Siemens Reyrolle 7SR45 User manual

Reyrolle
Engineering Guide
7SR45
V03.00
Manual
C53000-G7040-C102-1
Preface
Open Source Software
Table of Contents
Reydisp Evolution Overview 1
Essential Steps during Engineering 2
Configuration Software 3
Appendix A
Index

i
i
NOTE
For your own safety, observe the warnings and safety instructions contained in this document, if available.
Disclaimer of Liability
Subject to changes and errors. The information given in
this document only contains general descriptions and/or
performance features which may not always specifically
reflect those described, or which may undergo modifica-
tion in the course of further development of the products.
The requested performance features are binding only when
they are expressly agreed upon in the concluded contract.
Document version: C53000-G7040-C102-1.0
Edition: 08.2020
Version of the product described: V03.00
Copyright
Copyright © Siemens 2020. All rights reserved.
The disclosure, duplication, distribution and editing of this
document, or utilization and communication of the content
are not permitted, unless authorized in writing. All rights,
including rights created by patent grant or registration of a
utility model or a design, are reserved.

Preface
Purpose of the Manual
This manual provides comprehensive information on Reydisp Evolution, getting started with Reydisp Evolution
and essential steps during engineering with Reydisp Evolution.
Target Audience
This manual is mainly intended for protection system engineers, commissioning engineers, persons entrusted
with the setting, testing and maintenance of automation, selective protection and control equipment, and
operational crew in electrical installations and power plants.
Scope
This manual applies to the Reyrolle 7SR45 device family.
Further Documentation
[dw_7SR45_furtherdocumentation_engineeringguide, 1, en_US]
•Device manual
The device manual describes the functions and applications of the Reyrolle 7SR45 device. The printed
manual for the device has the same informational structure.
•Hardware manual
The hardware manual describes the hardware building blocks and device combinations of the Reyrolle
7SR45 device family.
Reyrolle, Engineering Guide, Manual 3
C53000-G7040-C102-1, Edition 08.2020

•Operating manual
The operating manual describes the basic principles and procedures for operating and installing the
devices of the Reyrolle 7SR45 range.
•Communication protocol manual
The communication protocol manual contains a description of the protocols for communication within
the Reyrolle 7SR45 device family and to higher-level network control centers.
•Engineering Guide
The engineering guide describes the essential steps when engineering with Reydisp Evolution. In addi-
tion, the engineering guide shows you how to load a planned configuration to a Reyrolle 7SR45 device
and update the functionality of the Reyrolle 7SR45 device.
•Reyrolle 7SR45 catalog
The Reyrolle 7SR45 catalog describes the system features and the devices of Reyrolle 7SR45.
•Selection guide for Reyrolle and SIPROTEC
The selection guide offers an overview of the device series of the Siemens protection devices, and a
device selection table.
Additional Support
For questions about the system, contact your Siemens sales partner.
Customer Support Center
Our Customer Support Center provides a 24-hour service.
Siemens AG
Customer Support Center
Humboldtstrasse 59
90459 Nuremberg
Germany
E-mail: [email protected]
Training Courses
Inquiries regarding individual training courses should be addressed to our Training Center:
Siemens AG Phone: [phone]
Siemens Power Academy TD Fax: [phone]
Humboldtstrasse 59 E-mail: [email protected]
90459 Nuremberg Internet: www.siemens.com/poweracademy
Germany
Notes on Safety
This document is not a complete index of all safety measures required for operation of the equipment (module
or device). However, it comprises important information that must be followed for personal safety, as well as
to avoid material damage. Information is highlighted and illustrated as follows according to the degree of
danger:
!
DANGER
DANGER means that death or severe injury will result if the measures specified are not taken.
²Comply with all instructions, in order to avoid death or severe injuries.
Preface
4 Reyrolle, Engineering Guide, Manual
C53000-G7040-C102-1, Edition 08.2020

!
WARNING
WARNING means that death or severe injury may result if the measures specified are not taken.
²Comply with all instructions, in order to avoid death or severe injuries.
!
CAUTION
CAUTION means that medium-severe or slight injuries can occur if the specified measures are not taken.
²Comply with all instructions, in order to avoid moderate or minor injuries.
NOTICE
NOTICE means that property damage can result if the measures specified are not taken.
²Comply with all instructions, in order to avoid property damage.
i
i
NOTE
Important information about the product, product handling or a certain section of the documentation
which must be given attention.
Preface
Reyrolle, Engineering Guide, Manual 5
C53000-G7040-C102-1, Edition 08.2020

6 Reyrolle, Engineering Guide, Manual
C53000-G7040-C102-1, Edition 08.2020

Open Source Software
The product contains, among other things, Open Source Software developed by third parties. The Open
Source Software used in the product and the license agreements concerning this software can be found in the
Readme_OSS. These Open Source Software files are protected by copyright. Your compliance with those
license conditions will entitle you to use the Open Source Software as foreseen in the relevant license. In the
event of conflicts between Siemens license conditions and the Open Source Software license conditions, the
Open Source Software conditions shall prevail with respect to the Open Source Software portions of the soft-
ware. The Open Source Software is licensed royalty-free. Insofar as the applicable Open Source Software
License Conditions provide for it you can order the source code of the Open Source Software from your
Siemens sales contact – against payment of the shipping and handling charges – for a period of at least 3
years after purchase of the product. We are liable for the product including the Open Source Software
contained in it pursuant to the license conditions applicable to the product. Any liability for the Open Source
Software beyond the program flow intended for the product is explicitly excluded. Furthermore any liability
for defects resulting from modifications to the Open Source Software by you or third parties is excluded. We
do not provide any technical support for the product if it has been modified.
The ReadmeOSS documents for the product can be found here: www.siemens.com/reyrolle
Reyrolle, Engineering Guide, Manual 7
C53000-G7040-C102-1, Edition 08.2020

8 Reyrolle, Engineering Guide, Manual
C53000-G7040-C102-1, Edition 08.2020

Table of Contents
Preface..........................................................................................................................................................3
Open Source Software..................................................................................................................................7
1 Reydisp Evolution Overview.......................................................................................................................11
1.1 Reydisp Evolution .............................................................................................................12
1.2 Offline Mode and Online Mode......................................................................................... 13
1.3 User Interface................................................................................................................... 14
1.3.1 Functional Sections of the User Interface .....................................................................14
1.3.2 Settings Templates...................................................................................................... 14
2 Essential Steps during Engineering............................................................................................................15
2.1 Preconfiguration Requirements......................................................................................... 16
2.2 Setting the Relay via Reydisp Evolution..............................................................................18
2.3 Configuring the Relay Serial Data Communication ............................................................ 20
3 Configuration Software.............................................................................................................................. 21
3.1 Get Device Data................................................................................................................ 22
3.2 Settings Editor Window..................................................................................................... 24
3.3 Changing Settings.............................................................................................................25
3.4 Using the Matrix Editor......................................................................................................27
3.5 Help Hints.........................................................................................................................28
3.6 Using the Config Editor..................................................................................................... 29
3.7 Send Settings....................................................................................................................30
3.8 Compare Settings Groups..................................................................................................31
A Appendix.................................................................................................................................................... 33
A.1 Revision History................................................................................................................ 34
Index...........................................................................................................................................................35
Reyrolle, Engineering Guide, Manual 9
C53000-G7040-C102-1, Edition 08.2020

10 Reyrolle, Engineering Guide, Manual
C53000-G7040-C102-1, Edition 08.2020

Reydisp Evolution Overview
1.1 Reydisp Evolution 12
1.2 Offline Mode and Online Mode 13
1.3 User Interface 14
1
Reyrolle, Engineering Guide, Manual 11
C53000-G7040-C102-1, Edition 08.2020

Reydisp Evolution
What is Reydisp Evolution?
Reydisp Evolution is a Windows based suite of software tools, providing the means for the user to fully
configure the 7SR45 Argus relay.
The setting configuration tool allows you to apply settings, interrogate settings, and retrieve events and fault
records from the 7SR45 Argus relay.
Reydisp Evolution can be used without being connected to a device. To demonstrate the use of Reydisp Evolu-
tion, some example (template) files of data and settings are supplied with the product.
[sc_enggguide_reydisp, 1, --_--]
Figure 1-1 Reydisp Evolution
1.1
Reydisp Evolution Overview
1.1 Reydisp Evolution
12 Reyrolle, Engineering Guide, Manual
C53000-G7040-C102-1, Edition 08.2020

Offline Mode and Online Mode
In the Offline mode, all of the data to be edited for the 7SR45 Argus relay is available in files and there is no
physical connection to the 7SR45 Argus relay.
The following list provides an overview of the tasks you can work with in the Offline mode:
•Defining the functional scope of a 7SR45 device
•Setting function parameters
In the Offline configuration, for example, the following data can be edited:
•Parameter values
•Communication settings
The following list provides an overview of the tasks you can work with in the Online mode:
•Transferring parameter values from Reydisp Evolution to the 7SR45 device.
•Transferring parameter values from the 7SR45 device to Reydisp Evolution and saving them in files.
•Transferring indications, measured values, and fault records from the 7SR45 device to Reydisp Evolution
and saving them in files.
•Set/reset output relays, LED reset.
•Setting 7SR45 Argus relay date and time.
1.2
Reydisp Evolution Overview
1.2 Offline Mode and Online Mode
Reyrolle, Engineering Guide, Manual 13
C53000-G7040-C102-1, Edition 08.2020

User Interface
Functional Sections of the User Interface
For more information about Reydisp Evolution configuration software, visit the Siemens Internet site https://
www.siemens.com/reyrolle.
Download the Reydisp Evolution Set up and install Reydisp Evolution to access the Help menu.
Settings Templates
Settings templates are used to view the available templates. For each type, click the appropriate tab at the top
of the Templates dialog box. The view can be sorted alphabetically on the contents of each column by
clicking on that columns header label.
Settings templates allow setting for the devices to be created offline. Templates are available for the different
software variants and I/O configurations of each device. The templates box contains a Find search box.
To search the template:
²Enter the complete relay ID or part of the relay ID item in the search field.
[sc_settings_templates, 1, --_--]
Figure 1-2 Settings Templates
²Click the Start (→) button.
This starts to search from the top of the list
²To continue the search, click the Next (↓) button.
²Select the template from the list and click OK to open.
1.3
1.3.1
1.3.2
Reydisp Evolution Overview
1.3 User Interface
14 Reyrolle, Engineering Guide, Manual
C53000-G7040-C102-1, Edition 08.2020

Essential Steps during Engineering
2.1 Preconfiguration Requirements 16
2.2 Setting the Relay via Reydisp Evolution 18
2.3 Configuring the Relay Serial Data Communication 20
2
Reyrolle, Engineering Guide, Manual 15
C53000-G7040-C102-1, Edition 08.2020

Preconfiguration Requirements
Ensure that your personal computer (PC) or laptop computer is equipped with the following software specifi-
cations and operating systems:
To set the relay using a communication port, you need the following:
•PC or laptop computer with Reydisp Evolution Version 9.51.02 or higher installed. You can download
Reydisp Evolution from the Siemens Internet site https://www.siemens.com/reyrolle under the submenu
Software.
•This software requires the following:
– Windows 2000 service pack 4 or higher
– Windows XP with service pack 2 or higher
– Microsoft .NET framework for tools
The 7SR45 Argus relay can be connected to Reydisp Evolution via communication ports available on the relay.
Depending on the communication port used, select a suitable communication interface cable and converters.
Front USB Connection
The following figure shows how to connect your PC or laptop computer locally via the front USB port.
[dw_communication_front-USB-port, 2, en_US]
Figure 2-1 USB Connection to PC
2.1
Essential Steps during Engineering
2.1 Preconfiguration Requirements
16 Reyrolle, Engineering Guide, Manual
C53000-G7040-C102-1, Edition 08.2020

Rear RS485 Connection
[dw_RS485-connection_to_PC, 2, en_US]
Figure 2-2 RS485 Connection to PC
Essential Steps during Engineering
2.1 Preconfiguration Requirements
Reyrolle, Engineering Guide, Manual 17
C53000-G7040-C102-1, Edition 08.2020

Setting the Relay via Reydisp Evolution
When the Reydisp software is running, all the available communication ports are automatically detected.
²On the homepage of Reydisp Evolution, open the submenu File and select Connect.
The Connection Manager window displays all the available communication ports.
²Select the preferred port and click Properties....
²In the Configure Communications window, ensure the baud rate and parity match with the selected
values in the 7SR45 Argus relay settings and click OK
²In the Connection Manager window Figure 2-3, click Connect to initiate the relay-PC connection.
[sc_reydisp_conn, 1, --_--]
Figure 2-3 PC Communication-Port Selection
²You can now configure the relay settings using the Reydisp Evolution software.
i
i
NOTE
In Reydisp Evolution, verify that the Do NOT Check Communication Connection option is selected in the
Advanced properties.
i
i
NOTE
In Reydisp Evolution, ensure that the relay address is set as 1 in the relay menu. This is applicable for
7SR450[1/3]-xGx10-1AA0.
2.2
Essential Steps during Engineering
2.2 Setting the Relay via Reydisp Evolution
18 Reyrolle, Engineering Guide, Manual
C53000-G7040-C102-1, Edition 08.2020

i
i
NOTE
In Reydisp Evolution, check that the relay address in the Relay menu is the same as that of the 7SR45 Argus
relay address. This is applicable for 7SR450[1/3]-x[H/J]A20-1AA0 and 7SR450[2/4]-x[H/J]B20-1AA0.
Essential Steps during Engineering
2.2 Setting the Relay via Reydisp Evolution
Reyrolle, Engineering Guide, Manual 19
C53000-G7040-C102-1, Edition 08.2020

Configuring the Relay Serial Data Communication
You can configure the 7SR45 Argus relay by using the keys on the relay fascia. Scroll down from the SETTING
MODE and navigate to the COMMUNICATION menu and change the settings for the communication port if
needed.
Reydisp Evolution uses the IEC 60870-5-103 protocol to communicate.
When connecting the relay to a PC using the front USB port, the Reydisp Evolution automatically detects the
relay. If the USB-Protocol selected is IEC60870-5-103, then setting changes are not required.
Table 2-1 Communication Settings
Description Range Default
COM1-RS485 Protocol
Selects protocol to use for COM1-
RS485
OFF
IEC60870-5-103
MODBUS-RTU
MODBUS-RTU
COM1-RS485 Stn Addr
Sets the station address for COM1-
RS485
0 to 254 for IEC60870-5-103
1 to 247 for MODBUS-RTU
1
COM1-RS485 Baud Rate
Sets the communications baud rate
for COM1-RS485
1200
2400
4800
9600
19200
38400
57600
19200
COM1-RS485 Parity
Selects whether parity information
is used
None
Odd
Even
None
COM1-RS485 Mode
Selects whether the port is Local or
Remote.
Local
Local or Remote
Remote
Local or Remote
COM2-USB Protocol
Selects protocol to use for COM2-
USB
OFF
IEC60870–5–103
MODBUS–RTU
IEC60870–5–103
COM2-USB Stn Addr
Sets the station address for COM2-
RS485
0 to 254 for IEC60870–5–103
1 to 247 for MODBUS–RTU
1
COM2-USB Mode
Selects whether the port is Local or
Remote.
Local
Local or Remote
Remote
Local or Remote
2.3
Essential Steps during Engineering
2.3 Configuring the Relay Serial Data Communication
20 Reyrolle, Engineering Guide, Manual
C53000-G7040-C102-1, Edition 08.2020
