SMITH SYSTEM Access Corner Station User manual

Access Corner Station
Assembly Instructions
www.smithsystem.com
For assistance in assembling product, missing or damaged
parts, or to place an order please contact customer service at 1-800-328-1061.
You may also place your order online at
Form #179851
9/2006
page 1 of 5

URGENT:
Please make sure you have received all hardware and components before assembling product.
If you have damaged or
missing components please
contact customer service.
1-800-328-1061
You will need a Phillips head screw driver.
If you have damaged or missing components or hardware please contact customer service at 1 [phone].
1. Check that all components are accounted for and undamaged before assembling.
2. Please assemble product in a clean and dry area.
3. For larger units you may need another person to help assemble the product.
4. Clean the product with a mild cleaner and a damp cloth.
Special Notes
Tools
Notes:
Hardware and Components
Wrench (2)
3/8"-16 Dog Nut Screw
(located in each PSD-Leg, 2-per leg)
#10 Wood Screws
1/4"-20UNC Connector Bolt (4) Key
(4)
Adjustable
PSD-Legs (2)
Table Top (1)
Wire Manager (2)
With Door
Corner Leg (1)
Form # 179851
9/2006
page 2 of 5

1-800-328-1061
Step 1 First attach the corner leg, using (2) Connector Bolts (located in your hardware pack),
to the wire manager. (See Drawing 1A). Next attach the PSD leg on the opposite side using
(2) Connecor Bolts. (See Drawing 1B). Keep bolts finger tight until the table is completely
assembled.
Drawing 1
Drawing 1A
Drawing 1B
Access Station Directions
Step 2 Now place the wire manager which is connected to both legs on a smooth, clean surface with
the bottom facing up. Next adjust the PSD leg to desired height. (See Drawing 2A). After
that, adjust the corner leg to the desired height. (See Drawing 2).
If you have damaged or
missing components please
contact customer service.
Drawing 2
Drawing 2A
Drawing 2B
Form # 179851
9/2006
page 3 of 5

www.smithsystem.com
Drawing 3
Drawing 3A
Drawing 3B
Assembly Instructions (cont.)
If you have damaged or missing components please contact customer service.
800-328-1061
Step 3 Attach the other PSD leg using (2) Connector Bolts to the wire manager. (See drawing 3B). Then adjust
the PSD leg to desired height. (See Drawing 3A).
Step 4 Flip over the assembled frame over which was made in step 2. (Reference to drawing 4 for help).
Then flip over the other wire manager which was assembled in step 3 and align the holes from the
wire manager to the corner leg. Next screw the wire manager to the corner leg using (2) Connector
Bolts. (See Drawing 4A).
Drawing 4
Drawing 4A
Form # 179851
9/2006
page 4 of 5

Step 6 Now go back and tighten all the screws referenced in all 5 steps. Your desk is ready for use.
Step 5 Next gently slide the table top with the top facing up on the assembly frame from step four. Then
align the predrilled holes underneath the table top with the wire manager and the PSD leg. Verify
alignment before you start screwing in the top. Next attach the PSD legs using (4) Truss Head
Screws to the table top through the predrilled holes. Do not place screws in the back two holes
of leg. (See Drawing 5B). Then screw the wire manager into the table top using Truss Head
Screws. (See Drawing 5A).
Drawing 5
Drawing 5A
Drawing 5B
Assembly Instructions (cont.)
*Mirror image*
*Mirror image*
Form # 179851 9/2006
page 5 of 5
