Siemens BT300 LonWorks User manual

DPD01391
Building Technologies
2016-08-05 DPD01391D
Siemens BT300 Bypass
Operator's Manual

Copyright Notice
2
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Copyright Notice
Notice
Document information is subject to change without notice by Siemens Industry, Inc.
Companies, names, and various data used in examples are fictitious unless otherwise
noted. No part of this document may be reproduced or transmitted in any form or by
any means, electronic or mechanical, for any purpose, without the express written
permission of Siemens Industry, Inc.
All software described in this document is furnished under a license agreement and
may be used or copied only in accordance with license terms.
For further information, contact your nearest Siemens Industry representative.
Copyright 2016 Siemens Industry, Inc.
To the Reader
Your feedback is important to us. If you have comments about this manual, please
submit them to: [e-mail]
Other product or company names mentioned herein may be the trademarks of their
respective owners.
Printed in the USA.

3
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Table of contents
How to Use this Manual
................................
................................
................................
5
Reference Documents
................................
................................
................................
.....
7
Safety Instructions
................................
................................
................................
.......
8
Bypass Overview
................................
................................
................................
........
10
General Description
................................
................................
................................
.......
10
Operation Overview
................................
................................
................................
.......
10
Start
-
up Procedures
................................
................................
................................
....
12
Safety Precautions
................................
................................
................................
........
12
Installation Inspection
................................
................................
................................
....
12
Start
-
up Procedure, Conventional Bypass (C
-
Bypass)
................................
...................
13
Start
-
up Procedure, Electronic Bypass (E
-
Bypass)
................................
........................
15
Quick Commissioning Procedure
................................
................................
...................
17
Factory Reset
................................
................................
................................
................
18
Startup Wizard (P1.19)
................................
................................
................................
..
19
Bypass Wizard (P1.21)
................................
................................
................................
..
21
Communications Configuration
................................
................................
......................
22
Additional Configuration
................................
................................
................................
.
22
Wiring Diagrams
................................
................................
................................
.........
23
Power Wiring
................................
................................
................................
.................
23
Electronic Bypass Control Wir
ing
................................
................................
...................
24
Conventional Bypass Control Wiring
................................
................................
..............
25
Motor Rotation Correction Wiring
................................
................................
...................
26
Operation (Electronic Bypass Only)
................................
................................
..............
27
Drive Mode
–
Auto
................................
................................
................................
.........
27
Drive Mode
–
Hand
................................
................................
................................
........
28
OFF Mode
................................
................................
................................
.....................
29
Bypass Mode
................................
................................
................................
................
30
Bypass
-
Specific Parameters
................................
................................
..........................
31
Application Features (Electronic Bypass Only)
................................
...............................
32
Standard I/O Assigned for Bypass
................................
................................
.................
33
Additional I/O Assigned for Bypass (OPT
-
B5)
................................
................................
33
Manual Bypass Delay (P3.18.1, ID: 1818)
................................
................................
......
34
Auto Bypass
................................
................................
................................
..................
34
Auto Bypass Enable (P3.18.2, ID: 1813)
................................
................................
...
34
Auto Bypass Faults (P3.18.3, ID: 1812)
................................
................................
....
34
Auto Bypass Delay (P3.18.4, ID: 1817)
................................
................................
.....
35
Essential Services
................................
................................
................................
.........
35
Essential Services Enable (P3.18.5)
................................
................................
.........
35

4
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Essential Services Digital Inp
ut Configuration: (P3.5.1.52, ID: 1827)
..........................
35
Interlock
................................
................................
................................
........................
36
Remote Bypass
................................
................................
................................
.............
36
Remote Bypass Enable (P3.18.6, ID: 1828)
................................
...............................
36
Troubleshooting
................................
................................
................................
.........
37
Bypass
-
Specific Fault Codes
................................
................................
.........................
37
General Bypass
................................
................................
................................
.............
37
Diagnostic Test Points
................................
................................
...............................
38
Electronic Bypass Diagnostic Board
................................
................................
..............
39
Conventional Bypass
Diagnostic Board
................................
................................
.........
42
Technical Information
................................
................................
................................
.
45
Product Numbers
................................
................................
................................
..........
45
Power Ratings
................................
................................
................................
...............
46
Technical D
ata
................................
................................
................................
..............
47
Accessories and Replacement Parts
................................
................................
.............
48

How to Use this Manual
Reference Documents
5
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
How to Use this Manual
About This Manual
This manual is written for the owner and user of the Siemens BT300 Bypass. It is
designed to help you become familiar with the Siemens BT300 Bypass and its
applications.
This section covers manual organization, document conventions and symbols used in
the manual, how to access help, related publications, and any other information that
will help you use this manual.
Document Organization
This manual contains the following sections:
● Safety Instructions provides general guidelines for your safety and to prevent
equipment damage.
● Bypass Overview describes both the Conventional and Electronic Bypass devices.
● Startup Procedures describes the precautions, installation, preparation, and
commissioning procedures.
● Wiring Diagrams for power and control wiring of the Bypass.
● Operation (Electronic Bypass Only) describes the use of the electronic Bypass.
● Application Features (Electronic Bypass Only) describes the electronic Bypass
extended features.
● Troubleshooting provides guidelines for troubleshooting the Bypass.
● Technical Information provides product numbers, power ratings, technical data,
and ordering information for accessories and replacement parts.
Document Conventions
The following table lists conventions to help you use this manual in a quick and
efficient manner.
Convention Examples
Numbered Lists (1, 2, 3…) indicate a
procedure with sequential steps. 1. Turn OFF power to the field panel.
2. Turn ON power to the field panel.
3. Contact the local Siemens Industry
representative.
Conditions that must be completed or
met before beginning a task are
designated with a ⊳.
Intermediate results (what will happen
following the execution of a step), are
designated with a ⇨.
Results, which inform the user that a task
was completed successfully, are
designated with a ⇨.
⊳Composer software is properly installed.
⊳A Valid license is available.
1. Select Start > Programs > Siemens > GMS >
Composer.
⇨The Project Management window displays.
2. Open an existing project or create a new one.
⇨The project window displays.
Actions that should be performed are
specified in boldface font. Type Ffor Field panels.
Click OK to save changes and close the dialog box.
Error and system messages are
The message
Report Definition

How to Use this Manual
Reference Documents
6
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Convention Examples
displayed in Courier New font.
successfully renamed
displays in the status
bar.
New terms appearing for the first time are
italicized. The field panel continuously executes a user- defined set of instructions called the control
program .
This symbol signifies Notes. Notes provide
additional information or helpful hints.
Cross references to other information are
indicated with an arrow and the page
number, enclosed in brackets: [→92]
For more information on creating flowcharts, see
Flowcharts [→92].
Placeholders indicate text that can vary
based on your selection. Placeholders
are specified by italicized letters, and
enclosed with brackets [ ].
Type A C D H [ username ] [ field panel #] .
Safety Symbols
The following table lists the safety symbols used in this manual to draw attention to
important information.
Table 1: Warning Symbols.
Symbol Description
DANGER or WARNING: Dangerous voltage is present.
DANGER ou AVERTISSEMENT: Présence de tension dangereuse.
WARNING or CAUTION
AVERTISSEMENT ou ATTENTION
NOTE
REMARQUE
The following table describes the safety notices used in this manual to draw attention
to important information.
Table 2: Warning Descriptions.
Warning Type Description
DANGER Serious injury, death, or severe equipment damage is imminent if a procedure or
instruction is not followed as specified.
Le non respect d'une procédure ou instruction peut provoquer instantanément des
blessures graves, voir mortelles, ou endommager l'équipement
WARNING Serious injury, death, or severe equipment damage could occur if a procedure or
instruction is not followed as specified.
Le non respect d'une procédure ou instruction peut provoquer des blessures graves
voir mortelles ou endommager l'équipement.

How to Use this Manual
Reference Documents
7
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Warning Type Description
CAUTION Minor or moderate injury may occur if a procedure or instruction is not followed as
specified.
Le non respect d'une procédure ou instruction peut provoquer des blessures
mineures ou modérés.
NOTICE Equipment damage or unwanted operation may occur if a procedure or instruction is
not followed as specified.
Le non respect d'une procédure ou instruction peut endommager l'équipement ou
entraîner un fonctionnement intempestif.
NOTE Notes provide additional information or helpful hints.
Les remarques fournissent des informations supplémentaires ou des conseils utiles.
Getting Help
For more information about BT300 products, contact your local Siemens Industry
representative.
Reference Documents
The following documentation is available from your local Siemens Industry, Inc.
representative:
● BT300 Variable Frequency Drive Bypass Installation Instructions
(DPD01375Siemens BT300 Bypass.
● BT300 Variable Frequency Drive Installation Manual (DPD01148 ), provides
installation instructions for the Siemens BT300 HVAC Variable Speed Drive.
● Siemens BT300 HVAC Drive Operator's Manual (DPD01809) provides operating
instructions and procedures for the BT300 Drive.
● BT300 VFD Submittal Sheet (154-126), provides a synopsis of the BT300 Drive
product line, accessories, and technical data.
● BT300 HVAC Drives Conventional Bypass (C-Bypass) Options Submittal Sheet
(154-128) provides a comprehensive overview of the BT300 Conventional Bypass.
● BT300 HVAC Drives Electronic Bypass (E-Bypass) Options Submittal Sheet (154-
129) provides a comprehensive overview of the BT300 Electronic Bypass.
● Siemens BT300 I/O Option Boards User's Manual (DPD01158) provides
installation instructions and technical information for the wide selection of expander
boards that are available for the BT300 Drive.

Safety Instructions
8
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Safety Instructions
The following guidelines are provided for your safety, to prevent damage, and to
extend the service life of the BT300 Drive and any connected equipment. Read this
information carefully. Specific Warnings, Cautions, and Notes are provided in the
relevant sections of this manual.
WARNING
The
BT300 Drive
uses hazardous voltages and controls potentially dangerous
rotating mechanical components.
●Non-compliance with warnings or failure to follow the instructions contained in this
manual can result in loss of life, severe personal injury, or serious damage to
property/equipment.
●Only authorized personnel should work on this equipment, and only after
becoming familiar with all local regulations and ordinances; safety notices; and
installation, operation, and maintenance procedures in this manual. Successful
and safe operation of this equipment depends upon its proper handling,
installation, operation, and maintenance.
●Before carrying out any installation and commissioning procedures, you must
read all safety instructions and warnings, including all warning labels attached to
the equipment. Make sure that the warning labels are kept in a legible condition
and ensure missing or damaged labels are replaced.
●Observe the regulations of Safety Code VBG 4.0 (in particular, "Permissible
Deviations when Working with Live Components") whenever measuring or testing
is performed on live equipment. Also, use suitable electronic tools.
●Only use the equipment for the purpose specified by the manufacturer.
Unauthorized modifications and the use of spare parts and accessories that are
not sold or recommended by the manufacturer of the equipment can cause fires,
electric shocks, and injuries.
●Prevent the general public from accessing or approaching this equipment

Safety Instructions
9
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
WARNING
Le variateur Siemens BT300 utilise des tensions dangereuses et commande des
pièces mécaniques rotatives potentiellement dangereuses.
●Le non-respect des avertissements et des instructions contenus dans ce manuel
peut occasionneré la mort de personnes, des blessures graves, ou des
dommages sérieux aux biens et aux équipements.
●Seul le personnel autorisé doit entretenir cet équipement, et cela uniquement
après s'être familiarisé avec toutes les ordonnances et réglementations locales en
vigueur, de même que les notices de danger, et les procédures d'installation, de
fonctionnement et de service de ce manuel. Le fonctionnement fiable et sans
faille de cet équipement dépend de son maniement correct, ainsi que de son
installation, de sa mise en œuvre et de son service.
●Avant d'effectuer des procédures d'installation et de mise en service, vous devez
lire toutes les instructions et avertissements de sécurité, y compris les étiquettes
portant les avertissements sur le variateur. Assurez-vous que ces étiquettes
demeurent lisibles, et que toute étiquette manquante ou endommagée est
remplacée.
●Observer les réglementations du code de sécurité VBG 4.0 (en particulier
" Permissible Deviations when Working with Live Components "), lorsque des
mesures ou des essais sont effectués sur un équipement sous tension. Utiliser
également des outils électroniques appropriés.
●N’utiliseré que l'équipement pour l'usage spécifié par le constructeur. Toute
modification ou utilisation de pièces de rechange ou d'accessoires non vendus ou
recommandés par le constructeur peuvent causer un incendie, des électrochocs,
or des blessures.
●
Empêcher l'accès de cet équipement au grand public.
NOTE:
Keep these Operating Instructions near the equipment and available to all users.

Bypass Overview
General Description
10
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Bypass Overview
General Description
During normal operation in a typical application, the input contactor (optional) and
output contactor close and the BT300 Drive operates the motor.
During bypass operation, the bypass contactor provides the ability to operate the motor
on utility power and eliminate the BT300 Drive from the motor control circuit.
Figure 1: Bypass Contactor Options.
The Siemens BT300 Bypass consists of a BT300 Drive and a bypass enclosure with
controls that include the following:
●Control terminals
●Operators (conventional only):
– "Drive-Off-Bypass" switch
– "Bypass On" light
– "Drive Test On-Off" switch (optional)
●Step-down control transformer
●Contactors:
– Bypass (M1)
– Output (M2)
– Input (M3) or Service Switch
●Overload (current) relay
●Disconnect with fuses, or circuit breaker
●Diagnostics board
Operation Overview
●Drive Mode
– Drive input contactor (M3) or selector switch closes.
– Drive output contactor (M2) closes.
– The motor is controlled by the BT300 Drive output.
●Local Bypass Operation
– Requires a jumper between the bottom two pins (LOC) of jumper block J7 on
the Bypass Diagnostic Board. This is the default jumper position from the
factory.
– "Off" opens the drive output contactor and the bypass contactor.

Bypass Overview
Operation Overview
11
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
– "Bypass" closes the bypass contactor (M1) and the bypass indicator is
energized.
– The motor is connected to utility/line power.
●Remote Bypass Operation (electronic only)
– Requires a jumper between the top two pins (REM) of jumper block J7 on the
Bypass Diagnostic Board.
– "Off" opens the drive output contactor and the bypass contactor.
– "Bypass" closes the bypass contactor (M1) and the bypass indicator is
energized only when the bypass control terminals (customer remote start input)
are closed.
– The motor is connected to utility/line power.
●Safety Input(s)
– Contact closure required for motor to be run in either Drive or Bypass modes of
operation.
WARNING
This disconnects the 120 Vac control power circuit.
Ceci déconnecte le circuit d'alimentation 120 Vac.
●Essential Services
– Requires jumper (or contact closure) between pins 5 and 6 of Terminal Block
TB1 on the Bypass Diagnostic Board to enable Essential Services.
– Requires contact closure between pins 7 and 8 of Terminal Block TB1 on the
Bypass Diagnostic Board to activate Essential Services.
– Bypass contactor (M1) is closed regardless of the selected operation.
– All calls to open the bypass contactor are ignored except the opening of this
contact or removal of the main power.
– The motor is connected to utility/line power.
●Auto-Bypass (electronic only)
– Requires to be enabled.
– Bypass operation is automatically initiated in the event of a fault at the BT300
Drive.
– The motor is connected to utility/line power.
●Interlock (electronic only)
– Requires to be enabled.
– Requires interlock device wired to terminals

Start-up Procedures
Safety Precautions
12
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Start-up Procedures
Safety Precautions
WARNING
Failure to disconnect input power may cause serious injury or death.
When you connect input power to the Siemens BT300 Bypass, the motor terminals
are energized even if the motor is not running. Do not make any connections with
input power connected to the Siemens BT300 Bypass. Disconnect and lock out power
to the Siemens BT300 Bypass before servicing it.
Si vous ne coupez pas l'alimentation, vous risquez des blessures graves ou
mortelles.
Lorsque vous branchez le variateur Siemens BT300 à l'alimentation, les bornes du
moteurs sont sous tension, même si le moteur n'est pas mis en route. N'effectuez
aucun branchement si l'alimentation est raccordée au variateur Siemens BT300.
Débranchez et consignez l'alimentation avant de procéder à un entretient.
WARNING
After you disconnect input power, allow the power supply to be off for at least five
minutes so that the DC bus capacitors can discharge to a safe voltage.
Après avoir débranché l'alimentation, laissez écouler une période d'attente d'au
moins cinq minutes, afin que les condensateurs du bus DC puissent décharger en
toute sécurité.
Installation Inspection
Inspect the mechanical and electrical installation for compliance with local electrical
codes and regulations. After installation, verify that:
●Siemens BT300 Bypass and motor are properly grounded.
●Input power and motor wire sizes are correct and connections are secure.
●Control wiring is correct and connections are secure.
●Control wiring is not routed with power wiring.
●Motor wiring is not routed in the same conduit with power wiring.
●Siemens BT300 Bypass installation environmental conditions are met as follows:
– Installed in an indoor controlled environment (except NEMA 3R units) that is
free of moisture and conductive contaminants such as condensation and dust.
– Ventilation/cooling is clean and free from corrosive gases.
– Ambient temperature must be between 14°F and 104°F (-10°C to 40°C).
– Relative humidity must be between 0% and 95%, non-condensing.
– The device is not mounted in direct sunlight.

Start-up Procedures
Start
-
up Procedu
re, Conventional Bypass (C
-
Bypass)
13
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Start-up Procedure, Conventional Bypass (C-Bypass)
NOTE:
Insert an Xin the Check column when completed; enter N/A if not used.
Step Check Description
1Verify that all three input phases are connected to the input fuse block (or circuit breaker depending upon model) and that
the motor leads are connected to the output terminals of the overload relay only.
NOTE: The M1 (Bypass) contactor and the M2 (Output) contactor outputs are connected together at the factory.
2Verify that all factory connections within the bypass are tight, as factory connections can loosen during shipment.
3Before applying power, verify the following:
- The DRIVE/OFF/BYPASS switch is in the OFF position.
- The DRIVE TEST switch (if installed) is in the OFF position.
4Dial in the current limit on the overload, in accordance with the connected motor.
5Apply power to the drive with C-Bypass option using the main disconnect. Verify that all three phases are present, and that
the input voltage is correct for the system.
6Place the DRIVE TEST switch (if installed) in the ON position.
7The keypad illuminates and the Startup Wizard of the drive is active. Complete the Startup Wizard. When prompted for
Bypass Wizard, answer YES.
NOTE: This should be activated when the unit is first powered up. If not, reset the drive to factory-default to return to a
good, known starting configuration. This can be completed by selecting the following:
User Settings (6)/Parameter Backup (6.6)/Restore Factory Defaults (6.5.1)/Activate.
See Startup Wizard for detailed information.
8When executing the Bypass Wizard, select Conventional. See Bypass Wizard for detailed information.
9Place the DRIVE/OFF/BYPASS switch in the DRIVE position.
10 Place the DRIVE TEST switch (if installed) in the OFF position.
11 “Bump” the unit into Drive mode by completing the following:
Press the HAND/AUTO button on the drive. Select Drive, and press OK. Select Hand, and press OK. When Activate
displays, press OK. Enter a setpoint of at least 5 hertz. Press the green I button to start the motor. Verify that the motor
rotation is correct for the application. Press the red Obutton to stop the motor.
NOTE: If the motor rotation is incorrect, do not correct now. Complete Steps 14 and 15 first, and then see Step 16 for
corrective actions.
12 Place the DRIVE/OFF/BYPASS switch in the OFF position. The drive’s keypad should turn off if a Drive Test switch is
installed (3-contactor versions).
13 Bump” the unit into Bypass mode by completing the following:
Place the DRIVE/OFF/BYPASS switch into the BYPASS position, and quickly back to the OFF position. Verify that the
motor rotation is correct for the application.
NOTE: If the motor rotation is incorrect, do not correct now. See Step 16 for corrective actions.
14 If the motor rotation was incorrect in either Step 13 or 15, remove power to the bypass assembly using the disconnect
switch. Wait 5 minutes to allow for the drive's DC Bus to discharge. See Motor Rotation Correction Wiring for required
changes. Apply power, and repeat Steps 13 through 15 to verify proper rotation again
15 Place the DRIVE/OFF/BYPASS switch in the DRIVE position.
16 Complete any other required wizards found in the Quick Setup (1) menu.

Start-up Procedures
Start
-
up Procedure, Conventional Bypass (C
-
Bypass)
14
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Step Check Description
17 Complete any other application specific settings for the site as required.
18 The automatic reset is configured for 30-second intervals and 10 reset attempts. If this is not acceptable, configure the
automatic reset settings found in the Parameters (3)/Automatic Reset (3.10) menu for desired settings.
19 The default display has been configured to wait for 2 minutes of keypad inactivity before switching to the multi-monitor
display. If this is not acceptable, see Timeout Time (5.7.1) and Default Page (5.7.2) for desired settings.
20 Manually run the drive throughout its entire operation range while observing operation.
If the drive trips on an over-current during acceleration, adjust the Accel time 1 (3.4.2).
If the drive trips on an over-voltage during deceleration, adjust the Decel time 1 (3.4.3).
If excessive vibration of the driven load is noted at specific input frequencies, use Prohibited Frequencies (3.7) to eliminate
this vibration.
21 Determine whether the speed reference signal is 0 to 10 Vdc or a 4 to 20 mA. Connect signal wires, and place the DIP
switch in the appropriate position.
NOTE: Ensure that the drive power is off before changing the DIP switches.
22 Verify the speed reference signal for proper polarity and operation.
23 Place the drive in AUTO mode at the keypad. Verify that the drive is controlled properly by the building automation system.
Observe if the speed command can achieve the minimum and maximum speeds desired. If not, scale as required.
24 Configure the Password and Access Level, if desired. This prevents unauthorized parameterization using the keypad.

Start-up Procedures
Start
-
up Procedure, Electronic Bypass (E
-
Bypass)
15
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Start-up Procedure, Electronic Bypass (E-Bypass)
NOTE:
Insert an Xin the Check column when completed; enter N/A if not used.
Step Check Description
1Verify that all three input phases are connected to the input fuse block (or circuit breaker depending upon model) and
that the motor leads are connected to the output terminals of the overload relay only.
NOTE: The M1 (Bypass) contactor and the M2 (Output) contactor outputs are connected together at the factory.
2Verify that all factory connections within the bypass are tight, as factory connections can loosen during shipment.
3Dial in the current limit on the overload in accordance with the connected motor.
4Apply power to the drive with E-Bypass option using the main disconnect. Verify that all three phases are present, and
that the input voltage is correct for the system.
5The keypad illuminates and the Startup Wizard of the drive is active. Complete the Startup Wizard. When prompted for
Bypass Wizard, answer YES.
NOTE:
This should be activated when the unit is first powered up. If not, reset the drive to factory-default to return to a good,
known starting configuration. This can be completed by selecting the following:
User Settings (6)/Parameter Backup (6.6)/Restore Factory Defaults (6.5.1)/Activate.
See Startup Wizard for detailed information.
6During the execution of the Bypass Wizard, select Electronic.
NOTE:
ARemote Safety 1 and Remote Safety 2 fault will occur. Press the Back/Reset button once to return to the wizard.
Configure the Remote Safety 1 (3.5.1.44) and Remote Safety 2 (3.5.1.45) once the Bypass Wizard is complete. See
Bypass Wizard for detailed information..
7“Bump” the unit into Drive mode by completing the following:
Press the HAND/AUTO button on the drive. Select Drive, and press OK. Select Hand, and press OK. When Activate
displays, press the OK button. Enter a setpoint of at least 5 hertz. Press the green Ibutton to start the motor. Verify that
the motor rotation is correct for the application. Press the red Obutton to stop the motor.
NOTE: If the motor rotation is incorrect, do not correct now. Complete Step 10 first, then see Step 11 for corrective
actions.
8"Bump" the unit into Bypass mode by completing the following:
Press the HAND/AUTO button on the drive. Select Bypass, and press OK. When Activate displays, press OK. Then,
quickly press the HAND/AUTO button on the drive. Select OFF, and press OK. When Activate displays, press OK. Verify
that the motor rotation is correct for the application.
NOTE: If the motor rotation is incorrect, do not correct now. See Step 11 for corrective actions.
9If the motor rotation was incorrect in either Step 9 or 10, remove power to the bypass assembly using the disconnect
switch. Wait 5 minutes to allow for the drive's DC Bus to discharge. See Motor Rotation Correction Wiring for required
changes. Apply power, and repeat Steps 9 and 10 to verify proper rotation again.
10 Press the HAND/AUTO button on the drive. Select Drive, and press OK. Select Auto and press O. When Activate
displays, press OK..
11 Complete any other required wizards found in the Quick Setup (1) menu.
12 Complete any other application specific settings for the site as required.

Start-up Procedures
Start
-
up Procedure, Electronic Bypass (E
-
Bypass)
16
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Step Check Description
13 The automatic reset is configured for 30-second intervals and 10 reset attempts. If this is not acceptable, configure the
automatic reset settings found in the Parameters (3)/Automatic Reset (3.10) menu for desired settings.
14 The default display has been configured to wait for 2 minutes of keypad inactivity before switching to the multi-monitor
display. If this is not acceptable, see Timeout Time (5.7.1) and Default Page (5.7.2) for desired settings.
15 Manually run the drive throughout its entire operation range while observing operation.
If the drive trips on an over-current during acceleration, adjust the Accel time 1 (3.4.2).
If the drive trips on an over-voltage during deceleration, adjust the Decel time 1 (3.4.3).
If excessive vibration of the driven load is noted at specific input frequencies, use Prohibited Frequencies (3.7) to
eliminate this vibration.
16 Determine whether the speed reference signal is 0 to 10 Vdc or a 4 to 20 mA. Connect signal wires, and place the DIP
switch in the appropriate position.
NOTE:
Ensure that the drive power is off before changing the DIP switches.
17 Verify the speed reference signal for proper polarity and operation.
18 Place the drive in AUTO mode at the keypad. Verify that the drive is controlled properly by the building automation
system. Observe if the speed command can achieve the minimum and maximum speeds desired. If not, scale as
required.
19 Configure the Password and Access Level, if desired. This prevents unauthorized parameterization using the keypad.

Start-up Procedures
Quick Commissioning Procedure
17
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Quick Commissioning Procedure
It is important to use the quick commissioning procedure as listed in the workflow. The
wizards are in place to help minimize the startup time.

Start-up Procedures
Factory Reset
18
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Factory Reset
Since it is often unknown if any other users have attempted to run the unit, it is
recommended to complete a Factory Reset to return the drive to known factory
settings. Do the following to complete a Factory Reset:
At the drive keypad, select:
User Settings > Parameter Backup > Restore Factory Defa > Activate.
The drive restarts, the Siemens splash screen displays, and the Startup Wizard
automatically begins. See the Startup Wizard (P1.19) section for further details.

Start-up Procedures
Startup Wizard (P1.19)
19
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Startup Wizard (P1.19)
The Startup Wizard prompts you for the essential information needed by the drive so
that it can start controlling the output as desired. Once power is connected to the
BT300 HVAC Drive, the Startup Wizard should run automatically. If it is not running, it
can be activated in the Quick Setup (M1) menu or by completing Restore Factory
Defaults (P6.5.1)
The following steps are required to successfully complete the Startup Wizard:
Step Parameter/Question Settings
1Language Selections (P6.1) Select the icon for the language you want applied to the keypad. This
varies depending upon the language package installed.
2Daylight Saving (P5.5.5) Select the Daylight Saving Rule
1 = Off
2 = EU
3 = US
4 = Russia
3Time (P5.5.2) Specify the current time of day in the following format: hh:mm:ss where
h = hour, m = minute, s = seconds.
4Year (P5.5.4) Specify the current year in the following format: yyyy where
yyyy = 4-digit year.
5Date (P5.5.3) Specify the current date in the following format: dd.mm where
dd = 2-digit day, mm = 2-digit month.
6Startup Wizard? Specify if the Startup Wizard should be activated: Yes,No
If the option Yes is selected for Startup Wizard (recommended), you will be prompted
for the following values:
Step Parameter/Question Settings
7Fan or Pump
(Application Type) Pump
Automatically sets the following:
Accel Time 1 (P1.13) = 30
Decel Time 1 (P1.14) = 30
Start Function (P3.2.4) = Ramping
Stop Function (P3.2.5) = Ramping
Fan
Automatically sets the following:
Accel Time 1 (P1.13) = 120
Decel Time 1 (P1.14) = 120
Start Function (P3.2.4) = Flying Start
Stop Function (P3.2.5) = Coast to Stop
8Motor Nom Voltg (P3.1.1.1) Defines nominal motor voltage from motor nameplate data.
9Motor Nom Freq (P3.1.1.2) Defines nominal motor frequency from motor nameplate data.
10 Motor Nom Speed (P3.1.1.3) Defines nominal motor speed from motor nameplate data.
11 Motor Nom Currnt (P3.1.1.4) Defines nominal motor current from motor nameplate data.
12 Motor Cos Phi (P3.1.1.5)
(Power Factor) Defines nominal motor Cos Phi (power factor) from motor nameplate data.

Start-up Procedures
Startup
Wizard (P1.19)
20
Siemens Industry, Inc. BT300 Bypass Operator's Manual DPD01391
2016-08-05
Step Parameter/Question Settings
13 Motor Nom Power (P3.1.1.6) Defines nominal motor power from motor nameplate data.
14 Min Frequency (P3.3.1) Minimum allowed frequency reference.
15 Max Frequency (P3.3.2) Maximum allowed frequency reference.
16 I/O Ctrl Ref (P3.3.3) Selects location of frequency setpoint source when in I/O A control. In
the following list of possible settings, the main setpoint is selected:
1= Preset Freq 0
2 = Keypad Reference
3 = Fieldbus
4 = AI1
5 = AI2
6 = AI1+AI2
7 = PID 1 Reference
8 = Motor Potentiometer
17 Accel Time (P3.4.2) Defines the time required to increase output frequency from 0 to Max
Frequency (P3.3.1).
18 Decel Time (P3.4.3) Defines the time required to decrease output frequency from Max
Frequency (P3.3.1) to 0 frequency.
19 Ctrl Place Auto (P3.2.1) Start/Stop commands are given differently depending upon the control
place. This parameter defines whether the Start/Stop command is
controlled by digital inputs as defined in Control Signal 1 A (P3.5.1.1)
and Control Signal 2 A (P3.5.1.2) in accordance with the I/O A
Start/Stop Logic (P3.2.6) or if the Start/Stop command is controlled by
the Fieldbus that is in use.
Settings:
0 = I/O Control (control is from the physical I/O, PID control, or time
channels)
1 = Fieldbus (control is from the configured fieldbus found in Ethernet
or RS-485 settings).
20 Automatic Reset (P3.10.1) Determines if the Automatic Reset feature can be used.
21 Start Function (P3.2.4) Defines the start function of the drive.
0 = Ramping Start
1 = Flying Start
22 Stop Function (P3.2.5) Defines the stop function of the drive.
0 = Coast to Stop
1 = Ramping Stop
23 Motor Switch (P3.1.2.2) Prevents the drive from tripping when a motor switch is located
between the drive and motor.
0 = No
1 = Yes
24 Bypass Wizard (P1.21) Enable parameter for the Bypass Wizard. This wizard can be activated
during the Startup Wizard.
The Startup Wizard is now complete.
