SMITH SYSTEM CASCADE RISER SHELF User manual

ASSEMBLY
INSTRUCTIONS
For assistance in assembling product, missing or damaged parts,
or to place an order, please contact Customer Service at 800-328-1061.
Form# 179973 www.smithsystem.com 08.31.2015
CASCADE™ RISER SHELF
CASCADE RISER SHELF
AVAILABLE OPTION FOR CASCADE™ CASES OR CABINETS.
(NOT APPLICABLE TO CASCADE™ TOWERS).

[ 1 ] 69725 ZINC-R HARDWARE PACK, CASCADE RISER
QTY 16 #70080 -WOOD SCREW
QTY 4 3/8 - 16 X 1.25 HEX HEAD BOLTS
QTY 4 STEEL WASHERS
QTY 16 #70054 - #10 X 3/4” WOOD SCREW HI/LO PTH
CASCADE™ RISER SHELF
REPLACEMENT HARDWARE PACK
HARDWARE AND COMPONENTS
Form# 179973 www.smithsystem.com 08.31.2015
For assistance in assembling product, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form#179973 www.smithsystem.com 5/2014
Components and Hardware List
Replacement Hardware Pack 69725 ZINC-R includes:
(16) 70080 - Wood Screws
(4) 3/8-16 X1.25 Hex Head Bolts
(4) Steel Washers
#10X5/8” Wood Screws
P/N –70080
QTY. 16
Hex Head Bolt
QTY. 4
Steel Washer
QTY. 4
Cascade Riser Handles
QTY. 4
Cascade Unit
QTY. 1
Riser Shelf Top
Qty. 1

For assistance in assembling product, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form#179973 www.smithsystem.com 5/2014
Step 1: Flip the laminated top face down, so that the pre-drilled holes face up.
Step 2: Align the Pole Handles with the predrilled holes as shown and screw to the top using
(16) wood screws provided.
Optional Step: If you ordered a 17670 Laptop Shelf with your Cascade, now’s the time to attach
the shelf to the storage unit. Place the Laptop Shelf on the bottom of the riser shelf. The shelf
can be placed to be facing any direction as long as there’s clearance for the shelf to extend
forward. Once the shelf is placed as desired, fasten the shelf to the table top with the provided
wood screws as shown below.
STEP 1: Flip the laminated top face down, so that the pre-drilled holes face up.
ASSEMBLY INSTRUCTIONS
Form# 179973 www.smithsystem.com 08.31.2015
STEP 2: Align the pole handles with the predrilled holes as shown and screw to the top using the
(x16) wood screws provided.
NOTE: Step #3 is for Cascade™ Cabinets/Cases with optional Laptop Shelf #17670.
For assistance in assembling product, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form#179973 www.smithsystem.com 5/2014
Step 1: Flip the laminated top face down, so that the pre-drilled holes face up.
Step 2: Align the Pole Handles with the predrilled holes as shown and screw to the top using
(16) wood screws provided.
Optional Step: If you ordered a 17670 Laptop Shelf with your Cascade, now’s the time to attach
the shelf to the storage unit. Place the Laptop Shelf on the bottom of the riser shelf. The shelf
can be placed to be facing any direction as long as there’s clearance for the shelf to extend
forward. Once the shelf is placed as desired, fasten the shelf to the table top with the provided
wood screws as shown below.
STEP 3: If your Cascade™ Cabinet or Case was ordered with a #17670 Laptop Shelf, attach now:
STEP 3a: Place the laptop shelf on the bottom of the riser shelf. The shelf can be
placed in any orientation as long as there is clearance for the shelf to extend
forward.
STEP 3b: Once the shelf is positioned as desired; fasten the shelf to the table top with
the provided wood screws as shown below.

STEP 4: Using a Ratchet and socket or wrench, bolt in the Riser Shelf top and Poles to the
Cascade™ unit with the Washer plate placed on the underside (interior) of the Cascade™
as shown below.
STEP 4: Flip the top with pole handles attached (entire assembly) into the upright position and
align on the Cascade™ unit.
ASSEMBLY INSTRUCTIONS
Form# 179931 www.smithsystem.com 08.31.2015
For assistance in assembling product, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form#179973 www.smithsystem.com 5/2014
Step 3: Flip the top with pole handles attached into upright position, and align on cascade unit.
Step 4: Using a Ratchet and socket or wrench, bolt in the top to the cascade with the washer
underneath the cascade as shown.
For assistance in assembling product, missing or damaged parts, or to place an order, please contact
customer service at 1-800-328-1061. You may also place your order online at
Form#179973 www.smithsystem.com 5/2014
Step 3: Flip the top with pole handles attached into upright position, and align on cascade unit.
Step 4: Using a Ratchet and socket or wrench, bolt in the top to the cascade with the washer
underneath the cascade as shown.
