Features Benefits
ADSL PCI Modem
SMC7003-PCI
Asymmetrical Digital Subscriber Line (ADSL) broadband WAN technology is ideal for residential or
SOHO environments. Data and voice transmissions can be made simultaneously. Data is transmitted at
8 Mbps over distances up to 18,000 feet (more than 3 miles.)
The SMC7003-PCI is a plug-and-play ADSL modem that provides high-speed Internet access over exist-
ing telephone lines.It features an always-on digital connection,delivers concurrent voice and data over
a single line,and provides wide equipment interoperability and system compatibility. The modem’s PCI
bus seamlessly interfaces with PCs.
Designed to ensure a high-performance Internet connection for the SOHO environment, this new
modem connects to the web at speeds equal to those available in your office.Its always-on digital con-
nection saves you time by eliminating dial-up delays.The modem is interoperable with systems from
major central office equipment makers, and provides compatibility with various ISP services (static or
dynamic.)
The modem also supports both full-rate DMT connection (with 8 Mbps downstream and 640 Kbps
upstream), and the more economical G.lite connection (with 1.5 Mbps downstream and 512 Kbps
upstream.)
The new SMC ADSL/PCI modem allows SOHO users to employ a wide range of network applications.
Multiprotocol encapsulation of TCP/IP,Novell’s IPX,and Windows NetBEUI provides total access to the
Internet and all your corporate resources (i.e.printers,file servers,and multimedia services.)
With this new ADSL modem,investments are protected through the support of pop-
ular DSL connection models,including PPP over Ethernet, PPP over ATM,bridging
and routing.
All SMC products are supported by a limited lifetime warranty, the SMC Customer
Satisfaction Guarantee,and toll-free 24/7 technical support.
High Performance
• Full ADSL standard support
• Full rate transmission at up to 8 Mbps downstream;
640 Kbps upstream
• G.lite transmission at up to 1.5 Mbps downstream;
512 Kbps upstream
• Full rate adaptive modem at 32 Kbps steps
• Loop up to 18,000 feet (3.5 miles.)
• Plug-and-play connection
• Supports PPP over ATM
• MultiProtocol over ATM
•Windows 98/2000 compliant
• Interoperable with Alcatel’s DSLAM
Reliable
• Limited lifetime warranty
• 24/7 technical support
Web Site
• www.smc.com

Specifications
SMC7003-PCI Modem
TRANSMISSION CHARACTERISTICS:
ServiceType
Dual Mode full rate G.dmt or economical G.lite
Data Rate
G.dmt rate adaptive up to 8Mbps downstream,
640Kbps upstream
G.lite rate adaptive up to 1.5 Mbps downstream,
512Kbps upstream
DataType
Simultaneous data and voice (can coexist with HPNA
network)
Connection Length
Up to 18000 ft.(5.5 km) over 26 Gauge AWG
DSLAM Interoperability
Compatible withT1.413-standard,as well as Cisco and
AlcatelT1.413-like DSLAMs
PHYSICAL CHARACTERISTICS:
Interface
RJ-11 port for standard phone wire connection
to ADSL service provider
Power Consumption
0.75A Max @ +5V (+/-5%)
0.1A Max @ +/-12V (+/-5%)
Temperature
OperatingTemperature:0 ~ 50˚ C with 1 meter/sec airflow
StorageTemperature:-20 ~ 70˚ C
Humidity
Operating Humidity:0 ~ 95% (Non-condensing)
Storage Humidity:0 ~ 95%
SYSTEM REQUIREMENTS:
CPU
Pentium 133MHZ and up (Pentium 166 recommended),
Pentium II,Pentium III
Operating System
Windows 98,Windows 2000 (i.e.NT 5.0)
STANDARDS CONFORMANCE:
Emissions
FCC Part 15 Class B,CE Class B,FCC Part 68
Safety:
CE Mark
STANDARDS:
Basic ADSL
Full Rate ADSL – ANSIT1.413 Issue 2,G.dmt (ITU G.992.1),
G.lite (G.992.2),G.hs (G.994.1)
Transport Protocols
IP/ATM (RFC 1577),PPP/ATM (RFC 2364),PPP/Ethernet
(RFC 2516),PPP (RFC 1661),Multiprotocol encapsulation,
Bridged Ethernet/ATM,Routed IP/ATM (RFC 1483)
ATM Attributes
ATMTransmission Convergence,ATM Framing (with
traffic shaping),ATM SAR/AAL5,ATM Forum UNI3.1
signalling,ATM UBR Service Class
Product Description
SMC7003-PCI ADSL PCI Modem
