COOPER FREESTANDING TUB FAUCET INSTALLATION
GETTING STARTED
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing fixtures. Signature
Hardware accepts no liability for any damage to the
faucet, plumbing, bathtub, floor, or for personal injury
during installation.
Observe all local plumbing and building codes.
Unpack and inspect the items for shipping damage. If
any damage is found, contact our Customer Relations
team at 1-866-855-2284.
Ensure that you have gathered all the required
materials that are needed for the installation.
For these instructions, it is assumed that the old
faucet has been completely removed and any
necessary repairs or modifications to the water
supply have been completed.
TOOLS AND MATERIALS:
Plumbers
Tape
Thread
Sealant
Adjustable
Wrench
1Cooper Freestanding Tub Faucet Installation Instructions
Level Hex Wrench Drill
Pencil Safety Glasses
SKU(s): 940972

COOPER FREESTANDING TUB FAUCET INSTALLATION
INSTALLATION
3. Lower the faucet base into the drilled mounting
holes, as shown. Remove the protective cover. Ensure
that the base is level, and make adjustments as
needed before moving on.
4. Connect the hot and cold water lines to the inlets on
either side of the faucet base, as shown. Ensure that
the hot and cold lines are connected to the proper
inlet. Apply plumber’s tape or thread sealant to the
threads before tightening.
1. Set the faucet base at its desired location, and mark
the location of the mounting holes, as shown. Drill one
ø12mm hole at each marked location.
2. Insert the provided expansion bolts through the
bottom of the base, as shown. Slide the washer and
locking washer onto the bolt, then slightly tighten the
nut onto the bolt. Do not tighten fully.
2Cooper Freestanding Tub Faucet Installation Instructions
nut
locking washer
washer
expansion bolt
protective cover
faucet base
cold water
hot water
this side
facing bathtub
ø12mm
80mm 80mm
level
longitudinal
horizontal
remove
hot water line
cold water line

COOPER FREESTANDING TUB FAUCET INSTALLATION
8. Place the protective cover back onto the faucet
base. Proceed to the installation of your finished
floor before moving on with faucet installation.
Important: The top of the faucet support base must
be set at least 1-1/4" to 1-1/2" below the finished
floor, depending on tile and substrate thickness,
which lowers the height of the faucet an identical
amount.
5. Insert plugs into the outlets of the faucet base, as
shown. Then, secure the flange to the base using the
provided hex screws and hex wrench.
6. Perform a water pressure test before moving on.
Ensure that there are no leaks in the connections.
Note: If you are not familiar with performing this type
of procedure, consult a licensed plumber.
3Cooper Freestanding Tub Faucet Installation Instructions
hex wrench
M8x16 screw
flange
plug
outlet
flow water
flow water
hex wrench
M8x16 screw
flange
plug
outlet
7. Remove the hex screws, flange, and plugs that
were installed in step 5.

COOPER FREESTANDING TUB FAUCET INSTALLATION
10. Remove the protective cover from the faucet
base. Lower the faucet onto the base, ensuring that
the water lines are set into the water outlets. Fasten
the faucet to the base using the provided hex screws
and hex wrench.
9. Remove the protective caps from the outlets on
the facet body, to prepare for assembly. Assemble the
faucet as shown below, to prepare for installation.
4Cooper Freestanding Tub Faucet Installation Instructions
shower
outlet
screw
faucet body
protective caps
(remove)
M8x12 screw
hand shower
cradle
water lines
escutcheon
protective cap
(remove)

COOPER FREESTANDING TUB FAUCET INSTALLATION
12. Once installation is complete, turn the faucet on.
Allow the water to flow for approximately 60 seconds
to check for any leaks. Ensure that hot and cold water
are running appropriately. Divert water to the hand
shower and run for another 60 seconds.
11. Use the provided flexible hose to attach the hand
shower to the faucet body, as shown.
5Cooper Freestanding Tub Faucet Installation Instructions
hand shower
cold
hot
open
close
diverter
