Simoco SRM9020PLUS User manual

SRM9020plus Mobile Radio
Conventional PMR
Operating Instructions
TNM-U- -0086 Issue 1.0a
January 2010
abcde
Comgroup Australia Pty. Ltd.
1270 Ferntree Gully Road
Scoresby
ictoria, 3179
Australia

SRM9020plus ~ PMR Operating Instructions
© Comgroup Australia 2010 Page i TNM-U- -0086 Issue 1.0a
ASSOCIAT D DOCUM NTATION
The following documentation is available for use with the SRM9000 series of
products:
TNM-I-E-0005 SRM9000 Series Installation Instructions
TNM-M-E-0001 SRM9000 Service Manual
TNM-U-E-0003 SRM9030 PMR Operating Instructions
TNM-U-E-0004 SRM9030 Trunked Operating Instructions
TNM-U-E-0012 SRM9020 Trunked Operating Instructions
TNM-U-E-0014 SRM9025 PMR Operating Instructions
TNM-U-E-0015 SRM9025 Trunked Operating Instructions
To order copies of any of the above publications, or any other Simoco product,
contact Comgroup Australia on [phone] or send a Fax on +61 3 9730
3968.
ABOUT THIS DOCUM NT
This publication is copyright and no part may be reproduced without prior
permission of Comgroup Australia.
Due to our policy of continuous improvement to our products and services,
technical specifications and claims, correct at time of publication, may be subject
to variation without prior notice.
Comgroup Australia has endeavoured to ensure that the information in this
document is fairly and accurately stated, but does not accept liability for any
errors or omissions.

SRM9020plus ~ PMR Operating Instructions
© Comgroup Australia 2010 Page 24 TNM-U- -0086 Issue 1.0a
DOCUM NT BAS D ICONS
The following icons are used in this document to describe certain actions of the
screen display:
This icon indicates that the first screen is only displayed momentarily and
then the second screen is displayed.
This icon indicates that the screens shown are each displayed
momentarily in sequence.
SAF TY
1. Do NOT operate your radio, without a handsfree kit, whilst driving a
vehicle.
2. Do NOT operate your radio in an explosive atmosphere.
Obey the 'Turn Off Two-way Radios' signs where these are posted,
e.g. on a petrol station forecourt.
3. Do NOT touch the antenna while the radio is transmitting.
4. Do NOT operate the radio if the antenna has become disconnected
or damaged.
HINTS FOR USING TH RADIO
• When speaking, hold the microphone a few centimetres from your mouth and
speak across it, rather than into it.
• Keep the length of your conversation to a minimum and replace the
microphone on it’s cradle after use.
• When it is possible to move location, avoid making calls from known poor
signal-strength areas such as the radio systems fringe areas (limit of range)
or from screened or shadowed areas, e.g. an underground car park or
underpass.
• To avoid unnecessary drain on the vehicle battery, keep the engine running
when using the radio for extensive periods of time.

SRM9020plus ~ PMR Operating Instructions
© Comgroup Australia 2010 Page iii TNM-U- -0086 Issue 1.0a
CONT NTS
ASSOCIAT D DOCUM NTATION ............................................................ I
ABOUT THIS DOCUM NT......................................................................... I
DOCUM NT BAS D ICONS..................................................................... II
SAF TY ..................................................................................................... II
HINTS FOR USING TH RADIO............................................................... II
CONT NTS .............................................................................................. III
1. INTRODUCTION .............................................................................. 1
1.1 Installation ............................................................................. 1
2. FRONT PAN L CONTROLS ........................................................... 2
3. FUNCTIONS AND FACILITI S........................................................ 3
3.1 Display and Icons.................................................................. 3
3.2 Switch-On/Switch-Off ........................................................... 4
3.3 Volume Adjustment .............................................................. 5
3.4 Receiving ............................................................................... 5
3.5 Transmitting .......................................................................... 6
3.6 S LCALL Functions ............................................................. 7
3.6.1 Receiving a Selcall............................................................. 7
3.6.2 Sending a Selcall ............................................................... 7
3.6.3 Other Selcall Functions ...................................................... 7
3.7 Scan Functions ..................................................................... 8
3.7.1 Scan Screen....................................................................... 8
3.8 MUT Level Setting............................................................. 10
3.9 xternal alert ....................................................................... 10
4. M NU SYST M ............................................................................. 11
4.1 Menu Navigation ................................................................. 12
5. MAIN M NU SCR NS................................................................. 13
5.1 Channel Screen................................................................... 13
5.2 Phonebook Screen ............................................................. 13
5.3 Status Screen ...................................................................... 14
5.4 Stored Calls Screen ............................................................ 15
5.5 Setup Screen ....................................................................... 16
6. S TUP............................................................................................ 17
6.1 Setup Sub-Menus................................................................ 17
6.1.1 User Options .................................................................... 17

SRM9020plus ~ PMR Operating Instructions
© Comgroup Australia 2010 Page 24 TNM-U- -0086 Issue 1.0a
6.1.2 Mute Adjust ...................................................................... 18
6.1.3 Alert olume..................................................................... 18
6.1.4 Information ....................................................................... 19
6.1.5 Network ............................................................................ 19
7. SP CIAL FUNCTION BUTTONS .................................................. 20
7.1 Monitor................................................................................. 20
7.2 Squelch Defeat .................................................................... 20
7.3 Reset .................................................................................... 20
7.4 Scan ..................................................................................... 20
7.5 Send-2 and Special ncoder 1 to 8 ................................... 20
7.6 Transpond ........................................................................... 20
7.7 CTCSS.................................................................................. 20
7.8 Mute...................................................................................... 21
7.9 xternal Alert....................................................................... 21
7.10 Goto Chan A, B, C, D .......................................................... 21
7.11 Alarm.................................................................................... 21
7.12 Repeater Defeat................................................................... 21
7.13 Low Power ........................................................................... 21
7.14 Scrambler ............................................................................ 21
8. OPTIONS ....................................................................................... 22
8.1 Quick Release Transceiver Kit........................................... 22
8.2 Microphone/Control Head xtension Lead....................... 22
8.3 Handsfree Option................................................................ 22
8.4 Type 1 Parallel I/O xpansion Option................................ 22
8.5 GPS/ Audio Serial Interface Option ................................... 22
8.6 Cross-linked Cable.............................................................. 22
8.7 600 Ohm Interface Option .................................................. 22
8.8 Desk Top Base Kit............................................................... 22
9. TROUBL SHOOTING ................................................................... 23
APP NDIX A - AL RT TON S AND M SSAG S ................................. 24
APP NDIX B - GLOSSARY .................................................................... 25

SRM9020plus ~ PMR Operating Instructions
© TMC Radio 2007 Page 1 TNM-U- -0086 Issue 1.0
1. INTRODUCTION
The SRM9000 Series Radios are advanced, versatile Digital Signal Processor
(DSP) controlled, two-way mobile radios. The SRM9000 Series is available in a
number of frequency bands and versions for specific applications. This manual
describes the operation of the SRM9020plus PMR Alphanumeric Display
variant.
The radio consists of a SRM9000 Transceiver Unit that may be mounted in the
vehicle boot or under a seat, and a SRM9020plus Alphanumeric Control
Microphone which is designed to mount within view and reach of the driver. A
speaker connected to the radio provides the audio interface.
The radio is software programmable and it can be customised to the operational
requirements of your particular fleet. Your Simoco representative can help in
programming your radios facilities to meet your present and future
requirements. This guide describes the facilities that are currently available and
can be programmed into the SRM9020plus.
1.1 I NSTALLATION
As the installation of your SRM9020plus Radio is a technical and possibly
hazardous operation, we recommend that it is installed and set up for use by
your dealer or an authorised installer. However, if you need information
regarding the correct procedures for installation, please refer to the SRM9000
Series Installation Instructions supplied with the radio.

SRM9020plus ~ PMR Operating Instructions
© Comgroup Australia 2010 Page 24 TNM-U- -0086 Issue 1.0a
2. FRONT PAN L CONTROLS
Volume Up
Volume Down
On/Off
Icons
Scroll Up
Scroll Down
F4 - Scan On/Off
or Send Selcall
F2 - Function
F3 - Return to Menu
F1 - Change Menu
Display
PTT
Microphone
BUTTON/
CONTROL
FUNCTION
On/Off Push and hold for 1 second to switch the radio On
or Off.
PTT/Pressel Press-to-Talk switch.
M (Menu) F1 Move between Menu Screens.
F3 Used to return to the Main Menu Screen.
S (Select) F4 Used to make a call to the displayed identity, or
activate Scanning.
Scroll up and down through a list within a Menu.
The four programmable buttons, F1 to F4, can be programmed, using the FPP
Programmer, to perform different functions. If the default settings, described
above, are changed, alternative means should be provided to perform their
original functions.

SRM9020plus ~ PMR Operating Instructions
© Comgroup Australia 2010 Page 3 TNM-U- -0086 Issue 1.0a
3. FUNCTIONS AND FACILITI S
3.1 D ISPLAY AND I CONS
The display shows text information relevant to the
selected Menu Screen.
The Name field (e.g. Ch73) shows the selected entry from
the current screen (e.g. from the Channel List).
Several Icons can be individually displayed as shown
below:
ICONS
alid signal + CTCSS (and Selcall) is being received.
Audio can be heard from the loudspeaker.
Invalid signal. Carrier with incorrect CTCSS (and/or Selcall) is
being received.
This symbol indicates that the radio is transmitting.
The rotating icon indicates that the radio is searching for a
channel, (e.g. while oting). The symbol disappears when
stopped on a channel.
Scanning indicator shows that the radio is searching the
channels in the Scan Group.
When not transmitting or receiving, flashes to indicate stored
calls.
The M button scrolls through available Menu options. Where menu selection is
not required, this button can be reprogrammed to perform other functions in this
screen.
The buttons scroll up and down through the available selections within a
Menu Screen.
The F1, F2, F4 and F4 buttons are programmable function buttons, in this
screen.
If SELCALL is used, the
F3 button will send the Channel-Encode selcall (with
Current Phonebook Entry and/or Saved Status Value).
Searching
Invalid
Signal
alid Signal
Icons
Scanning
Stored Call

SRM9020plus ~ PMR Operating Instructions
© Comgroup Australia 2010 Page 24 TNM-U- -0086 Issue 1.0a
3.2 S WITCH -O N /S WITCH -O FF
Press and hold down the On/Off button for
approximately 2 seconds to switch the radio ON.
The display will illuminate and briefly show an
'Opening Message’ (arranged by your dealer) and the
Selcall Identity of the radio (if used).
After a brief time the display will show the selected
channel, at which time the radio is ready for use.
Pressing and holding the On/Off button for
approximately 2 seconds will switch the radio Off.
If the radio Inactivity imer is enabled, the radio will
automatically turn Off after several hours of inactivity
(i.e. no buttons pressed). The radio will emit warning
beeps for 10 seconds prior to switching off. Pressing
any button will reset this timer.
The radio can also be set up to switch on
automatically with the ehicle Ignition whenever the
vehicle is started.
