Ossur Bionic Symbionic Leg Reference guide

1/2 1/2
1/3 1/3 1/3
Quick Reference Card
Before fitting the SYMBIONIC®LEG, charge the unit for 2-4 hours to ensure a
full charge.
Turn the SYMBIONIC®LEG on
Bench alignment
a) Fit the foot with the selected cover and shoe.
b) Heel height adjustment on bench.
c) Optimize length/alignment of pylon and adaptors.
d) The alignment reference line should pass through a sagittal plane bisection
of the socket, the knee center and the posterior 1/3 of the Flex-Foot.
NOTE: If stability modifications are desired after patient assessment; the
reference line can be shifted up to 5 mm anterior or 5 mm posterior to the knee
center.
Static Alignment
a) Select appropriate heel wedge.
b) Check reference line during static alignment and adjust if required.
c) Optimize knee settings in RHEOLOGIC.
POWER
ON/OFF
2 BEEP = ON
3 BEEP = OFF
Function Hold
Sound
SET
HEEL
HEIGHT x2
1 BEEP = Start
1 BEEP = Move
1 BEEP = Complete
Function
Hold Press Sound
CALIBRATION
ON/OFF 2 BEEP = ON/OFF
x9
Function Hold Press Sound
d) Ankle calibration.

www.ossur.com QRC 0042 EN Rev. 1
©Copyright Össur 2013
Training checklist
1) Train user on level ground.
2) Train user on ramps/stairs.
Make sure the user knows how to:
1) Charge the unit and recognize low battery level warning.
2) Turn power ON/OFF and unlock the keypad.
3) Adjust the heel height when changing shoes.
Charging and power
Insert the charger cable into the charging port on the user interface panel on the knee module.
Charging: The yellow light on the ankle unit blinks when
charging and becomes a solid light when it is fully
charged.
The knee module does not indicate charging status.
Power: Fully charged battery is sufficient for 16-24 hours of
continuous use, depending on activity.
Warnings: Auditory warning signals indicate impending power
loss.
Relax Mode OFF
Relax Mode ON
(with chair exit mode)
Chair Exit Mode only
1 BEEP
2 BEEP
3 BEEP
x5
Mode Sequence Hold Press Sound
RELAX MODE
2x BEEP
3x BEEP
Approx. 5 hrs left
Warning Indicates
4x BEEP
5x BEEP
Approx. 4 hrs left
Approx. 3 hrs left
Approx. 2 hrs left
Ankle will return to neutral
(last set heel height)
Yellow LED is solid ON
1 x long high pitch
beep Ankle will return to neutral position and
SYMBIONIC LEG will turn OFF
