simply unique.
H.264 Multi-Channel
Covert Digital Video Recorder
Features
•4/8/16Channeldigitalvideorecorderincovertwallmountchassis
•NetworkableDVRwithfreeDDNSserver
•Easyandsimplegraphicaluserinterface
•EZCopy,EZRecordsetting
•Programmablerecordingonmotiondetection,sensor,schedule,
continuousandmanual
•Recordingrateat120FPSatD1
•H.264videocompression
•BuiltinS.M.A.R.T.(Self-Monitoring,AnalysisandReporting
TechnologyforHDD)technology
•4channelaudiorecording
•Covertcameraoperationprovidesenhancedsecurityand
administratorcontrol
•Noaccessibleusercontrols
•Passwordtosecureinstallationauthorization
•EasyrmwareupgradebyUSBportornetwork
•InstantandconvenientbackupviaUSBFlashDriveorNetwork
•Simultaneousplayback/recordwhilecontinuingtonetworktransferorbackup
•Remotemonitoring/recording/playback/conguration/softwareupgradesand
PTZcontrolviaInternet
•NetworkaccessibleviaSpecoTechMulti-ClientSoftware,Web-ViewerandMobileViewer
•PC&MAC®compatible
•Digitalwatermarking
•3yearwarranty
•FreeAppswithsupportforiPhone®orAndroid®
D4WRS 4 Channel
D8WRS 8Channel
D16WRS16Channel
FormoreinformationcontactSpecoTechnologies
200NewHighway,Amityville,NY11701•TollFree:1-800-645-5516•Fax:631-957-9142or631-957-3880
www.specotech.com
Specications
•120FPS@704x480(D1)
•1Internalharddrive
•H.264videocompression
•4Channelaudioinput,1Channelaudiooutput
•Motiondetection,sensor,schedule,continuousand
manualrecording
•VideoOutputs:1VGA,1BNC,1SPOT
•USB2.0portforsnapshotandvideoclipexporting
•Multiplelanguageon-screenmenus
•IRremotecontrolincluded
•NetworksoftwaresupportsStaticIP,DHCPandDDNS
•Networkhardwaresupports10/100/1000Mbps
•Powerrequirement:12VDC@3A(D4WRS),12VDC@5A
(D8WRS&D16WRS)(included)
•Operatingtemperature:41°Fto104°F
•Dimensions:11”Wx15”Hx3.5”D(D4WRS)
13.5”Wx17”Hx3.5”D(D8WRS&D16WRS)
•Weight:8.5lbs(D4WRS)/9lbs.(D8WRS&D16WRS)
D4WRS
15”H
17”H
3.5”D
11”W 13.5”W
3.5”D
D8WRS/D16WRS
D4WRS250/500/1TB
D8WRS250/500/1TB/2TB
D16WRS250/500/1TB/2TB
®
Set-Up DVR
Wirelessly with
Speco’s Configurator™
iPad® App
SpecoTechnologiesisconstantlydevelopingandimprovingproducts.
Wereservetherighttomodifyproductdesignandspecicationswithoutnoticeandwithoutincurringanyobligation. Rev.9/12/11

HD DVR Specifications
D4/D8/D16WRSTechnicalSpecications:
H.264 Multi-Channel Covert Digital Video Recorder
Pleasenotethatspecicationsandunitexteriordesignaresubjecttochangewithoutnotication.
For more information contact Speco Technologies200NewHighway,Amityville,NY11701Rev.9/12/11
Toll Free: 1-800-645-5516 Fax: [phone] or 631-957-3880 Website: www.specotech.com
ITEM D4WRS D8WRS D16WRS
Video
Input
Channel 48 16
InputLevel Composite,1.0Vp-p,75ohm
SignalFormat NTSC/PAL
VideoLossCheck Yes
Output
VGA 1VGA(1280x1024,1024x768)
BNC Selectable 1Channel
SPOT 1Channel
Audio Input&Output 4Lineinput&1Lineoutput
AudioCodec G.711(ADPCM)
Alarm SensorInput(NC/NOSelectable) 4ch(NC/NOSelectable)
AlarmOutput 1AlarmoutbySensor,MotionandVideoLoss
Record Compression H.264
Multi-operation QUADPLEX(Playback/Record/Network/Backup)
Resolution
D1 120fps 120fps 120fps
HalfD1 120fps 240fps 240fps
CIF 120fps 240fps 480fps
Recordingqualitygrade LEVEL1(L)~LEVEL5(H)
Recording Mode Continuous/Schedule/Motion/Sensor/Manual
Motion Detection MotiondetectionsetupbyGrid
Recordingbychannel’sResolution Yes
PreRecording 1fpsfor15secondsto20minutesbeforeanevent
PostRecording 10secondsto60secondsafteranevent
Display FrameRate(/Sec) NTSC:30fps/ch,60elds/PAL:25fps/ch,50elds
Playback Multi-Decoding 1,4 1,4,8 1,4,8,16
SearchMode Timeline,Event,Archive,Log
Storage
HDD
InterfaceType SerialATA
Capacityof1HDD 1TB 2TB
InternalHDDNumber 1
ESATA -1
Backup
USBFlashdrive Video&StillImage
USBExternalHDD Video&StillImage
Network Video&StillImage
USBPort 2(Front1,Rear1)
UserI/F MenuDisplay GUI
InputMethod Mouse,IRRemotecontrol
RS-485 PTZcontrol 1RS-485
Network DynamicDNS Yes(FreeDDNS)
NetworkInterface 10/100base-TXEthernet 10/100/1000base-TXEthernet
NetworkStreaming CIF10fps/channelmax.
NetworkAccess Webviewer(1:1) Live,Search,Backup,PTZF,RemoteSetup
3GMobileViewer(1:1) Live
Multi-sitesMonitoringSW(1:n) Live,Search,Backup,PTZF,RemoteSetup
Features DLS(DayLightSaving) Yes
EZRecord Yes
EZCopy Yes
S.M.A.R.T. Ye s
InternalBeep ByVideoLoss,HDDErrorandS.M.A.R.T.
MultiLanguage Yes(English,Spanish,French)
S/WUpgrade USBFlashdrive,RemoteNetwork
NTP Yes
Power PowerConsumption DC12V3A DC12V5A
Allowableoperationtemperature 41°F-104°F,Duringstorage:14°F-122°F
Allowableoperationhumidity 20-80%
Weight UnitWeight 8.5lbs. 9lbs.
Dimension UnitDimension(WxHxD) 11"x15"x3.5" 13.5"x17"x3.5"
13.5”Wx17”Hx3.5”D11”Wx15”Hx3.5”D
