SIIG CE-H23H11-S1 User manual

Button Function
OFF Standby mode
ON Power on the matrix switcher
MUTE Turn o output’s video and audio
STATUS Preset output status
SAVE Save current mapping mode
PRESET Preset mapping mode
DEFAULT EDID Begin default EDID selection
LEARN EDID Begin EDID learning from one output
CLEAR Clear the previous IR operation procedure
TAKE Trigger the previous setting
F1 F2 Reserved
Operation Procedure 7-Segment LED
IN/OUT Switch Push the button on the checkerboard
to select input & output port
Ex: Input 2
To Output 3
Push the red circle button as right pic to
select input 2 to output 3
3
2

Operation Procedure 7-Segment LED
Mute Output Mute + A~D(Output 1~4) + Take
Ex: Mute Output 3
1. Press “MUTE” button -
0
2. Press number key “C” to select Output 3 3
0
3.Press “TAKE” button 3
0
Output Status Status + A~D(Output 1~4) + Take
Ex: Output 4
(Input 2)
1.Press “STATUS” button -
-
2.Press number key “D” to select Output 4 4
3.Press “TAKE” button
-
4
2
Save Current Mapping Save + A~H(1-8 storage site) + Take
Ex: Save current
mapping to 5
1.Press “SAVE” button d
-
2.Press number key “E” to select the storage site 5 d
5
3.Press “TAKE” button
Preset Mapping Preset + A~H(1-8 storage site) + Take
Ex: Preset saved mapping
from 5
1.Press “PRESET” button P
-
2.Press number key “E” to select the storage site 5 P
5
3.Press “TAKE” button
Learn default EDID Default EDID + A~H(1-8 default EDID) + I~IV(input 1~4) + Take
Ex: Default EDID 2
Input 3
1.Press “DEFAULT EDID” button E
d
2.Press number key “B” to select default EDID 2 2
d
3.Press number key “III” to select Input 3 2
3
4.Press “TAKE” button 0 (success) F (fail)
Learn Output EDID Learn + A~B(Output 1~2) + I~IV(input 1~4) + Take
Ex: Learn Output 4
Input 3
1.Press “LEARN” button E
L
2.Press number key “D” to select Output 4 4
L
3. Press number key “III” to select Input 3 4
3
4.Press “TAKE” button 0 (success) F (fail)
Mute Output Mute + A~B(Output 1~2) + Take
Ex: Mute Output 3
1. Press “MUTE” button -
0
2. Press number key “C” to select Output 3 3
0
3.Press “TAKE” button 3
0

1Power ON/ Standby mode
2Control SW via RS-232
3COM Port Selection
4I/O Routing Button
5EDID Button
6Rename I/O Button
7Network Setting & Default Reset Button
8Firmware Update Button
