SMITH SYSTEM Flowform User manual

Document #: 179687
REVISED: 10/2020
Assembly Instructions
Flowform Adjustable Height Tables
If you have damaged or missing components,
please contact customer service at 1-800-328-1061

Document #: 179687
REVISED: 10/2020
Hardware and Components
PACK #60001
(
3 TO 4 LEGS
PER TABLE )
ORBIT LEG FOR CASTER
QTY. 1
5/16”-18 X 1/2”BOLT
QTY. 2
NYLON GLIDE TIP
QTY. 1
#10 X 3/4”HI-LO WOOD
SCREW
QTY. 14
3/8”-16 X 5/8”SET SCREW
QTY. 2
ORBIT LEG WITH GLIDE
QTY. 1
3/16”ALLEN WRENCH
QTY. 1
FELT GLIDE TIP
QTY. 1
2" CASTER 7/16" STEM W/LOCK
(PN: 60021)
QTY. 1
5/16”-18 X 1/2”BOLT
QTY. 2
3/8”-16 X 5/8”SET SCREW
QTY. 2
3/16”ALLEN WRENCH
QTY. 1
PACK #60002
( 3 TO 4
LEGS
PER TABLE )
ORBIT TOP WITH FRAME
(MAY APPEAR
DIFFERENT THAN SHOWN)
QTY. 1
ORBIT TOP, NO FRAME
(MAY APPEAR DIFFERENT THAN SHOWN)
QTY. 1
OR
#10 X 3/4”HI-LO WOOD
SCREW
QTY. 14

Document #: 179687
REVISED: 10/2020
Special Notes:
xTOOLS REQUIRED:
• Drill w/#2 Phillips driver bit, or #2 Phillips head screwdriver.
xCheck that all components are accounted for and undamaged beforeassembling.
xPlease assemble the product in a clean and dry area.
xYou may need another person to help assemble the product. Team lifting may be
required.
xClean the product with a mild cleaner and a damp cloth.

Document #: 179687
REVISED: 10/2020
Assembly Instructions
1. FOR LEGS WITH GLIDES: Insert either the Nylon or Felt Tip into the Glide. Press down
on tip until it snaps into place.
Helpful Hint: It is recommended that the Nylon Glide Tip is used for carpeted areas
and the Felt Glide Tip is used for hard surfaces such as hardwood floors.
NOTE: To remove Glide Tip, use a flat-head screwdriver inserted into the notch in the
back of the Glide to pry up the Glide Tip.
2. FOR LEGS WITH CASTERS: Insert stem of caster into Casket Socket on leg. Press down
until the caster stem is fully inserted into the leg.
OR

Document #: 179687
REVISED: 10/2020
3. FOR FRAMELESS TABLES: Lay top down on a clean smooth surface that will not harm
the top finish. Underside of top should be exposed. Top may be heavy, team lifting is
encouraged.
4. Align leg mounting plate holes with pilot holes on underside of top. Install all 14 of the
#10 x 3/4” Hi-Lo Wood Screws to secure the leg to the top.
5. Next install the 5/16”-18 x 1/2” Bolts into leg gusset.
Helpful Hint: These bolts are used on current and future accessories.

Document #: 179687
REVISED: 10/2020
6. Install the other legs as previously shown.
7. FOR TABLES WITH FRAMES: Lay top down on a clean smooth surface that will not harm
the top finish. Underside of top and frame should be exposed. Top may be heavy, team
lifting is encouraged.
8. Slide gusset of leg into frame and align leg mounting plate holes with pilot holes on
underside of top.

Document #: 179687
REVISED: 10/2020
9. Install 13 of the #10 x 3/4” Hi-Lo Wood Screws to secure the leg to the top leaving out
one of the screws as the hole is covered by the frame.
10. Next install the 5/16”-18 x 1/2” Bolts to connect the frame to the leg gusset.
11. Install the other legs as previously shown.

Document #: 179687
REVISED: 10/2020
12. TO ADJUST LEG HEIGHT: Remove the two 3/8”-16 x 5/8” set screws, adjust leg to the
desired height and reinstall the two set screws. Repeat this for all legs.
Helpful Hint: The spacing between each hole in the inner leg is for 1” of adjustment.
13. Lift table and flip to the upright position. You may need a partner to team lift the heavier
tables.
Helpful Hint: If equipped with casters, lock all casters to prevent unexpected rolling when table
legs touch down.
ASSEMBLY COMPLETE
