INSTRUCTION MANUAL
MEAT GRINDER
Models
34977.1- Março/2011
- ALÉM DESTAS MÁQUINAS, FABRICAMOS UMA LINHA COMPLETA DE EQUIPAMENTOS. CONSULTE SEU REVENDEDOR.
- ESTE PRODUTO CONTA COM ASSISTÊNCIA TÉCNICA, REPRESENTANTES E REVENDEDORES EM TODO TERRITÓRIO NACIONAL.
DEVIDO À CONSTANTE EVOLUÇÃO DOS NOSSOS PRODUTOS, AS INFORMAÇÕES AQUI CONTIDAS PODEM SER MODIFICADAS SEM AVISO PRÉVIO.
LINHA DIRETA
SKYMSEN
Ramais 2011
2012
2013
E-mail: [email protected]
METALRGICA SIEMSEN LTDA.
Rua Anita Garibaldi, nº 262 – Bairro: Sno Luiz – CEP: 88351-410
Brusque – Santa Catarina – Brasil
Fone: +55 47 3211 6000 / 3255 2000
Fax: +55 47 3211 6020 / 3255 2020


01
SUMMARY
5. Analyses and Problem Solving
5.1 Problems, Cause and Solutions
11
5.3 Electric Diagram Mod. PCP-10L and PCP-22L
5.2 Components Adjustment and Replacement
12
12
11
4. General Safety Practices
4.1 Basic Operation Procedures
4.4 Operation
4.2 Safety Procedures and Notes Before Switching the Machine On
4.5 After Finishing the Work
4.3 Routine Inspection
4.6 Maintenance
4.7 Advices
8
8
9
9
10
10
10
10
3. Operation
3.1 Grind Device Assembling
3.2 Operating Procedures
3.3 Starting
5
5
6
6
2. Installation and Pre Operation
2.1 Installation
2.2 Pre Operation
4
4
4
1.2 Main Components
1.3 Technical Characteristics
1. Introduction
2
1.1 Safety
2
2
4
4.8 Safety System
10
3.4 Cleaning
6
12
5.2 Components Adjustment and Replacement
5.2.1 Plate and knife sharpening
Well-sharpened plates and knife will make machine to work with less effort and
consequently all components will last longer. Therefore call your nearest technical assistant to
sharpen plates and knife periodically.
5.3 Electric Diagram Mod. PCP-10L and PCP-22L
ON/OFF Switch
+
110/220V Selector Switchs
5.2.2 Gear Box
The Meat Grinders models PCP-10L and PCP-22L have gear box lubricated with
oil.
To keep your machine in good conditions for a long time check oil level at every
5.000 hours of use. Take your machine to the nearest technical assistant to do this job.
Use 250 ml of oil each time you need to refill gear box. The following oils are
recommended: SAE140,APIGL-4 orANP1006.

02
