... 365
9.3.7.9 Timeout monitoring .............................................................................................................. 365
9.3.7.10 Operator inhibit lock/Parameters disable............................................................................. 365
9.3.8 Faults and alarms................................................................................................................. 367
9.3.9 Saving the parameters permanently .................................................................................... 369
9.3.10 Parameterization errors ....................................................................................................... 369
9.3.11 Assigning parameters to make AOP30 time-of-day master ................................................ 370
10 Descriptions of functions ......................................................................................................................371
10.1 Inputs/Outputs...................................................................................................................... 371
10.1.1 Overview of inputs/outputs................................................................................................... 371
10.1.2 Digital inputs/outputs............................................................................................................ 371
10.1.3 Analog inputs ....................................................................................................................... 372
10.1.4 Analog outputs ..................................................................................................................... 373
10.2 Communication, IT security ................................................................................................. 373
10.3 Communication according to PROFIdrive ........................................................................... 373
10.3.1 Application classes .............................................................................................................. 376
10.3.2 Cyclic communication .......................................................................................................... 378
10.3.2.1 Telegrams and process data ............................................................................................... 378
10.3.2.2 Description of control words and setpoints .......................................................................... 381
10.3.2.3 Description of status words and actual values..................................................................... 387
10.3.2.4 Control and status words for encoders ................................................................................ 392
10.3.2.5 Extended encoder evaluation .............................................................................................. 401
10.3.2.6 Central control and status words ......................................................................................... 401
10.3.2.7 Diagnostics channel for cyclic communication .................................................................... 404
10.3.3 Parallel operation of communication interfaces ................................................................... 406
10.3.4 Acyclic communication......................................................................................................... 409
10.3.4.1 General information about acyclic communication .............................................................. 409

Table of contents
SINAMICS DCM Control Module
Operating Instructions, 12/2018, A5E34888669A 13
10.3.4.2 Structure of orders and responses .......................................................................................411
10.3.4.3 Determining the drive object numbers ..................................................................................417
10.3.4.4 Example 1: Read parameters ...............................................................................................417
10.3.4.5 Example 2: Write parameters (multi-parameter request) .....................................................420
10.4 Communication via PROFIBUS DP......................................................................................423
10.4.1 PROFIBUS connection .........................................................................................................423
10.4.2 General information about PROFIBUS.................................................................................425
10.4.2.1 General information about PROFIBUS for SINAMICS .........................................................425
10.4.2.2 Example of a telegram structure for cyclic data acquisition..................................................427
10.4.3 Commissioning PROFIBUS..................................................................................................429
10.4.3.1 Setting the PROFIBUS interface ..........................................................................................429
10.4.3.2 PROFIBUS interface during operation..................................................................................430
10.4.3.3 Commissioning PROFIBUS..................................................................................................431
10.4.3.4 Diagnostics options...............................................................................................................432
10.4.3.5 SIMATIC HMI addressing .....................................................................................................432
10.4.3.6 Monitoring, telegram failure ..................................................................................................434
10.4.4 Direct data exchange ............................................................................................................436
10.4.4.1 Setpoint assignment in the subscriber..................................................................................438
10.4.4.2 Activating/parameterizing slave-to-slave communication.....................................................438
10.4.4.3 Commissioning of the PROFIBUS slave-to-slave communication .......................................440
10.4.4.4 GSD during operation ...........................................................................................................449
10.4.4.5 Diagnostics of the PROFIBUS slave-to-slave communication in STARTER .......................450
10.4.5 Messages via diagnostics channels .....................................................................................450
10.5 Communication via PROFINET IO .......................................................................................453
10.5.1 Activating online mode: STARTER via PROFINET IO .........................................................453
10.5.2 General information about PROFINET IO ............................................................................459
10.5.2.1 Real-time (RT) and isochronous real-time (IRT) communication .........................................460
10.5.2.2 Addresses .............................................................................................................................461
10.5.2.3 Data transmission .................................................................................................................462
10.5.2.4 Communication channels for PROFINET .............................................................................464
10.5.3 Drive control with PROFINET ...............................................................................................464
10.5.3.1 Media redundancy ................................................................................................................467
10.5.4 RT classes for PROFINET IO...............................................................................................467
10.5.5 PROFINET GSDML ..............................................................................................................473
10.5.6 Communication with CBE20 .................................................................................................473
10.5.7 Messages via diagnostics channels .....................................................................................474
10.5.8 Support of I&M data sets 1...4 ..............................................................................................478
10.6 Communication via SINAMICS Link .....................................................................................480
10.6.1 Basic principles of SINAMICS Link.......................................................................................480
10.6.2 Topology ...............................................................................................................................482
10.6.3 Configuring and commissioning............................................................................................483
10.6.4 Example ................................................................................................................................488
10.6.5 Communication failure when booting or in cyclic operation..................................................490
10.6.6 Examples: Transmission times for SINAMICS Link..............................................................491
10.6.7 Function diagrams and parameters ......................................................................................492
10.7 EtherNet/IP ...........................................................................................................................493
10.7.1 Connection of SINAMICS DCM with EtherNet/IP to Ethernet networks...............................493
10.7.2 Configuration of SINAMICS DCM for EtherNet/IP................................................................494
10.7.2.1 Setting the IP address and activating the EtherNet/IP protocol ...........................................494
10.7.2.2 Communication with the SINAMICS DCM............................................................................495

Table of contents
SINAMICS DCM Control Module
14 Operating Instructions, 12/2018, A5E34888669A
10.7.3 Examples of the use of a Rockwell PLC.............................................................................. 501
10.7.3.1 Configuration of a Rockwell PLC for the communication with SINAMICS DCM ................. 501
10.7.3.2 Writing and reading parameters with Class 4xx .................................................................. 504
10.8 Communication via MODBUS TCP ..................................................................................... 506
10.8.1 Overview .............................................................................................................................. 506
10.8.2 Configuring Modbus TCP via interface X1400..................................................................... 507
10.8.3 Mapping tables..................................................................................................................... 508
10.8.4 Read and write access using function codes....................................................................... 511
10.8.5 Communication via data set 47............................................................................................ 513
10.8.5.1 Communication details......................................................................................................... 514
10.8.5.2 Examples: Read parameter ................................................................................................. 515
10.8.5.3 Examples: Write parameter ................................................................................................. 516
10.8.6 Communication sequence ................................................................................................... 517
10.8.7 Messages and parameters .................................................................................................. 518
10.9 Serial interface with USS protocol ....................................................................................... 519
10.10 Switch on, switch off, enable................................................................................................ 520
10.10.1 Switch on/Switch off (ON/OFF1) – Control word bit 0.......................................................... 520
10.10.2 OFF2 (disconnection) – Control word bit 1 .......................................................................... 523
10.10.3 OFF3 (quick stop) – Control word bit 2 ................................................................................ 523
10.10.4 Operation enable (enable) - control word bit 3 .................................................................... 525
10.11 Safety shutdown (E-STOP).................................................................................................. 525
10.12 Setpoint channel .................................................................................................................. 526
10.12.1 Ramp-function generator ..................................................................................................... 526
10.12.2 Jog ....................................................................................................................................... 531
10.12.3 Creep ................................................................................................................................... 532
10.12.4 Fixed setpoint....................................................................................................................... 533
10.13 Encoder evaluation .............................................................................................................. 534
10.13.1 Actual speed values............................................................................................................. 535
10.13.2 Control and status words for encoders ................................................................................ 536
10.13.2.1 Control and status words for encoders ................................................................................ 536
10.14 Speed controller................................................................................................................... 536
10.15 Adaptation of the armature and field current controller ....................................................... 540
10.16 Technology controller........................................................................................................... 543
10.17 Switch-on command for holding or operational brake ......................................................... 546
10.18 Switching on auxiliary circuits .............................................................................................. 549
10.19 Operating hours counter, unit fan ........................................................................................ 549
10.20 Thermal overload protection for the DC motor (I2t monitoring of the motor)....................... 550
10.21 Measuring the motor temperature........................................................................................ 555
10.22 Speed-dependent current limitation ..................................................................................... 556
10.23 Thyristor blocking voltage calculation .................................................................................. 559
10.24 Automatic restart.................................................................................................................. 560
10.25 Operation on a single-phase line supply.............................................................................. 560

Table of contents
SINAMICS DCM Control Module
Operating Instructions, 12/2018, A5E34888669A 15
10.26 Connecting units in parallel and in series .............................................................................562
10.26.1 6-pulse parallel connection ...................................................................................................565
10.26.2 12-pulse parallel connection .................................................................................................571
10.26.3 6-pulse series connection .....................................................................................................573
10.26.4 6-pulse series connection: controlled converter + uncontrolled converter ...........................576
10.26.5 12-pulse series connection ...................................................................................................578
10.26.6 12-pulse series connection: controlled converter + uncontrolled converter .........................580
10.26.7 Switchover of the power unit topology – Option S50 ............................................................581
10.27 Field reversal ........................................................................................................................582
10.27.1 Direction of rotation reversal using field reversal..................................................................582
10.27.2 Braking using field reversal...................................................................................................584
10.28 Serial interface with peer-to-peer protocol............................................................................586
10.28.1 Examples of peer-to-peer connections .................................................................................588
10.29 Expanding the SINAMICS DCM to include a second CUD ..................................................590
10.30 Terminal Module Cabinet TMC (option G63)........................................................................593
10.31 Runtime (operating hours counter) .......................................................................................593
10.32 Diagnostics ...........................................................................................................................594
10.32.1 Diagnostic memory ...............................................................................................................594
10.32.2 Trend recorder function.........................................................................................................595
10.32.3 Thyristor diagnostics .............................................................................................................595
10.32.4 Description of the LEDs on the CUD ....................................................................................597
10.32.5 Diagnostics via STARTER....................................................................................................600
10.32.5.1 Function generator................................................................................................................601
10.32.5.2 Trace function .......................................................................................................................604
10.32.6 Faults and alarms .................................................................................................................610
10.32.6.1 General information ..............................................................................................................610
10.32.6.2 Buffer for faults and alarms...................................................................................................613
10.32.6.3 Configuring messages ..........................................................................................................616
10.32.6.4 Parameters and function diagrams for faults and alarms .....................................................618
10.32.6.5 Forwarding faults and alarms ...............................................................................................619
10.32.7 Simulation mode ...................................................................................................................619
10.33 CPU time load with SINAMICS DCM....................................................................................621
10.33.1 Maximum configuration.........................................................................................................623
10.33.2 Computation examples .........................................................................................................623
10.34 Free function blocks..............................................................................................................625
10.35 Drive Control Chart (DCC)....................................................................................................627
10.35.1 Loading the DCC technology option into the drive unit memory ..........................................628
10.35.2 CPU time load through DCC.................................................................................................630
10.35.3 Memory load through DCC ...................................................................................................631
10.35.4 Backing up the DCC diagrams .............................................................................................632
10.36 Write and know-how protection ............................................................................................633
10.36.1 Write protection.....................................................................................................................633
10.36.2 Know-how protection ............................................................................................................635
10.36.2.1 Copy protection.....................................................................................................................638
10.36.2.2 Configuring know-how protection .........................................................................................638
10.36.2.3 Loading know-how protected data to the file system............................................................642
10.36.3 Overview of important parameters........................................................................................647

Table of contents
SINAMICS DCM Control Module
16 Operating Instructions, 12/2018, A5E34888669A
11 Maintenance ........................................................................................................................................649
11.1 Upgrading the device firmware ............................................................................................ 650
11.1.1 Upgrading the device firmware ............................................................................................ 651
11.1.2 Upgrading the DCC technology option ................................................................................ 654
11.2 Replacing the CUD .............................................................................................................. 656
11.3 Replacing the back-up battery in the AOP30 operator panel .............................................. 659
12 Applications .........................................................................................................................................661
12.1 Using SINAMICS DCM in shipbuilding ................................................................................ 661
12.2 Connecting an incremental encoder .................................................................................... 661
12.3 Use of the SINAMICS DCM in galvanizing and dip-painting plants..................................... 662
12.4 Using SINAMICS DCM as thyristor controller in heating applications................................. 664
13 Functional safety..................................................................................................................................665
13.1 Functional safety: Deactivated – Activated .......................................................................... 665
13.2 General technical specifications of the DCM (6RA80)......................................................... 665
13.3 Standards............................................................................................................................. 666
13.4 Fundamental safety technology principles........................................................................... 667
13.4.1 Standard stop functions ....................................................................................................... 667
13.4.1.1 Emergency Off and Emergency Stop .................................................................................. 667
13.4.2 Standard safety functions according to EN 61800-5-2 ........................................................ 668
13.4.2.1 Safe Torque Off (STO)......................................................................................................... 668
13.4.2.2 Safe Stop 1 (SS1-t, time controlled) .................................................................................... 668
13.4.3 Safety functions of the SINAMICS DC MASTER................................................................. 669
13.5 Application examples ........................................................................................................... 670
13.6 Validating/checking the safety functions.............................................................................. 678
13.7 Diagnostics test.................................................................................................................... 678
13.8 Relationship between the test stop interval and SIL or PL and Cat. ................................... 678
13.9 Circuit breakers and power contactors ................................................................................ 679
13.10 Recommended safety relays ............................................................................................... 684
A Appendix A ..........................................................................................................................................685
A.1 Certifications and standards ................................................................................................ 685
A.2 List of abbreviations ............................................................................................................. 688
A.3 Environmental compatibility ................................................................................................. 696
A.4 Servicing .............................................................................................................................. 697
B Appendix B ..........................................................................................................................................699
B.1 Runtimes of the DCC blocks for SINAMICS DCM............................................................... 699
B.2 BOP20 status display during power-up ............................................................................... 704
Index ...................................................................................................................................................705

SINAMICS DCM Control Module
Operating Instructions, 12/2018, A5E34888669A 17
Safety instructions
1
1.1
General safety instructions
WARNING
Electric shock and danger to life due to other energy sources
Touching live components can result in death or serious injury.
•Only work on electrical equipment if you are appropriately qualified.
•Always observe the country-specific safety rules for all work.
Generally, the following six steps apply when establishing safety:
1. Prepare for disconnection. Notify all those who will be affected by the procedure.
2. Isolate the drive system from the power supply and take measures to prevent it being
switched back on again.
3. Wait until the discharge time specified on the warning labels has elapsed.
4. Check that there is no voltage between any of the power connections, and between any
of the power connections and the protective conductor connection.
5. Check whether the existing auxiliary supply circuits are de-energized.
6. Ensure that the motors cannot move.
7. Identify all other dangerous energy sources, e.g. compressed air, hydraulic systems,
or water. Switch the energy sources to a safe state.
8. Check that the correct drive system is completely locked.
After you have completed the work, restore the operational readiness by following the
above steps in the reverse order.
WARNING
Electric shock due to connection to an unsuitable power supply
When equipment is connected to an unsuitable power supply, exposed components may
carry a hazardous voltage that might result in serious injury or death.
•Only use power supplies that provide SELV (Safety Extra Low Voltage) or PELV
(Protective Extra Low Voltage) output voltages for all connections and terminals of the
electronics modules.

Safety instructions
1.1 General safety instructions
SINAMICS DCM Control Module
18 Operating Instructions, 12/2018, A5E34888669A
WARNING
Electric shock due to equipment damage
Improper handling may cause damage to equipment. For damaged devices, hazardous
voltages can be present at the enclosure or at exposed components; if touched, this can
result in death or severe injury.
•Ensure compliance with the limit values specified in the technical data during transport,
storage and operation.
•Do not use any damaged devices.
WARNING
Electric shock due to unconnected cable shield
Hazardous touch voltages can occur through capacitive cross-coupling due to unconnected
cable shields.
•Connect cable shields and unused conductors of power cables (e.g. brake conductors)
at least on one side to the grounded housing potential.
WARNING
Electric shock if there is no ground connection
For missing or incorrectly implemented protective conductor connection for devices with
protection class I, high voltages can be present at open, exposed parts, which when
touched, can result in death or severe injury.
•Ground the device in compliance with the applicable regulations.
WARNING
Arcing when a plug connection is opened during operation
Opening a plug connection when a system is in operation can result in arcing that may
cause serious injury or death.
•Only open plug connections when the equipment is in a voltage-free state, unless it has
been explicitly stated that they can be opened in operation.
WARNING
Electric shock due to residual charges in power components
Because of the capacitors, a hazardous voltage is present for up to 5 minutes after the
power supply has been switched off. Contact with live parts can result in death or serious
injury.
•Wait for 5 minutes before you check that the unit really is in a no-voltage condition and
start work.
