Sony FDDR-7000 User manual

MULTI-CHANNEL DIGITAL DISK RECORDER
FDDR-7000
INSTALLATION MANUAL
1st Edition (Revised 1)
BKFD-7800
HDD UNIT
BKFD-7009/7009A
HDD EXTENSION BOX
VIDEO CHANNEL BOARD SET
BKFD-7110
VIDEO PROCESS BOARD
BKFD-7120
SCSI BOARD
BKFD-7500
AUDIO BOARD
BKFD-7600
OPERATION SOFTWARE
BZFD-7010/7020

!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
DieAnleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt dieAngaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien.Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
Attention-when the product is installed in Rack:
1. Prevention against overloading of branch circuit
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
make sure that the rack does not overload the supply
circuit.
2. Providing protective earth
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
confirm that the outlet is provided with a suitable
protective earth connection.
3. Internal air ambient temperature of the rack
When this product is installed in a rack, please make
sure that the internal air ambient temperature of the
rack is within the specified limit of this product.
4. Prevention against achieving hazardous
condition due to uneven mechanical loading
When this product is installed in a rack, please make
sure that the rack does not achieve hazardous
condition due to uneven mechanical loading.
FDDR-7000 Serial No. 10001 and Higher
BKFD-7800 Serial No. 10001 and Higher
BKFD-7009 Serial No. 10001 and Higher
BKFD-7009A Serial No. 10001 and Higher
BKFD-7110 Serial No. 10001 and Higher
BKFD-7120 Serial No. 10001 and Higher
BKFD-7500 Serial No. 10001 and Higher
BKFD-7600 Serial No. 10001 and Higher
BZFD-7010 Software Version 1.10 and Later
BZFD-7020 Software Version 1.10 and Later

1(E)
FDDR-7000 IM
Table of Contents
Manual Structure
Purpose of this manual ........................................................................................ 3 (E)
Related manuals................................................................................................... 3 (E)
1. Installation
1-1. Operating Environment.........................................................................1-1 (E)
1-2. Power Supply ........................................................................................1-2 (E)
1-2-1. Power Specifications ............................................................1-2 (E)
1-2-2. Power Cord...........................................................................1-2 (E)
1-3. Space for Attachment............................................................................1-3 (E)
1-3-1. FDDR-7000 (Multi-channel digital disk recorder) ..............1-3 (E)
1-3-2. BKFD-7800 (HDD extension box) ......................................1-4 (E)
1-4. Rack Mounting......................................................................................1-5 (E)
1-4-1. FDDR-7000 (Multi-channel digital disk recorder) ..............1-5 (E)
1-4-2. BKFD-7800 (HDD extension box) ......................................1-8 (E)
1-5. Installation and Removal of Exterior Parts .........................................1-11 (E)
1-5-1. FDDR-7000 (Multi-channel digital disk recorder) ............1-11 (E)
1-5-2. BKFD-7800 (HDD extension box) ....................................1-13 (E)
1-6. Installation of Power Unit ...................................................................1-14 (E)
1-6-1. FDDR-7000 (Multi-channel digital disk recorder) ............1-14 (E)
1-6-2. BKFD-7800 (HDD extension box) ....................................1-14 (E)
1-7. List of Supplied Accessories...............................................................1-15 (E)
1-7-1. FDDR-7000........................................................................1-15 (E)
1-7-2. BKFD-7800........................................................................1-15 (E)
1-8. Accessories..........................................................................................1-15 (E)
1-8-1. FDDR-7000........................................................................1-15 (E)
1-8-2. BKFD-7800........................................................................1-15 (E)
2. Installation of Options
2-1. Location of Main Parts..........................................................................2-1 (E)
2-1-1. FDDR-7000 (Multi-channel digital disk recorder) ..............2-1 (E)
2-1-2. BKFD-7800 (HDD extension box) ......................................2-3 (E)
2-2. Inserting/Pulling Out of Plug-in Boards ...............................................2-3 (E)
2-3. Installation of Optional Boards .............................................................2-5 (E)
2-4. Precautions on Installation and Removal of
BKFD-7009/7009A (HDD unit) ...........................................................2-7 (E)
2-4-1. For Maintain the Performance of BKFD-7009A .................2-7 (E)
2-4-2. When BKFD-7009/7009A is Installed.................................2-7 (E)
2-4-3. When BKFD-7009/7009A is Increased ...............................2-8 (E)
2-4-4. When HDD (Hard Disk Drive) Unit Becomes Defective ....2-8 (E)

2(E) FDDR-7000 IM
2-5. Installation and Removal of BKFD-7009/7009A (HDD unit)............2-10 (E)
2-5-1. FDDR-7000 (Multi-channel digital disk recorder) ............2-10 (E)
2-5-2. BKFD-7800 (HDD extension box) ....................................2-10 (E)
3. Confirmation in Installation
3-1. Description of On-Board Switch Settings and LEDs............................3-1 (E)
3-1-1. CPU-253 Board ....................................................................3-1 (E)
3-1-2. DPR-88 Board ......................................................................3-4 (E)
3-1-3. SCS-15 Board.......................................................................3-5 (E)
3-1-4. VIO-30 Board.......................................................................3-7 (E)
3-2. Confirmation and Adjustment of Secondary Power Supply Voltage ...3-8 (E)
3-2-1. FDDR-7000 (Multi-channel digital disk recorder) ..............3-8 (E)
3-2-2. BKFD-7800 (HDD extension box) ....................................3-10 (E)
4. Connectors
4-1. Connectors.............................................................................................4-1 (E)
4-1-1. Matching Connectors ...........................................................4-1 (E)
4-2. Input and Output Signals of Connectors ...............................................4-2 (E)
4-2-1. FDDR-7000 (Multi-channel digital disk recorder) ..............4-2 (E)
4-2-2. BKFD-7800 (HDD extension box) ......................................4-7 (E)
5. System Setup
5-1. Initial Setup ...........................................................................................5-1 (E)
5-2. System Startup and Shut Down.............................................................5-1 (E)
5-2-1. System Startup .....................................................................5-1 (E)
5-2-2. System Shut Down ...............................................................5-2 (E)
5-3. Installation of Operation Software ........................................................5-3 (E)
5-4. Resource Setup Using the Initial Setup Tool ........................................5-6 (E)
5-4-1. When One FDDR-7000 is Connected to the
Host Computer .....................................................................5-6 (E)
5-4-2. When Two or More FDDR-7000s Are Connected to the
Host Computer .....................................................................5-7 (E)
5-5. Initial Setup Tool...................................................................................5-8 (E)
5-5-1. Using the Command “faradres” of the Initial Setup Tool ....5-8 (E)
5-5-2. How to Use the Initial Setup Tool........................................5-8 (E)
5-6. HDD Restoration Tool ..........................................................................5-9 (E)
5-6-1. Preparations ..........................................................................5-9 (E)
5-6-2. System Settings ..................................................................5-10 (E)
5-6-3. Starting the System ............................................................5-10 (E)
5-6-4. End of Restoration..............................................................5-12 (E)

3(E)
FDDR-7000 IM
Purpose of this manual This manual is the installation manual of the multi channel digital disk recorder
FDDR-7000 and the it’s options video channel board set BKFD-7110, video process
board BKFD-7120, SCSI board BKFD-7500, audio board BKFD-7600, HDD
extension box BKFD-7800 and HDD unit BKFD-7009/7009A.
This manual is intended for use by trained system and service engineers, and
describes the information for install the FDDR-7000 and it’s options and,
installation of operation software BZFD-7020.
Related manuals Besides this Installation Manual, the following manuals are available for FDDR-
7000.
..
..
.User’s Guide (Supplied with BZFD-7020.)
This manual describes the application and operation of FARAD system.
Part number : 3-860-511-01
..
..
.Operation Manual (Supplied with FDDR-7000.)
This manual explains the overview of FDDR-7000 and options, and the system
configuration examples.
Part number : 3-860-507-03
..
..
.Operation and Maintenance Guide
(Supplied with BKDF-7600, BKFD-7800 or BKFD-7009/7009A/7120/
7110/7500.)
Part number : 3-865-595-01 <BKFD-7600>
Part number : 3-860-508-01 <BKFD-7800>
Part number : 3-860-509-03 <BKFD-7009/7009A/7120/7110/7500>
..
..
.Maintenance Manual Part 1 (Supplied with FDDR-7000.)
This manual describes the informatin on primary service.
Part number : 3-193-258-02
..
..
.Maintenance Manual Part 2 (Not supplied with FDDR-7000.)
(Service Overview, Electrical Alignment, Spare parts and Semiconductor pin
assingnments, Block diagrams, Board layouts and Schematic diagrams)
Part number : 9-968-510-01
This manual describes the information that premise the service based on parts.
If this manual is required, please contact to Sony’s service organization.
The part numbers of these manuals as of September, 1998 describe.
Manual Structure

1-1(E)
FDDR-7000 IM
Section 1
Installation
1-1. Operating Environment
w
Avoid placing or using this unit where it will be exposed to
greasy fumes, steam, dampness and dust environments.
If placing or using this unit in these environments, it may
cause a fire and an electric shock.
n
1. Do not install these units near heat sources.
2. To prevent a temperature rise inside the unit, pay
careful attention to circulation of air in the place where
the unit is installed.
Do not block the ventilation holes on the outer cabinet.
3. Do not install the unit in the following places:
.Where it is subject to direct sun light or strong light.
.Places subject to severe vibration or much dust.
.Places subject to strong electric or magnetic fields.
.In a location subject to much electrical noise especially
subject to static electricity noises.
4. Precautions when installed in vehicle
.Do not attempt to operate (by turning on the main
power) the FDDR-7000 and BKFD-7800 while the
vehicle is moving. (Vehicles are prohibited from
moving while the FDDR-7000 and BKFD-7800 are
turned on.)
.The operating environment must satisfy the following
impact resistance characteristics and vibration resistance
characteristics for hard disks both while the vehicle is
stopped and moving. (The hard disk non-operation
specifications of impact resistance characteristics and
vibration resistance characteristics must also be satisfied,
when a vehicle containing a hard disk moves.)
Temperature range
Operating temperature : +5 to +40 dC (41 to 104 dF)
Performance warranty : +10 to +35 dC (50 to 95 dF)
Storage temperature : _20 to +60 dC (_4 to +140 dF)
Humidity
Operating humidity : 20 to 80 % (no condensation)
Storage humidity : 20 to 85 %
..
..
.HDD UNIT BKFD-7009/7009A (Internal Hard Disk)
Operating altitude : _1,000 to10,000 feet
(_305 to 3,048 m)
Storage altitude : _1,000 to 40,000 feet
(_305 to 12,210 m)
Impact resistance characteristics
<HDD operation specifications>
Performance warranty : Maximum 2.0 G (Half period of
sine wave, max. 11 ms)
Operation warranty : Maximum 10 G (Half period of
sine wave, max. 11 ms, 2 impacts/
second)
<HDD non-operation specifications>
:Maximum 50 G (Half period of
sine wave, maximum 11 ms
without repetitive impact). Or,
maximum 100 G (Half period of
sine wave, maximum 2 ms
without repetitive impact)
Vibration resistance characteristics
<HDD operation specifications>
Performance warranty : 5 to 400 Hz, maximum 0.5 G
Operation warranty : 5 to 400 Hz, maximum 0.5 G
<HDD non-operation specifications>
: 5 to 22 Hz, maximum
displacement 0.033 inches
(1 mm), 22 to 400 Hz,
maximum 2.0 G

1-2(E) FDDR-7000 IM
1-2. Power Supply
1
1
1
For the customer in the U.S.A. and Canada
Required Parts
1Power Cord, 125 V 13 A(2.5 m)
(SONY P/N : 1-558-527-11)
For the customer in the United Kingdom
Required Parts
DK-2401 (EK)
1Power Cord, 250 V 10 A(2.4 m)
AC inlet
(Main unit)
AC inlet
(Main unit)
AC inlet
(Main unit)
For the customer in the all European countries
except the United Kingdom
Required Parts
DK-2401 (AE)
1Power Cord, 250 V 10 A(2.4 m)

1-2. Power Supply
1-2-1. Power Specifications
Power requirements : 100 to 240 V AC ±10 %, 50/60 Hz
FDDR-7000 : Current consumption
9.0 A/AC100 V to 3.8 A/AC240 V
maximum
(with all optional boards and eight
HDD unit BKFD-7009/7009A
installed)
BKFD-7800 : Current consumption
2.0 A/AC100 V to 0.9 A/AC240 V
maximum
(with four HDD unit BKFD-7009/
7009A installed )
A switching regulator is used for the power supply of
FDDR-7000 (Multi-channel digital disk recorder) and
BKFD-7800 (HDD extension box). The voltage within the
range of 100 V to 240 V can be used without changing the
supply voltage.
n
As the inrush current at turn-on is the maximum 14 A
<FDDR-7000>/4.8 A <BKFD-7800>, the capacity of the
AC power must be commensurate in it with the inrush
current.
If the capacity of the AC power is not the adequately large,
the breaker of the AC power at the supply side will operate
or the unit will abnormal operate.
1-2-2. Power Cord
w
The power cord is not supplied with FDDR-7000 and
BKFD-7800. Be sure to use the power cord that is
applicable to places in the world.
To avoid a fire or an electric shock, be sure to use the
designated power cord.
And do not damage to the power cord.

1-3(E)
FDDR-7000 IM
1-3. Space for Attachment
510
55
470
2929
16.5 5.5
13
40
40
23.5 368.3
443 (10 UNIT)
465
424
482 52.7
111.1 250.8 403.2
13
221.5

37.35

8-M4 Unit : mm
Mass : 73 kg (160 Ib 14 oz) (with all units installed)
1-3. Space for Attachment
n
1. Be sure to attach the units in a stable place. If the units are attached in a wobbly table or a slant surface, the units may
be dropped. This may cause a injury.
2. Install the unit in a level.
3. When a BKFD-7009/7009A is installed in a vehicle, use impact absorbing materials (such as shock absorber, etc.) such
that the internal hard disk non-operation specifications of the impact resistance characteristics and the vibration
resistance characteristics are satisfied. (Refer to section 1-1.)
1-3-1. FDDR-7000 (Multi-channel digital disk recorder)

1-4(E) FDDR-7000 IM
1-3. Space for Attachment
8-M4
98.7 304.8
254
101.6
2244
37
57.2
37
132.4 (3 UNIT)
482
465
424
23.5
55
5.716.3
29 29
465
Unit : mm
Mass : 29 kg (63 lb 14 oz) (with all units installed)
1-3-2. BKFD-7800 (HDD extension box)
