Regency LADSR7130 User manual

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
IMPORTANT NOTICE:
● Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched.
● Check to be sure that you have all parts and hardware.
● Remove all wrapping materials, including staples & packing straps before you start to assemble.
● Do not tighten all screws/bolts until completely assembled.
● Keep all hardware parts out of reach of children.
You will need 2 person(s) for this assembly. You will need a Phillips head screw driver.
LADSR7130, LADSL7130 • INSTRUCTIONS
A B C
F
DE
Hardware: A: Grommet(1) • B: Cam Pins(33) • C: Caps(33) • D: Small Screws(24) • E: Flat Brackets (4)
GH
Parts: F: Desk Modesty • G: Right Desk Leg • H: Left Desk Leg • I: Desk Shelf • J:Desk top
•K: Return Modesty • L: CPU Base • M: Right CPU Leg • N: Left CPU Leg • O: Return Top.
IJ L
M N
O
STEP 1 : Lay Desk Top(J) face down and
insert 6 cam pins (B) .
STEP 2 : Insert 2 Cam Pins(B) into Desk Modesty(F) then
attach Desk Shelf(I) to Modesty and Lock cams (see g 1) .
K
B
B
B
B
B
B
B
B
J
FF
I
Figure 1: To open Cam, point
arrow toward Cam Pin hole.
To lock Cam, turn clockwise.

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
IMPORTANT NOTICE:
● Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched.
● Check to be sure that you have all parts and hardware.
● Remove all wrapping materials, including staples & packing straps before you start to assemble.
● Do not tighten all screws/bolts until completely assembled.
● Keep all hardware parts out of reach of children.
STEP 3 : Insert 5 cam pins(B) into Right Desk Leg(G)
and 3 cam pins into Left Desk Leg(H).
STEP 4 : Connect Legs (G/H) To the Desk as shown.
Lock cams. (see g 1)
STEP 5 : Stand the frame right side up with feet on the
ground and attach Desk Top(J) by locking cams.
(see g 1)
P
B
G
B
B
B
B
B
B
B
H
H
G
F
J
STEP 6 : Insert 2 cam pins(B) into Left CPU leg(N).
Attach CPU base(L) to the leg and insert Grommet(A).
Lock cams (see g 1)
N
L
A
You will need 2 person(s) for this assembly. You will need a Phillips head screw driver.
BB
A
LADSR7130, LADSL7130 • INSTRUCTIONS

Any problems or questions call Regency Ofce Furniture at 1-866-816-9822
IMPORTANT NOTICE:
● Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched.
● Check to be sure that you have all parts and hardware.
● Remove all wrapping materials, including staples & packing straps before you start to assemble.
● Do not tighten all screws/bolts until completely assembled.
● Keep all hardware parts out of reach of children.
STEP 7 : Insert 3 cam pins(B) into the Return
Modesty(K) and attach the CPU Base(L) and the Left
CPU Leg(N) to Modesty. Lock cams (see g 1)
K
STEP 8 : Insert 5 cam pins(B) into Right CPU leg(M) and
attach to Return modesty(K) and CPU Base(L).
STEP 9 : Insert 7 cam pins(B) into Return Top(O).
Connect Return Top to the return base by inserting
and locking cam pins into locks. (see g 1)
STEP 10 : Connect Return to Desk by using the 4 at
brackets(E) and 24 Small Screws(D). Place 2 brackets in
place to join the underside of the desk tops and 2 to join the
modesties.
B
B
B
K
N
L
M
K
L
B
B
BBB
M
B
B
B
B
B
B
B
O
OEE
E
E
You will need 2 person(s) for this assembly. You will need a Phillips head screw driver.
LADSR7130, LADSL7130 • INSTRUCTIONS
