Sonoma CAMERON User manual

1
PART LIST QUANTITY
A1 PC
B1 PC
C1 PC
D3 PCS
E3 PCS
F3 PCS
G16 PCS + 1 PC
H16 PCS + 1 PC
I8 PCS + 1 PC
J1 PC
SAVE THESE INSTRUCTIONS
ASSEMBLE ON A FLAT, PROTECTED SURFACE
FIGURE
DESCRIPTION
TOP
RIGHT SIDE FRAME
SONOMA CAMERON 3 DRAWER STORAGE TOWER ASSEMBLY INSTRUCTIONS
FLAT WASHER
WOOD DOWEL
ALLEN WRENCH
FOR MISSING OR INCORRECT PARTS/HARDWARE, CONTACT THE MANUFACTURER'S CUSTOMER SERVICE DIRECTLY AT
1-847-608-5202 OR [email protected]
REFER TO LAST PAGE FOR ADDITIONAL CUSTOMER SERVICE DETAILS.
LEFT SIDE FRAME
BOLT
SHELF
BASKET
BASKET BOTTOM

2
STEP 2
A. INSERT WOOD DOWELS (I) INTO THE DOWEL
HOLES IN SHELVES (D) AS SHOWN.
STEP 1
A. PLACE TOP (A) UPSIDE DOWN ON A FLAT,
PROTECTED SURFACE.
B. INSERT WOOD DOWELS (I) INTO DOWEL HOLES
IN TOP (A) AS SHOWN.
STEP 3
A. PLACE SIDE FRAME (B) ON A FLAT, PROTECTED
SURFACE.
B. ATTACH RIGHT SIDE FRAME (B) TO TOP (A) AND
SHELVES (D) WITH BOLTS (G) AND FLAT WASHERS
(H) USING ALLEN WRENCH (J). DO NOT TIGHTEN
COMPLETELY.
ASSEMBLY INSTRUCTIONS (CONTINUED)
J
H

3
STEP 5
A. CAREFULLY ROTATE THE ASSEMBLED UNIT
UPSIDE DOWN ON A FLAT, PROTECTED SURFACE.
B. ATTACH TOP (A) AND SHELVES (D) TO LEFT SIDE
FRAME (C) WITH BOLTS (G) AND FLAT WASHERS (H)
USING ALLEN WRENCH (J).
C. TIGHTEN COMPLETELY ALL BOLTS (G).
STEP 4
A. ALIGN THE LEFT SIDE FRAME (C) TO TOP (A) AND
SHELVES (D) AS SHOWN.
ASSEMBLY INSTRUCTIONS (CONTINUED)
STEP 6
A. INSERT BASKET BOTTOMS (F) INTO BASKETS (E).
B. REPEAT FOR REMAINING BASKETS.
C

4
WEIGHT LIMIT:
CARE AND CLEANING
WIPE CLEAN WITH A SOFT, DRY CLOTH AS NEEDED.
BASKETS: DO NOT BRING IN CONTACT WITH WATER OR LIQUIDS.
DO NOT SIT, STAND, OR CLIMB ON STORAGE TOWER.
INTENDED FOR INDOOR USE ONLY.
** WE RECOMMEND THAT YOU SAVE THE ALLEN WRENCH AND PERIODICALLY TIGHTEN ALL BOLTS.
TOP: 40 LBS, SHELVES: 20 LBS EACH, BASKETS: 20 LBS EACH.
ASSEMBLY INSTRUCTIONS (CONTINUED)
STEP 7
A. ROTATE THE ASSEMBLED UNIT TO UPRIGHT
POSITION.
B. PLACE THE ASSEMBLED BASKETS ONTO THE
SHELVES AS SHOWN.
C. ASSEMBLY IS COMPLETE.
FOR MISSING OR INCORRECT PARTS/HARDWARE, CONTACT THE MANUFACTURER'S CUSTOMER SERVICE
DIRECTLY AT 1-847-608-5202 OR [e-mail]

5
PHILIPS HEAD SCREW DRIVER, DRILL, 7/32" DRILL BIT NEEDED FOR ASSEMBLY; NOT INCLUDED.
FOR SAFETY REASONS, WE RECOMMEND THAT YOU INSTALL THE INCLUDED ANTI-TIP HARDWARE TO HELP
PREVENT THE STORAGE TOWER FROM UNEXPECTEDLY TIPPING OR SHIFTING.
THE INCLUDED MATERIALS ARE DESIGNED TO MOUNT THE ANTI-TIP HARDWARE TO DRYWALL.
PLEASE CONSULT A REPRESENTATIVE AT A HARDWARE/HOME IMPROVEMENT STORE TO DISCUSS
ADDITIONAL MOUNTING OPTIONS FOR OTHER TYPES OF WALLS.
SAVE THESE INSTRUCTIONS
ANTI-TIP HARDWARE MOUNTING INSTRUCTIONS FOR DRYWALL
STEP 1
A. DETERMINE WHERE THE STORAGE TOWER WILL BE PLACED,
THEN MARK THE POSITION OF MOUNTING BRACKET ON THE
WALL.
B. DRILL HOLES IN THE WALL. PRESS THE PLASTIC
ANCHOR (N) INTO THE HOLES.
C. POSITION ONE END OF MOUNTING BRACKET (M) OVER
THE PLASTIC ANCHOR (N) AND USE LONG SCREWS (K)
TO ATTACH THE MOUNTING BRACKET (M) TO THE WALL.
TIGHTEN LONG SCREWS (K) BY USING PHILLIPS HEAD
SCREWDRIVER (NOT INCLUDED).

6
SAVE THESE INSTRUCTIONS
ANTI-TIP HARDWARE MOUNTING INSTRUCTIONS FOR DRYWALL
STEP 2
A. USE SHORT SCREWS (L) TO ATTACH THE
OTHER END OF MOUNTING BRACKET (M)
TO THE CENTER OF SHELF FRAME OF
THE FIRST TIER OF THE STORAGE TOWER.
B. TIGHTEN SHORT SCREWS (L) BY USING
PHILLIPS HEAD SCREWDRIVER (NOT
INCLUDED).
STEP 3
A. PLACE THE STORAGE UNIT SO THAT THE
MOUNTING BRACKET (M) ON THE BACK
OF STORAGE UNIT IS IN LINE WITH
MOUNTING BRACKET (M) ON THE WALL.
B. FEED THE ZIP TIE (O) THROUGH EACH
MOUNTING BRACKET (M) AND SECURE IT.
C. CHECK TO MAKE SURE THE ZIP TIE (O) IS
SECURELY TIGHTENED AND LOCKED TO
MOUNTING BRACKETS (M).
