Siemens RAR Series User manual

CC1N7713en
15.06.2016
Building Technologies Division
7713
Photocell Detectors RAR...
The photocell detectors are designed for use with burner controls, for the super-
vision of yellow-flame oil flames.
They are used especially in connection with burner controls for the control and
supervision of large-capacity burners.
The RAR... and this Data Sheet are intended for use by OEMs which integrate the
flame detectors in their products!
Use The RAR... flame detectors are used for the supervision of yellow-burning oil flames.
They are designed for use with the following types of burner controls: LAL..., LAE1...,
LAE10..., LOK16..., LFS1.1...
2/6
Building Technologies Division CC1N7713en
15.06.2016
Warning notes
To avoid injury to persons, damage to property or the environment, the following
warning notes must be observed!
Do not open, interfere with or modify the flame detector!
All activities (mounting, installation and service work, etc.) must be performed by
qualified staff
Before making any wiring changes in the connection area, completely isolate the
plant from mains supply (all-polar disconnection). Ensure that the plant cannot be
inadvertently switched on again and that it is indeed dead. If not observed, there is
a risk of electric shock hazard
Ensure protection against electric shock hazard by providing adequate protection
for the connection terminals. If this is not observed, there is a risk of electric shock
Each time work has been carried out (mounting, installation, service work, etc.),
check to ensure that wiring is in an orderly state. If this is not observed, there is a
risk of loss of safety functions and a risk of electric shock
Fall or shock can adversely affect the safety functions. Such flame detectors or
burner controls must not be put into operation, even if they do not exhibit any dam-
age. If this is not observed, there is a risk of loss of safety functions and a risk
of electric shock
Mounting notes
Ensure that the relevant national safety regulations are complied with
The flame detector plugs into the burner (the detector’s clamp engages on the
burner’s light metal flange)
Installation notes
Always run the high-voltage ignition cables separate from the unit and other cables
while observing the greatest possible distances
Electrical connection of the flame detector
It is important to achieve practically disturbance- and loss-free signal transmission:
Never run the detector cable together with other cables
– Line capacitance reduces the magnitude of the flame signal
– Use a separate cable
Observe the permissible detector cable lengths (refer to Type summary and Tech-
nical Data)
3/6
Building Technologies Division CC1N7713en
15.06.2016
Commissioning notes
The intensity of light radiation on site is checked by measuring the detector current.
4
5
LFS1.1..
.
22 24
22 24
910
1314
LOK16...
LAE1...
LAE10...
+
M
RAR +
7
7
1
3
v
0
1
/
0
6
1
6
A
A Incidence of light
M Microammeter (DC), internal resistance 5,000 
For the minimum detector currents required, refer to the Data Sheet of the relevant
burner control.
Standards and certificates
Note!
Only in connection with burner controls!
EAC Conformity mark (Eurasian Conformity mark)
ISO 9001:2008
ISO 14001:2004
OHSAS 18001:2007
China RoHS
Hazardous substances table:
http://www.siemens.com/download?A6V10883536
Service notes Each time a unit has been replaced, check to ensure that wiring is in an orderly state
and that the wires are firmly connected.
Disposal notes The flame detector contains electrical and electronic components and must not be dis-
posed of together with household waste.
Local and currently valid legislation must be observed.
Mechanical design
Housing made of dust-proof duroplast
Photocell is under protective glass
Flame detector can be supplied with or without flange (version 4 241 8855 0) and
clamp (refer to «Type summary»)
Measuring circuit for
measuring the detector
current
Legend
4/6
Building Technologies Division CC1N7713en
15.06.2016
Type summary
Artikel-Nr. Type
reference Length of
detector cable *) Clamp and flange Photocell
made of
BPZ:RAR9 RAR9 Max. 100 m Without clamp / flange Silicon
BPZ:RAR9(1) RAR9(1) Max. 100 m With clamp and flange with radius Silicon
BPZ:RAR9(2) RAR9(2) Max. 100 m With clamp and flange straight Silicon
*) The information in the data sheet for the relevant burner control also apply
When ordering, please give the type reference according to «Type summary».
Accessories (to be ordered separately)
Item Part number
Flange with radius 4 241 8855 0
Flange straight 4 241 8898 0
Clamp 4 199 8806 0
Type reference Description
AGG09
IP40 Kit for RAR...
- Cable sealing element Ø 5...8 mm
5/6
Building Technologies Division CC1N7713en
15.06.2016
Technical data Safety class II
Degree of protection IP20
Note!
IP40 to DIN EN 60529, at relative
design of cable entry (e.g. AGG09)
Mounting position optional
Weight approx. 85 g
Cable connection Screw terminals for min. 0.5 mm² and max.
1,5 mm² wire cross section
Cable with ferrules
A
dapt at stranded wire cross section
Detector cable Supplied by customer
Cable type Recommended: H05VV-F 2 x 0.75
A
pplication standards should be observed.
Storage DIN EN 60 721-3-1
Climatic conditions class 1K3
Mechanical conditions class 1M2
Temperature range -20...+60 °C
Humidity < 95 % r.F.
Transport DIN EN 60 721-3-2
Climatic conditions class 2K2
Mechanical conditions class 2M2
Temperature range -20...+60 °C
Humidity < 95 % r.h.
Operation DIN EN 60 721-3-3
Climatic conditions class 3K5
Mechanical conditions class 3M2
Temperature range -20...+60 °C
Humidity < 95 % r.h.
Installation altitude Max. 2,000 m above sea level
Warning!
Condensation, formation of ice and ingress of water are not permitted!
If not observed, the safety functions are no longer ensured and there will be a
risk of electric shock!
Function With this type of flame supervision, the radiation of oil flames in the visible band of the
light spectrum is used for generating the flame signal. The light-sensitive element is a
photocell. When illuminated, it generates DC voltage, causing a current to flow to the
input of the flame signal amplifier. Hence, the RAR... is an active detector. The photo-
cell is insensitive to infrared radiation so that glowing firebrick in the combustion cham-
ber cannot produce a flame signal.
General data
Environmental
conditions
Dimensions Dimensions in mm
130
49...73 2,5
30
48 18
ø23
18
ø22,5
M4
7713m01/0597
10
4 199 8806 0
Clamp for direct mounting on the burner
M4 E2 DIN 7952
4,2
A
4
Ø4,3
25°
A
ca.Ø21
Ø22
A-A
3
R0,1
1
5,5
8,4
-0,2
12
7713m02/0716
4 241 8855 0
36
24.3
R0.3
10
R2
7
R2
R4
1824
48
3
3
15 30
25°
Company logo to
LN 3 8380 0102
0.2 mm elevated
7712m09e/1001
4 241 8898 0
7
25°
3
36 18
15 30
R4
310 24
48
Company logo to
LN 3 8380 0102
0.2 mm elevated
7712m10e/1001
Accessories
Ordering Information: Part No. SBRAR9(1)
