SMITH SYSTEM UXL Nest and Fold Table User manual

For assistance in assembling product, missing or damaged parts, or to place an order, please contact
customer service at 800-328-1061.
You may also place your order online at
Form #179977 www.smithsystem.com 08/2016
ASSEMBLY INSTRUCTIONS
UXL Nest and Fold Table
SPECIAL NOTES
1. Check that all components are accounted for and undamaged before
assembling.
2. Please assemble product in a clean dry area.
3. For larger units, you may need another person to help assemble the
product.
4. Clean the product with a mild cleaner and a damp cloth.

For assistance in assembling product, missing or damaged parts, or to place an order, please contact
customer service at 800-328-1061.
You may also place your order online at
Form #179977 www.smithsystem.com 08/2016
P/N: 70054
¾” Wood Screw
QTY: 14
M5X.8X10mm
Machine Screw
QTY: 2
M4X.7X6mm
Machine Screw
QTY: 4
Nest & Fold
Support caps
QTY: 2
Nest & Fold
Threaded Caster
QTY: 4 Casters
Caster Wrench
QTY: 1
Nest & Fold Folding
Mech.
QTY: 1 Pair
Nest & Fold
Handle
QTY: 1
Nest & Fold
Beam
QTY: 1
Nest & Fold Leg Set
QTY: 1 Set
Nest & Fold
Support
QTY: 1
Replacement Hardware Pack
70148-R includes:
(4) M8X1.25X30mm Countersunk Machine
Screws
(1) 5mm Allen Wrench
COMPONENTS & HARDWARE

For assistance in assembling product, missing or damaged parts, or to place an order, please contact
customer service at 800-328-1061.
You may also place your order online at
Form #179977 www.smithsystem.com 08/2016
ASSEMBLY INSTRUCTIONS
Step 1: Lay the frame with the attached top upside down on a clean dry surface.
Step 2: Pull the handle towards the front of the table to unlock the mechanisms and
flip both mechanisms up.
Step 3: Remove the top plate from both legs.

For assistance in assembling product, missing or damaged parts, or to place an order, please contact
customer service at 800-328-1061.
You may also place your order online at
Form #179977 www.smithsystem.com 08/2016
Step 4: Slide the leg around the beam ensuring that the longer leg faces towards the
handle and the shorter leg faces away from the handle. (FACE LEG’S FEET OUTWARDS)
Step 5: Attach both legs to each side of the beam and tighten using a 5mm Allen
Wrench, bolts, and plate removed in Step 2.
Step 6 (Optional): Lock the legs back into their upright positions. Attach casters to the
bottom of the leg sets using the supplied wrench to tighten fully.

For assistance in assembling product, missing or damaged parts, or to place an order, please contact
customer service at 800-328-1061.
You may also place your order online at
Form #179977 www.smithsystem.com 08/2016
Step 7: Ensure legs are locked into position and place table into upright position.
Step 8: To level table, adjust caster up or down by turning the hex nut below
silver knurled disc - clockwise or counter-clockwise until level. Lock in place by
turning.
