Snom M45R SC User manual

M45R SC
SIP DECT Rugged Handset
Quick Installa� on Guide
Mickey Law | 22.Jan.2019 | Revision 1.0AW | M45R SC HS
Silkscreen on the top
Pantone 8001 C
Silkscreen on the top
Pantone Cool Grey 3 C
Laser etching on 2nd. Spray
Pantone Cool Grey 3 C
DRAFT

2
Important Safety Information
This symbol is to alert you to important operating or servicing
instructions that may appear on the product or in this user’s
manual. Always follow basic safety precautions when using
this product to reduce the risk of injury, re, or electric shock.
Important Safety Instructions
When using your telephone equipment, basic safety precautions
should always be followed to reduce the risk of re, electric shock and
injury, including the following:
1. This product should be installed by a qualied technician.
2. This product should only be connected to the host equipment and
never directly to the network such as Public Switch Telephone
Network (PSTN) or Plain Old Telephone Services (POTS).
3. Read and understand all instructions.
4. Follow all warnings and instructions marked on the product.
5. Unplug this product from the wall outlet before cleaning. Do not
use liquid or aerosol cleaners. Use a damp cloth for cleaning.
6. Do not use this product near water such as near a bath tub, wash
bowl, kitchen sink, laundry tub or swimming pool, or in a wet
basement or shower.
7. Do not place this product on an unstable table, shelf, stand or
other unstable surfaces.
8. Slots and openings in the back or bottom of the base station
and handset are provided for ventilation. To protect them from
overheating, these openings must not be blocked by placing the
product on a soft surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator or heat register.
This product should not be placed in any area where proper
ventilation is not provided.
9. This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of the
type of power supplied at the premises, consult your dealer or
local power company.
10. Do not allow anything to rest on the power cord. Do not install
DRAFT

3
this product where the cord may be walked on.
11. Never push objects of any kind into this product through the
slots in the base station or handset because they may touch
dangerous voltage points or create a short circuit. Never spill
liquid of any kind on the product.
12. To reduce the risk of electric shock, do not disassemble this
product, but take it to an authorized service facility. Opening or
removing parts of the base station or handset other than specied
access doors may expose you to dangerous voltages or other
risks. Incorrect reassembling can cause electric shock when the
product is subsequently used.
13. Do not overload wall outlets and extension cords.
14. Unplug this product from the wall outlet and refer servicing to an
authorized service facility under the following conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled onto the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following
the operating instructions. Adjust only those controls that are
covered by the operation instructions. Improper adjustment
of other controls may result in damage and often requires
extensive work by an authorized technician to restore the
product to normal operation.
E. If the product has been dropped and the telephone base
and/or handset has been damaged.
F. If the product exhibits a distinct change in performance.
15. Avoid using a telephone (other than cordless) during an electrical
storm. There is a remote risk of electric shock from lightning.
16. Do not use the telephone to report a gas leak in the vicinity of the
leak. Under certain circumstances, a spark may be created when
the adapter is plugged into the power outlet, or when the handset
is replaced in its cradle. This is a common event associated with
the closing of any electrical circuit. The user should not plug
the phone into a power outlet, and should not put a charged
handset into the cradle, if the phone is located in an environment
containing concentrations of ammable or ame-supporting
gases, unless there is adequate ventilation.
DRAFT

4
A spark in such an environment could create a re or explosion.
Such environments might include: medical use of oxygen without
adequate ventilation; industrial gases (cleaning solvents; gasoline
vapors; etc.); a leak of natural gas; etc.
17. Only put the handset of your telephone next to your ear when it is
in normal talk mode.
18. The power adapters are intended to be correctly oriented in a
vertical or oor mount position. The prongs are not designed to
hold the plug in place if it is plugged into a ceiling, under-the-table
or cabinet outlet.
19. Use only the power cord indicated in this manual.
20. For pluggable equipment, the socket-outlet shall be installed near
the equipment and shall be easily accessible.
21. In wall mounting position, make sure to mount the telephone
base on the wall by aligning the eyelets with the mounting
studs of the wall plate. Then slide the telephone base down on
both mounting studs until it locks into place. Refer to the full
installation instructions in the User Guide.
22. CAUTION: Keep small metallic objects such as pins and staples
away from the handset receiver.
SAVE THESE INSTRUCTIONS
For cUL compliance only
Mesures de sécurité importantes
Ce symbole vous alertera d’informations importantes ou
d’instructions d’entretien pouvant apparaître dans ce guide
d’utilisation. Respectez toujours les mesures de sécurité et
de sécurité de base lorsque vous utilisez ce produit, an de
réduire les risques de blessures, d’incendie, ou
d’électrocution.
Mesures de sécurité importantes
An de réduire les risques d’incendie, de blessures corporelles ou
d’électrocution, suivez toujours ces mesures préventives de base
lorsque vous utilisez votre téléphone :
DRAFT

5
1. Cet appareil doit être installé par un technicien qualié.
2. Cet appareil doit être branché à un équipement hôte et jamais
branché à un réseau, tel qu’un réseau PSTN publique ou un
réseau téléphonique standard (POTS).
3. Lisez et comprenez bien toutes les instructions.
4. Observez toutes les instructions et mises en garde inscrites sur
l’appareil.
5. Débranchez ce téléphone de la prise murale avant de le
nettoyer. N’utilisez pas de nettoyeurs liquides ni en aérosol.
N’utilisez qu’un chi󰀨on doux et légèrement humecté.
6. N’utilisez pas ce produit près de l’eau, tel que près d’un bain,
d’un lavabo, d’un évier de cuisine, d’un bac de lavage ou d’une
piscine, ou dans un sous-sol humide ou sous la douche.
7. Ne déposez pas ce téléphone sur un chariot, support ou table
chancelants. L’appareil pourrait tomber et être sérieusement
endommagé.
8. Le boîtier de l’appareil est doté de fentes et d’ouvertures
d’aération situées à l’arrière ou en dessous. An d’empêcher
la surchau󰀨e, ces ouvertures ne doivent pas être obstruées
en plaçant l’appareil sur un lit, divan, tapis ou autre surface
similaires. Ne placez pas cet appareil à proximité d’un élément
de chau󰀨age ni d’une plinthe électrique. De plus, ne l’installez
pas dans une unité murale ou un cabinet fermé qui ne possède
pas d’aération adéquate.
9. Ne faites fonctionner cet appareil qu’avec le type d’alimentation
indiqué sur les étiquettes de l’appareil. Si vous ne connaissez
pas le voltage de votre maison, consultez votre marchand ou
votre fournisseur d’électricité.
10. Ne déposez rien sur le cordon d’alimentation. Installez cet
appareil dans un endroit sécuritaire, là où personne ne pourra
trébucher sur la ligne d’alimentation ni le cordon téléphonique
modulaire.
11. N’insérez jamais d’objets à travers les fentes et ouvertures de
cet appareil, car ils pourraient toucher à des points de tension
dangereux ou court-circuiter des pièces, ce qui constituerait un
risque d’incendie ou d’électrocution. N’échappez pas de liquides
dans l’appareil.
DRAFT

6
12. An de réduire les risques d’électrocution, ne démontez pas
l’appareil, mais apportez-le plutôt à un centre de service
qualié s’il doit être réparé. En enlevant le couvercle, vous
vous exposez à des tensions dangereuses ou autres dangers
similaires. Un remontage inadéquat peut être à l’origine d’une
électrocution lors d’une utilisation ultérieure de l’appareil.
13. Ne surchargez pas les prises de courant ni les rallonges
électriques, car ceci peut constituer un risque d’incendie ou
d’électrocution.
14. Débranchez cet appareil de la prise de courant et communiquez
avec le département de service à la clientèle de Snom dans les
cas suivants:
A. Lorsque le cordon d’alimentation est endommagé ou
écorché.
B. Si du liquide a été échappé dans l’appareil.
C. Si l’appareil a été exposé à une source d’humidité telle que
la pluie ou l’eau.
D. Si l’appareil ne fonctionne pas normalement en suivant
les directives du guide. N’ajustez que les commandes
couvertes dans le guide d’utilisation, car un mauvais
réglage de celles-ci peut être à l’origine de dommages,
ce qui nécessiterait des réparations considérables pour
remettre l’appareil à son état de fonctionnement normal.
E. Si l’appareil a été échappé ou son boîtier, endommagé.
F. Si le produit a󰀩che une nette diminution de sa
performance.
15. Évitez d’utiliser un téléphone (autre qu’un sans l) pendant un
orage. Les éclairs peuvent être à l’origine d’une électrocution.
16. N’utilisez pas le téléphone pour rapporter une fuite de gaz
à proximité de celle-ci. Sous certaines circonstances, une
inteincelle pourrait survenir lorsque l’adaptateur est branché
à une prise de courant, ou lorsque le combiné est déposé sur
le combiné. Ceci est un événement commun associé avec la
fermeture d’un circuit électrique. L’utilisateur ne devrait pas
brancher le téléphone dans une prise de courant, et ne devrait
pas déposer le combiné chargé sur le socle, si le téléphone
se trouve dans un environnement ou la concentration de gaz
DRAFT

7
inammables, sans ventilation adéquate. Une étincelle dans
ces endroits pourrait provoquer un incendie ou une explosion.
Ces environnements pourraient être l’utilisation médicale
de l’oxygène sans ventilation adéquate; le gaz industriel
(dissolvants, vapeurs d’essence, etc.); une fuite de gaz naturel,
etc.
17. Placez uniquement le combiné de votre appareil près de votre
oreille lorsqu’il est en mode de conversation normal.
18. Les adaptateurs sont conçus pour être orientés en position
verticale ou en position horizontale sur le plancher.
19. N’utilisez que cordon d’alimentation et les piles indiquées dans
ce guide d’utilisation.
20. Pour les PRODUITS À BRANCHER À UNE PRISE DE
COURANT, la prise de courant doit être installée près du produit,
an d’assurer une accessibilité sécuritaire à la prise de courant.
21. En position de montage mural, assurez-vous de monter le socle
du téléphone sur le mur en alignant les oeillets avec les goujons
de xation de la plaque murale. Ensuite, faites glisser le socle
vers le bas sur les deux goujons de xation jusqu’à ce qu’il se
verrouille en place. Reportez-vous aux instructions complètes
dans la section Installation dans ce guide d’utilisation.
22. MISE EN GARDE : Éloignez les petits objets métalliques tels
que les broches de l’écouteur du combiné.
CONSERVEZ CES INSTRUCTIONS
DRAFT

8
Compliance
FCC part 15
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits
of a Class B digital device, pursuant to Part 15 of FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation; if this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o󰀨 and on, you are
encouraged to try to correct the interference by one of the following
measures:
1. Reorient or relocate the receiving television or radio antenna.
2. Increase the separation between the telephone equipment and
the receiver.)
3. Connect the telephone equipment into an outlet on a circuit
di󰀨erent from that to which the television, radio or other receiver
is connected.
4. Consult the dealer or an experienced Radio/TV Technician for
help.
Privacy of communications may not be ensured when using this phone.
Warning: Changes or modications to this equipment not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Caution: To maintain the compliance with the FCC’s RF exposure
guideline, place the base unit at least 20 cm from nearby persons.
For body-worn operation, this handset has been tested and meets the
FCC RF exposure guidelines when used with the accessories supplied
or designated for this product. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
DRAFT

9
Industry Canada
This Class B digital apparatus complies with Canadian requirements:
CAN ICES-3 (B)/NMB-3(B). Cet appareil numérique de la classe B
est conforme à la norme CAN ICES-3 (B)/NMB-3(B) du Canada.
This device contains licence-exempt transmitter(s)/receiver(s)
that comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired
operation of the device.
Privacy of communications may not be ensured when using this
telephone.
The term ‘’IC:‘’ before the certication/registration number only
signies that the Industry Canada technical specications were met.
This product meets the applicable Innovation, Science and Economic
Development Canada technical specications.
DRAFT

10
Parts Checklist
Your package contains the following items. Save your sales receipt
and original packaging in the event warranty service is necessary.
About this Guide
This quick start guide provides a reference for the external features of
the base station and handset and basic installation instructions.
Please refer to the M45R SC User Guide for complete installation and
operation instructions.
For customer service or product information, visit our website at
snomamericas.com.
Handset charger
DC adapter
Handset
(battery included)
Mickey Law | 22.Jan.2019 | Revision 1.0AW | M45R SC HS
Silkscreen on the top
Pantone 8001 C
Silkscreen on the top
Pantone Cool Grey 3 C
Laser etching on 2nd. Spray
Pantone Cool Grey 3 C
Handset
charger
Mickey Law | 22.Jan.2019 | Revision 1.0AW | M45R SC Charger
Pantone 8001C
Quick
Installation
Guide
M45R SC
Key to switch on
handset
DRAFT

11
Quick Reference Guide
Cordless handset external features
Mickey Law | 22.Jan.2019 | Revision 1.0AW | M45R SC HS
Silkscreen on the top
Pantone 8001 C
Silkscreen on the top
Pantone Cool Grey 3 C
Laser etching on 2nd. Spray
Pantone Cool Grey 3 C
End call & cancel
Signal Strength
Fuction key line,
context-sensitive

While in a call:
Volume +
While in a menu:
Scroll up
On back:
• BELT CLIP
• SPEAKER
2 context-sensitive
function keys
Battery charging
status
Earpiece
Settings menu
OK/Select
Accept or
Make Calls
Mickey Law | 22.Jan.2019 | Revision 1.0AW | M45R SC HS
Silkscreen on the top
Pantone 8001 C
Silkscreen on the top
Pantone Cool Grey 3 C
Laser etching on 2nd. Spray
Pantone Cool Grey 3 C
Microphone
Mute microphone
Speakerphone
(on/off )
Dial pad
REDIAL
while idle

While in a call:
Volume -
While in a menu:
Scroll down
Message
(MWI) LED
Dial pad and audio controls
Mickey Law | 22.Jan.2019 | Revision 1.0AW | M45R SC HS
Silkscreen on the top
Pantone 8001 C
Silkscreen on the top
Pantone Cool Grey 3 C
Laser etching on 2nd. Spray
Pantone Cool Grey 3 C
End call & cancel
Signal Strength
Fuction key line,
context-sensitive

While in a call:
Volume +
While in a menu:
Scroll up
On back:
• BELT CLIP
• SPEAKER
2 context-sensitive
function keys
Battery charging
status
Earpiece
Settings menu
OK/Select
Accept or
Make Calls
Mickey Law | 22.Jan.2019 | Revision 1.0AW | M45R SC HS
Silkscreen on the top
Pantone 8001 C
Silkscreen on the top
Pantone Cool Grey 3 C
Laser etching on 2nd. Spray
Pantone Cool Grey 3 C
Microphone
Mute microphone
Speakerphone
(on/off )
Dial pad
REDIAL
while idle

While in a call:
Volume -
While in a menu:
Scroll down
Message
(MWI) LED
DRAFT

12
Handset Installation
This section assumes that your network infrastructure is established
and that your IP PBX phone service has been ordered and congured
for your location.
For more information about IP PBX conguration, see the
M400 SC Administrator and Provisioning Manual, available at
snomamericas.com.
Handset installation involves both the the handset and the handset
charger. The charger is powered using the supplied power adapter. The
charger can be placed on a at surface or mounted on a wall.
Avoid placing the handset and charger too close to:
• Communication devices such as television sets, DVD players, or
other cordless telephones
• Excessive heat sources
• Noise sources such as a window with tra󰀩c outside, motors,
microwave ovens, refrigerators, or uorescent lighting
• Excessive dust sources such as a workshop or garage
• Excessive moisture
• Extremely low temperature
• Mechanical vibration or shock such as on top of a washing
machine or work bench
DRAFT

13
Installing the charger
Install the charger as shown below.
Plug the power adapter into an electrical outlet not controlled by a
wall switch.
DRAFT

14
IMPORTANT INFORMATION
Use only the power adapter supplied with this product (Ten Pao,
model number S003AKU0600040). To order a replacement power
adapter, visit our website at snomamericas.com.
The power adapter is intended to be correctly oriented in a vertical or
oor mount position.
The prongs are not designed to hold the plug in place if it is plugged
into a ceiling, under-the-table or cabinet outlet.
Switching on the handset
The handset battery is preinstalled. When you unpack the handset
form the delivery box, you must switch on the handset using the
provided key. Follow the steps below. You only have to do this once.
To switch on the handset:
1. Insert the provided key into the hole at the bottom rear of the
handset.
illustration scale 50%
PART DESCRIPTION COLOUR TEXTURE/FINISH
Mickey Law | 22. Jan . 2019 | Revision 1.0
03. Lens
Rubber (Injection molding) - Transparent - Milky white Matte
Ra 3. 15
Matte
04. Keys
Ra 3. 15
06. Antenna
PMMA (Injection molding) - Transparent
Rubber spray - 1st - Pantone Cool grey 3C / 2nd - Snom standard black
Rubber spray - 1st - Pantone Cool grey 3C / 2nd - Snom standard black
Laser etching on 2nd spray ( Legends , )
Silkscreen on the top ( ) - Pantone 361C, ( ) - Pantone 485C
Silkscreen on the top ( , , , , , , , ) - Pantone Cool grey 3C
Rubber (Injection molding) - Snom standard black
High gloss
ABS (Injection molding) - graphite
ABS (Injection molding) - Snom standard black
SPI B-1
SPI A-1
PMMA (Injection molding) - Transparent - Milky white - backlit High gloss
01. Front cabinet
01a. LCD frame
02. LED
Silkscreen on the top ( ) - Pantone 8001C
Silkscreen on the top ( ) - Pantone 361C, ( , ) - Pantone 485C
Rubber (Injection molding) - Transparent - Milky white04a. Keys - laser etching
05. Side rim
ABS (Injection molding) - graphite
Ra 3. 15
07. Belt clip ABS (Injection molding) - Snom standard black
Ra 3. 15
08. Back cabinet ABS (Injection molding) - graphite
Ra 3. 15
09. Battery door ABS (Injection molding) - graphite
Ra 3. 15
10. Pin button Rubber (Injection molding) - graphite
Ra 3. 15
11. Charging pin holder ABS (Injection molding) - graphite
CSP / SNOM M45R SC HS
6
7
8
9
10
1
2
3
4a
11
5
4
1a
illustration scale 50%
PART DESCRIPTION COLOUR TEXTURE/FINISH
Mickey Law | 22. Jan . 2019 | Revision 1.0
03. Lens
Rubber (Injection molding) - Transparent - Milky white Matte
Ra 3. 15
Matte
04. Keys
Ra 3. 15
06. Antenna
PMMA (Injection molding) - Transparent
Rubber spray - 1st - Pantone Cool grey 3C / 2nd - Snom standard black
Rubber spray - 1st - Pantone Cool grey 3C / 2nd - Snom standard black
Laser etching on 2nd spray ( Legends , )
Silkscreen on the top ( ) - Pantone 361C, ( ) - Pantone 485C
Silkscreen on the top ( , , , , , , , ) - Pantone Cool grey 3C
Rubber (Injection molding) - Snom standard black
High gloss
ABS (Injection molding) - graphite
ABS (Injection molding) - Snom standard black
SPI B-1
SPI A-1
PMMA (Injection molding) - Transparent - Milky white - backlit High gloss
01. Front cabinet
01a. LCD frame
02. LED
Silkscreen on the top ( ) - Pantone 8001C
Silkscreen on the top ( ) - Pantone 361C, ( , ) - Pantone 485C
Rubber (Injection molding) - Transparent - Milky white04a. Keys - laser etching
05. Side rim
ABS (Injection molding) - graphite
Ra 3. 15
07. Belt clip ABS (Injection molding) - Snom standard black
Ra 3. 15
08. Back cabinet ABS (Injection molding) - graphite
Ra 3. 15
09. Battery door ABS (Injection molding) - graphite
Ra 3. 15
10. Pin button Rubber (Injection molding) - graphite
Ra 3. 15
11. Charging pin holder ABS (Injection molding) - graphite
CSP / SNOM M45R SC HS
6
7
8
9
10
1
2
3
4a
11
5
4
1a
2. Gently push the pin into the hole until you hear a click.
3. Remove the pin.
Your handset will power on after ve seconds.
From now on, you can turn your handset o󰀨/on by pressing and
holding the OFF/CANCEL button on the handset.
DRAFT

15
Battery charging
The handset screen indicates the battery status (see the table
below). If necessary, place the handset in the charger to charge the
battery. For best performance, keep the handset in the charger when
not in use. The battery is fully charged after 11 hours of continuous
charging.
If the screen is blank, you need to charge the handset without
interruption for at least 30 minutes to give the handset enough charge
to use the telephone for a short time. When the battery is low, the
handset shows Low battery and a ashing .
Battery indicators Battery Status Action
The screen is blank or
shows Place in charger
and ashes.
The battery
has no or little
charge. The
handset cannot
be used.
Charge without
interruption (at
least 30 minutes).
The screen shows Low
battery and ashes.
Battery has
enough charge
to be used for a
short time.
Charge without
interruption (at
least 30 minutes).
Full battery icon ( )
appears. The screen
shows HANDSET x
(x represents the handset
ID number 1 to 6).
Battery is
charged.
To keep the
battery charged,
place it in the
charger when not
in use.
Charge the handset by placing it face forward in the charger.
The battery icon indicates the charge status as the battery charges.
Very low battery.
Charging less
than 30 minutes.
Charging
30 to 80
minutes.
Charging
80 minutes
to 7 hours.
Charging more than
7 hours. Fully charged
at 11 hours.
DRAFT

16
Opening the battery door
Your handset battery is preinstalled. If you need to remove or insert
the battery, follow the steps below.
To remove or insert the handset battery:
1. Remove the three screws on the battery door.
2. Lift up the bottom of the battery door to remove it.
3. To remove the battery: Lift the end of the battery nearest the top of
the handset, and unplug the battery connector from the socket.
4. To insert the battery: Plug the battery connector securely into the
socket. Place the battery inside the handset battery compartment.
5. Hold the battery door at an angle and align the three notches at
the top of the battery compartment. Push the bottom of the battery
door down until it clicks into place.
6. Tighten the three screws to secure the battery door.
IMPORTANT INFORMATION
• Use only the supplied rechargeable battery or replacement battery
(model GP100AAAHC2BMXZ). To order a replacement battery,
visit our website at snomamericas.com.
• If you do not use the handset for a long time, disconnect and
remove the battery to prevent possible leakage.
DRAFT

17
Handset Registration
Registering the handset to the base station
The handset is pre-registered to the base station. If the handset
becomes deregistered, perform the registration procedure as follows.
To register the handset:
1. Make sure the handset has a charged battery before proceeding.
Make sure the base station is connected to power.
2. If the handset is displaying the message “Press and hold handset
locator key at base for 4 seconds”, press OK and then go to
step 10.
3. Press MENU on the handset.
The Main Menu appears.
4. Press qand uto select (Settings) and press ENTER.
5. Press qto scroll to User Settings and press ENTER.
6. Press pto scroll to Registration and press ENTER.
7. With Handset highlighted, press OK.
8. Press qand pto highlight the Base (1-4) to which you want to
register.
An asterisk * indicates the base slot has been registered to a base.
For example: Base 1*. Highlight a base without an asterisk *.
9. Press ENTER.
The handset screen displays “Registering / Please wait.”
10. On the base station, press the HANDSET LOCATOR button for
at least four seconds, and then release the button.
Both LEDs on the base station begin to ash.
11. If prompted, enter the PIN on the handset, and then press OK to
begin registration.
The default PIN is 1592.
The process takes up to 10 seconds to complete.
When the rst handset registers, it beeps and the
screen displays “Handset Registered”. Press the
MENU/SELECT button.
If the handset fails to register, place it in the charger again for a
few seconds, remove it and repeat the registration procedure.
DRAFT

18
Deregistering the handset
Before using the handset with a di󰀨erent base station, you must
deregister the handset from the base station to which it is currently
registered.
To deregister the handset:
1. Press MENU on the handset. The Main Menu appears.
2. Press qand uto select (Settings) and press ENTER.
3. Press qto scroll to User Settings and press ENTER.
4. Press pto scroll to Registration and
press ENTER.
5. Press qto highlight Deregistration and press OK.
The handset screen displays a list of registered handsets.
6. Press qand pto highlight the name of the handset you want to
deregister, and then press OK.
The handset you are using is indicated by asterisks **.
For example: HANDSET 1**
7. If prompted, enter the PIN, and then press OK to begin
deregistration.
The default PIN is 1592.
The process takes up to 10 seconds to complete.
When the handset deregisters, it beeps and the screen displays
“Press and hold handset locator key at base for 4 seconds.”
Note: The handset enters an energy-saving charging mode after
being deregistered. All cordless telephone functions except handset-
battery charging are disabled. Energy-saving charging mode is
deactivated after the handset registers to the base station.
DRAFT

19
Maintenance
Taking care of your telephone
• Your base station and cordless handset contain sophisticated
electronic parts, so you must treat them with care.
• Avoid rough treatment.
• Place the handset down gently.
• Save the original packing materials to protect your products if you
ever need to ship them.
Avoid water
• You can damage your cordless telephone if it gets wet. Do not use
the handset in the rain, or handle it with wet hands. Do not install
the base station and handset near a sink, bathtub or shower.
Electrical storms
• Electrical storms can sometimes cause power surges harmful to
electronic equipment. For your own safety, take caution when using
electric appliances during storms.
Cleaning your telephone
• Your products have a durable plastic casing that should retain
its luster for many years. Clean it only with a soft cloth slightly
dampened with water or a mild soap.
• Do not use excess water or cleaning solvents of any kind.
Remember that electrical appliances can cause serious injury if
used when you are wet or standing in water. If the telephone base
should fall into water, DO NOT RETRIEVE IT UNTIL YOU UNPLUG
THE POWER CORD FROM THE WALL, then pull the unit out by the
unplugged cord.
DRAFT

20
Technical Specications
RF frequency band 1921.536–1928.448 MHz
Channels 5
Operating
temperature
32–104 °F (0–40 °C)
Power requirements Base: 5.0 Vdc @ 800 mA
Handset charger: 6.0 Vdc @ 400 mA
Handset: 2.4 V, 950mAh, Ni-MH battery
pack
Power over Ethernet IEEE 802.3af supported, class 2
Ethernet network port 10/100 Mbps RJ-45 port
DRAFT
