Siemens RDD10 Series User manual

CE1N3031en
24.09.2003
Siemens Building Technologies
HVAC Products
3031
Room Temperature Controllers
with LCD
RDD10...
for heating systems
2-position control with ON / OFF output for heating
Operating modes: normal operation and energy saving mode
Automatic operating mode change over as an option
Mains-powered AC 230 V (RDD10) or battery-powered DC 3 V (RDD10.1)
Use
The RDD10... is used for the control of the room temperature in heating systems.
Typical applications:
• Apartments
• Commercial spaces
• Schools
For the control of the following pieces of equipment:
• Thermic valves or zone valves
• Gas or oil burners
• Fans
• Pumps

2/8
Siemens Building Technologies Room temperature controllers CE1N3031en
HVAC Products 24.09.2003
Functions
The controller acquires the room temperature with its integrated sensor and maintains
the setpoint by delivering control commands. The switching differential is 1 K.
Q14
T[°C]
ON
OFF W
SD
3031D01
T Room temperature
SD Switching differential
W Room temperature setpoint
Q14 Output signal for heating
Operating modes
The RDD10... provides normal operation and, optionally, energy saving mode or OFF.
The difference between normal operation and energy saving mode is only the room
temperature setpoint. The changeover from normal operation to energy saving mode,
and vice versa, is made by pressing a button.
When normal operation is activated, symbol “ “ appears on the display. The setpoint
can be readjusted by pressing buttons +and -.
When energy saving mode is activated, symbol “ “ appears on the display. The set-
point can be readjusted by pressing buttons +and -. When the energy saving set-
point is set to “ 0 ”, the controller is switched off, that is, the RDD10... is not active in
energy saving mode. In that case, symbol “ “ does not appear.
When this function is activated and a manual changeover has been made, the operat-
ing mode will automatically be reset on completion of an adjustable period of time. This
period of time can be adjusted with buttons +and -after pressing the hour glass
button.
The operating action of the reset depends on the setting of the DIL switch, from normal
operation to energy saving mode / OFF, or vice versa. The operating mode can be
manually reset before the delay time has elapsed. When the delay is active, the hour
glass symbols appears on the display.
The digital display shows the actual room temperature and the symbol of the operating
mode currently active. When the heating output is activated, the triangle symbol ap-
pears. When the function “automatic operating mode change over” is activated, the
hour glass symbol is shown.
Display in normal operation Display in energy saving mode
Normal operation
Energy saving mode
or OFF
Automatic operating
mode change over
Display

3/8
Siemens Building Technologies Room temperature controllers CE1N3031en
HVAC Products 24.09.2003
Type summary
Type reference Features
RDD10 Mains-powered AC 230 V
RDD10.1 Battery-powered DC 3 V
Ordering
When ordering, please give name and type references, e.g. room temperature con-
troller RDD10.
Valve actuators are to be ordered as separate items.
Equipment combinations
Type of unit Type reference Data sheet
Motoric on/off actuator SFA21... 4863
Thermal actuator (for radiator valve) STA21... 4893
Thermal actuator (for small valve 2,5 mm) STP21... 4878
Accessories
Description Type reference
Adapter plate 120 x 120 mm for 4“ x 4“ conduit boxes ARG70
Adapter plate 96 x 120 mm for 2“ x 4“ conduit boxes ARG70.1
Adapter plate for surface wiring 112x130 mm ARG70.2
Mechanical design
The unit consists of two parts:
• A plastic housing with digital display, which accommodates the electronics, the
operating elements and the built-in room temperatures sensor
• A mounting base
The housing engages in the mounting base and snaps on.
The base carries the screw terminals. The DIP switch is located at the rear of the hous-
ing.
3031Z01
.
.
.
.
.
.
.
.
.

4/8
Siemens Building Technologies Room temperature controllers CE1N3031en
HVAC Products 24.09.2003
1 Display of the room temperature, setpoints or operating mode changeover time
2 symbol when actual room temperature is displayed
3 Normal operation
Energy saving mode
4 symbol when displaying the operating mode changeover time or when the oper-
ating mode changeover function is activated
5 heating on
6 symbol indicating that batteries need to be replaced
(only with battery-powered versions)
7 Buttons for adjusting the setpoint and the operating mode changeover time
8 Button for operating mode changeover “Normal operation ↔energy saving
mode”
9 Button for adjusting the operating mode changeover time
10 Battery compartment (only with battery-powered versions)
The required room temperature setpoints for normal operation and energy saving mode
and the operating mode changeover time are adjusted with buttons. Operating mode
changeover can be triggered by pressing a button.
The operating action for the automatic operating mode changeover function is selected
with a DIP switch.
DIP switch
no.
Meaning Position ON Position OFF
1 Operating action of
automatic operating
mode changeover
Automatic operating
mode changeover from
normal operation to en-
ergy saving mode or OFF
Automatic operating
mode change over from
energy saving mode or
OFF to normal operation
Notes
The room temperature controller should be mounted in a location where the air tem-
perature can be measured as accurately as possible without getting adversely affected
by direct solar radiation or other heat or refrigeration sources.
Mounting height is about 1.5 m above the floor.
The unit can be fitted to a recessed conduit box.
• Only authorised staff may open the controller.
Caution: AC 230 V!
• The cables used must satisfy the insulation requirements with regard to mains
potential
When mounting the unit, fix the baseplate first. Then, make the electrical connections
and fit and secure the cover (also refer to Mounting Instructions).
The controller must be mounted on a flat wall and in compliance with local regulations.
Legend
Mounting, installation
and commissioning

5/8
Siemens Building Technologies Room temperature controllers CE1N3031en
HVAC Products 24.09.2003
If there are thermostatic radiator valves in the reference room, they must be set to their
fully open position.
The controller is maintenance-free.
If the temperature on the display does not agree with the room temperature effectively
measured, the temperature sensor can be recalibrated. For that purpose, both buttons
+and must be pressed simultaneously for 3 seconds. Then, the temperature
displayed can be changed by a maximum of +/- 3 Kelvin by pressing the +and -
buttons. Five seconds after the last push of a button, the controller will automatically
return to the normal operational statuses.
If the battery symbol appears, the battery power is almost exhausted and the batteries
should be replaced.
Technical data
Operating voltage
• RDD10 at L - N AC 230 V +10/-15 %
• RDD10.1 DC 3 V (2 x 1.5 V AAA Alkaline batteries)
Frequency (RDD10) 50 or 60 Hz
Power consumption (RDD10) 4VA
Battery life (RDD10.1) > 1 years (AAA Alkaline batteries)
Control output Q12 (N.C. contact)
Rating RDD10 (AC 230 V) max. 5 A
Rating RDD10.1 (AC 24...250 V) max. 5(2) A
Control output Q14 (N.O. contact)
Rating RDD10 (AC 230 V) max. 5 A
Rating RDD10.1 (AC 24...250 V) max. 5(2) A
Switching differential SD 1 K
Setpoint setting range 5…35 °C (normal operation)
0 (OFF) and 5…35 °C (energy saving mode)
Increments 0.5 °C
Factory setting normal operation 20 °C
Factory setting energy saving mode 8 °C
Setting range of operating mode
changeover time 0.5…24 h
Increment 0.5 h
Factory setting 0 h (not activated)
Operation to IEC 721-3-3
Climatic conditions class 3K5
Temperature 0…+50 °C
Humidity <95 % r. h.
Transport to IEC 721-3-2
Climatic conditions class 2K3
Temperature -25…+60 °C
Humidity <95 % r. h.
Mechanical conditions class 2M2
Storage to IEC 721-3-1
Climatic conditions class 1K3
Temperature -25…+60 °C
Humidity <95 % r. h.
Maintenance
Sensor calibration
Change of batteries
(only with battery-
powered versions)
Power supply
Control outputs
Functional data
Environmental conditions

6/8
Siemens Building Technologies Room temperature controllers CE1N3031en
HVAC Products 24.09.2003
conformity to
EMC directive 89/336/EEC
Low voltage directive 73/23/EEC and 93/68/EEC
N474 C-Tick conformity to
EMC emission standard
AS/NSZ 4251.1:1994
Product standards
Automatic electrical controls for EN 60 730 – 1 and
household and similar use EN 60 730 – 2 - 9
Electromagnetic compatibility
Emissions EN 50 081-1
Immunity EN 50 082-1
Safety class II to EN 60730
Pollution class normal
Degree of protection of housing IP30 to EN 60529
Connection terminals for use solid wires or prepared stranded wires
2 x 1.5 mm2or 1 x 2.5 mm2(min. 0.5 mm2)
Weight 0.20 kg
Colour of housing front white, NCS S 0502-G (RAL9003)
Norms and standards
General

7/8
Siemens Building Technologies Room temperature controllers CE1N3031en
HVAC Products 24.09.2003
Connection diagram
L
N
Y1
3031A01
N1
Q14
Q11
Q12
N
L
L
N
Ln
Lx
Nx
Y1
3031A02
N1
Q14
Q11
3V
Q12
RDD10 RDD10.1
N1 Room temperature controller
Y1 Regulating unit
L, Ln Live, AC 230 V
N Neutral, AC 230 V
Lx Live, AC 24 ... 250 V
Q11, Q12 N.C. contact (for N.O. valves)
Q11, Q14 N.O. contact (for N.C. valves)
Nx Neutral, AC 24 ... 250 V
Application examples
T
T
F1
F2
N1
M1
Y2
2222S01
T
T
F1
F2
N1
M1
Y2
2222S02
T T
Room temperature controller with direct
control of a gas-fired wall-hung boiler
Room temperature controller with direct
control of a gas-fired floor-standing boiler
T
N1
Y1
2222S03
M1
Room temperature controller with direct
control of a heating circuit pump (pre-control
by manual mixing valve)
F1 Thermal reset limit thermostat
F2 Safety limit thermostat
M1 Circulating pump
N1 RDD10... room temperatures controller
Y1 3-point valve with manual adjustment
Y2 Magnetic valve

8/8
Siemens Building Technologies Room temperature controllers CE1N3031en
HVAC Products 24.09.2003
Dimensions
96
119
23,8
3031M01
89,45
4
3031M02
28 28
2828
26 30
3530
11,8
112,3
4
Controller
Baseplate
