SMITH SYSTEM Cascade 26161 User manual

Form# 179953A 05/2019
Assembly Instructions
Cascade®
Single Ped Teacher Desk
If you have damaged or missing components,
Please contact customer service at 1-800-328-1061
179998

Form# 179953A 05/2019
Hardware and Components
Special Notes:
Check that all components are accounted for and undamaged before assembling.
Please assemble the product in a clean and dry area.
For larger units you may need another person to help assemble theproduct.
Clean the product with a mild cleaner and a damp cloth.
*Our Cascade Teacher Desks come in diīĞrent lengths, so hardware and screw hole placement will vary.
If you feel you have not received all the necessary hardware, please call us at 800-328-1061.
Replacement Pack 69756-R Includes:
(16) 77471- ¼-20X1/2” Combo Drive Machine Screw
(27) 70054- SM Screw #10X.75 HI/LO PTH
#10 Wood Screws
(Qty. 16)*
P/N-70054
¼-20X1/2” Machine Screws
(Qty. 8)
P/N- 77471
3” Dual Wheel Caster Pack
(Qty. 2 casters, ½ pack)
P/N-17553
Table Top
(Qty. 1)
Modesty
Panel
(Qty. 1)
Cascade Ped
(Qty. 1)
Acrobat Leg
(Qty. 1 Leg)
(Right or LeŌͿ
179998

Form# 179953A 05/2019
Assembly Instructions
Step 1: Lay the top upside down, with the cut of the T-mold at the back and make sure the Laminate is
Face Down and the pre-drilled holes are facing upwards. Line up the Cascade Teacher Desk Leg with the
predrilled holes, and a h it to the top with the supplied wood screws.
Step 2 : (If your Ped is a Box Box File): Place the Box Box File (BBF) upside down on the table top
opposite the leg. Align the Modesty Panel with the two holes on the BBF and the leg, a ach to the BBF
and the leg using (4) ¼-20 Machine Screws. The screw holes on the BBF are along the outside of the top
plate (as seen in the picture).
Modesty Panel
Cabinet
ith
¼-20 Machine Screw
Screw holes on BBF
(Same 4 holes on the outside
with 3 holes on the back side)
179998

Form# 179953A 05/2019
Step 2B: (If your Ped contains totes): Remove all totes from the ped. Place your Tote Ped upside down
on the top opposite the leg. Align the modesty panel to with the Ped and the Leg. A ach to the Ped and
the leg with (4) ¼-20 Screws.
Cabinet
Modesty Panel
ith
¼-20 Machine Screw
Screw holes for Tote
ped is inside on the
top plate.
Step 3: A the Cascade Ped and modesty panel to the table top using the supplied wood screws.
Hole placement for the Peds are shown in the previous step.
Step 4: A the plate casters to the cabinet using the supplied screws. Next, a the stem casters
to the single leg.
Step 5: With assistance, place the unit upright.
Step 6: (Only Cascade Teacher Desk with Totes): Re-insert the totes into the Cascade Ped.
179998
