COMMUNICATION SYSTEM
PCS-1
PCS-1P
SYSTEM INTEGRATION MANUAL
1st Edition

PCS-1/PCS-1P
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien.Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.

1
PCS-1/PCS-1P
Table of Contents
1. Installation
1-1. Caution on Installation ................................................................................1-1
1-1-1. Lay Out the Videoconferencing Room ......................................1-1
1-1-2. Operating Environment ..............................................................1-6
1-2. Flowchart of Installation .............................................................................1-7
1-3. System Connections ....................................................................................1-8
1-3-1. When Used in LAN (100BASE-TX/10BASE-T) ......................1-8
1-3-2. When Used in ISDN...................................................................1-9
1-4. Initialization ..............................................................................................1-10
1-4-1. Inserting Batteries into the Remote Commander .....................1-10
1-4-2. Turning On/Off the TV Monitor Together With the
Communication Terminal ........................................................1-11
1-4-3. Adjust the Volume of a Monitor Television ............................1-12
1-4-4. Installing the Communication Terminal and Camera ..............1-12
1-4-5. Turning On ...............................................................................1-13
1-4-6. When the Power was First Turned on after Installation...........1-14
1-5. System Setting...........................................................................................1-17
1-6. Flowchart of Opening Test........................................................................1-20
1-6-1. Outgoing Procedure of ISDN ...................................................1-21
1-6-2. Incoming Procedure of ISDN...................................................1-23
1-6-3. Outgoing Procedure of LAN ....................................................1-24
1-6-4. Incoming Procedure of LAN....................................................1-26
2. Maintenance
2-1. Confirmation Procedure of Local Terminal Operation Using Self-Loop ...2-1
2-2. Separation of Components ..........................................................................2-2
2-3. Operation Log ...........................................................................................2-18
2-4. Updating of Software ................................................................................2-28
2-4-1. Updating Using Memory Stick ................................................2-28
2-5. Service Mode ............................................................................................2-29
3. Compatibility in LAN Network
3-1. Connection via Hub.....................................................................................3-1
3-2. Connection via Router.................................................................................3-3
3-3. Connection via DHCP.................................................................................3-5
3-4. Connection via Gatekeeper .........................................................................3-7
3-5. Connection via DHCP and Gatekeeper.......................................................3-9

2PCS-1/PCS-1P
4. Technical Data
4-1. PCS-1/1P Port Number Used ......................................................................4-1
4-1-1. During Opposed Connection (Specified Value) ........................4-1
4-1-2. Opposed Connection (User Setting: When TCP port number is set
to 3000 and UDP port number is set to 3100)............................4-1
4-1-3. During Use of Internal MCU Function (Specified Value) .........4-2
4-1-4. During Use of Internal MCU Function (User Setting: When TCP
port number is set to 3000 and when UDP port number is set to
3100) ..........................................................................................4-2
4-2. Setting of PCS-1 and HUB .........................................................................4-3

1-1
PCS-1/PCS-1P
Section 1
Installation
1-1. Caution on Installation
1-1-1. Lay Out the Videoconferencing Room
Arrange it in consideration of the space of a camera and
microphone when laying out the videoconferencing room.
Camera Range
represents the shooting area of the camera when the
zoom has been extended fully. indicates the shooting
area of the camera when the left/right angling function is
fully utilized. Use the measurements below as a guide for
the layout of your videoconference room.
Top view (horizontal range at maximum zoom-
out)
Side view (vertical range at maximum zoom-out)
4 m
(13.12 ft)
1.5 m (4.92 ft)
5.1 m (16.73 ft)
100d
100d
65d
3.1 m
(8.41 ft)
4 m (13.12 ft)
42d
25d
25d

1-2 PCS-1/PCS-1P
1: For internal microphone
2: For extension microphone (PCS-A300)
0.5 1
3: For extension microphone (PCS-A1)
0.5 to 1.2m
Highly directional range of microphone
The ideal directional range of a microphone is shown below. The numeric value is a rough standard.
Use the value as the reference of the videoconferencing room used.

1-3
PCS-1/PCS-1P
The microphone built in the PCS-C1/C1P Camera Unit is
assumed to be used to conduct a conference among about
three participants. You can connect the optional PCS-A1 or
PCS-A300 microphone to the System, allowing more
persons to participate in the conference.
Microphone layout examples
PCS-1/1P
Microphone built in the PCS-1/1P
PCS-A300 microphones
PCS-A300
PCS-1/1P
PCS-A1 microphones
PCS-A1
PCS-1/1P
Notes on installation of the microphones
.Install microphone about 50 cm away from the
participants.
.Install the speakers behind the microphones.
.Place the microphone in a quiet, echo-free location.
.Install microphones away from equipment that may
cause noise.
.Avoid covering a microphone with paper, etc., or
moving it. If you do either, extreme noise and echo may
be heard temporarily by the remote party. In this case,
wait until the echo disappears.

1-4 PCS-1/PCS-1P
The blue line in the light
emitter indicates the
direction of infrared rays.
Infrared light emitter
: Adjustment in vertical direction
: Adjustment in horizontal direction
Document stand
Infrared rays Infrared photosensor
PCS-1/1P
Installation of document stand
a. Adjust the direction of an infrared light emitter.
Install so that the infrared light emitter of the document stand is linear in direction with the infrared
photosensor of PCS-1/1P when the video signal input to a document stand is transmitted to PCS-1/1P
using an infrared video transmission function. The range in which infrared rays reach is a maximum
of about 5 m.
Connect it with PCS-1/1P using a MONITOR OUT terminal when the infrared light emitter is used in
excess of about 5 m.

1-5
PCS-1/PCS-1P
45d
30d
Infrared
light emitter
Infrared
light emitter
Infrared
light emitter
5 m 15d
3.5 m 2.5 m
Infrared
photosensor
PCS-1/1P
b. Installation range (Reference)
If an image is disturbed in the range shown below, bring it near PCS-1/1P with the infrared light
emitter of a documents stand turned toward PCS-1/1P.
m
.Install so that the infrared light emitter of a document stand is linear in direction with the infrared
photosensor of PCS-1/1P. Do not put an object that interrupts transmission. When the direction of the
infrared light emitter is shifted by five degrees or more, normal reception cannot be carried out, that is,
an image is disturbed or stands still.
.Multiple document stands cannot be used at the same time. Infrared rays interfere and any signal
cannot be received.
.The resolution of an image deteriorates when a video signal is transmitted using an infrared video
transmission function. Connect the infrared light emitter with PCS-1/1P using a MONITOR OUT
terminal when you do not want to deteriorate the resolution.
.Connect the infrared light emitter with PCS-1/1P using a MONITOR OUT terminal when an infrared
video transmission function cannot be used due to the situation of a videoconferencing room.
.An image may be disturbed when other infrared light emitters are used or when a remote controller is
used near the photosensor. Stop the use of other infrared light emitters or connect them with PCS-1/1P
using a MONITOR OUT terminal.

1-6 PCS-1/PCS-1P
1-1-2. Operating Environment
Layout Considerations
.Avoid having large, moving objects, especially people,
behind the participants, as the quality of the picture
transmitted to the remote party will deteriorate.
.Do not seat participants in front of a wall with fine stripe
patterns.
.Choose a room where echo will not occur.
.Do not install the system near noise sources such as air
conditioners or copy machines.
.Avoid placing the system in a room where there are the
speakers used for an in-house broadcasting system.
Lighting Considerations
Do not point the camera toward a window where sunlight
comes in as back lighting may decrease the contrast. If it is
necessary, cover the window with a thick curtain.
Adjust room lighting so that it falls on the participants.
Avoid direct light on the TV monitor. Light intensity on
faces should be about 300 lux or more.
If an inverter type or brightness-adjustable type of
fluorescent lamp is used, the sensitivity of the Remote
Commander may deteriorate.
Installing the Communication Terminal and Camera

1-7
PCS-1/PCS-1P
Place used
Unpacking
Check of supplied accessories
Power and cable connection, and
preparation
Start the power of the system and
initialize.
<Refer to “1-1. Caution on Installation” on page 1-1.>
<Refer to “1-3. System Connections” on page 1-8.>
<Refer to “1-4. Initialization” on page 1-10.>
Initialize the related block.
End
<“1-5. System Setting” on page 1-17.>
1-2. Flowchart of Installation

1-8 PCS-1/PCS-1P
1-3. System Connections
This section describes the typical system connections.
m
.Be sure to turn off all the equipment before making any connections.
.Do not connect/disconnect the camera cable with the power on. Doing so may damage the Camera Unit
or Communication Terminal.
.For safety, do not connect the 100BASE-TX/10BASE-T connector to a network that applies an excess
voltage via the 100BASE-TX/10BASE-T connector
1-3-1. When Used in LAN (100BASE-TX/10BASE-T)
DC 19.5V
AUDIO OUT AUDIO IN AUX1– VIDEO IN –AUX2 CAMERA UNIT MIC
(PLUG IN POWER)
ISDN UNIT WHITE
BOARD
(MIXED)
AUX
MAIN – MONITOR – SUB
VIDEO OUT RGB OUT DSB
IR OUT
100BASE-TX
10BASE-T
12
12
TERMINAL VISCA OUT
PCS-C1 Camera Unit
to TERMINAL
Camera cable
*
to CAMERA UNIT
to DC19.5V Power cord
*
to wall outlet
to 100BASE-TX/
10BADSE-T PCS-AC195
AC adaptor
UTP cable (category 5, straight)
**
TV monitor
**
to a wall outlet
to LAN
to AUDIO
OUT to VIDEO OUT
MONITOR
MAIN
S-video
connecting
cable
*
to S-video
input
to audio input
*
supplied
**
not supplied
Audio
connecting
cable
*
PCS-P1
Communication
Terminal

1-9
PCS-1/PCS-1P
1-3-2. When Used in ISDN
n
Do not connect/disconnect the camera cable or the interface cable with the power on. Doing so may
damage the Camera Unit, Communication Terminal or ISDN Unit.
12 3 4 56
DC 19.5V
AUDIO OUT AUDIO IN AUX1– VIDEO IN –AUX2 CAMERA UNIT MIC
(PLUG IN POWER)
ISDN UNIT WHITE
BOARD
(MIXED)
AUX
MAIN – MONITOR – SUB
VIDEO OUT RGB OUT DSB
IR OUT
100BASE-TX
10BASE-T
12
12
TERMINAL VISCA OUT
PCS-C1 Camera Unit
to TERMINAL
Camera cable*
to CAMERA UNIT
PCS-P1
Communication
Terminal
to AUDIO
OUT to VIDEO OUT
MONITOR
MAIN Interface cable
(supplied with the PCS-B768)
to ISDN 1-6 to ISDN
Front
PCS-B768 ISDN Unit**
ISDN modular
cable**
to a wall outlet
to ISDN
UNIT
to
TERMINAL
TV monitor**
S-video
connecting
cable*
to S-video
input
to audio input
*supplied
** not supplied
Audio
connecting
cable*
to DC19.5V Power cord*
to a wall outlet
PCS-AC195
AC adaptor

1-10 PCS-1/PCS-1P
1-4. Initialization
1-4-1. Inserting Batteries into the Remote
Commander
Most of the operations with the Video Communication
System can be controlled with the supplied Remote
Commander.
1. Remove the battery compartment cover.
2. Insert two size AA (R6) batteries (supplied) with
correct polarities into the battery compartment.
n
Be sure to insert the batteries _side first. Inserting them
forcibly +side first may damage the insulated film
covering the batteries and cause a short circuit.
3. Replace the cover.
m
Battery life
When the Remote Commander does not function properly,
replace both the batteries with new ones.
Notes on batteries
.To avoid damage from possible battery leakage or
corrosion, observe the following:
.Make sure to insert the batteries with the polarities in the
correct direction.
.Do not mix old and new batteries, or different types of
batteries.
.Do not attempt to charge the batteries.
.If you do not intend to use the Remote Commander for a
long period of time, remove the batteries.
.If battery leakage occurs, clean the battery compartment
and replace all the batteries with new ones.

1-11
PCS-1/PCS-1P
1-4-2. Turning On/Off the TV Monitor Together With the Communication
Terminal
If you use a Sony TV, insert the IR repeater under the remote sensor of the TV. Once you set the IR
repeater, the TV will turn on or go to standby together with the Communication Terminal when you press
the I/O button on the supplied Remote Commander.
n
If the TV monitor is not turned on by pressing the I/O button on the Remote Commander, change the “IR
Repeater Mode” setting in the General Setup menu.
For details on the “IR Repeater Mode” setting, see “General Setup Menu” on page 1-18.
DC 19.5V
CAMERA UNIT MIC
(PLUG IN POWER)
ISDN UNIT WHITE
BOARD
DSB
IR OUT
100BASE-TX
10BASE-T
12
12
to IR OUT
IR repeater (supplied)
Remoted sensor
TV monitor

1-12 PCS-1/PCS-1P
1-4-3. Adjust the Volume of a Monitor
Television
Adjust the television side after the volume is adjusted on
the PCS-1/1P side.
1. Press the volume/bright button of a remote controller
and adjust so that the volume adjustment bar is in the
center position
2. Adjust the volume of a monitor television.
Set to the volume in which the remote voice can be
heard well.
After adjustment is completed, adjust the volume on
the PCS-1/1P side.
1-4-4. Installing the Communication
Terminal and Camera
You can fix the Communication Terminal or the Camera to
your chosen place of installation using the supplied Velcro.
1. Stick the supplied Velcro to the bottom of the
Communication Terminal or Camera.
2. Stick another piece of Velcro to the installation place.
3. Install the Communication Terminal or the Camera on
the installation place by securing the two pieces of
Velcro.
3
3
3
3
Bottom of the Communication
Terminal
Bottom of the Camera Unit

1-13
PCS-1/PCS-1P
1-4-5. Turning On
1. Turn on the TV monitor.
If the IR repeater is installed in the TV monitor, set the
TV monitor to standby mode. The TV monitor will
turn on simultaneously when the Communication
Terminal is turned on.
2. Turn on the power of any other equipment to be used
for the videoconference.
3. Set the power switch on the right side of the
Communication Terminal to the on position (I).
The Communication Terminal turns on after a while. Three
indicators on the front of the Communication Terminal and
the POWER indicator on the camera light, then only the
POWER indicators on both units remain on in green. The
launcher menu will appear on the monitor screen and the
picture shot by the local camera will also appear in the
launcher menu.
Launcher menu
POWER indicators
(Light in green.)
Power switch
m
.After the power is turned on, the camera moves
automatically for trial operation. Be careful not to catch
your finger.
.If you use force to prevent the camera moving, it may
not resume moving and not output a signal to the
Communication Terminal. In this case, turn off the
Terminal, and turn it on again.
.When you turn on the power of the Communication
Terminal for the first time after installation, the setup
wizard will appear after the self-diagnosis is completed.
Set up your system following the wizard.
.For setups using the wizard, see “Setting Up the System
for the First Time - Initial Setup Wizard”on page 1-14.
Standby Mode Function
To save power the Communication Terminal will enter
standby mode if you do not operate it for a specified period
of time.
When the Communication Terminal is in standby mode,
the POWER indicator lights in orange. Once the
Communication Terminal receives a call, the standby
mode is automatically released.
To release the standby mode
Press the I/O button on the Remote Commander.
To specify the standby time
Specify the time that you want the system to remain on
before entering into standby mode (1 to 99 minutes) using
“Standby Time”in the General Setup menu. If you do not
want the system to enter the standby mode, set “Standby
Mode”in the General Setup menu to “Off”.
For the “Standby Time”and “Standby Mode”settings, see
“General Setup Menu”on page 1-17.
m
.The POWER indicator on the camera goes off when the
system enters standby mode.
.If you use a Sony TV monitor with the IR repeater
installed under the remote sensor, the TV monitor will
enter standby mode together with the Communication
Terminal.
IP:0.0.0.0 ISDN:012345678912
Audio:MIC(INT)+AUX
Video:Main
Connect
Angle Adj.
Phone Book
Dial
Menu
Show Help

1-14 PCS-1/PCS-1P
Language Setup Wizard
CancelNext
English
Language
1-4-6. When the Power was First Turned on
after Installation
When you turn on the Communication Terminal for the
first time after installation and the self-diagnosis is
completed, the setup wizard appears on the monitor screen.
Register your local system data with the setup wizard using
the Remote Commander.
n
You can change the settings made with the setup wizard
later using the Setup menus.
1. Select the language used for the on-screen menus and
messages in the Language Setup Wizard.
Language: Select one of seven languages; English,
French, German, Japanese, Spanish, Italian, Chinese.
2. Use the ↑, ↓, ←or →button on the Remote
Commander to select “Next”, then press the PUSH
ENTER button.
The ISDN Setup Wizard appears.
n
When you are not using the ISDN line, select “Next”
to display the LAN Setup Wizard, then proceed to step
9.
ISDN Setup Wizard
CancelNextPrevious
USA
Country/Region
1
Country/Region Code
National ISDN
Protocol
3. Set the following items on the ISDN line.
Country/Region:
Select your country or region.
Country/Region Code:
Enter your country code or region code with the
number buttons on the Remote Commander.
Protocol:
Select the protocol of the ISDN line you are using.
4. Use the ↑, ↓, ←or →button to select “Next”, then
press the PUSH ENTER button.

1-15
PCS-1/PCS-1P
Area Code Local Number
CancelNextPrevious
A2
A1
B1
B2
C1
C2
5. Enter the telephone number of the ISDN used by the
system.
When you use one ISDN line, enter the same number
both in the A1 and A2 text boxes (except for the USA
and Canada).
Area Code:
Enter the area code. Do not enter the first “0”number.
Local Number:
Enter the telephone number.
When you select Auto SPID (only for customers in
the USA and Canada)
You can automatically set up the Area Code and Local
Number on this page, and SPID items in the SPID
menu.
n
When 2-6 ISDN lines are used, enter the telephone
numbers in the B1 to F2 text boxes in addition to the
A1 and A2 boxes. To open the menu with D1 to F2
text boxes, select “Next”, then press the PUSH
ENTER button.
6. Use the ↑, ↓, ←or →button to select “Next”, then
press the PUSH ENTER button.
Sub Address
CancelNextPrevious
A2
A1
B1
B2
C1
C2
7. Enter the sub-addresses.
Only numerals are available for a sub-address.
When you use one ISDN line, enter the same number
both in the A1 and A2 text boxes (except for the USA
and Canada).
n
When 2-6 ISDN lines are used, enter the sub-addresses
in the B1 to F2 text boxes in addition to the A1 and A2
boxes. To open the menu with these text boxes, select
“Next”, then press the PUSH ENTER button.
8. Use the ↑, ↓, ←or →button to select “Next”, then
press the PUSH ENTER button.
For customers in other countries than the USA and
Canada
The LAN Setup Wizard appears.
For customers in the USA and Canada
The ISDN Setup Wizard (SPID menu) appears.
Set the SPID items, then select “Next”and press the
PUSH ENTER button.
The LAN Setup Wizard appears.
For details on the SPID settings, see “SPID Setting for
Customers in the USA and Canada”on page 46.
n
When you do not use the LAN, select “Next”to
display the message window for confirmation, then
proceed to step 11.

1-16 PCS-1/PCS-1P
LAN Setup Wizard
CancelNextPrevious
Auto
DHCP Mode
Host Name
IP Address
Network Mask
Gateway Address
DNS Address
. . .
. . .
. . .
. . .
9. Set the following items on the LAN.
DHCP Mode:
Sets the DHCP (Dynamic Host Configuration Protocol).
Auto:
Automatically assigns your IP address, network mask,
gateway address and DNS address.
Off:
Deactivates DHCP. In this case set your IP address,
network mask, gateway address and DNS address
manually.
Host Name:
Enter your host name.
IP Address:
Enter your IP address.
Network Mask:
Enter your network mask.
Gateway Address:
Enter your default gateway address.
DNS Address:
Enter your DNS (Domain Name System) server
address.
n
When you set “DHCP Mode”to “Auto”, the assigned
IP address is shown in the launcher menu or Machine
Information menu.
When you do not know how to set up the LAN
configuration, contact your network administrator.
10. Use the ↑, ↓, ←or →button to select “Next”, then
press the PUSH ENTER button.
The message window for confirmation appears.
CancelPrevious
Save
11. Use the ↑, ↓, ←or →button to select “Save”, then
press the PUSH ENTER button.
The settings are saved.
To cancel the setting
Press the ↑, ↓, ←or →button to select “Cancel”, then
press the PUSH ENTER button.
To go back to the previous wizard
Press the ↑, ↓, ←or →button to select “Previous”, then
press the PUSH ENTER button.
