SIMATIC
Industrial PC
SIMATIC IPC847D
Operating Instructions
01/2014
A5E32997454
-AA
Preface
Overview
1
Safety Instructions
2
Installing and connecting the
device
3
Commissioning the device
4
Extended device functions
5
Expanding and assigning
parameters to the device
6
Device maintenance and
repair
7
Technical specifications
8
Technical support
A
Abbreviations
B
Additional information
"BIOS Description" Operating Manual:
Detailed description of the BIOS setup and the setup parameters
"SIMATIC IPC647D/847D Hardware RAID Configuration" Compact Operating Instructions:
Detailed description of the Hardware RAID systems
"SIMATIC IPC847D with Uninterruptible AC Power Supply (AC-UPS)" Compact Operating Instructions:
Detailed description for systems with uninterruptible AC power supply

Siemens AG
Industry Sector
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E32997454-AA
Ⓟ
01/2014 Technical data subject to change
Copyright © Siemens AG 2014.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA 3
Preface
These operating instructions contain all the information you need for commissioning and
operation of the SIMATIC IPC847D.
It is intended both for programming and testing personnel who commission the device and
connect it with other units (automation systems, programming devices), as well as for service
and maintenance personnel who install add-ons or carry out fault/error analyses.
Basic knowledge required
A solid background in personal computers and Microsoft operating systems is required to
understand this manual. General knowledge in the field automation control engineering is
recommended.
Validity of the Operating Instructions
These operating instructions are valid for all supplied versions of the SIMATIC IPC847D.
Scope of this documentation
The documentation for the SIMATIC IPC847D includes the following sections:
●Product Information "Important notes on your device"
●Quick Install Guide SIMATIC IPC847D
●SIMATIC IPC847D operating instructions in English and German
The documentation is part of the "Documentation and Drivers" DVD supplied with the
product.
Refer to the corresponding user documentation for information and instructions on using
software.
Conventions
The terms "PC" or "device" are sometimes used in place of the product name
SIMATIC IPC847D in these operating instructions.
History
Currently released versions of these operating instructions:
Version
Comments
01/2014
First edition

Preface
SIMATIC IPC847D
4Operating Instructions, 01/2014, A5E32997454-AA

SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA 5
Table of contents
Preface ................................................................................................................................................... 3
1 Overview................................................................................................................................................. 9
1.1 Product description ........................................................................................................................9
1.1.1 Scope of application.......................................................................................................................9
1.1.2 Highlights .....................................................................................................................................10
1.1.3 Function .......................................................................................................................................11
1.1.4 Features .......................................................................................................................................12
1.2 Design of the device ....................................................................................................................16
1.2.1 Device views ................................................................................................................................16
1.2.2 Operator Controls.........................................................................................................................17
1.2.3 Interfaces .....................................................................................................................................19
1.2.4 Status displays .............................................................................................................................22
1.3 Accessories..................................................................................................................................25
2 Safety Instructions ................................................................................................................................ 29
2.1 General safety instructions ..........................................................................................................29
2.2 Notes on use ................................................................................................................................32
3 Installing and connecting the device ...................................................................................................... 35
3.1 Preparing for installation ..............................................................................................................35
3.1.1 Checking the delivery package ....................................................................................................35
3.1.2 Identification data of the device ...................................................................................................36
3.1.3 Permitted mounting positions.......................................................................................................37
3.2 Mounting the device.....................................................................................................................38
3.2.1 Installation guidelines...................................................................................................................38
3.3 Connecting the device .................................................................................................................40
3.3.1 Connection information ................................................................................................................40
3.3.2 Connection of equipotential bonding ...........................................................................................41
3.3.3 Connecting the power supply.......................................................................................................42
3.3.4 Connecting peripherals ................................................................................................................44
3.3.5 Connecting the device to networks..............................................................................................45
3.3.6 Securing the lines.........................................................................................................................48
3.3.6.1 Basic power supply ......................................................................................................................48
3.3.6.2 Redundant power supply .............................................................................................................49
3.3.6.3 Network and USB cables .............................................................................................................49
3.3.6.4 COM, DP, DVI/VGA, PS/2 and audio cables...............................................................................51
3.3.7 Multi-monitoring............................................................................................................................51
4 Commissioning the device .................................................................................................................... 53
4.1 General information on commissioning .......................................................................................53
4.2 Switching on the device ...............................................................................................................54
4.3 Windows Action Center................................................................................................................55

Table of contents
SIMATIC IPC847D
6Operating Instructions, 01/2014, A5E32997454-AA
4.4 Notes on different device configurations..................................................................................... 55
4.4.1 Opening the front door ................................................................................................................ 55
4.4.2 DVD burner drive ........................................................................................................................ 56
4.4.3 Replacing hard disks................................................................................................................... 56
4.4.4 2HDD system (optional) .............................................................................................................. 58
4.4.5 RAID system ............................................................................................................................... 58
4.4.5.1 RAID1 system ............................................................................................................................. 58
4.4.5.2 RAID5 system ............................................................................................................................. 58
4.4.5.3 RAID system with hot spare drive............................................................................................... 59
4.5 Switching off the device .............................................................................................................. 59
5 Extended device functions .................................................................................................................... 61
5.1 Monitoring functions .................................................................................................................... 61
5.1.1 Overview of the monitoring functions.......................................................................................... 61
5.1.2 Temperature monitoring/display ................................................................................................. 62
5.1.3 Watchdog (WD) with LED ........................................................................................................... 62
5.1.4 Fan monitoring ............................................................................................................................ 63
5.1.5 Battery monitoring ....................................................................................................................... 63
5.1.6 Drive monitoring .......................................................................................................................... 63
5.2 Active Management Technology (AMT)...................................................................................... 64
5.3 Trusted Platform Module (TPM).................................................................................................. 65
6 Expanding and assigning parameters to the device............................................................................... 67
6.1 Retrofitting instructions................................................................................................................ 67
6.2 Open the device. ......................................................................................................................... 69
6.3 Expanding memory ..................................................................................................................... 71
6.3.1 Removing and installing memory modules ................................................................................. 71
6.4 Expansion cards.......................................................................................................................... 74
6.4.1 Notes on the expansion cards .................................................................................................... 74
6.4.2 Removing and installing expansion cards................................................................................... 75
6.5 Drives .......................................................................................................................................... 76
6.5.1 Installation options of drives........................................................................................................ 76
6.5.2 Removing and installing drive fans ............................................................................................. 78
6.5.3 Removing and installing drives in the front drive cage ............................................................... 79
6.5.4 Removing and installing drives in the internal drive cage........................................................... 82
6.5.5 Removing and installing the drive in the fixed hard disk bay ...................................................... 83
6.5.6 Replacing a defective hard disk drive in the RAID system ......................................................... 84
7 Device maintenance and repair............................................................................................................. 87
7.1 Repair information....................................................................................................................... 87
7.2 Maintenance................................................................................................................................ 88
7.2.1 Maintenance intervals ................................................................................................................. 88
7.2.2 Replacing filters........................................................................................................................... 89
7.3 Managing RAID systems............................................................................................................. 90
7.3.1 Example for a RAID1 system during the boot phase of the system ........................................... 90
7.3.2 Example for a RAID5 system during the boot phase of the system ........................................... 90
7.3.3 RAID software ............................................................................................................................. 91
7.3.4 Checking the status of the RAID system .................................................................................... 91

Table of contents
SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA 7
7.3.5 Displaying a defective hard disk of a RAID system in the RAID software...................................92
7.3.6 Points to note if the hard disk in the RAID system is replaced when the computer is
turned off ......................................................................................................................................92
7.3.7 Integrating a new hard disk drive in the RAID system.................................................................93
7.3.8 Integrating a hot spare hard disk drive in the RAID system ........................................................95
7.4 Installing and removing hardware ................................................................................................96
7.4.1 Replacing device fan....................................................................................................................96
7.4.2 Replacing the backup battery ......................................................................................................98
7.4.3 Removing AC power supply.......................................................................................................100
7.4.4 Removing the redundant power supply .....................................................................................100
7.4.5 Replacing the redundant power supply completely ...................................................................101
7.4.6 Removing the bus board............................................................................................................102
7.4.7 Removing the OP.......................................................................................................................102
7.4.8 Removing the motherboard .......................................................................................................103
7.4.9 Replacing the processor ............................................................................................................104
7.5 Installing the software ................................................................................................................106
7.5.1 Sources for installation of the operating system ........................................................................106
7.5.2 Updating the operating system ..................................................................................................106
7.5.3 Installing drivers and software ...................................................................................................107
7.5.4 Installing Windows 7 or Windows Server 2008 R2 ....................................................................108
7.5.5 Setting up the language selection using the Multilanguage User Interface (MUI).....................111
7.5.6 Restoring the delivery state .......................................................................................................113
7.5.7 Installing the RAID controller software.......................................................................................114
7.5.8 CP 1616 onboard.......................................................................................................................114
8 Technical specifications ...................................................................................................................... 115
8.1 Certificates and approvals .........................................................................................................115
8.2 Directives and declarations........................................................................................................116
8.2.1 CE marking ................................................................................................................................116
8.2.2 ESD guideline ............................................................................................................................117
8.3 Dimension drawings...................................................................................................................119
8.3.1 Dimensional drawing of the device ............................................................................................119
8.3.2 Dimension drawing of the telescope rails ..................................................................................120
8.3.3 Dimension drawing of the expansion cards ...............................................................................121
8.4 Technical data............................................................................................................................122
8.4.1 General specifications................................................................................................................122
8.4.2 Ambient and environmental conditions......................................................................................127
8.4.3 Current and power requirements ...............................................................................................128
8.4.4 AC power supply ........................................................................................................................129
8.4.5 AC power supply, redundant......................................................................................................130
8.4.6 Technical data of the telescopic rails .........................................................................................130
8.5 Hardware description .................................................................................................................131
8.5.1 Motherboard...............................................................................................................................131
8.5.1.1 Structure and functions of the motherboard ..............................................................................131
8.5.1.2 Technical features of the motherboard ......................................................................................132
8.5.1.3 Position of the interfaces on the motherboard ...........................................................................134
8.5.1.4 External interfaces .....................................................................................................................135
8.5.1.5 Internal ports ..............................................................................................................................146
8.5.2 Bus board...................................................................................................................................154

Table of contents
SIMATIC IPC847D
8Operating Instructions, 01/2014, A5E32997454-AA
8.5.2.1 Bus board - Layout and principle of operation .......................................................................... 154
8.5.2.2 Pin assignment of the bus board connectors............................................................................ 156
8.5.2.3 Interrupt assignment of the slot connectors on the bus board.................................................. 161
8.5.2.4 Exclusive PCI hardware interrupt.............................................................................................. 162
8.5.3 System resources ..................................................................................................................... 163
8.5.3.1 Currently allocated system resources....................................................................................... 163
8.5.3.2 System resources used by the BIOS/DOS ............................................................................... 164
8.5.4 Displays and operator panel ..................................................................................................... 168
8.5.4.1 Operating panel - Layout and function...................................................................................... 168
8.5.4.2 Pin assignment of the OP connectors....................................................................................... 168
8.5.5 Communication processor CP 1616 onboard ........................................................................... 169
8.5.5.1 Introduction................................................................................................................................ 169
8.5.5.2 Firmware loader ........................................................................................................................ 171
8.5.5.3 Further actions in STEP 7/NCM PC.......................................................................................... 173
8.6 BIOS description ....................................................................................................................... 173
8.6.1 Overview ................................................................................................................................... 173
8.6.2 Starting BIOS Setup.................................................................................................................. 174
8.6.3 BIOS Setup menus ................................................................................................................... 175
8.6.4 Exit menu .................................................................................................................................. 176
8.6.5 BIOS update.............................................................................................................................. 177
8.6.6 BIOS Setup settings.................................................................................................................. 178
8.6.7 Alarm, error and system messages .......................................................................................... 182
8.6.7.1 Power On Self Test ................................................................................................................... 182
8.6.7.2 BIOS beep codes ...................................................................................................................... 184
8.7 Active Management Technology (AMT).................................................................................... 189
8.7.1 AMT basics................................................................................................................................ 189
8.7.2 Overview of AMT....................................................................................................................... 190
8.7.3 Enabling AMT, basic configuration ........................................................................................... 190
8.7.4 Advanced settings..................................................................................................................... 191
8.7.5 Resetting with Unconfigure ....................................................................................................... 191
8.7.6 Determining the network address ............................................................................................. 192
8.7.7 Forcing user consent................................................................................................................. 192
A Technical support.................................................................................................................................193
A.1 Service and support .................................................................................................................. 193
A.2 Troubleshooting ........................................................................................................................ 194
A.3 RAID system and device startup............................................................................................... 197
A.4 Notes on the use of third-party modules ................................................................................... 198
B Abbreviations.......................................................................................................................................199
Glossary ..............................................................................................................................................205
Index ...................................................................................................................................................217

SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA 9
Overview
1
1.1
Product description
SIMATIC IPC847D is an industrial PC in 19" rack format (4 HU) with high-performance
industrial functionality.
●Wide range of expansion options
●High degree of ruggedness
●Extensive product continuity
1.1.1
Scope of application
The SIMATIC IPC offers system integrators, cabinet designers, system engineers and
machine designers a 19" rack PC platform for high-performance applications and IT
applications on the control and cell level for:
●Process and visualization applications
●Industrial image processing
●Quality assurance and monitoring tasks
●Measurement, control and rule-based tasks
●Data acquisition and management
The SIMATIC IPC has CE certification for use in the industrial sector as well as in residential
and commercial areas and small businesses. In addition to the industrial applications,
therefore, it can also be used in building automation or in public facilities.

Overview
1.1 Product description
SIMATIC IPC847D
10 Operating Instructions, 01/2014, A5E32997454-AA
1.1.2
Highlights
Highly compatible to industrial standards:
●High operational vibration and shock resistance
●Wide operational temperature range
●High service friendliness
●Distinct diagnostic features
High-performance industrial functionality:
●Integrated PROFIBUS DP / MPI interface (optional, compatible with CP5622)
●Integrated PROFINET interface CP 1616 onboard (optional)
●PCI, PCIe I/O, PEG slots
PEG graphics and onboard graphics can be used simultaneously
●High flexibility and expansibility of components
High investment security:
●High continuity of the components/design
●Guaranteed spare parts availability for at least 5 years
High system availability:
●SIMATIC IPC DiagMonitor – PC diagnostics/message software by way of
OPC/SNMP/LAN
●SIMATIC IPC/PG Image Creator – data imaging software
●RAID based on SATA hard disks on-board
●RAID1 – redundant data storage on two hard drives, also "hot swap" in connection with
removable drive bays
Configuration hot-spare drive available for order.
●RAID5 – striping with parity on three hard disks, "hot swap" in connection with removable
drive bays
Configuration hot-spare drive available for order.
●Optional ECC memory module
●Redundant power supply with status message

Overview
1.1 Product description
SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA 11
1.1.3
Function
●Integrated programmable monitoring functions (program execution (watchdog), internal
housing temperature, fan speed)
●Enhanced diagnostic/messaging by way of Ethernet, e-mail, text, and for direct input in
SIMATIC software by way of OPC (optional using SIMATIC PC DiagMonitor):
–Operating hours counter
–Hard drive status, hot spare drives of a RAID system are not displayed
–System status (heartbeat)
–Automatic logging of all messages to a log file
–Option of remote monitoring of networked SIMATIC IPCs
●RAID1 (mirroring): For automatic data mirroring on two hard disks. Configurations with
hot-spare drive available for order.
●RAID5 (striping with parity): For increased memory capacity and improved data security
on three hard disks. Configurations with hot-spare drive available for order.

Overview
1.1 Product description
SIMATIC IPC847D
12 Operating Instructions, 01/2014, A5E32997454-AA
1.1.4
Features
General features
Design •19” rack, 4 HU
•Rugged panel-mount housing, all metal
•Prepared for mounting telescopic rails
•Horizontal and vertical mounting position is possible
•Tower installation by means of Tower Kit
•Lockable front cover as access protection
Enclosure •
Dust protection by means of overpressure ventilation using
bearing seated front fan through filter
•Enclosure cover fastened with a single screw
•Front fan can be exchanged without tools
•Card retainer for reliable operation of PC modules under
vibration and shock conditions
Drive bays •Front:
–3 × 5.25" or
–1 × 5.25" and maximum 3 × slimline removable drive
bays or
–4 × slimline removable drive bays
and 1 × slimline format for DVD burner
•Internal: 2 × 3.5" (fixed installation or in vibration-damping
drive cage)
Slots for expansion cards (long) Variant 1:
•7 × PCI
•3 × PCIe x4
•1 × PCIe x16
Variant 2:
•3 × PCI
•5 × PCIe x16
•3 × PCIe x4
total of up to 11 expansion cards simultaneously
Graphics •CRT (via DVI-I VGA adapter): up to 2560 × 1600 at 120
Hz / 32-bit color depth
•LCD via DVI-D: up to 2048 × 1152 at 60 Hz / 32-bit color
depth
•LCD via DisplayPort: up to 4096 × 1152 at 24Hz / 32-
bit color depth

Overview
1.1 Product description
SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA 13
General features
Interfaces
PROFIBUS/MPI 12 Mbps (electrically isolated, compatible with CP 5622),
optional
PROFINET
10/100 Mbps (CP 1616 onboard), three RJ45; optional
Ethernet 2 × 10/100/1000 Mbps (two RJ45)
Wake on LAN, Remote Boot and teaming are supported
USB
2 × front panel, 4 × rear panel, 1 × internal; (high current)
Serial
COM1 (V.24), COM2 (V24) optional
Parallel
LPT, optional
Monitor •1 × DVI-I (for DVI-D or VGA using cable adapter)
•2 × DisplayPort
•2 × DisplayPort / DVI-D/VGA with Dual Head graphics
card (optional)
Keyboard
PS/2
Mouse
PS/2
Audio
Microphone, Line out / Headset
Power supply 100 VAC to 240 VAC, wide range; with short-term power
failure backup in accordance with NAMUR: Max. 20 ms at
0.85 rated voltage
Monitoring functions
Temperature •Overshoot/undershoot of permissible operating
temperature
•Messages can be evaluated by an application program.
Fan •Speed monitoring
•Messages can be evaluated by an application program.
Watchdog •Monitoring of the IPC
•Monitoring time can be parameterized in software
•Restart can be parameterized in the event of a fault
•Messages can be evaluated by an application program.
Status LEDs •POWER (internal power supply unit, PC switched On)
•ETHERNET 1, ETHERNET 2 (Ethernet status)
•PN ΙMPI/DP (activity display of the PROFIBUS/MPI
interface, optional product feature or status display of the
CP 1616 onboard interface, optional product feature)
•WATCHDOG (Watchdog function/error display)
•TEMP (temperature status)
•FAN (speed monitoring)
•HDD0 Alarm, HDD1 Alarm, HDD2 Alarm, HDD | HDD3
Alarm: Access to hard disk and with RAID option: RAID
status message in conjunction with SIMATIC monitoring
software

Overview
1.1 Product description
SIMATIC IPC847D
14 Operating Instructions, 01/2014, A5E32997454-AA
Basic variant
Motherboard
Motherboard without fieldbus, Intel® DH82C226 Express Chipset
Bus board
PCI, PCIe x4, PCIe x16, 2 variants
Processor •Intel® Xeon™ E3-1268L v3 2.3 (3.3) GHz, 4 cores, GT2, 8 MB SLC,
HT
•Intel® Core™ i5-4570TE 2.7 (3.3) GHz, 2 cores, GT2, 4 MB SLC, AMT
•Intel® Core™ i3-4330TE 2.4 GHz, 2 cores, GT2, 3 MB SLC, AMT
RAM expansion up to 32 GB SDRAM DDR3 1600MT/s
4 DIMM socket without or with ECC
1
Drives
Hard disks
3.5" SAS 6 Gbps, 500 / 1000 GB
Optical drive
Slimline SATA
Operating system
without
1 memory expansions ≥4 GB can only be used in combination with 64-bit operating systems.
Optional accessories
PROFIBUS/MPI
12 Mbps (isolated potential, compatible to CP 5622)
PROFINET
10/100 Mbps (CP 1616 onboard, three RJ45)
Drives
DVD burner Read:
DVD ROM: Single Layer8x, Dual Layer 6x
DVD-R/+R: Single Layer8x, Dual Layer 6x
DVD-RW/+RW 8x, DVD-RAM 5x
CD-ROM/CD-R Read 24x, CD-RW 24x
Write:
DVD+R 8x, DVD+RW 8x, DVD-R 8x, DVD-RW 6x
DVD+R (DL) 6x, DVD-R DL 2x
CD-R 24x, CD-RW 24x
Hard disks 3.5" (SATA) Installation in internal drive cage (fixed or vibration-damping)
•500 / 1000 GB (SATA)
•2 × 1000 GB (SATA)
RAID1: 1000 GB (2 × 1000 GB, SATA)
Installation in the front drive cage of the removable drive bay
•500 GB (SATA)
•1000 GB (SATA)
•2 × 1000 GB (SATA)
•RAID1**: 1000 GB (2 × 1000 GB, SATA)
•RAID5**: 2TB (3 × 1000 GB, SATA)
** An additional hot-spare drive or additive SSD drive can be
ordered as an option.
Solid State Drive 2.5" (SATA) •240 GB MLC
Graphics cards
PCIe x16 graphics card, dual head (2 × VGA or 2 × DVI-D)

Overview
1.1 Product description
SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA 15
Optional accessories
DVI-I to VGA adapter Used to connect a monitor with a VGA port to the PC (can be
ordered by configurator).
Operating system Preinstalled and activated / included on restore DVD
•Windows Server 2008 R2, MUI*, 64-bit
•Windows 7 MUI*, 32 bits / 64 bits
*MUI:
M
ulti language
U
ser
I
nterface; 5 languages (German,
English, French, Spanish, Italian)
Power supply
Redundant AC power supply
Monitored 100–230 V AC power supply, 350 W
Operating system languages
The following languages for the operating system can be installed at a later time from the
recovery DVD:
Language
Windows Server 2008 R2
Windows 7
32/64-bit
German
X
X
English
X
X
French
X
X
Italian
X
X
Spanish
X
X
Japanese
X
X
Chinese (Hong Kong)
X
X
Chinese (simplified)
X
X
Chinese (Taiwan) X
Korean
X
X
Russian
X
X
Optional software
SIMATIC IPC DiagMonitor V4.4.2 or
higher
Software tool for monitoring local and remote SIMATIC PCs:
•Watchdog
•Temperature
•Fan speed
•Hard disk monitoring (SMART, RAID status 1)
•Monitoring modules of the redundant power supply
•System / Ethernet monitoring (Heartbeat)
SIMATIC IPC Image & Partition
Creator V3.3.2 or higher
Software tool for local data backup and setting up of the hard
disks.
1A hot-spare drive of a RAID system is not displayed.

Overview
1.2 Design of the device
SIMATIC IPC847D
16 Operating Instructions, 01/2014, A5E32997454-AA
1.2
Design of the device
1.2.1
Device views
Front view of the device (example)
Item
Description
①Front panel with vent openings (filter pad
and fan behind the front panel).
②
Status displays
③
Cover screws
④
On/off button
⑤
Reset button
⑥Lock
•Key vertical: open
•Key horizontal: closed
⑦Installation option for hard disk removable
drive bay or 5.25" hard disks
⑧
Installation option for optical drive
(slimline), e.g., DVD
⑨USB interface: 1 × USB 3.0, 1 × USB 2.0
(left on the front door)
⑩
Lockable front door for access security.
Lock the front door during normal
operation with the lock
⑥
.
Rear view of the device (example)
Item
Description
①
Ventilation
②Bay for power supply (optional, e.g.,
redundant power supply)
③
Expansion card slots
④
Interfaces
⑤
Power supply mains connection

Overview
1.2 Design of the device
SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA 17
1.2.2
Operator Controls
WARNING
Fire hazard and electrical shock hazard
The on/off button and on/off switch(es) do not disconnect the device from the mains. A fire
hazard exists in case of a short circuit. An electrical shock hazard exists inside the device.
Unplug all power cords from the device when you open it or take it out of service.
Note
Data loss is possible when you operate the reset button.
Operator control element
Item
Description
①On/off button
Used to switch the device on or off.
Note: The device rear has one or 2 line side
switches ③. These have to be switched on so
that the on/off button at the front functions.
②Reset button
The reset button can be operated using a
pointed object, for example, an open paper clip.
You trigger a hardware reset when you operate
the button. The device restarts (cold start).
③
On/Off switch (simple power supply)
Used to connect the device to the mains.
Depending on the "After G3 On" BIOS setting,
the device may turn on automatically.
Otherwise, you may have to operate the on/off
button ①on the front.

Overview
1.2 Design of the device
SIMATIC IPC847D
18 Operating Instructions, 01/2014, A5E32997454-AA
Operator control element
Item
Description
③On/Off switch (redundant power supply)
Used to connect the device to the mains.
Depending on the "After G3 On" BIOS setting,
the PC may turn on automatically. Otherwise,
you may have to operate the on/off button ①
on the front.
④Acknowledgment button (redundant power
supply)
The acoustic error signal is deactivated when
the button is pressed.

Overview
1.2 Design of the device
SIMATIC IPC847D
Operating Instructions, 01/2014, A5E32997454-AA 19
1.2.3
Interfaces
Layout of the interfaces on the rear of the device

Overview
1.2 Design of the device
SIMATIC IPC847D
20 Operating Instructions, 01/2014, A5E32997454-AA
Layout of the interfaces on the rear of the device
Item
Name
Description
①PROFIBUS/MPI PROFIBUS interface, compatible to CP5622 (RS 485, electrically isolated), 9-pin D-sub
socket (optional product characteristic)
PROFINET
CP-1616 onboard interface, three RJ45 sockets (optional product version)
②USB Sockets on left: Connection for USB 2.0 devices
Sockets on right: Connection for USB 3.0/USB 2.0 devices
USB 2.0 and USB 3.0 connections use different USB ports.
③
ETHERNET 1 1, 2 2 x RJ45 connectors, Ethernet 10/100/1000 Mbps (ETHERNET 1 is AMT-capable)
④COM Serial interface (V.24), 9-pin sub D plug, COM2 (optional)
⑤
LPT Parallel interface, 25-pin (optional)
⑥DP Two DisplayPort interfaces for CRT or LCD monitor with DP interface, CRT or LCD monitor
with VGA interface via DP->VGA adapter (optional)
⑦
KEYBOARD Connection for a PS/2 keyboard
⑧
MOUSE Connection for a PS/2 mouse
⑨DVI-I DVI/VGA port for CRT or LCD monitor with DVI interface, VGA via DVI/VGA adapter
⑩
Audio (input) Connection for analog audio source, microphone, 3.5 mm phono jack
⑪
Audio (output) Connection for active speakers or headset, 3.5 mm phono jack
⑫Connecting
potentials
Connection for equipotential bonding
⑬
Expansion slots Slots for expansion cards (behind slot cover)
1
For unique labeling, the LAN interfaces are numbered on the enclosure. The numbering by the operating system may
deviate from this.
Dual-head adapter for connection of two monitors to the optional graphics card 2
⑭DMS59 connector DMS59 connection
⑮
DVI-I connector DVI-I connections
⑯
VGA connector VGA connections
2Not shown in figure
