SIGE wilson & bradley KAOS ART K100 User manual

X
Z
Min.520
REV 00.2022
F0IST00198
ART K100
SIGE SLIDES
MADE AND ASSEMBLED IN ITALY
KAOS
Pull out frame, slides with soft closing and adjustable spacers.
N°4 M5x10 T.c.e.i. Screw
N°8 6,3x14 T.c. Euroscrew
N°1 Key exagonal
A. N°1Frame / Châssis / Marco
B. N°1Lateral spacer Sx
C. N°1Lateral spacer Dx
D. N°1 Slide kit
E. N°1 L.2.5m Rubber gasket
MAINTENANCE
TOOLS
PARTS
FITTINGS
FEATURES
Clean with a soft, dry cloth. Avoid using solvents or abrasive.
7
KG
7
KG
A
B
C
D
E
H 58 H 128
Z min 250 min 320
WEB SITE
L. CABINET X MIN X MAX
450 400 418
500 450 468
600 550 568
800 750 768
900 850 868
1000 950 968
1200 1150 1168
SIGE S.P.A.
TEL [phone] R.A.
FAX [phone]
MELBOURNE 94 BELL ST PRESTON,
3072 VICTORIA, AUSTRALIA
ABN: 56 630 675 375
1800 633 507
WWW.WILBRAD.COM.AU
[e-mail]
SIGE WILL NOT BE RESPONSIBLE FOR ANY EVENTUAL DAMAGE DUE TO A DIFFERENT USE FROM THE ONE IT HAS BEEN MADE.

1N°4 M5x10
2
Disassemble the spacers (B and C) and screw the guides in the indicated holes.
N°8 6.3x14
Pre-drill the sides of the cabinet (ø5x13) at the indicated dimensions and screw the spacers.
FRONT
Min 150
Min 200
10
37 112 112 112
10
EURO SCREW
SELF TAPPING
SCREW

CLICK!
Place the spacer inside the profile.
Insert the rubber gasket inside the groove and hook the frame to the guides as shown.
3
4

Adjust both spacers to the same distance, then tighten the 6 screws (2 rear and 4 lower).
5
= =
CLICK!
SIGE SPA HAS THE RIGHT TO MAKE CHANGES ON IT WITHOUT NOTICE
