Siemens QAX32.1 User manual

CA2N1641
en_03
2015
-12-23
Building Technologies
1641
Desigo
™ RX
Room unit with PPS2
interface
QAX32.1
for use with:
– devices of the ranges Desigo RXC, RXB, RXL, and RXA (PPS2)
–Desigo PX Automation stations 1)
– devices with a PPS2 interface
•Room temperature measurement
•Room temperature setpoint adjuster
•Control mode selector switch ( / Auto)
•PPS2 interface to controller
•Socket for commissioning and service tool or service terminal
Use
The room unit is used in rooms controlled by an individual room control system, to
measure the room temperature and for operation of a room controller.
It can also be used in conjunction with a Desigo PXC… automation station 1).
The room unit incorporates a socket for a commissioning and service tool or service
terminal. This tool socket provides access via the PPS2 interface or via a bus system
(e.g. LONWORKS® bus) to the connected individual room controller.
1) If room units QAX32.1, QAX33.1, QAX34.1 or QAX84.1 are used in conjunction with a PXC
automation station, the room unit will show the request of the user and not the effective state.

2/6
Siemens QAX32.1 – Room unit with PPS2 interface CA2N1641en_03
Building Technologies 2015-12-23
Ordering
When ordering, please specify the quantity, product name and type code.
Example:
30 Room units QAX32.1
Equipment combinations
The room unit is suitable for use in conjunction with all controllers which incorporate a
PPS2 room unit interface (e.g. Desigo RX, Desigo PX).
Mechanical design
The room unit is designed for surface mounting (with knock-outs for cable entry from
the top or bottom) or for mounting on a recessed conduit box with the cables connected
from the rear.
The unit comprises a housing and base unit, connected by releasable snap-fittings.
The base unit accommodates the screw terminals which have an integrated terminal
strip.
The housing accommodates a printed circuit board, room temperature sensor element,
setpoint adjuster, rocker switch for mode selection, plug-in connectors and a socket for
the commissioning and service tool or service terminal.
Both the housing and base are made of plastic.
Base unit
Housing
80082
80084
Socket for the commissioning
and service tool or service
terminal
80167A
Dial for stepless adjustment of the setpoint
LEDs to indicate control mode
Rocker switch for mode selection
The controller control mode can be selected on the basis of occupancy, using the
rocker switch on the room unit (press left or right arrow). The current control mode is
indicated by a LED.
Position
Control mode 1)
The controller operates at the setback setpoints (at night, or when room is
unoccupied or occupied intermittently)
Auto
Comfort mode (room occupied)
1) For details of these functions, refer to the application description for the relevant controller range.
Operator controls
and indication
Rocker switch for mode
selection

3/6
Siemens QAX32.1 – Room unit with PPS2 interface CA2N1641en_03
Building Technologies 2015-12-23
01884
Address plugs inside the housing
They allow setting the address in cases where several
room units are connected to one controller.
The room units are delivered with address 1.
Disposal
The device is classified as waste electronic equipment in terms of the European
D
irective 2012/19/EU (WEEE) and should not be disposed of as unsorted municipal
waste
.
The relevant national legal rules are to be adhered to.
Regarding disposal, use the systems setup for collecting electronic waste.
Observe all local and applicable laws.
Engineering notes
The device receives its power from the connected controller via the PPS2 interface
(extra low voltage). Only one room unit may be connected to a RX… room controller.
A maximum of 5 room units may be connected to a PXC… automation station (they are
identified by different settings of their address plugs)
A twisted-pair cable is required for the connection to the controller.
Desigo RX uses four-core cables, Desigo PX uses two-core cables (see the respective
installation guides). Screening is not required.
Mounting
•The room unit is suitable for wall-mounting and for mounting on a recessed conduit
box.
•Do not mount in recesses, shelves, behind curtains or doors, or above or near heat
sources.
•Avoid exposure to direct sunlight or draughts.
•The electrical wiring conduit must be sealed where it joins the room unit, to prevent
the occurrence of draughts in the conduit which could affect the sensor.
•The specified ambient conditions must be complied with.
•Mounting instructions are printed on the room unit packaging.
•A mounting kit is included with the unit.
Installation notes
Local installation regulations must be observed.
The room unit is not protected against connection to AC 230 V.
Address plugs
STOP
Note!

4/6
Siemens QAX32.1 – Room unit with PPS2 interface CA2N1641en_03
Building Technologies 2015-12-23
Commissioning notes
After an interrupt of the PPS2 interface the communication will only be re-established
when the connected controller polls the PPS2 addresses. The duration of the
corresponding cycle is:
RXA: 10 sec; RXB, RXL and RXC: 3 min; PX: 30 sec.
The following routine occurs in the room unit when the power supply is connected (via
the PPS2 interface) or after a reset via the controller:
Step
Function
Description
1
LED test
The LEDs are operated in sequence for 1 s each
2 Device
ready
After a delay of 1 s the device will be ready for PPS2
communication. The actual control mode is displayed after a
further delay of 5 s.
Technical data
Supply voltage
Operating voltage range
DC 12...15 V
(SELV)
DC 12…15 V class 2 (US)
The room unit receives its power from the connected controller, via the PPS2 interface
Power consumption (from controller)
Max. 0.10 VA
Function data
Temperature sensor
Measuring element
NTC resistor
Measuring range
0 ... 40 °C
Response time
≤8 min
Accuracy (5 ... 30 °C)
±0.5 K
Accuracy (25 °C)
±0.25 K
Setpoint correction
Correction range (determined by controller)
max. ±12 K (default ±3 K)
Accuracy over full correction range
10 %
Indication (control mode)
2 LEDs, yellow
Interfaces
Type of interface between controller and
room unit
PPS2
(point-to-point interface, Version 2)
Baud rate
4.8 kbit/s
Cable connections
Connection terminals (screw terminals)
Stranded or solid conductors
0.8 ... 2.5 mm
2
Single cable length controller
– Room unit
See Installation guidelines:
Desigo
RXC: CA110334,
Desigo
RXB & RXL: CM110381
Desi
go RXA: CA2Z3884
Desigo PX: CA110396
Cable type
2
-core or 4-core, twisted pairs,
unscreened
Connecting cable for service tool
Off-the-shelf, max. 3 m
Protection data
Housing protection
IP 30 to EN 60529
Protection class
III to EN 60730-1
Ambient conditions
IEC 721
Operation
Transport
Ambient air conditions
Class 3K5
Class 2K3
Temperature
0 ... 50 °C
– 25 ... 70 °C
Humidity
< 85 %rH
< 95 %rH
Mechanical conditions
Class 3M2
Class 2M2
Response on start-up

5/6
Siemens QAX32.1 – Room unit with PPS2 interface CA2N1641en_03
Building Technologies 2015-12-23
Standards, directives
and
approvals
Product standard
EN 60730-1
Automatic electrical controls for
household and similar use
Electromagnetic compatibility (Applications)
For use in residential, commerce, light
-
industrial and industrial environments
EU conformity (CE)
CA2T1741xx *)
UL certification (US)
UL916, http://ul.com/database
RCM-conformity (EMC)
A5W00005055 *)
EAC conformity
Eurasia conformity
Environmental
compatibility
Product environmental declaration (co
ntains
data on RoHS compliance, material
s compo-
sition, packaging, environmental benefit,
disposal)
A6V10736277_en
--_a *)
Dimensions
See “Dimensions”
Color
Housing front, dial
NCS S 0502-G, ≈RAL 9003 signal white
Housing, base unit, rocker switch
RAL 7035 light grey
Weight
Excluding packaging
0.12 kg
*) The documents can be downloaded from http://siemens.com/bt/download.
Connection
terminals
The tool socket on the room unit provides access to the connected individual room
controller via the commissioning and service tool or the service terminal.
The bus cable (Terminals 3 and 4) is therefore looped to the tool socket (Pins 1 and 2).
The bus cable is not affected by the room unit.
For connection of a service terminal, the PPS2 interface (Terminals 1 and 2) is also
connected to the tool socket.
87654321
C– C+ CP– CP+
80085
PPS2 interface, supply voltage
CP+ 1 Device supply, Data PPS2 (pos.)
CP– 2 Device supply, Data PPS2 (neg.)
Bus connection (looped to tool socket)
C+ 3 With LONWORKS® bus (Desigo RXC): CLA
C– 4 With LONWORKS® bus (Desigo RXC): CLB
5 ... 8 Not used
Standard type RJ45 tool socket.
1
3206Z01
2 3 4 5 6 7 8
With L
ON
W
ORKS
® bus (Desigo RXC): CLA
With LONWORKS® bus (Desigo RXC): CLB
Not used
Not used
Not used
Not used
CP+ Data PPS2
CP– Data PPS2
Terminal layout
Tool socket

6/6
Siemens QAX32.1 – Room unit with PPS2 interface CA2N1641en_03
Building Technologies 2015-12-23
Connection diagram (Example: RXC)
The following example shows the room unit connected to a Desigo RXC room
controller:
1741A03
PPS2
Tool
A
R1
B
7 8 1 2
4321
C– C+ CP– CP+
N1
CP+ CP– CLA CLB
PPS2
LonWorks® Bus
= Twisted pair
R1 Room unit QAX32.1
N1 Room controller RXC...
A Connection for RXT10 commissioning and service tool
B Connection for service terminal with PPS2 interface
Dimensions
9,5
32
36
4,2
60
80087
90
100
56 60
56
Published by:
Siemens Switzerland Ltd.
Building Technologies Division
International Headquarters
Gubelstrasse 22
6301 Zug
Switzerland
Tel. +41 41
-724 24 24
www.siemens.com/buildingtechnologies
© Siemens Switzerland Ltd 2000
Delivery and technical specifications subject to change
All dimensions in mm
