RiverRidge LADDER SPACESAVER 06-098 User manual

ASSEMBLY INSTRUCTIONS
RiverRidge® LADDER SPACESAVER
ITEM #:06-098 WHITE
ITEM #:06-099 GRAY
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be
taken in unpacking and assembling this item to keep small parts away from children.
WARNING SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over. Don’t
use this item for a TV stand or place heavy objects on top of item. Always
use angle-braces or anchors to secure furniture to the wall.

Send requests for missing or damaged parts replacements by email to:
customer.serv[email protected] or call toll free 1-(844)-223-5201 or order parts on
line at www.riverridgehome.com
THIS SHELF UNIT WILL HOLD UP TO 20 POUNDS PER SHELF OR A TOTAL OF 60 POUNDS.
DO NOT LOAD EACH SHELF WITH MORE THAN 20 POUNDS.IF LOADED WITH MORE THAN 20
POUNDS PER SHELF AS THIS MAY CAUSE DAMAGE TO THE SHELF AND MAY CAUSE
SERIOUS INJURY OR DEATH.

PARTS LIST
NO
QTY
DESCRIPTION
1
1PC
TOP SHELF LEFT RAIL BOARD
2
1PC
TOP SHELF RIGHT RAIL BOARD
3
1PC
MIDDLE SHELF LEFT RAIL BOARD
4
1PC
MIDDLE SHELF RIGHT RAIL BOARD
5
1PC
BOTTOM SHELF LEFT RAIL BOARD
6
1PC
BOTTOM SHELF RIGHT RAIL BOARD
7
1PC
TOP SHELF
8
1PC
MIDDLE SHELF
9
1PC
BOTTOM SHLF
10
2PCS
REAR RAIL BOARD
11
1PC
TOP REAR RAIL BOARD
12
1PC
BOTTOM REAR CROSS BAR
13
1PC
UPPER LEFT SIDE FRAME
14
1PC
UPPER RIGHT SIDE FRAME
15
1PC
BOTTOM LEFT SIDE FRAME
16
1PC
BOTTOM RIGHT SIDE FRAME

NO
PART
QTY
DESCRIPTION
22PCS
WOOD DOWEL
8PCS
SCREW (4 X 60MM)
12PCS
MACHINE SCREW
(6 X 20MM)
27PCS
WOOD SCREW (3.5 X 25MM)
1PC
WOOD SCREW (4 X 30MM)
1PC
WOOD SCREW (3 X 12MM)
1PC
PLASTIC ANCHOR
2PCS
BRACKET
I
1PC
PLASTIC LOCK STRAP

STEP 1
STEP 1
1.Insert 1 wood dowel (A) into wood dowel hole on end of top rear rail board (11).
2.Attach top shelf left rail board (1) to top rear rail board (11) by inserting wood dowel (A)
into hole on top shelf left rail board (1). Make sure hole on top rear rail board (11) is
facing towards back side of shelf.
3.Insert 1 wood screw (D) through hole on top shelf left rail board (1) and tighten to top rear
rail board (11).
4.Repeat above steps to assemble top shelf right rail board (2) to top rear rail board (11).
STEP 2
STEP 2
1.Insert 1 wood dowel (A) into wood dowel hole on end of rear rail board (10)
2.Attach middle shelf left rail board (3)torear rail board (10)by inserting wooddowel (A)
into hole on middle shelf left rail board (3).
3.Insert 1 wood screw (D) through hole on middle shelf left rail board (3) and tighten to rear
rail board (10).
4.Repeat above steps to assemble middle shelf right railboard (4)torearrail board(10).

STEP 3
STEP 3
1.Insert 1 wood dowel (A) into wood dowel hole on end of rear rail board (10).
2.Attached bottom shelf left rail board (5) to rear rail board (10) by inserting wood dowel (A)
into hole on bottom shelf left rail board (5).
3.Insert 1 wood screw (D) through hole on bottom shelf left rail board (5) and tighten to rear
rail board (10).
4.Repeat above steps to assemble bottom shelf right rail board (6) to rearrail board (10).
STEP 4
STEP 4
1.Insert 4 wood dowels (A) into wood dowel holes on top shelf (7).
2.Attach top shelf (7) to pre-assembled top shelf left rail board (1), top shelf right rail board (2)
and top rear rail board (11) by inserting wood dowels (A) into wood dowel holes on top shelf
left rail board (1), top shelf right rail board (2) and top rear rail board (11).
3.Insert 7 wood screws (D) through holes on top shelf (7) and tighten to top shelf left rail board (1),
top shelf right rail board (2) and top rear rail board (11).

STEP 5
STEP 5
1.Insert 4 wood dowels (A) into wood dowel holes on middle shelf (8).
2.Attach middle shelf (8) to pre-assembled middle shelf left rail board (3), middle shelf right rail
board (4) and rear rail board (10) by inserting wood dowels (A) into wood dowel holes on
middle shelf left rail board (3), middle shelf right rail board (4) and rear rail board (10).
3.Insert 7 wood screws (D) through holes on middle shelf (8) and tighten to middle shelf left
rail board (3), middle shelf right rail board (4) and rear rail board (10).
STEP 6
STEP 6
1.Insert 4 wood dowels (A) into wood dowel holes on bottom shelf (9).
2.Attach bottom shelf (9) to pre-assembled bottom shelf left rail board (5), bottom shelf right rail
board (6) and rear rail board (10) by inserting wood dowels (A) into wood dowel holes on
bottom shelf left rail board (5), bottom shelf right rail board (6) and rear rail board (10).
3.Insert 7 wood screws (D) through holes on bottom shelf (9) and tighten to bottom shelf left
rail board (5), bottom shelf right rail board (6) and rear rail board (10).

STEP 7
STEP 7
1.Insert 2 wood dowels (A) into wood dowel holes on upper left side frame (13).
2.Attach upper left side frame (13) to bottom left side frame (15) by inserting wood dowels (A) into
wood dowel holes on bottom left side frame(15).
3.Insert 2 screws (B) through holes on bottom left side frame (15) and tighten to upper left side
frame (13).
4.Repeat above steps to assemble upper right side frame (14) to bottom right side frame(16).
STEP 8
STEP 8
1.Attach pre-assembled top shelf (7) and rail boards to upper right side frame (14) by inserting 2
machine screws (C) through holes on top shelf right rail board (2) and tighten to upper right side
frame (14).
2.Repeat above step to assemble middle shelf (8) and bottom shelf (9) to upper right side frame (14).
3.Attach bottom rear cross bar (12) to bottom right side frame (16) by inserting 2 screws (B) through
holes on bottom right side frame (16) and tighten to bottom rear cross bar (12).

STEP 9
STEP 9
1. Attach pre-assembled topshelf (7) and rail boards to upper left side frame (13) by inserting 2
machine screws (C) through holes on topshelf left rail board (1) and tighten to upper left side
frame (13).
2. Repeat above step to assemble middle shelf (8) and bottom shelf (9) to upper left side frame (13).
3. Attach bottom rear cross bar (12) to bottom left side frame (15) by inserting 2 screws (B) through
holes on bottom left side frame (15) and tighten to bottom rear cross bar (12).
STEP 10
STEP 10
1.Attach 1 bracket (H) to toprear rail board (11) by inserting 1 wood screw (F) through hole on
bracket (H) and tighten to top rear rail board (11).
2. Drill hole on wall at same height of bracket (H) on spacesaver and insert plastic anchor (G) into hole.
4.Attach 1 bracket (H) to plastic anchor (G) on wall by inserting 1 wood screw (E) through hole on
bracket (H) and tighten into plastic anchor (G).

1.Place spacesaver against wall and close to Bracket(H).
2.Insert plastic lock strip (J) through hole on bracket (H) on spacesacer and through hole on bracket
(H) on wall, then fasten plastic lock strip (J) to secure 2 Brackets (H) firmly together.
WALL
J
J
