Sizewise Alliance User manual

Sizewise Alliance™
User Manual
Doc. #8110, Rev. 5.0, Rev. Date: 2/26/2021
MFG-0020A-0619

2
Table of Contents
Definition of Symbols.......................................................................................................................5
Manual Definitions ....................................................................................................................5
Warnings and
Cautions
...............................................................................................................6
Important Safety Instructions....................................................................................................10
Device Infor
mation ..........................................................................................................................13
Description of Alliance™.........................................................................................................13
Purpose of Device …………………………………………………………………………...13
General Bed Components ........................................................................................................14
Description of RSS ..................................................................................................................14
Specifications ..................................................................................................................................15
Alliance™ Specifications ........................................................................................................15
RSS Specifications ..................................................................................................................16
Control Box …..........................................................................................................................16
Hand Control...........................................................................................................................17
Unpacking and Setup Instructions ...................................................................................................18
Unpacking/Parts Breakdown ...................................................................................................18
RSS Setup .......................................................................................................................................19
Basic Setup ..............................................................................................................................19
Bed Exit Alarm: Alert Type.....................................................................................................20
Scale System: Zeroing the Scale..............................................................................................19
Scale System: Adding/Removing Items ..................................................................................21
Scale System: Weight History Time Setting ...........................................................................21
Protocol: Set Alert Reminder...................................................................................................22
Protocol Timer: Sound Level Setting......................................................................................22
Setting the Time/Date ..............................................................................................................23
Operating Instructions....................................................................................................................24
Alliance™ Operating Instructions ...........................................................................................24
Foot Controls ..........................................................................................................................24
Hand Control...........................................................................................................................25
Operation of Bed.....................................................................................................................26
Wiring Diagram.......................................................................................................................28
Symbols and Labels....................................................................................................................7

3
Operation of Controls …………….………………………………………………….……30
Bed Exit Alarm.......................................................................................................................33
Scale System...........................................................................................................................35
Protocol Timer........................................................................................................................36
Bed Exit Alarm: Alert Tones ..................................................................................................37
Bed Exit Alarm: Record Message..........................................................................................37
Scale System: Weight Adjustm..............................................................................................38
Scale System: lbs/ kgs Setting .................................................................................................38
Scale System: Locking/Unlocking Unit in lbs/kgs........... .......................................................39
Proper Use.....................................................................................................................................40
Reaching or Leaning ................................................................................................................40
Side Rails ................................................................................................................................41
CPR Release System and Transfers.........................................................................................45
Features ..........................................................................................................................................46
Casters.....................................................................................................................................46
Connection of Electrical Components .....................................................................................47
Emergency Battery Backup ....................................................................................................48
Serial Number Location ..........................................................................................................49
IV Pole .....................................................................................................................................49
Trapeze Assembly....................................................................................................................50
Safety Tips .....................................................................................................................................51
EMC Information.....................................................................................................................51
General Safety...........................................................................................................................55
Pinch Point. ...............................................................................................................................55
Transport. ..................................................................................................................................56
Cleaning Instructions. ..................................................................................................................... 57
Head Side Rail Contro…..........................………….…………….......…………….…….…29
Controls………………………………………………………………………………….…..29
Seven Zones of Bed Rail Entrapment......................................................................................42

4
Limited Product Warranty ............................................................................................................70
Manufacturer Disclaimer ...........................................................................................................72
User Assistance Information .......................................................................................................73
RSS Troubleshooting.................................................................................................................69
Troubleshooting ............................................................................................................................67
Storage and Disposal................................................................................................................. 66
Fasteners.....................................................................................................................................64
Maintenance....................................................................................................................................63

5
Definition of Symbols
Electrical Shock Hazard Warning: Intended to alert user to the presence of
electrical shock hazards. It is important to follow all instructions and special
procedures to avoid electrical shock to the operator, caregiver and/or patient.
Warnings/Cautions: Intended to alert user to the presence of important operating,
maintenance or servicing instructions. Disregarding a warning could result in patient
and/or user injury as well as damage to equipment.
•DO NOT obstruct certain areas during movement, as
this may cause crushing and/or trapping.
Pinch Point Hazard Warning: Intended to alert user to the presence of a potential
pinch-point, crushing hazard. It is important to follow all instructions and special
procedures to avoid patient and/or user, injury as well as damage to equipment.
The third conductor in the Power Supply Cord is only a functional earth.
Warning against crushing.
•DO NOT obstruct certain areasduring
movement, as this may cause crushing.
Ensure proper clearance between footboard and patient
Incompatible mattresses can create hazards. Read instructions for use” Only use siderails
designed for the Sizewise Alliance bed
When routing cables from other equipment in the MEDICAL BED, precautions taken to
avoid squeezing those between parts of the MEDICAL BED

6
Important Safety Instructions
WARNING: Read the User Manual before operating the bed.
The bed is to be used in accordance with each facility’s policies and
procedures.
For user and patient safety, read and follow all warnings and instructions that apply to use of
Alliance™ and Rest Secure System™ (RSS). Before using this bed, the user must know what to
do to ensure safety.
Put the patient at ease. The caregiver should ensure the patient understands procedures.
Work with the patient’s doctor, nurse or therapist to learn safe methods best suited to the
caregiver and patients abilities.
Always use good posture and proper body mechanics. When possible use assistive safe patient
handling devices if necessary to manually lift or support the patient bend knees slightly, keep
back as upright and straight as possible.
DO NOT strike the control unit. DO NOT handle it if broken and DO NOT open the control
unit. The maximum duration of a continuous maneuver should not exceed two minutes.
If the power fails, the control will automatically Enter locking mode.
ANY use of electrical equipment represents an electrical hazard. Staff should be
trained and have information made available to them on the inherent hazards of
electrical equipment.
•Exceeding the safe working load listed in the specifications could result in patient or user
injury, as well as damage to equipment or other property.
•Any change to the specifications can result in malfunction or damage to the Alliance™
and RSS.
•Failure to follow setup instructions could result in patient or user injury, as well as
damage to equipment or other property.
•To avoid electrical shock when plugging this bed into the wall outlet, only use grounded
hospital-grade outlets.
•Follow EMC guidelines and safety precautions when the bed is connected to powered
source.

7
Symbols and Labels
Symbols, denitions, and fonts are used throughout this manual to aid user readability and understanding of content.
Standard Text Used for regular information.
Bold Text Emphasizes a word or phrase.
NOTE Sets apart special information or important instruction clarication.
Safe Working Load The equipment’s maximum external mechanical load permitted in normal use. The sum of
the patient’s weight, other equipment/accessories, and load supported by that equipment/
accessories may not exceed the Safe Working Load.
Maximum Patient Weight The greatest permissible patient weight in normal use. The maximum patient weight may be
lower than the Safe Working Load if additional equipment/accessories are used.
Symbol Denition
Certication:
Indicates device has been independently tested
and meets the published safety standard(s).
Conformity:
Indicates conformity with health, safety, and
environmental protection standards for products
sold within the European Economic Area.
Electrical Shock Hazard Warning:
Symbol alerts user to the presence of electrical
shock hazards. It is important to follow all
instructions and special procedures to avoid
electrical shock to the operator, caregiver, and/or
patient.
Warning/Caution:
Symbol alerts user to the presence of important
operating, maintenance, or servicing instructions.
Disregarding a warning could result in patient
and/or user injury, as well as damage to
equipment.
Read Instructions Carefully:
Indicates the need for user to consult instructions
before use.
MDD Class I Device

Symbols and Labels
Symbol Denition
Device Type:
Indicates a Type B device properly
protected from electrical shock.
Label Denition
Manufacturer’s Label with UDI:
Indicates numerous product details, including
safety standard conformance, manufacture date,
and electrical rating. Located on bed frame.
Patient Size for Adults:
Physical description of an adult.
Safe Working Load:
Graphic symbol for maximum patient weight
and safe working load.
Type B
Mattress Information:
Graphic symbol for manufacturer
recommended mattress dimensions.
27008227, Rev. 1.0
Alliance™ Series
408 lbs. / 185 kg 550 lbs. / 249 kg
Extension Weight Limit:
Graphic symbol for maximum weight
limit on extension.
8

Symbols and Labels
Label Denition
Danger: Pinch Point:
Marking to signify pinch point danger area.
Lock Casters:
Marking to direct locking brake casters before
operation.
CPR:
Graphic symbol for CPR Position.
Hip Positioning:
Graphic symbol for position of
patient hips.
Minimal Clearance Area:
Marking to caution areas required to be free
from obstructions.
Shipping Label:
Marking to provide caution and hazards in
contents of packaging.
9

10
•If the side rails are not secured in the proper place, entrapment to the patient may occur. Bed
rail entrapment is a serious health risk that can result in serious injury or even death. We
recommends the caregiver be mindful of the FDA guidelines relevant to bed rail
entrapment, as serious injury can result. These guidelines can be found on the FDA
website. It is the caregiver’s ultimate decision whether or not to use bed rails with the
patient.
•Radio wave sources such as radio stations, TV stations, amateur radio (HAM)
transmitters, two-way radios and cellular phones can affect this bed. Following the
warnings listed for electromagnetic interference should reduce the chance of the bed’s
unintended movement that could result in serious injury.
•To lessen the possibility of electric shock when plugging the RSS into the wall outlet,
use ONLY grounded or hospital-grade outlets.
•DO NOT use Alliance™ or RSS if the power cord is cut, frayed or loosely connected to
the bed.
•To ensure reliable functionality, the battery reserve should only be used as a temporary
power source until AC power is restored. When the battery reaches 15% charge, the unit
should be plugged into a properly grounded hospital-grade outlet.
•Once the bed is positioned correctly, lock casters. Failure to do this could result in
patient and/or user injury as well as damage to equipment or other property.
•Electrical shock or malfunction may occur if the hand control cord is pinched or frayed.
Keep the cord away from moving parts.
•Failure to heed warnings pertaining to the operation of the bed could result in patient and/
or user injury as well as damage to equipment or other property.
•Never work under the bed while it is operational.
•Keep fingers, arms and feet away from moving parts when mechanisms are operating.
•Operating this bed with any part of the body in the frame can result in injury. Stand clear
of the bed frame before operating.
•Stand clear of the bed during operation due to minimum floor clearance on all sides of the
bed.
•The bed is for indoor use only. Only operate the bed on a flat surface.
•DO NOT use the bed near an open flame or an extreme heat source.
•This bed is not intended for use in high moisture areas (e.g. showers, pool therapy) or
extreme temperature environments.
•Use only parts, accessories, and adapters authorized by the manufacturer.
•DO NOT use the bed with any unintentionally missing or abnormal parts.
Important Safety Instructions

11
•Make sure all cords are properly positioned before operating the bed. Failure to do so
could result in electrical shock and serious injury.
•Never work on a bed while it is plugged into an electrical outlet.
•Electrical hazard may occur if the bed is plugged into inadequate power supply. Make
sure the bed is plugged into a hospital-grade grounded outlet.
•Never let fingers or other body parts come between moving parts when operating the bed.
Doing so may cause a pinch- or crush-type injury
•Follow the instructions for assisting patients in and out of the bed to avoid a fall or injury to
the patient and/or caregiver.
•Reaching or leaning affects the patient’s center of balance. Follow the instructions for
patients reaching or leaning from the bed to avoid a fall or injury to the patient and/or
caregiver.
•Never try to move the bed by the side rail. The side rails may come loose or break.
•Exceeding the weight capacity of the side rails could result in patient and/or user
injury as well as damage to equipment or other property.
•Follow the instructions for transferring patients to avoid a fall or injury, to the patient and/or
caregiver.
•While the patient is in the bed, it is recommended to lock the casters to reduce risk of
injury to the patient and/or caregiver.
•To avoid and reduce risk of tripping injury to the patient and/or caregiver, align the casters
with the bed.
•Failure to follow the provided battery specifications could result in patient and/or
caregiver injury, as well as damage to equipment or other property.
•If the weight capacity of the IV pole is exceeded, it could result in patient and/or
caregiver injury, as well as damage to equipment or other property.
•Do not attempt to install, perform maintenance, or use this product without first reading and
understanding these instructions and accompanying documents such as, the User Manual,
Technical Manual, and Work Instructions. If you do not understand these instructions, or
documents referenced, contact Sizewise at 1-800-814-9389.
•Do not attempt to install, repair, or remove the trapeze,
single pole patient assist, or any other overhead components/devices
while bed is occupied.
•Before positioning patient on bed, verify all components are secure after adjustments,
repairs, or servicing of the trapeze, single pole patient assist, or any other overhead
components/devices.
•Use only parts, accessories and adapters authorized by Sizewise.

12
•The bed requires regular maintenance to uphold performance and avoid premature wear,
damage and injury.
•Never dispose of batteries in a fire, because they may explode.
•Many of the screws and bolts used in the bed are special high-strength fasteners. Contact an
authorized Sizewise technician to assist in finding the correct fasteners. If improper
fasteners are used, they could result in patient and/or user injury as well as damage to
equipment or other property.
•Only use Sizewise Alliance specific parts for replacement or repairs. The use of improper
replacement parts could result in patient and/or user injury as well as damage to equipment
or other property.
•Only authorized personnel should engage in the troubleshooting process. Troubleshooting
and repair by unauthorized persons could result in personal injury or equipment damage.
•If the weight capacity of the trapeze is exceeded, it could result in patient and/or user
injury as well as damage to equipment or other property.
•Pay close attention to pinch points on the bed to avoid injury to the patient and/or
caregiver.
•Medical equipment should not be used, stacked ,or located on or around equipment that
may create electromagnetic interferences.
•Using other manufacturer’s cables and accessories may affect EMC performance.
Unauthorized use of these items will void warranty and could result in patient and/or
caregiver injury, as well as damage to equipment or other property.
•The use of cables or accessories other than those for which the bed was designed or tested
can significantly degrade emissions and immunity performance.
•It is very important to read the information regarding the possible effects of
electromagnetic interference on Alliance™ and RSS.
•The bed is to be used in accordance with each facility’s policies and procedures.
•Possible fire hazard when used with oxygen administering equipment other than the
nasal mask or 1/2 bed length type tent. Oxygen tent should not extend below the
mattress support level. Lock hand control at foot of bed when using oxygen-administering
equipment.
•During transport, use caution so the bed does not tip or overbalance. Failure to do so
could result in patient and/or caregiver injury, as well as damage to equipment or
other property.
•The bed needs to be stored and transported in a temperature range of 5°C to 40°C (41°F
to 104°F).
•DO NOT expose the bed to humidity greater than 95%.
•Before cleaning the bed, be sure to unplug the power cord from the AC power source.
Failure to do so could result in electrical shock and could result in patient and/or user
injury as well as damage to equipment or other property. Allow to dry completely before
plugging the bed into a properly grounded hospital-grade outlet.

13
Device Information
Description of Alliance™ is designed for use in hospitals, clinics and other related uses. It is
designed to give a useful life of 10 to 15 years depending on usage.
Features include a steel structure
with a polycarbonate-covered surface.
The bed base is divided into two articulated surfaces that are activated electronically (backrest
and legs), a manually articulated surface, (feet) and a fixed module. The mattress platform is made
up of four modules of high-resistance, detachable and HPL (High-Pressure Laminate).
There are four holders in thermoplastic material to hold the IV pole, support handle, etc., as well
as drain bag and nasogastric bag supports on both sides of the bed.
It has four 6" (150 mm) casters, one of which is anti-static and directional. The multifunction
lever(s) or pedal(s), located at each corner that include the following actions: activating the
directional wheel, unlocking the wheels, and total locking of the wheels.
Equipment provided provides a highly stable, raising and lowering arm system.
When activated, the synchronized movement of the backrest module and legs improves the
distribution of pressure and contributes to reducing pressure injuries. It has an automatic
retraction of 5.9” (15 cm).
Electrical Trendelenburg and Reverse Trendelenburg positioning system degree/angle
specifications can be located in the Table of Contents under the Specifications section.
There are different controls to control the movements of the bed, such as the patient hand control,
the patient controls (found on the inside of the left and right head side rails) permitting control
by the patient, and the nurse controls (found on the outside of the left and right head side
rails) permitting control by the nurse/caregiver. The footboard controls allow the nurse/
caregiver the ability to lock out functions. Additional options include IV pole holder,
single pole patient assist, X-ray cassette, 37-pin connector cable for nurse call option.
Purpose of the Device
The positioning nature of this bed provides the caregivers the convenience when attending
to the patients. It is intended for a broad patient population as determined appropriate by
the caregiver or institution. It is intended for patient populations weighing at least 70
lb (32 kg) and is capable of supporting patients up to 550 lb (250 kg).
Product is only intended for use with patient groups described in manual.

14
General Bed Components
NOTE: Not shown: Power Interface Box, Foot Junction Box, 6 Volt, Lead Acid Battery and
Nurse Call Interface.
RSS Description
The purpose of the RSS is to alert the caregiver that a patient is attempting to exit the
bed or is at an immediate risk of falling in settings where continuous surveillance of a
patient is not possible. This is achieved by precisely monitoring a change in patient position.
When the patient attempts to get out of bed an alarm will sound and the nurse call signal will
activate.
The RSS also has an integrated scale that utilizes a transducer-based system to
accurately record the weight of the patient while in the bed. It also has the capability to
record the weight automatically every day for 30 days at user-defined intervals.
Another feature is the protocol timer, which can be set for 1, 2, or 4 hours, to alert the caregiver
that the patient needs attention to or checked on. It has the capability to alert the caregiver by
an audible tone or activate the nurse call signal.
CPR Release

15
Alliance™ Specifications
Specifications
Quality Assurance Standard
...............................IEC 60601-1-6:2010 Ed.3 +A1
……………………………………….. IEC 60601-1:2005 Ed.3+A1]
………………………….... IEC 60601-2-52:2009 Ed. 1+C1: A1
……………………………………… CSA C22.2#60601-1:2014 Ed.3]
……………………... AAMI ES60601-1:2005 +A1
Degree of Protection Against Electric Shock.
............................................................Type B
Degree of Protection Against Ingress of Water . ............................................................... IPX4
Electrical Rating..……………………………….........................................................Class II
Widths: Sleep Surface/Mattress ………………
……….…….….....…...34” /86.4 cm
Overall Width (lowered rails)………...….…....37.6” /95.5 cm (±.20”/5 mm)
Overall Width (raised rails)..................................38.1”/97 cm (±.20”/5 mm)
Lengths: Sleep
Surface/Mattress…….………..…..…....……. 80-88”/203.2-218.4 cm
Retracted .......................................................... 86.6"/220 cm (±.39”/10 mm)
Extended .......................................................... 90.6”/230 cm (±.39”/10 mm)
Mattress Support Platform Minimum………….
..................... 17.0”/43.18 cm (±.50”/1.27 cm)
Mattress Support Platform Maximum ………….…….............
31.5”/80.01 cm (±.50”/12.7 cm)
Trendelenburg ................................................................................................
12º (± 2º tolerance)
Reverse Trendelenburg..................................................................................-12º
(± 2º tolerance)
Head Section................................................................................................. ..60º
(± 5º tolerance)
Knee Section................................................................................................... 45º (± 2º tolerance)
Foot Section....................................................................................................20º (± 2º tolerance)
Under Bed C learance...............................................................................................6.8”/17.3 cm
Safe Working Load. ............................................................................................. 550 lbs./250 kg
Single Pole Patient Assist Weight ............................................................................ 13 lbs./1 kg
Single Pole Assist Weight Capacity .
......................................................................... 165 lbs./75 kg
WARNING: Exceeding the safe working load listed in the
specifications could result in patient or user injury, as well as
damage to equipment or other property. Safe Working Load includes the
patient, mattress and accessories.
Bed Weight ................ .........................................................................................
385 lbs./175 kg
Maximum Altitude. .............................................................................................
6560ft (2000m)
Electrical Rating........................................................................100 - 240 VAC, 50/60 Hz, 5A
Intended for use in Application Environments 1, 2, 3, and 5 per IEC 60601-2-52
Atmospheric Pressure. ...............................................................................
70.0 kPa to 106.0 kPa
Maximum Patient Weight.................................................................................... 408 lbs./185 kg
Heights:
Sleep Surface/Mattress……....................................…….6-8” / 15.3-25.4 cm

16
RSS Specifications
Control Box
Housing
Material ................................................................................................. ABS, UL94-V0 rated
Width................................................................................................................5.79” /14.7 cm
Length ...................................................................................................................3.16” /8 cm
Height …….........................................................................................................2.08” /5.3 cm
Connectors
DC Power Input... .............................................................................5.5mmx2.1 mm coaxial
Load Cell.......................................................................................................4 x RJ12 shielded
Nurse Call .............................................................................Two relay outlets (dual priority)
USB Debug/FW Update………………………………………………………..…USB Port
Nurse Call
Open............................................................................................................................ 0 Ohms
Alarm ....................................................................................................................... .0.3 Ohms
Output ......................................................................................................... 0.206 VRMS Max
Indicators
Load Cell Status………………………………………..4 x bi-color LEDS (green and red)
Power…………………………………………………………………………...Green LED
Status/CPU Activity………………………………………………....Green Heartbeat LED
Charge/Done……………………………………………2 LEDS (1 for charge, 1 for done)
External Power
AC Adapter ........................................................................ 12V, DC, UL-Recognized supply
Current ................................................................................................................................ 1A
Battery Power
Type .......................................................................................................................... 6V SLA
Capacity .........................................................................................................................3.5AH
Recharge Time.....................................................................................................12–15 hours
Operating Time................................................................................... 8 hours approximately
Operating Current
Normal ......................................................................................................................... 120 mA
Charging......................................................................................................................150 mA
Alarming......................................................................................................................250 mA
Weighing Function
Resolution....................................................... 1 lb./0.45 kg. Normal, 0.1 lb./0.05 kg. Internal
Sampling Frequency ....................................................................................................... 10 Hz
Averaging........................................................................................... 16 samples/1.6 seconds

17
WARNING: Any change to the specifications can result in malfunction or
damage to the RSS.
Footboard Control with Integrated RSS System
This Control is located inside the footboard.
Operating Current
Normal ................................................................................................................... 54-160 mA
Alarming.....................................................................................................................150 mA
Audio
Record Memory............................................................................................................... 4 Mb
Voice Record Alarm Time..................................................................................... 15 seconds
Sound Level............................................................................................... 90 dB @ 12 inches
Tones.................................................................................................... 5 user selectable tones
Display
Type .......................................................................... LCD Graphic, blue LED backlighting
Size.............................................................................................................. 64 mmx17.9 mm
Resolution............................................................................ .....................................32 Pixels
Functions
Bed Exit Alarms............................................................................ High, Medium, Low, Off
Protocol Alarm.......................................................................................... Off, 1, 2, 4 Hours
Sound Volumes.............................................................................. Off, Low, Medium, High
Scale .................................................................................................. .0-1000 lbs./0-453.5 kg
Scale Accuracy.............................................................................................. ± 5 lbs./2.25 kg

18
Unpacking and Setup Instructions
The principal components of the Alliance™
Unpacking/Parts Breakdown Unpacking Instructions: Remove the products from the packing
material and examine for shipping damage. If damage is detected in shipping, contact the freight
company and file a damage complaint immediately.
DO NOT CONNECT THE BED BATTERY BACKUP OR PLUG THE POWER CORD INTO
AN AC POWER SOURCE! Remove packaging from the foot board and use the 1/8" screw driver to
secure the connector. After the connector is securely in place attach the cover by inserting the four
plastic rivets at the top and bottom corners. Now you are ready to insert the foot board into the
designated holes.
Next, plug bed in the Linak battery backup. Now remove the top cover from rest secure system tray,
plug in the connector then replace top cover. After these steps are completed you are ready to plug the
bed into the wall. Failure to follow these instructions in the correct order could lead to property
damage and/or injury to the operator.
DO NOT HOT PLUG (This is when you plug the bed into a properly grounded
hospital-grade outlet before you connect the bed battery backup and the RSS
battery backup.)
CAUTION: Keep out of direct sunlight.
DO NOT expose to temperatures below 5°C (41°F) or above 40°C (104°F).
DO NOT expose to moisture or areas of humidity greater than 95%.
Environmental Conditions:
Beware of Electromagnetic Interference from Radio Wave Sources such as: hand-held portable
transceivers with the antenna mounted directly to the transmitting unit including: citizen band (CB)
radios; walkie-talkies; security, fire and police transceivers; cell phones; and other personal
communication devices.
NOTE: Some cell phones and similar devices transmit signals while they are ON, even when not being
used.
Warning or Safety Instructions relating to setup:
WARNING: (100-240 V unit) Make sure the power cord is plugged into a
properly grounded hospital-grade outlet.
WARNING: Failure to follow the Setup instructions could result in patient or
user injury, as well as damage to equipment or other property.

19
RSS Setup
Basic Setup
DO NOT use the RSS if the power cord is cut, frayed or loosely connected to
the bed.
The Nurse Call Interface cable at the head of the bed should be securely plugged into the Nurse
Call Interface on the wall to function properly. Press the Enter button in order to activate
the nurse call located at the foot of the bed.
The first photo shows the unit operating on AC power. The second photo shows the unit
operating on battery reserve power with full charge. The third photo shows the battery reserve with
15% charge.
The display will go in to standby after 60 seconds of inactivity. If this occurs, press
any button except back to resume.
CAUTION: To ensure reliable functionality, the battery reserve should only be
used as a temporary power source until AC power is restored. When the
battery Low Battery Warning screen is shown, the bed should be plugged
into a properly grounded hospital-grade outlet immediately. 24 hours is
required to fully charge/recharge the unit.
SWEIGHT 0 LBS S250 LBS S250 LBS

20
Bed Exit Alarm: Alert Type
The nurse call is always active no matter what selection is made. When selecting nurse call only,
the audio alert will be disabled at the bedside. An alarm will sound if a voice message has not
been recorded and the unit is set to Voice Recording.
1. Access the Menu by pressing the Up or Down arrow until BED
EXIT SETTINGS is highlighted and press Enter.
2. Select SET ALERT TYPE an d then Enter=
3. Choose one of the four alert types and press Enter. The selection will take the
user to the home screen.
With the tare weight set, the patient may now be placed in the bed and begin recording weight.
NOTE: Make sure all equipment and linens are on the bed before zeroing the scale. If an air
support mattress is being used with the patient, be sure to fully inflate the mattress prior to
zeroing the scale. Adding or removing items during the zeroing process will cause inaccurate
patient weight. It is highly recommended that the scale be zeroed before each new patient.
Scale System: Zeroing the Scale
With the patient out of the bed, allow weight to stabilize for 10 seconds, then press and hold the
ZERO button for 3 seconds. This process sets the tare weight (base weight) and will return to
the home screen when complete.
