Silvercrest 326917 1904 Technical specifications

STEAM MOP & HANDHELD STEAM CLEANER
SDM 1500 D3
STEAM MOP & HANDHELD
STEAM CLEANER
Assembly, operating and safety instructions
GŐZÖLŐS FELMOSÓ ÉS
KÉZI GŐZTISZTÍTÓ
Szerelési, használati és biztonsági tudnivalók
PARNI ČISTILNIK IN ROČNI
PARNI ČISTILNIK
Navodila za montažo, uporabo in varnostna
navodila
PARNÍ MOP A RUČNÍ
PARNÍ ČISTIČ
Pokyny k montáži, obsluze a bezpečnostní
pokyny
PARNÝ MOP A RUČNÝ
PARNÝ ČISTIČ
Pokyny pre montáž, obsluhu a bezpečnostné
pokyny
DAMPFMOPP UND
HANDDAMPFREINIGER
Montage-, Bedienungs- und Sicherheitshinweise
143 mm 143 mm
IAN 326917_1904

143 mm
GB Assembly, operating and safety instructions Page 5
HU Szerelési, használati és biztonsági tudnivalók Oldal 16
SI Navodila za montažo, uporabo in varnostna navodila Stran 27
CZ Pokyny k montáži, obsluze a bezpečnostní pokyny Strana 38
SK Pokyny pre montáž, obsluhu a bezpečnostné pokyny Strana 49
DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 60

138 mm 143 mm
16
20
24
25
8
10
15
5
6
7
9
11
13
14
2
19
18
12
21
4
17
3
22
1
23
17

A
138 mm
5
13
6 7 9 11

5GB
Warnings and symbols used ............................................. Page 6
Introduction ................................................................ Page 6
Intended use.................................................................. Page 6
Scope of delivery.............................................................. Page 7
Description of parts ............................................................ Page 7
Technical data ................................................................ Page 7
Safety instructions......................................................... Page 7
Before first use ............................................................. Page 11
Assembly ................................................................... Page 11
Unfolding/folding the handle .................................................... Page 11
Attaching the steam foot ........................................................ Page 11
Using as a handheld steamer .................................................... Page 11
Operation................................................................... Page 12
Filling the water tank ........................................................... Page 12
Turning on/off ................................................................ Page 12
Adjusting the steam power....................................................... Page 13
Pump safety shutdown .......................................................... Page 13
Cleaning and care ......................................................... Page 13
Storage ..................................................................... Page 14
Disposal..................................................................... Page 14
Warranty ................................................................... Page 14

6 GB
Warnings and symbols used
The following warnings are used in this user manual and on the packaging:
DANGER! This symbol in combination
with the signal word “Danger” marks a
high-risk hazard that if not prevented could
result in death or serious injury.
Voltage (alternating current)
Hertz (supply frequency)
Watts
Protected against splashing water from all
directions.
WARNING! This symbol in combination
with the signal word “Warning” marks a
medium-risk hazard that if not prevented
could result in death or serious injury.
NOTE: This symbol in combination
with “Note” provides additional useful
information.
CAUTION! This symbol in combination
with the signal word “Caution” marks a
low-risk hazard that if not prevented could
result in minor or moderate injury.
Danger – risk of electric shock!
Warning – danger of scalding! Washable at 60 °C
Do not use bleach. Do not tumble dry.
Do not iron. Professional cleaning
STEAM MOP &
HANDHELD STEAM CLEANER
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the product as
described and for the specified applications.
If you pass the product on to anyone else, please
ensure that you also pass on all the documentation
with it.
Intended use
This product is designed for cleaning indoor surfaces.
Do not use it for any other purpose.
This product is only intended for private household
use, not for commercial purposes.
The manufacturer accepts no liability for damages
caused by improper use.

7GB
Scope of delivery
After unpacking the product, check if the delivery
is complete and if all parts are in good condition.
Remove all packing materials before use.
1x Steam mop & handheld steam cleaner
1x Steam foot
1x Funnel
1x Filling cup
1x Microfiber cover
2x Microfiber cloth
1x Carpet glider
1x Large round brush
1x Small round brush
1x Oblong brush
1x Angle nozzle
1x Scraper
1x Upholstery attachment
1x Squeegee attachment
1x Extension nozzle
1x Extension hose
Description of parts
Before reading, unfold the page containing the
illustrations and familiarise yourself with all the
functions of the product.
1Handle
2Extension hose
3Funnel
4Filling cup
5Angle nozzle
6Scraper
7Oblong brush
8Microfiber cover
9Large round brush
10
Upholstery attachment
11
Small round brush
12
Squeegee attachment
13
Extension nozzle
14
Microfiber cloth
15
Carpet glider
16
Steam foot
17
Release lever (of the handle 1, extension hose
2and handheld unit 22
)
18
Water tank/water tank cover
19
Light indicator
20
Hanging hook (for power cable)
21
Power knob/steam level regulator
22
Handheld unit
23
Power cord with power plug
24
Eject button (handheld unit)
25
Folding button
Technical data
Input voltage: 220–240 V~, 50/60 Hz
Power consumption: 1500 W
Water tank capacity: 350 ml
Protection class: I
Ingress protection class: IPX4 (splash proof)
Safety instructions
BEFORE USING THE PRODUCT,
PLEASE FAMILIARISE
YOURSELF WITH ALL OF THE
SAFETY INFORMATION AND
INSTRUCTIONS FOR USE! WHEN
PASSING THIS PRODUCT ON TO
OTHERS, PLEASE ALSO INCLUDE
ALL THE DOCUMENTS!
In the case of damage resulting
from non-compliance with these
operating instructions the warranty
claim becomes invalid! No liability is
accepted for consequential damage!
In the case of material damage or
personal injury caused by incorrect
handling or non-compliance with
the safety instructions, no liability is
accepted!

8 GB
Children and persons with
disabilities
m WARNING! RISK OF LOSS
OF LIFE OR ACCIDENT TO
INFANTS AND CHILDREN!
Never leave children
unsupervised with the packaging
material. The packaging
material represents a danger of
suffocation. Children frequently
underestimate the dangers.
Always keep children away from
the packaging material.
This product can be used by
persons with reduced physical,
sensory or mental capabilities
or lack of experience and
knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
Children shall not play with the
product.
Cleaning and user maintenance
shall not be made by children
without supervision.
Keep the product and its cord
out of reach of children when it is
energized or cooling down.
Intended use
m WARNING! Misuse may
lead to injury. Use this product
solely in accordance with these
instructions. Do not attempt to
modify the product in any way.
Use the product only on floors
made of marble, stone, tile,
parquet flooring or hardwood
that have been well sealed and
treated and are impervious to
water.
Never use the product
–on untreated or permeable
floors,
–on wax polished furniture or
floors,
–on carpets with wool content,
–on steam sensitive materials
Electrical safety
m DANGER! Risk of electric
shock! Never attempt to repair
the product yourself.

9GB
In case of malfunction, repairs
are to be conducted by qualified
personnel only.
m WARNING! Risk of electric
shock! Do not immerse the
product’s electrical components in
water or other liquids. Never hold
the product under running water.
m WARNING! Risk of electric
shock! Never use a damaged
product. Disconnect the product
from the power supply and
contact your retailer if it is
damaged.
m WARNING! Risk of injury!
The product has to be unplugged
after use and before cleaning or
maintaining the product.
Connect the product only to an
earthed wall socket.
Always make sure that the power
plug is correctly inserted into the
wall socket.
The product is not to be used if
it has been dropped, if there are
visible signs of damage or if it is
leaking.
Before connecting the product
to the power supply, check that
the voltage and current rating
corresponds with the power
supply details shown on the
product’s rating label.
Regularly check the power plug
and the supply cord for damages.
If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
Protect the power cord against
damages. Do not let it hang over
sharp edges, do not squeeze or
bend it. Keep the power cord
away from hot surfaces and
open flames and ensure that
nobody can pull on or trip over it
unintentionally.
The product must not be left
unattended while it is connected
to the supply mains.
The liquid or steam must not
be directed towards equipment
containing electrical components,
such as the interior of ovens.

10 GB
The filling aperture must not be
open during use.
Burn hazards
m DANGER! Risk of burns!
Do not touch hot surfaces and
beware of escaping steam. Hold
the product by its handle only.
Steam is very hot. Never put your
hands in front of the steam jet.
Operation
Only use the product in dry
indoor rooms.
The plug must be removed from
the wall socket before the water
tank is filled with water.
The use of extension cords is not
recommended. If the use of an
extension cord is necessary, it
must be designed for a current
flow of at least 10 A. Lay cords
in such a way that they may not
be tripped over or otherwise
damaged.
Do not operate the product with
wet hands or while standing on a
wet floor. Do not touch the power
plug with wet hands.
Stop using the product if the anti-
kink protection on the power cord
is damaged!
Cleaning and storage
Always turn off the product
before disconnecting it from the
power supply.
Do not pull the power plug out
of the wall socket by the power
cord. Do not wrap the power
cord around the product.
Protect the product, its power
cord and power plug against
dust, direct sunlight, dripping and
splashing water.
Store the product in a cool, dry
place, protected from moisture
and out of the reach of children.
