SKYDANCE T1-KB User manual

LVD
User Manual Ver 1.0.1
Technical Parameters
Model No.: T1-KB, T2-KB, T3-KB
Features
Page 1
1-3 color/Glass panel/Rotary dimming/Wireless remote 30m distance/CR2032 battery
Wall Mounted Rotary Panel RF Remote
● Rotary glass panel RF remote, apply to single color, dual color or RGB LED controller.
● Rotate knob to change RGB color, color temperature or brightness,
support long press or twice click operation.
● Each remote can match one or more receiver.
● CR2032 battery powered.
● White & Black glass panel available.
T1-KB T2-KB T3-KB
After turn on light:
● Rotate: Rotate knob to adjust brightness (2.5 turns, 50 levels).
● Long push(1-6s): Continuous 256 levels brightness adjustment.
T1-KB Single color dimmer
T2-KB Dual color temperature
T3-KB RGB
● Push: Turn on or off light.
● Push: Turn on or off light.
After turn on light:
● Rotate: Rotate knob to change color temperature or brightness (2.5 turns, 50 levels).
● Push twice: Switch between color temperature or brightness adjustment.
● Long push(1-6s): Continuous 256 levels brightness adjustment.
After turn on light:
● Rotate: Rotate knob to change RGB color (3 turns, 60 colors)
or brightness (2.5 turns, 50 levels).
● Push twice: Switch between RGB color or brightness adjustment.
● Long push(1-6s): Continuous 256 levels brightness adjustment.
● Push: Turn on or off light.
Push ON / OFF
Long Push Dimming
Push ON / OFF
Double Push Switch CCT/DIM
Push ON / OFF
Double Push Switch Color/DIM
Knob function
Input and Output
Warranty
5 years
Warranty
Operation temperature
Environment
IP20
IP rating
Ta: -30
O
C ~ +55
O
C
Output signal RF 2.4GHz( )
Working voltage 3VDC CR2032( )
Working current ＜5mA
Standby current ＜10μA
Standby time 1 year
Remote distance 30m(Barrier-free space)
Safety and EMC
EMC standard (EMC) EN301 489,EN 62479
Radio Equipment(RED) EN300 328
Certification CE,EMC,LVD,RED
EN60950
Safety standard(LVD)
www.iskydance.pl

User Manual Ver 1.0.1 Page 2
Mechanical Structures and Installations
Typical base as below:
European style
Baseplate Base
Uninstall
Installation diagram:
86 size
Touch panel
86.00 mm
86.00 mm
52.00 mm
52.00 mm
59.00 mm
48.00 mm
11.50 mm
Safety information
1. Read all instructions carefully before you begin this installation.
2. When installing battery, pay attention to the battery positive and negative polarity.
A long time without the remote control, remove the battery.
When remote distance becomes smaller and insensitive, replace the battery.
3. If no response from the receiver, please re-match the remote.
4. Gently handle remote, beware of falling.
5. For indoor and dry location use only.
Match Remote Control (two match ways)
Use the controller’s Match key
Match:
Short press match key, immediately push the knob.
The LED indicator fast flash a few times
means match is successful.
Use Power Restart
Match:
Switch off the power, then switch on power again,
immediately push the knob 3 times.
The light blinks 3 times means match is successful.
Delete:
Switch off the power, then switch on power again,
immediately push the knob 5 times.
The light blinks 5 times means all matched remotes were
deleted.
Delete:
Press and hold match key for 5s to delete all match,
The LED indicator fast flash a few times
means all matched remotes were deleted.
End user can choose the suitable match/delete ways. Two options are offered for selection:
Replace batter y:
Note: Before the first use,
please remove the protective
film on the battery.
Remove old C 2032 BatteryR
Insert new C 2032 BatteryR
1
2
3
4
T1-KB,T2-KB,T3-KB Wall Mounted Rotary Panel RF Remote
+
+
