SKYDANCE R11 User manual

● Apply to single color, dual color or RGB LED controller.
● Ultra sensitive color adjustment touch slide.
● Each remote can match one or more receiver.
● CR2032 battery powered.
● Operate with LED indicator light.
● Magnet on the back which can be easily stuck on back holder or any metal surfaces.
Model No.: R11,R12,R13
Features
Touch color slide/1-3 color/Wireless remote 30m distance/CR2032 battery/Magnet stuck fix
Ultrathin Touch Slide RF Remote Controller
R11 R12 R13
Technical Parameters
Input and Output
Warranty
5 years
Warranty
Operation temperature
Case temperature (Max.)
Environment
IP20
IP rating
Ta: -30
O
C ~ +55
O
C
T c: +85
O
C
Output signal RF 2.4GHz( )
Working voltage 3VDC CR2032( )
Working current ＜5mA
Standby current ＜10μA
Standby time 1 year
Remote distance 30m
Safety and EMC
EMC standard (EMC) EN301 489,EN 62479
Radio Equipment(RED) EN300 328
Certification CE,EMC,LVD,RED
EN60950
Safety standard(LVD)
LVDRED
1 Zone Dimming 1 Zone CCT 1 Zone RGB
User Manual Ver 1.0.2 www.iskydance.com Page 1

Mechanical Structures and Installations
36.00 mm
139.00 mm
11.00 mm
Operation
● To extend battery life, no operation after 20 seconds, the touch slide will enter sleep state.
● If the light is on, long press on/off key exceed 1 second, then touch slide ming.to dim
● If the light is off, short press on/off key to turn on light, then touch slide ming.to dim
Match Remote Control (two match ways)
Use the controller’s Match key
Match:
Short press match key, immediately press on/off
key of the remote.
Use Power Restart
Match:
Switch off the power, then switch on power again,
immediately short press on/off key 3 times on the remote.
The light blinks 3 times means match is successful.
Delete:
Switch off the power, then switch on power again,
immediately short press on/off key 5 times on the remote.
The light blinks 5 times means all matched remotes were
deleted.
Delete:
Press and hold match key for 5s to delete all match,
The light blinks 5 times means all matched remotes
were deleted.
End user can choose the suitable match/delete ways. Two options are offered for selection:
R11,R12,R13 Ultrathin Touch Slide RF Remote Controller
53.50 mm
Note: Before the first use,
please remove the protective
film on the battery.
C 2032 BatteryR
Back holder with magnet
To fix the remote, three options are offered for selection:
Option 1: stuck the remote on any metal surfaces directly.
Option 2: fix the remote' back holder on the wall with two screws.
Option 3: adhere the remote' back holder to the wall with paster.
User Manual Ver 1.0.2 www.iskydance.com Page 2

1%
100%
50%
WW 50%
CW 50%
WW 100%
CW 0%
WW 0%
CW 100%
Short press to turn on or turn off light.
Long press 1-6s to adjust brightness.
Bright touch slide
Color touch slide
● R11 1 zone dimming remote
● R12 1 zone CCT remote
On/Off
On/Off
LED indicator
LED indicator
Key function
User Manual Ver 1.0.2 www.iskydance.com Page 3
R11,R12,R13 Ultrathin Touch Slide RF Remote Controller

Safety information
1. Read all instructions carefully before you begin this installation.
2. When installing battery, pay attention to the battery positive and negative polarity.
A long time without the remote control, remove the battery.
When remote distance becomes smaller and insensitive, replace the battery.
3. If no response from the receiver, please re-match the remote.
4. Gently handle remote, beware of falling.
5. For indoor and dry location use only.
R 100%
G 100%
B 100%
Color touch slide
● R13 1 zone RGB remote
Short press to turn on or turn off light.
Long press 1-6s to adjust brightness.
On/Off
R11,R12,R13 Ultrathin Touch Slide RF Remote Controller
LED indicator
User Manual Ver 1.0.2 www.iskydance.com Page 4
