SKF 143 Series Installation guide

EN
for SKF CircOil centralized lubrication systems
Gerotor pumps and
pump units of series 143
Version 02
Assembly instructions acc. to EC Dir. 2006/42/EC
for partly completed machinery, with associated operating instructions

2
EN
The products
gerotor pumps of product series:
143
are hereby confirmed to comply with the
essential protection requirements stipulated
by the following Directive(s) of the Council
on the approximation of laws of the Member
States:
Machinery Directive 2006/42/EC
Low Voltage Devices 2014/35/EU
RoHS II Directive 2011/65/EU
Information concerning EC Declaration of Conformity and EC Declaration of Incorporation
in conjunction with fluids of Group 1
(Dangerous Fluids) as defined in Article 2,
Para. 2 of Directive 67/548/EEC of June
27, 1967. The product is neither designed
nor approved for use in conjunction with
gases, liquefied gases, pressurized gases in
solution, vapors, or such fluids whose vapor
pressure exceeds normal atmospheric
pressure (1013 mbar) by more than 0.5
bar at their maximum permissible temper-
ature.
When used in conformity with their intend-
ed use, products supplied by SKF do not
reach the limit values listed in Article 3,
Para. 1, Clauses 1.1 to 1.3 and Para. 2 of
Directive 97/23/EC. They are therefore not
subject to the requirements of Annex 1 of
the Directive. Consequently, they do not
bear a CE marking in respect of Directive
97/23/EC. SKF classifies them according to
Article 3, Para. 3 of the Directive. The
Declaration of Conformity and Incorporation
forms part of the product documentation
and is supplied together with the product.
Note:
(a) This declaration certifies compliance
with the aforementioned Directives but
does not constitute a guarantee of charac-
teristics.
(b) The safety instructions in the documen-
tation included with the product must be
observed.
(c) The commissioning of the products here
certified is prohibited until the machine,
vehicle, or similar in which the product is
installed conforms with the provisions and
requirements of the applicable Directives.
(d) The operation of the products at non-
standard supply voltage, as well as non-
adherence to the installation instructions,
can negatively impact the EMC characteris-
tics and electrical safety.
We further declare:
The aforementioned product is, according
to EC Machinery Directive 2006/42/EC,
Annex II Part B, designed for installation
in machinery / for incorporation with
other machinery to form a machine.
Within the scope of the EC Directive,
commissioning shall be prohibited until
the machinery in which this product is
installed conforms with the provisions of
this Directive.
The aforementioned product may, with
reference to EC Directive 97/23/EC
concerning pressure equipment, only
be used in accordance with its intended
use and in conformity with the instruc-
tions provided in the documentation.
The following must be observed in this
regard:
The product is neither designed nor ap-
proved for use
Information concerning EC Declaration of Conformity

3
Masthead
Masthead
These assembly instructions pursuant to
EC Machinery Directive 2006/42/EC are an
integral part of the product described here
and must be kept for future use.
Warranty
The instructions do not contain any infor-
mation on the warranty. This can be found in
the General Terms and Conditions.
Copyright / Integration of instructions
© SKF Lubrication Systems Germany GmbH.
All rights reserved.
These instructions are protected by copy-
right.
The use of the contents for the purpose of
integration into the documentation of the
machine manufacturer in whose product it
will be integrated is expressly allowed. This
also includes the preparation of training
documents for internal, non-commercial
purposes. Any other usage of any kind with-
out written permission of the rights holder
is prohibited and constitutes a violation of
copyright.
Manufacturer and service address
If you have technical questions, please
contact:
SKF Lubrication Systems Germany GmbH
Berlin Plant
Motzener Strasse 35/37
12277 Berlin
Germany
Tel. [phone]
Fax [phone]
www.skf.com/lubrication
Hockenheim Plant
2. Industriestrasse 4
68766 Hockenheim
Germany
Tel. [phone]
Fax [phone]
www.skf.com/lubrication
EN

4
Information concerning EC Declaration of
Conformity and EC Declaration of
Incorporation 2
Explanation of symbols and signs 6
1. Safety instructions 8
1.1 General safety instructions 8
1.2 General behavior when handling
the product 8
1.3 Qualified technical personnel 9
1.4 Electric shock hazard 10
1.5 System pressure or hydraulic
pressure hazard 10
1.6 Operation 10
1.7 Assembly/maintenance/malfunction/
decommissioning/disposal 11
1.8 Intended use 12
1.9 Foreseeable misuse 12
1.10 Disclaimer of liability 13
1.11 Referenced documents 13
1.12 Warning labels on the product 14
1.13 Residual risks 15
2. Lubricants 17
2.1 General information 17
2.2 Selection of lubricants 17
2.3 Approved lubricants 18
2.4 Lubricants and the environment 19
2.5 Lubricant hazards 19
3. Overview 20
3.1 Product codes 21
3.2 Order example 23
4. Assembly 24
4.1 General information 24
4.2 Setup and attachment 25
4.2.1 Installation instructions 26
4.2.2 Information on assembly holes 27
4.2.3 Minimum mounting dimensions 27
4.3 Gerotor pump 28
4.3.1 Gerotor pump design, assembly
holes and minimum
mounting dimensions 28
4.3.2 Gerotor pump with pump flange
and shaft coupling design,
assembly holes and minimum
mounting dimensions 29
4.3.3 Technical data 30
4.3.4 Installation of the gerotor pump 32
4.3.5 Installation of the gerotor pump
with pump flange and shaft
coupling 33
4.4 Gerotor pump unit 34
4.4.1 Foot design, type IM B34, assembly
holes and minimum mounting
dimensions 34
4.4.2 Flange design, type IM B14,
assembly holes and minimum
mounting dimensions 35
4.4.3 Technical data 36
4.4.4 Assembly of gerotor pump unit in
foot design, type IM B34 38
4.4.5 Assembly of gerotor pump unit in
flange design, type IM B14 39
4.4.6 Electrical motor connection 40
4.5 Lubrication line arrangement 41
4.6 Note on the rating plate 43
EN
Table of contents
Table of contents
Assembly instructions

5
Operating instructions 45
1. Safety instructions 46
1.1 General information 46
2. Lubricants 46
3. Delivery, returns, and storage 47
3.1 Checking the delivery 47
3.2 Returns 47
3.3 Lubrication units 47
3.4 General notes 47
4. Assembly 48
4.1 Information on assembly 48
5. Functional description 48
5.1 General system description 48
5.2 Gerotor (annular gear) pumps 49
5.3 Gerotor (annular gear) pump units 50
6. Operation/decommissioning and
disposal 51
6.1 Operation 51
6.1.1 General 51
6.2 Commissioning 51
6.3 Recommissioning after downtime 52
6.4 Temporary shutdown 52
6.5 Decommissioning and disposal 53
7. Maintenance 54
7.1 General information 54
7.2 Maintenance schedule 55
8. Malfunctions, causes, and remedies 56
8.1 Gerotor pumps and gerotor
pump units 57
9. Technical data 59
9.1 Technical data 59
Characteristic curves: 59
9.2 Operating viscosity, 20 mm2/s 60
9.3 Operating viscosity, 140 mm2/s 61
9.4 Operating viscosity, 750 mm2/s 61
9.5 Operating viscosity, 1000 mm2/s 61
9.6 Viscosity-temperature relationship
of oils with different rated viscosity 62
Viscosity range:
9.6.1 2.6 to 50 mm2/s 63
9.6.2 50 to 2000 mm2/s 64
10. Spare parts 65
11. Appendix 67
11.1 IEC squirrel cage motors 67
11.1.1 Principles 67
11.1.2 Voltage code, motor design
50 /60 Hz 72
11.1.3 Installation drawing and dimensions 75
11.1.4 Technical data 77
EN
Table of contents

6
EN
Possible symbols
Meaning
Note
Electrical component hazard, elec-
tric shock hazard
Slipping hazard
Hazard from hot components
Hazard from hot surface
Risk of being drawn into machinery
Crushing hazard
Danger from suspended load
Pressure injection hazard
Explosion-proof component
Electrostatic sensitive components
Wear personal safety equipment
(goggles)
Secure (lock) the closing device
against accidental starting of the
machine
Environmentally sound disposal
Explanation of symbols and signs
Explanation of symbols and signs
You will find these symbols, which warn of
specific dangers to persons, material assets,
or the environment, next to all safety in-
structions in these operating instructions.
Read the instructions completely and follow
all operating instructions and the warning
and safety instructions.
Information symbols within the text
Symbol Meaning
Prompts an action
Used for itemizing
Refers to other facts, causes, or consequences
Provides additional information within procedures
Warning level Consequence Probability
DANGER Death / serious injury Immediate
WARNING Serious injury Possible
CAUTION Minor injury Possible
NOTE Property damage Possible
Symbol

7
EN
Instructions placed on a unit, machine, or
equipment, such as:
 Rotation arrows
 Fluid connection labels
must be followed and kept in fully legible
condition.
 Warnings
Read the assembly and operating instruc-
tions thoroughly and follow the safety
instructions.
Explanation of symbols and signs
Abbreviations and conversion factors
Abbreviations
°C degrees Celsius sq.in. square inch
s seconds kp kilopond
dB (A) sound pressure level cu.in. cubic inch
i.e. that is mph miles per hour
< less than fpsec feet per second
± plus or minus °F degrees Fahrenheit
> greater than fl.oz. fluid ounce
e.g. for example in. inch
Ø diameter gal. gallon
incl. including
K Kelvin Conversion factors
kg kilogram Length 1 mm = 0.03937 in.
rh relative humidity Area 1 cm² = 0.155 sq.in.
kW kilowatt Volume 1 ml = 0.0352 fl.oz.
l liter 1 l = 2.11416 pints (US)
Min. minute Mass 1 kg = 2.205 lbs
max. maximum 1 g = 0.03527 oz.
min. minimum Density 1 kg/cm³ = 8.3454 lb./gal.
(US)
mm millimeter 1 kg/cm³ = 0.03613 lb./
cu.in.
ml milliliter Force 1 N = 0.10197 kp
N Newton Speed 1 m/s = 3.28084 fpsec
Nm Newton meter 1 m/s = 2.23694 mph
oz. ounce Acceleration 1 m/s² = 3.28084 ft./s²
psi pounds per square inch Pressure 1 bar = 14.5 psi
hp horsepower Temperature °C = (°F-32) x 5/9
lb. pound Power 1 kW = 1.34109 hp
sq.in. square inch

8
ENEN
1. Safety instructions
1.1 General safety instructions
The operator must ensure that the assembly
instructions/operating instructions are read
by all persons tasked with working on the
product or who supervise or instruct such
persons. The operator must also ensure
that the staff fully understands the content
of the instructions.
The assembly instructions/operating in-
structions must be kept readily available
together with the product.
Note that the assembly instructions/operat-
ing instructions form part of the product
and must accompany the product if sold to a
new owner.
The product described here was manu-
factured according to the state of the art.
Risks may, however, arise from its usage
and may result in harm to persons or dam-
age to other material assets.
Any malfunctions which may affect safety
must be remedied immediately. In addi-
tion to the assembly instructions/operating
instructions, statutory regulations and other
regulations for accident prevention and
environmental protection must be observed
and applied.
1.2 General behavior when handling the
product
o The product may only be used in aware-
ness of the potential dangers, in proper
technical condition, and according to the
information in this manual.
o Technical personnel must familiar-
ize themselves with the functions and
operation of the product. The specified
assembly and operating steps and their
sequences must be observed.
o Any unclear points regarding proper
condition or correct assembly/operation
must be clarified. Operation is prohib-
ited until issues have been clarified.
o Unauthorized persons must be kept
away from the product.
o All safety instructions and in-house
instructions relevant to the particular
activity must be observed.
o Responsibilities for different activities
must be clearly defined and observed.
Uncertainty seriously endangers safety.
o Protective and safety mechanisms can-
not be removed, modified, or disabled
during operation and must be checked
for proper function and completeness at
regular intervals.
If protective and safety mechanisms
must be removed, they must be in-
stalled immediately following conclu-
sion of work and then checked for
proper function.
o Any malfunctions that occur must be
resolved according to responsibility. The
operator of the system/machine must
1. Safety instructions

9
1
ENEN
1.3 Qualified technical personnel
Only qualified technical personnel may in-
stall, operate, maintain, and repair the prod-
ucts described in the assembly instructions.
Qualified technical personnel are persons
who have been trained, assigned, and in-
structed by the operator of the final product
into which the product described here is
incorporated. Such persons are familiar
with the relevant standards, rules, accident
prevention regulations, and assembly condi-
tions as a result of their training, experience,
and instruction. They are qualified to carry
out the required activities and in doing so
recognize and avoid any potential hazards.
The definition of qualified personnel and the
prohibition against employing non-qualified
personnel are laid down in DIN VDE 0105
and IEC 364.
Relevant country-specific definitions of
qualified technical personnel apply for coun-
tries outside the scope of DIN VDE 0105 or
IEC 364. The core principles of these coun-
try-specific qualification requirements for
technical personnel cannot be below those
of the two standards mentioned above.
The operator of the final product is re-
sponsible for assigning tasks and areas of
responsibility and for the responsibility and
monitoring of the personnel. These areas
must be precisely specified by the operator.
The personnel must be trained and in-
structed if they do not possess the requisite
knowledge.
Product training can also be performed by
SKF in exchange for costs incurred.
The operator must ensure that its personnel
have fully understood the content of the as-
sembly instructions/operating instructions.
be notified in case of malfunctions out-
side the scope of responsibility.
o Wear personal protective equipment.
o Observe the relevant safety data sheets
when handling lubricants.
1. Safety instructions

10
ENEN
1.5 System pressure or hydraulic
pressure hazard
1.4 Electric shock hazard
Electrical connections for the described
product may only be established by quali-
fied and trained personnel authorized to do
so by the operator, and in observance of
the local electrical operating conditions and
local regulations (e.g., DIN, VDE). Serious
injury or death and property damage may
result from improperly connected products.
WARNING
System pressure
Hydraulic pressure
Lubrication systems are pressur-
ized during operation. Centralized
lubrication systems must there-
fore be depressurized before
starting assembly, maintenance,
or repair work, or any system
modifications or system repairs.
WARNING
Electric shock
Performing work on products that
have not been de-energized may
result in serious injury or death.
Assembly, maintenance, and
repair work may only be per-
formed on products that have
been de-energized by qualified
technical personnel. The supply
voltage must be switched off be-
fore opening any of the product's
components.
1.6 Operation
The following must be observed during
commissioning and operation.
o All information within this manual and
the information within the referenced
documents
o All laws/regulations that the operator
must observe
o The information on explosion protection
according to Directive 1999/92/EC (ATEX
137), if necessary
1. Safety instructions

11
1
ENEN
The following must be observed while work-
ing on the product.
o All relevant persons (e.g., operating per-
sonnel, supervisors) must be informed of
the activity prior to the start of work.
Precautionary operational measures /
work instructions must be observed.
o Take appropriate measures to ensure
that moving/detached parts are im-
mobilized during the work and that no
body parts can be pinched by unintended
movements.
o Assemble the product only outside the
operating range of moving parts, at an
adequate distance from sources of heat
or cold.
o Prior to performing work, the product
and the machine/system in which the
product is or will be integrated must be
depressurized and secured against un-
authorized activation.
o All work on electrical components may be
performed only with voltage-insulated
tools.
o Fuses must not be bridged. Always
replace fuses with fuses of the same type.
o Ensure proper grounding of the product.
o Drill required holes only on non-critical,
non-load-bearing parts.
o Other units of the machine/the vehicle
must not be damaged or impaired in their
function by the installation of the central-
ized lubrication system.
o No parts of the centralized lubrication
device may be subjected to torsion, shear,
or bending.
o Use suitable lifting gear when working
with heavy parts.
o Avoid mixing up/incorrectly assembling
disassembled parts. Label parts.
1.7 Assembly/maintenance/malfunction/decommissioning/disposal
1. Safety instructions

12
ENEN 1. Safety instructions
1.9 Foreseeable misuse
Any usage of the product differing from
the aforementioned conditions and stated
purpose is strictly prohibited. Particularly
prohibited are use:
o To feed / forward / store Group 1 dangerous
fluids according to Directive 67/548/EEC
o In another, more critical explosion protec-
tion zone, if applied as ATEX
o To feed / forward / store Group 1 dangerous
fluids according to Directive 67/548/EEC
o To feed / forward / store gases, liquefied
gases, dissolved gases, vapors, or fluids
whose vapor pressure exceeds normal at-
mospheric pressure (1013 mbar) by more
than 0.5 bar at their maximum permis-
sible operating temperature
Unless specially indicated otherwise, gerotor
pumps/pump units of SKF series 143 are not
approved for use in potentially explosive ar-
eas as defined in the ATEX Directive 94/9/EC.
Any other usage is deemed non-compliant
with the intended use.
1.8 Intended use
Gerotor pumps/pump units of SKF series
143 are used to supply
centralized lubrication systems with lubri-
cant and are intended for use in centralized
lubrication systems. They feed mineral and
synthetic oils that are compatible with plas-
tic and NBR elastomers or FKM (FPM). The
permissible operating viscosity for the oils is
20 to 1000 mm2/s at a permissible pumped
medium temperature of 0 to 80°C.
The assembly instructions in Chapter 4 of
these operating instructions must be ad-
hered to. The information in Chapter 9 of
the operating instructions, "Technical data,"
must also be observed.
Only media approved for these gerotor
pumps/pump units
may be used. Unsuitable media may result
in pump unit failure and potentially severe
bodily injury or death and property damage.
The use of synthetic and biodegradable oils
requires prior approval from SKF.

13
1
ENEN
1. Safety instructions
1.10 Disclaimer of liability
SKF shall not be held responsible for
damages:
o Resulting from failure to comply with
these instructions
o Caused by contaminated or unsuitable
lubricants
o Caused by the installation of non-original
SKF components or SKF spare parts
o Caused by inappropriate usage
o Resulting from improper assembly,
configuration, or filling
o Resulting from improper response to
malfunctions
o Caused by non-observance of mainte-
nance intervals
o Caused by independent modification of
system components
o Only media approved for these types of
units may be used. Unsuitable media
may result in pump unit failure and
potentially severe bodily injury or death
and property damage.
1.11 Referenced documents
In addition to this manual, the follow-
ing documents must be observed by the
respective target group:
o Operating and assembly instructions from
the coupling and motor manufacturer
o Operational instructions / approval rules
o Instructions from suppliers of purchased
parts
o Manual for the insulation resistance
tester
o Safety data sheet of the lubricant used
o Project planning documents and other
relevant documents, if provided
The operator must supplement these docu-
ments with applicable national regulations
for the country of use. This documentation
must be included if the product/machine is
sold or transferred.

14
1.12 Warning labels on the product
A rotation arrow and (on larger pump types:
30, 40, 50 l/min) a "Hot surface" sign are
affixed on the product. Before commission-
ing, check that these are present and intact.
Immediately replace warning labels if dam-
aged or missing. The product must not be
operated until then.
Item 1 Rotation arrow
Order No.: MS-WN 1021.038
Item 2 Hot surface
Only for gerotor pumps
of type: 143-1...R...
143-1...T...
143-1...V...
Order No.: 951-111-035
Positioning of rotation arrow, Fig. 1
S
S
Item 1
Item 2
ENEN 1. Safety instructions

15
1
ENEN
1. Safety instructions
1.13 Residual risks
Residual risk Remedy
Life cycle: Assembly
Electric shock due to defective power
lead/mains plug
• Inspect the power lead/mains plug for damage before starting gerotor pump units of SKF
series 143.
People slipping due to floor contamina-
tion with spilled/leaked lubricant
• Exercise caution when connecting the gerotor pump unit’s hydraulic connections.
• Promptly apply suitable binding agents and remove the leaked/spilled lubricant.
• Follow operational instructions for handling lubricants and contaminated parts
Tearing/damage to lines when installed
on moving machine components
• If possible, do not install on moving parts; if this cannot be avoided, use flexible hose lines.
Life cycle: Commissioning / operation
Electric shock due to defective power
lead/mains plug
• Before starting up gerotor pump units of SKF series 143, check the power lead/mains plug
for damage.
Lubricating oil spraying out due to faulty
component fitting/line connection.
• Securely tighten all components with a suitable tool or using the specified torques. Use
hydraulic screw unions and lines suitable for the indicated pressures. These must be checked for
proper connection and for damage prior to commissioning.
Life cycle: Setup, retrofit
People slipping due to floor contamina-
tion with spilled/leaked lubricant
• Exercise caution when loosening or connecting the gerotor pump unit’s hydraulic connections.
• Promptly apply suitable binding agents and remove the leaked/spilled lubricant.
• Follow operational instructions for handling lubricants and contaminated parts

16
ENEN 1. Safety instructions
Residual risk Remedy
Life cycle: Malfunctions, fault-finding
Life cycle: Maintenance, repair
Electric shock due to defective power lead/
mains plug
• Inspect the power lead/mains plug for damage before starting gerotor pump units of SKF
series 143.
Electric shock from open electric motor or
active energized components
Disconnect the mains plug (cut power) before performing any work on electrical components.
Exercise caution when winding and unwinding the power lead and when operating the gerotor
pump unit.
Strong heating of the electric motor due
to a motor jam or continuous duty
Turn off the pump motor and let it cool down. Remedy the cause
People slipping due to floor contamination
with spilled/leaked lubricant
• Exercise caution when loosening or connecting the gerotor pump unit’s hydraulic
connections.
• Promptly apply suitable binding agents and remove the leaked/spilled lubricant.
• Follow operational instructions for handling lubricants and contaminated parts
Life cycle: Decommissioning, disposal
Environmental contamination by lubricants
and wetted parts
• Dispose of contaminated parts according to the applicable legal/company rules
People slipping due to floor contamination
with spilled/leaked lubricant
• Exercise caution when loosening the gerotor pump unit’s hydraulic connections.
• Promptly apply suitable binding agents and remove the leaked/spilled lubricant.
• Follow operational instructions for handling lubricants and contaminated parts
Environmental contamination by lubricants
and wetted parts
• Dispose of contaminated parts according to the applicable legal/company rules

17
2
1
EN
2. Lubricants
2. Lubricants
2.1 General information
Intended use is the use of the products for
the purpose of providing centralized lubri-
cation/lubrication of bearings and friction
points using lubricants within the physical
usage limits which can be found in the doc-
umentation for the devices, e.g., operating
instructions and the product descriptions,
e.g., technical drawings and catalogs.
Particular attention is called to the fact that
hazardous materials of any kind, especially
those materials classified as hazardous by
EC Directive 67/548/EEC, Article 2, Para.
2, may only be filled into SKF centralized
lubrication systems and components and
delivered and/or distributed with such
systems and components after consulting
Selection of a lubricant suitable for the
lubrication task is made by the machine/
system manufacturer and/or the operator of
the machine/system in cooperation with the
lubricant supplier.
When selecting a lubricant, the type of
bearings/friction points, the expected load
during operation, and the anticipated ambi-
ent conditions must be taken into account.
All economic and environmental aspects
must also be considered.
NOTE
Observe the instructions from the machine
manufacturer regarding the lubricants that
are to be used. The amount of lubricant
required at a lubrication point is specified
by the bearing or machine
manufacturer. It must be ensured that the
required quantity of lubricant is provided
to the lubrication point. The lubrication
point may otherwise not receive adequate
lubrication, which can lead to damage and
failure of the bearing.
2.2 Selection of lubricants
NOTE
All products from SKF Lubrication
Systems may be used only for their in-
tended purpose and in accordance with
the information in the product's operating
instructions.
with and obtaining written approval from
SKF Lubrication Systems.
No products manufactured by SKF Lubrication
Systems are approved for use in
conjunction with gases, liquefied gases,
pressurized gases in solution, vapors, or
such fluids whose vapor pressure exceeds
normal atmospheric pressure (1013 mbar)
by more than 0.5 bar at their maximum
permissible temperature.
Other media which are neither lubricant nor
hazardous substance may only be fed after
consultation with and written approval from
SKF Lubrication Systems.
SKF Lubrication Systems considers lubricants
to be an element of system design that
must always be factored into the selection
of components and the design of centralized
lubrication systems. The lubricating properties
of the lubricants are critically important in
making these selections.

18
EN 2. Lubricants
Please contact SKF Lubrication Systems
if you have further questions regarding
lubricants. It is possible for lubricants to be
tested in the company's laboratory for their
suitability for pumping in centralized lubri-
cation systems (e.g., "bleeding").
You can request an overview of the lubricant
tests offered by SKF Lubrication Systems
from the company's Service department.
The product described here can be operated
using lubricants that meet the specifications
in the technical data. Depending on the
product design, these lubricants may be oils,
fluid greases, or greases.
Mineral, synthetic, and/or and rapidly bio-
degradable oils and base oils can be used.
Consistency agents and additives may be
added depending on the operating condi-
tions.
Note that in rare cases, there may be
lubricants whose properties are within the
permissible limits values but whose other
characteristics render them unsuitable for
use in centralized lubrication systems. For
example, synthetic lubricants may be in-
compatible with elastomers.
NOTE
Only lubricants approved for the product
may be used. Unsuitable lubricants can
lead to failure of the product and to property
damage.
2.3 Approved lubricants
NOTE
Different lubricants must not be mixed
together. Doing so can cause damage and
require costly and complicated cleaning of
the product/lubrication system. It is
recommended that an indication of the
lubricant in use be attached to the lubri-
cant reservoir in order to prevent acciden-
tal mixing of lubricants.
NOTE
If necessary, SKF Lubrication Systems can
help customers to select suitable compo-
nents for feeding the selected lubricant
and to plan and design their centralized
lubrication system.

19
2
EN
2. Lubricants
2.5 Lubricant hazards2.4 Lubricants and the environment
NOTE
Lubricants can contaminate soil and
waterways. Lubricants must be properly
used and disposed of. Observe the local
regulations and laws regarding the disposal
of lubricants.
It is important to note that lubricants are
environmentally hazardous, flammable
substances which require special precau-
tionary measures during transport, storage,
and processing. Consult the safety data
sheet from the lubricant manufacturer
for information regarding transport, storage,
processing, and environmental hazards of
the lubricant that will be used.
The safety data sheet for a lubricant can be
requested from the lubricant manufacturer.
WARNING
Lubricants
Gerotor pumps must always be
free of leaks. Leaking lubricant is
hazardous due to the risk of slip-
ping and injury. Beware of any
lubricant leaking out during as-
sembly, operation, maintenance,
or repair of centralized lubrication
systems. Leaks must be sealed off
without delay.
Lubricant leaking from centralized lubrica-
tion systems is a serious hazard. Leaking
lubricant can create risks that may result
in physical harm to persons or damage to
other material assets.
NOTE
Follow the safety instructions on the lubri-
cant's safety data sheet.

20
EN 3. Overview
3. Overview
Overview, Fig. 2
Item Description
1Gerotor pump unit
in flange design
1.1 Gerotor pump
1.2 Electric motor
1.3 Electric motor terminal box
1.4 Pump flange
1.5 Suction port (S), opposite
pressure port (P)
2Gerotor pump
2.1 Gerotor pump
2.2 Pump flange
2.3 Shaft coupling
3Gerotor pump unit
in foot design
3.1 Gerotor pump
3.2 Electric motor
3.3 Electric motor terminal box
3.4 Pump foot
3.5 Suction port (S), opposite
pressure port (P)
S
S
S
Gerotor pump unit
in flange design
2 Gerotor pump+pump flange+shaft coupling
1
2.1
1.1
1.2
1.3
1.5
2.2 2.3
Gerotor pump unit in foot design
3
1.4
3.1
3.23.3
3.4
3.5
