Siemens Simcenter SCADAS RS User manual

User Manual
Simcenter SCADAS RS
Simcenter Testlab

Unpublished work. © 2023 Siemens
This Documentation contains trade secrets or otherwise condential information owned by Siemens Industry Software Inc. or
its aliates (collectively, “Siemens”), or its licensors. Access to and use of this Documentation is strictly limited as set forth in
Customer’s applicable agreement(s) with Siemens. This Documentation may not be copied, distributed, or otherwise disclosed
by Customer without the express written permission of Siemens, and may not be used in any way not expressly authorized by
Siemens.
This Documentation is for information and instruction purposes. Siemens reserves the right to make changes in specications
and other information contained in this Documentation without prior notice, and the reader should, in all cases, consult
Siemens to determine whether any changes have been made.
No representation or other armation of fact contained in this Documentation shall be deemed to be a warranty or give rise to
any liability of Siemens whatsoever.
If you have a signed license agreement with Siemens for the product with which this Documentation will be used, your use of
this Documentation is subject to the scope of license and the software protection and security provisions of that agreement.
If you do not have such a signed license agreement, your use is subject to the Siemens Universal Customer Agreement, which
may be viewed at https://www.sw.siemens.com/en-US/sw-terms/base/uca/, as supplemented by the product specic terms
which may be viewed at https://www.sw.siemens.com/en-US/sw-terms/supplements/.
SIEMENS MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS DOCUMENTATION INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT OF
INTELLECTUAL PROPERTY. SIEMENS SHALL NOT BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, CONSEQUENTIAL OR
PUNITIVE DAMAGES, LOST DATA OR PROFITS, EVEN IF SUCH DAMAGES WERE FORESEEABLE, ARISING OUT OF OR RELATED
TO THIS DOCUMENTATION OR THE INFORMATION CONTAINED IN IT, EVEN IF SIEMENS HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES.
TRADEMARKS: The trademarks, logos, and service marks (collectively, "Marks") used herein are the property of Siemens or other
parties. No one is permitted to use these Marks without the prior written consent of Siemens or the owner of the Marks,
as applicable. The use herein of third party Marks is not an attempt to indicate Siemens as a source of a product, but is
intended to indicate a product from, or associated with, a particular third party. A list of Siemens’ Marks may be viewed at:
www.plm.automation.siemens.com/global/en/legal/trademarks.html. The registered trademark Linux® is used pursuant to a
sublicense from LMI, the exclusive licensee of Linus Torvalds, owner of the mark on a world-wide basis.
About Siemens Digital Industries Software
Siemens Digital Industries Software is a global leader in the growing eld of product lifecycle management (PLM),
manufacturing operations management (MOM), and electronic design automation (EDA) software, hardware, and services.
Siemens works with more than 100,000 customers, leading the digitalization of their planning and manufacturing processes. At
Siemens Digital Industries Software, we blur the boundaries between industry domains by integrating the virtual and physical,
hardware and software, design and manufacturing worlds. With the rapid pace of innovation, digitalization is no longer
tomorrow’s idea. We take what the future promises tomorrow and make it real for our customers today. Where today meets
tomorrow. Our culture encourages creativity, welcomes fresh thinking and focuses on growth, so our people, our business, and
our customers can achieve their full potential.
Support Center: support.sw.siemens.com
Send Feedback on Documentation: support.sw.siemens.com/doc_feedback_form

Copyright
Version: 2.2
Date: Decmber 2023
© 2023 Siemens Digital Industries Software. All rights are explicitly reserved. All information in this manual, including
additional drawings and technical descriptions, remains the property of Siemens. No part of this publication may be used
(otherwise than for the use of this product), photocopied, duplicated, translated and/or disclosed to third parties without
explicit prior written permission by Siemens.
User Manual Simcenter SCADAS RS system, Simcenter Testlab 3
© 2023 Siemens

Contents
Copyright 3
Version history 9
General terms
Manufacturer ──────────────────────────── 1-1
Disclaimer ────────────────────────────── 1-1
Conditions of change ───────────────────────── 1-1
Licenses and trademarks ─────────────────────── 1-2
Warranty ────────────────────────────── 1-2
Inspection of received goods ───────────────────── 1-2
Transportation of goods ─────────────────────── 1-2
Support ─────────────────────────────── 1-2
Feedback ────────────────────────────── 1-2
About this manual
Usage and availability ──────────────────────── 2-1
Target audience ─────────────────────────── 2-1
Conventions ───────────────────────────── 2-1
Cautions and Warnings ──────────────────────── 2-1
Related documentation ──────────────────────── 2-2
Introduction
Introduction to SCADAS RS system ─────────────────── 3-1
Main functions and intended use ─────────────────── 3-1
Use in accordance with the purpose ────────────────── 3-2
Scope of delivery ────────────────────────── 3-2
Safety information
Hazards and residual risks ────────────────────── 4-1
Residual risks ────────────────────────────── 4-1
Safety provisions ─────────────────────────── 4-1
Product safety ────────────────────────────── 4-1
Covering ──────────────────────────────── 4-2
Electrical safety ───────────────────────────── 4-2
Components and accessories ─────────────────────── 4-2
Safety precautions ──────────────────────────── 4-2
Built-in Li-Ion battery ───────────────────────── 4-3
System overview
User Manual Simcenter SCADAS RS system, Simcenter Testlab 4
© 2023 Siemens

System architecture ───────────────────────── 5-1
Topologies ───────────────────────────── 5-1
Units overview
General dimensions and weight ──────────────────── 6-3
Uninterruptable Power Supply Unit ────────────────── 6-4
Recorder Unit ──────────────────────────── 6-6
Digital Pulse and CAN bus Conditioning Unit ────────────── 6-8
24 Channel 120 Ω Bridge Conditioning Unit ─────────────── 6-9
24-Channel 350 Ω Bridge Conditioning Unit ────────────── 6-10
24-Channel Sensor Conditioning Unit ───────────────── 6-11
12-Channel Universal Signal Conditioning Unit ──────────── 6-12
12-Channel Universal Signal Conditioning Unit Extended Bandwidth ── 6-13
Ethercat® Unit ─────────────────────────── 6-15
TC20 Thermocouple Conditioning Unit ──────────────── 6-16
Unit features and conditioning options
Supported functions of REC and DI Unit ──────────────── 7-1
Supported functions of analog Signal Conditioning Units ──────── 7-3
8-Channel Thermocouple type K Conditioning Unit ─────────── 7-6
Mounting and combining units
Stacking and de-stacking ─────────────────────── 8-1
How to stack units ──────────────────────────── 8-2
How to de-stack units ─────────────────────────── 8-4
Back to back mounting ──────────────────────── 8-7
How to mount units back to back ────────────────────── 8-7
Mounting onto a back plate ────────────────────── 8-9
Strapping units ─────────────────────────── 8-11
How to strap units ─────────────────────────── 8-11
Conguring units
Conguring ───────────────────────────── 9-1
Connecting cables
Daisy chaining ─────────────────────────── 10-1
Handling sensor plugs ──────────────────────── 10-2
System connectivity
Host interface ─────────────────────────── 11-1
Synchronization interface ────────────────────── 11-2
Security ────────────────────────────── 11-2
Operating Simcenter SCADAS RS
Contents
User Manual Simcenter SCADAS RS system, Simcenter Testlab 5
© 2023 Siemens

Preparing for rst use ──────────────────────── 12-1
Setup and conguring ──────────────────────── 12-1
Grounding stacked units ─────────────────────── 12-1
Before powering up ───────────────────────── 12-2
ON/OFF switching ────────────────────────── 12-3
Remote ON/OFF switching ────────────────────── 12-4
General operational considerations ────────────────── 12-6
Li-ion battery safety precautions ───────────────────── 12-7
Guidelines for aerial transport of batteries ───────────────── 12-8
LED indications ─────────────────────────── 12-9
All Units status LED ─────────────────────────── 12-9
UPS Unit LEDs ───────────────────────────── 12-10
Conditioning Units status LED ────────────────────── 12-12
REC Unit status LED ────────────────────────── 12-12
DI Unit Status LEDs ─────────────────────────── 12-13
ECAT Unit LEDs states ───────────────────────── 12-13
Shaping lters ───────────────────────────── 12-14
Pin-out & wiring
Analog channels pin-out ─────────────────────── 13-1
Digital channels pin-out ─────────────────────── 13-3
Connecting sensors ───────────────────────── 13-4
Wiring ───────────────────────────────── 13-4
Wiring Notes ───────────────────────────── 13-11
Maintenance and calibration
Cleaning ────────────────────────────── 14-1
Calibration ───────────────────────────── 14-2
Software
Simcenter SCADAS RS Recorder App and Conguration App ─────── 15-1
Simcenter Testlab Neo ──────────────────────── 15-1
Firmware updates ──────────────────────────── 15-1
Troubleshooting
Solving common problems ────────────────────── 16-1
Glossary
List of technical terms ──────────────────────── 17-1
Product compliance
FCC compatibility ────────────────────────── 18-2
Safety labels ──────────────────────────── 18-3
6 User Manual Simcenter SCADAS RS system, Simcenter Testlab
© 2023 Siemens

End of life and Disposal
Disposal at end-of-life ──────────────────────── 19-1
Notes
Remarks ────────────────────────────── 20-1
Contents
User Manual Simcenter SCADAS RS system, Simcenter Testlab 7
© 2023 Siemens

8 User Manual Simcenter SCADAS RS system, Simcenter Testlab
© 2023 Siemens

Version history
Version Date Comment
1.0 May 2021 First issue
2.0 January 2023 Second issue
2.1 June 2023 Updated second issue
2.2 December 2023 Updated second issue
User Manual Simcenter SCADAS RS system, Simcenter Testlab 9
© 2023 Siemens

10 User Manual Simcenter SCADAS RS system, Simcenter Testlab
© 2023 Siemens

1. General terms
Manufacturer
Simcenter SCADAS RS data acquisition systems are products of
Siemens Industry Software Netherlands B.V.
Simulation and Test Solutions
Weidehek 53
4824 AT Breda
P.O. Box 3132
4800 DC Breda
The Netherlands
This manual forms an integral part of the product. It gives information about the use of the Simcenter
SCADAS RS system. Familiarize yourself with this information, and make sure that you understand it
before using the Simcenter SCADAS RS system.
Disclaimer
Siemens does not guarantee any work caused by or arising out of the failure of the user to comply with
the instructions or recommendations in this User Manual.
Siemens reserves the right to change parts at any moment without prior notice or direct notication.
This User Manual is subject to change without prior notice or direct notication.
Conditions of change
Changes and/or modications to the product (to be conducted by the owner) may only be done after
explicit prior written instruction, permission and/or approval by Siemens. Non-conformance to this rule
will void the authority to further use of the product. Furthermore, any consequential damage, loss or
costs thereof are the responsibility of the proprietor and user.
User Manual Simcenter SCADAS RS system, Simcenter Testlab 1-1
© 2023 Siemens

Licenses and trademarks
Any software, described in this manual and/or delivered with the Simcenter SCADAS RS, is provided
under license and may only be used in accordance with the conditions, stated in the licenses concerned.
Company and product names in this manual are trademarks or registered trademarks of their respective
owners.
Warranty
The conditions of the warranty are part of the delivery.
Inspection of received goods
We recommend that you inspect the shipment upon receipt for completeness and signs of damage. In
case the shipment is not complete, please contact your local Siemens representative. In case parts are
damaged and/or defective, act as follows.
• Save all packing materials in case of return shipment.
• File a claim with the carrier.
• Contact your local Siemens representative for further instructions.
Transportation of goods
In case you need to return parts to Siemens for repair, you are requested to contact your local Siemens
representative rst. You will be informed about the applicable procedures and follow-up.
Support
The content of this manual has been designed and written with the aim to support you, the user, in
the use of the Simcenter SCADAS RS system. In case you need specic information that is not described
in this manual, please do not hesitate to contact your local Siemens representative for support. We are
dedicated to help you accomplish your goals and tasks.
Feedback
Although utmost care has been given to achieve a high level of quality for this manual, it may
contain information that is not (fully) clear and/or accurate. In case you should nd any unclarities
or inaccuracies, please report this to Siemens. In case you have suggestions for improvement, we invite
you to share your ideas with us.
Contact your local Siemens customer support center.
1. General terms
1-2 User Manual Simcenter SCADAS RS system, Simcenter Testlab
© 2023 Siemens

2. About this manual
Usage and availability
This manual provides information for the safe and correct use of the Simcenter SCADAS RS system. Make
sure that you carefully read the instructions to use the Simcenter SCADAS RS system in accordance with
its purpose and intended use.
Target audience
This User Manual is primarily aimed at experienced Test Engineers who have gained a level of
prociency through education, training and experience. Knowledge of other Simcenter SCADAS products
is an advantage. When you work with the Simcenter SCADAS RS system it is assumed that you
have appropriate knowledge of the hardware and software required to accomplish your tasks. These
may include: working with computers and computer networks, Simcenter Testlab Neo, front-end and
recording devices, sensors and instrumentation.
Conventions
Standard font Most of the content in this manual is presented in standard font.
Special Bold Figure titles and captions are presented in Special Bold font.
Emphasis Where necessary, words or phrases are emphasized in italic print.
Symbols Elements that require extra attention by the reader (see Cautions and Warnings).
Cautions and Warnings
Where necessary, symbols are used to indicate cautions and warnings or instructions to perform certain
actions.
All safety related measures described in this manual are based on the intended use of the products.
Make sure to use the products in accordance with its purpose.
The user must adhere to the boundaries specied in this manual and work according to the Safety
precautions (see Safety information).
User Manual Simcenter SCADAS RS system, Simcenter Testlab 2-1
© 2023 Siemens

Symbol Explanation
Attention!
Please pay attention while performing a task.
Caution!
There is a risk of minor damage to the equipment or minor personal injury.
Warning!
There is a risk of major damage to the equipment or major personal injury.
Related documentation
This User Manual describes the hardware that makes up the Simcenter SCADAS RS system. This system
can only be used in combination with other Simcenter named products that have their own dedicated
manuals. Where applicable, the relation between the Simcenter SCADAS RS system and other Simcenter
named products is described. For details about other Simcenter named products or parts of products,
reference is made to:
• Simcenter Testlab Neo – Software application manuals
• Simcenter SCADAS RS Recorder App *)
*) Applies to Simcenter SCADAS RS systems containing a Recorder Unit.
2. About this manual
2-2 User Manual Simcenter SCADAS RS system, Simcenter Testlab
© 2023 Siemens

3. Introduction
Introduction to SCADAS RS system
This chapter gives generic information about the Simcenter SCADAS RS system. The purpose of this
chapter is to inform the user about what the Simcenter SCADAS RS system is meant for and what the
products comprise of. It is the responsibility of the user to use the Simcenter SCADAS RS system in
accordance with its purpose and intended use.
Main functions and intended use
The Simcenter SCADAS RS system is a mobile system of the Simcenter SCADAS family. SCADAS stands for
Signal Conditioning And Data Acquisition System.
Simcenter SCADAS RS is both a distributed and centralized system for front-end signal conditioning
and data acquisition hardware. There are several ways of mounting and connecting the dierent units.
Simcenter SCADAS RS is especially designed for data acquisition under demanding test conditions.
Each system may consist of one or more Signal Conditioning Units, connected in daisy chain to a
Simcenter SCADAS RS Recorder Unit for autonomous operation or in combination with a PC, tablet or
smartphone. Similarly, daisy chains of Signal Conditioning Units (CU) can be connected directly to a PC.
Units are combined in daisy chains using a single cable for power and data.
Simcenter SCADAS RS hardware for data acquisition under demanding test conditions
As and when required the Simcenter SCADAS RS system is connected with a host PC that runs Simcenter
Testlab Neo software.
The user must adhere to the boundaries specied in this User Manual and the relevant Product
Information Sheet and work according to the Safety Information given in this User Manual.
User Manual Simcenter SCADAS RS system, Simcenter Testlab 3-1
© 2023 Siemens

Use in accordance with the purpose
Simcenter SCADAS RS systems must only be used for the specic purpose described above. Any attempt
to alter or modify a Simcenter SCADAS RS system or its use for any other purpose will be considered not
to be in accordance with its purpose and regarded as misuse. Misuse may result in injury to personnel or
serious damage to equipment. In all cases any warranty will be void, while Siemens will not accept any
liability for misuse.
Scope of delivery
The Simcenter SCADAS RS system is delivered for one or more test congurations. The units that are
required for testing depend on the test conguration that is chosen. Each Simcenter SCADAS RS system
is delivered to customer order, which leads to a large variety of possible combinations of units. The
System Overview chapter shows which units may be part of the delivery.
3. Introduction
3-2 User Manual Simcenter SCADAS RS system, Simcenter Testlab
© 2023 Siemens

4. Safety information
Hazards and residual risks
Simcenter SCADAS RS has been designed in such a way that known potential hazards have been
eliminated to the highest possible extent. Where elimination of risks proved not (completely) feasible,
safety provisions have been implemented to reduce the risks to a minimal or acceptable level.
Residual risks
However, some risks still exist. These residual risks and relevant details are listed below. During normal
operation, personnel who work with a Simcenter SCADAS RS system must obey the safety precautions
and follow the instructions in this manual. It is important to meet these conditions to assure personal
safety and product integrity.
Risk Explanation
Electrical shock Connecting the equipment
to mains power
Serious injury; death See: Safety provisions,
Safety precautions
Physical damage
to a battery pack
At impact, e.g. a battery
pack gets cracked
Leakage of dangerous fumes
and/or materials; battery
pack can catch re
See: Li-ion battery safety
precautions
Burn injuries Ambient temperature
above 40 °C (104 °F)
Units can get so hot that it is
unsafe to touch them
Care should be taken to
prevent burn injuries
Safety provisions
By design, the Simcenter SCADAS RS system has several safety provisions to establish the required level
of personal safety. Furthermore, the owner of the Simcenter SCADAS RS system has the responsibility to
provide a safe environment to work in.
Product safety
Simcenter SCADAS RS products SCRS-UPS, SCRS-REC, SCRS-DI, SCRS-S24, SCRS-B24-120, SCRS-B24-350,
SCRS-U12, SCRS-U12-E, SCRS-ECAT and SCRS-TC20 comply with IEC 61010-1 on the aspects listed below.
• Simcenter SCADAS RS products are safe for indoor and outdoor use.
• Simcenter SCADAS RS products can safely be used to an altitude of 5,000 m above sea-level.
• Simcenter SCADAS RS products are safe for use in a wet location.
• Simcenter SCADAS RS products can withstand 100% relative humidity (IP67).
User Manual Simcenter SCADAS RS system, Simcenter Testlab 4-1
© 2023 Siemens

• Simcenter SCADAS RS products are rated Pollution degree 3 of the intended environment.
• The degree of ingress protection of Simcenter SCADAS RS products according to IEC 60529 is IP66 and
IP67.
Covering
During normal operation – i.e. unused connectors are properly capped – exposure to any hazards is
reduced to a minimum. The units are not to be opened by the user. There are no serviceable parts inside.
Electrical safety
The following applies.
• The Simcenter SCADAS RS system complies with international safety standards and local regulations.
• All circuits are adequately protected when used within limits.
• Power levels of the outputs of the Simcenter SCADAS RS system are within safe limits.
Components and accessories
To assure the required level of personal safety and product integrity, Siemens applies approved and
certied components and accessories. For the Simcenter SCADAS RS system, the most prominent items
are:
• State-of-art connectors & plugs that provide a high level of protection against intrusion.
• Power cables that are approved by Siemens for use with the Simcenter SCADAS RS system.
Safety precautions
The presence of safety provisions alone is no guarantee against injury. This section gives instructions
and guidelines to help the user to work safely. Users of the Simcenter SCADAS RS system are always
responsible for their actions, their own safety and that of others.
To prevent injury, obey these rules when working with the Simcenter SCADAS RS system.
• Use the system and its components in accordance with its purpose and within its design
specications.
• Only use original and approved devices, components and accessories. Apply them in accordance with
their intended use.
• Prevent actions that can result in unsafe situations.
4. Safety information
4-2 User Manual Simcenter SCADAS RS system, Simcenter Testlab
© 2023 Siemens

• Always report abnormal situations to your superior.
• Avoid – direct and indirect – contact with live electrical parts.
• Do not operate units at extreme temperatures.
• Do not cover units up and make sure they can dissipate generated heat.
• Do not drop units and avoid situations in which they can get crushed.
• Always place units in a stable position; if necessary, secure the units.
• Dispose used equipment and components in accordance with local laws and regulations.
Built-in Li-Ion battery
• When not using UPS Units for a longer period of time, it is best to store them at room temperature
and with a battery charge level between 40% and 80%.
• Do not exceed 50 °C storage temperature to avoid excessive degradation of battery capacity.
Built-in Li-Ion battery
User Manual Simcenter SCADAS RS system, Simcenter Testlab 4-3
© 2023 Siemens

4. Safety information
4-4 User Manual Simcenter SCADAS RS system, Simcenter Testlab
© 2023 Siemens
