Fibre optic isolating repeater
Series 9186
1 General Information
1.1 Manufacturer
R. STAHL Schaltgeräte GmbH
Am Bahnhof 30
74638 Waldenburg
Germany
Phone: [phone]
Fax: [phone]
Internet: www.stahl-ex.com
E-Mail: [email protected]
1.2 Information about the Manual
ID-No.: 918660330020
Publication Code: 2016-10-18·HB00·III·en·01
Hardware version: 20 (Type 9186/12); 12 (Type 9186/.5)
Software version: 122 (Type 9186/12); 130 (Type 9186/.5)
The original instructions are the English edition.
They are legally binding in all legal affairs.
1.3 Further Documents
• Data sheet 9186
• Product information 9186
For further languages, see www.stahl-ex.com.
1.4 Conformity with Standards and Regulations
See certificates and EU Declaration of Conformity: www.stahl-ex.com.
The device has IECEx approval. See IECEx homepage: http://iecex.iec.ch/
Further national certificates can be downloaded via the following link:
http://www.r-stahl.com/downloads/certificates.html.

Explanation of the Symbols
4918660330020
2016-10-18·HB00·III·en·01
Fibre optic isolating repeater
Series 9186
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
2 Explanation of the Symbols
2.1 Symbols used in this Manual
2.2 Warning Notes
Warnings must be observed under all circumstances, in order to minimize the risk due to
construction and operation. The warning notes have the following structure:
• Signalling word: DANGER, WARNING, CAUTION, NOTICE
• Type and source of danger/damage
• Consequences of danger
• Taking countermeasures to avoid the danger or damage
Symbol Meaning
Tips and recommendations on the use of the device
General danger
Danger due to explosive atmosphere
Danger due to laser radiation
DANGER
Danger to persons
Non-compliance with the instruction results in severe or fatal injuries to
persons.
WARNING
Danger to persons
Non-compliance with the instruction can result in severe or fatal injuries
to persons.
CAUTION
Danger to persons
Non-compliance with the instruction can result in light injuries to
persons.
NOTICE
Avoiding material damage
Non-compliance with the instruction can result in material damage to the device
and / or its environment.

918660330020
2016-10-18·HB00·III·en·01
Safety Notes
5
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Fibre optic isolating repeater
Series 9186
2.3 Symbols on the Device
3 Safety Notes
3.1 Storage of the Manual
• Read the manual carefully.
• Store the manual at the mounting location of the device.
• Observe applicable documents and operating instructions of the devices to be
connected.
3.2 Personnel Qualification
Qualified specialist personnel are required to perform the tasks described in this manual.
This primarily applies to work in the following areas:
• Project engineering
• Mounting/dismounting the device
• (Electrical) installation
• Commissioning
• Maintenance, repair, cleaning
Specialists who perform these tasks must have a level of knowledge that meets
applicable national standards and regulations.
Additional knowledge is required for tasks in hazardous areas! R. STAHL recommends
having a level of knowledge equal to that described in the following standards:
• IEC/EN 60079-14 (Electrical installations design, selection and construction)
• IEC/EN 60079-17 (Inspection and maintenance of electrical installations)
• IEC/EN 60079-19 (Equipment repair, overhaul and reclamation)
Symbol Meaning
05594E00
CE marking according to the currently applicable directive.
02198E00
Electric circuit certified for hazardous areas according to the marking.
11048E00
Safety instructions that must always be observed: For devices with this
symbol, the corresponding data and/or the safety-relevant instructions
contained in this manual must be observed!

Safety Notes
6918660330020
2016-10-18·HB00·III·en·01
Fibre optic isolating repeater
Series 9186
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
3.3 Safe Use
Before mounting
• Read and observe the safety notes in this manual.
• Ensure that the contents of this manual are fully understood by the personnel in
charge.
• Always consult with R. STAHL Schaltgeräte GmbH if using the device under operating
conditions which are not covered by the technical data.
• We are not liable for damage caused by incorrect or unauthorised use of the device or
by non-compliance with this manual.
For assembly and installation
• Have mounting and installation performed only by qualified and authorised persons
(see "Personnel qualification" section).
• During installation and operation, observe the information (characteristic values and
rated operating conditions) on the type plates, data plates and information signs
located on the device.
• Only connect the device to equipment which does not carry voltages higher than
253 V AC (50 Hz).
• The safety characteristic values of the connected field devices must correspond to the
specifications in the data sheet or in the EU Type Examination Certificate.
• The laser diode of the fibre optic isolating repeater emits laser radiation.
The laser beam is emitted through the emitting diode (TD-A, TD-B) or through the end
of the fibre optic cable. According to EN 60825-1, the laser diode is assigned to the
laser class 1M. In order to avoid eye injuries, do not view the laser beam directly with
optical instruments (e.g. magnifiers, microscopes).
Additionally for Type 9186/12
• Install the device in Zones 1, 2, 21, 22 or outside of hazardous areas.
• When used in Zones 1, 2 or 22, the device must be built into an enclosure which
corresponds to the requirements of IEC/EN 60079-7, IEC/EN 60079-15 or
IEC/EN 60079-31.
• When used in Zones 2 and 22, the intrinsically safe devices of Zones 1, 0, 21 and
20 can be connected to the intrinsically safe signal circuits.
• Separate non-intrinsically safe circuits from intrinsically safe circuits.
• Electric circuits with the "Ex i" type of protection can no longer be operated as circuits
with this protection type after being operated with circuits with other types of protection.
• Interconnecting several devices in a single intrinsically safe circuit can result in
different safety characteristic values. This may impair intrinsic safety!
• Observe the system certificate (PTB 04 ATEX 2089) and operating instructions for the
Sub-D connector (94 900 02 22 0) if the RS-485-IS interface is to be connected with
other fieldbus devices to form a fieldbus system.
• Avoid making connections or disconnections at Ex e terminals 1 and 2 for auxiliary
power supply while the system is energised. After switching off the supply voltage,
wait one minute before disconnecting the lines from the device.

918660330020
2016-10-18·HB00·III·en·01
Safety Notes
7
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Fibre optic isolating repeater
Series 9186
Additionally for Type 9186/.5
• Install the device in Zones 2, 22 or outside of hazardous areas.
• When used in Zones 2 or 22, the device must be built into an enclosure which
corresponds to the requirements of IEC/EN 60079-15 or IEC/EN 60079-31.
• Only connect the FO interface with devices that correspond to the Ex op is type of
protection. Devices connected with the fibre optic isolating repeater may be installed
in Zones 2 or 22 or in the safe area.
• Only install the device in a de-energised state.
Commissioning, maintenance, repair
• Only have commissioning and repairs performed by qualified and authorised persons
(see "Personnel qualification" section).
• Before commissioning, make sure that the device is not damaged.
• Only perform maintenance work described in this manual.
3.4 Modifications and Alterations
DANGER
Explosion hazard due to modifications and alterations to the device!
Non-compliance results in severe or fatal injuries.
• Do not modify or alter the device.
No liability or warranty for damage resulting from modifications and
alterations.

Function and Device Design
8918660330020
2016-10-18·HB00·III·en·01
Fibre optic isolating repeater
Series 9186
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
4 Function and Device Design
4.1 Function
Application range
The fibre optic isolating repeater is used in hazardous areas to set up FO network
structures.
It enables transfer of asynchronous UART protocols such as Profibus DP and
Modbus signals over long distances.
Mode of operation
The signals are transmitted from an intrinsically safe RS-485-interface according to
PNO specification to an intrinsically safe optical interface (Ex op is).
DANGER
Explosion hazard due to improper use!
Non-compliance results in severe or fatal injuries.
• The device may only be used according to the operating conditions
described in this manual.
• Use the device only for the intended purpose specified in this
manual.

918660330020
2016-10-18·HB00·III·en·01
Function and Device Design
9
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Fibre optic isolating repeater
Series 9186
4.2 Device Design
Type 9186/12
# # Device component Description
09134E00
15636E00
Screw terminals
1,2 Terminal not used
3,4 Terminals 3 + 4 Fault message contact
21,22 Terminals 5 + 6 Shield connection (equipotential bonding)
RS-485 interface
5 Sub-D, RS-485 RS-485 interface, data line
Supply voltage status, RS-485
6 Green LED Indication for supply voltage
7 Yellow LED Indication for data sent
8 Green LED Indication for data received
Port A status
9 Green LED LED for very good transmission level
10 Green LED LED for good transmission level
11 Yellow LED System reserve reached (fault message contact
opened if both green LEDs are off)
12 Red LED "ERR A" Insufficient reception level, fibre breakage port A
13 Optical fibre
connection
transmitter
Port A (left)
Optical fibre transmitter port A, TD-A
14 Optical fibre
connection
receiver
Port A (left)
Optical fibre receiver port A, RD-A
Status Port B
15 Green LED LED for very good transmission level
16 Green LED LED for good transmission level
17 Yellow LED System reserve reached (fault message contact
opened if both green LEDs are off)
18 Red LED "ERR B" Insufficient reception level, fibre breakage port B
19 Optical fibre
connection
transmitter
Port B (right)
Optical fibre transmitter port B, TD-B
20 Optical fibre
connection
receiver
Port B (right)
Optical fibre receiver port B, RD-B
Connection terminal X4 for supply voltage (auxiliary power)
23 Terminal 2 0 V auxiliary power connection
24 Terminal 1 +24 V auxiliary power connection
6
7
8
12 3 4
9
10
11
12
15
16
17
18
19
20
5
13
14
21 22
23
24

Function and Device Design
10 918660330020
2016-10-18·HB00·III·en·01
Fibre optic isolating repeater
Series 9186
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Type 9186/.5
#Device component Description
08625E00
Screw terminals
1 Terminal +24 V auxiliary power connection
2 Terminal 0 V auxiliary power connection
3,4 Terminals 3 + 4 Fault message contact
RS-485 interface
5 Sub-D, RS-485 RS-485 interface, data line
Supply voltage status, RS-485
6 Green LED Indication for supply voltage
7 Yellow LED Indication for data sent
8 Green LED Indication for data received
Port A status
9 Green LED LED for very good transmission level
10 Green LED LED for good transmission level
11 Yellow LED System reserve reached (fault message contact
opened if both green LEDs are off)
12 Red LED "ERR A" Insufficient reception level, fibre breakage port A
13 Optical fibre
connection
transmitter
Port A (left)
Optical fibre transmitter port A, TD-A
14 Optical fibre
connection
receiver
Port A (left)
Optical fibre receiver port A, RD-A
Port B status (only for type 9186/15-12-11)
15 Green LED LED for very good transmission level
16 Green LED LED for good transmission level
17 Yellow LED System reserve reached (fault message contact
opened if both green LEDs are off)
18 Red LED "ERR B" Insufficient reception level, fibre breakage port B
19 Optical fibre
connection
transmitter
Port B (right)
Optical fibre transmitter port B, TD-B
20 Optical fibre
connection
receiver
Port B (right)
Optical fibre receiver port B, RD-B
6
7
8
12 3 4
9
10
11
12
15
16
17
18
19
20
5
13
14

918660330020
2016-10-18·HB00·III·en·01
Technical Data
11
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Fibre optic isolating repeater
Series 9186
5 Technical Data
Marking
Type designation 9186/..-1.-11
CE marking C0158
Explosion Protection
Version 9186/12-11-11 9186/.5-12-11
Global (IECEx)
Gas and dust IECEx BVS 12.0081X IECEx BVS 13.0107X
Ex e mb ib [ia op is Ga] IIC T4 Gb Ex nA nC [op is T6 Ga] IIC T4 Gc
[Ex ia Da] IIIC [Ex op is Da] IIIC
Europe (ATEX)
Gas and dust BVS 06 ATEX E 145 X BVS 07 ATEX E 068 X
E II 2 (1) G Ex e mb ib [ia op is Ga]
IIC T4 Gb
E II 3 (1) G Ex nA nC [op is T6 Ga]
IIC T4 Gc
E II (1) D [Ex ia Da] IIIC E II (1) D [Ex op is Da] IIIC
Certifications and certificates
Certificates IECEx, ATEX, Brazil (INMETRO), Canada (cFM), Kazakhstan (TR),
Russia (TR), USA (FM), Belarus (TR)
Ship approval ABS, CCS, ClassNK, DNVGL, LR, RS
Further parameters
Installation Zone 1 Zone 2 and in the safe area
Further information see respective certificate and operating instructions
Safety data
Max. voltage Uo± 3.7 V –
Max. current Io148 mA –
Max. power Po137 mW –
Safety-related
maximum voltage Um
253 V –
For connection
RS-485-IS
Max. permissible
voltage Ui
± 4.2 V –
Internal capacity
Ci and inductivity
Li
negligible –

Technical Data
12 918660330020
2016-10-18·HB00·III·en·01
Fibre optic isolating repeater
Series 9186
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Ex i fault-contact
Max. permissible
voltage Ui
24 V –
Max. permissible
current Ii
600 mA –
Internal capacity
Ci and inductivity
Li
negligible –
Optical interface
Type of protection Ex op is IIC T6
Radiant power Po15 mW
Technical Data
Version 9186/12-11-11 9186/.5-12-11
Electrical data
Auxiliary power
Nominal voltage
UN
24 V DC
Voltage range 18 to 31.2 V
Residual ripple < 3.6 Vss
Nominal current
(at UN)
67 mA 130 mA
Power input ( 2 W 3 W
Operation
indication
LED green "PWR"
Polarity reversal
protection
yes
Galvanic separation
Test voltage
acc. to standard EN 60079-11 –
between
RS-485 and
power supply
– 1.5 kV
Ex i RS-485 to
auxiliary power
1.5 kV –
Error-contact to
power supply
1.5 kV –
PA to power
supply
1.5 kV –
Explosion Protection

918660330020
2016-10-18·HB00·III·en·01
Technical Data
13
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Fibre optic isolating repeater
Series 9186
Ex i RS-485 to
fault message
contact
500 V –
Ex i RS-485 to
equipotential
bonding
500 V –
Error contact to
PA
500 V –
Optical interface
Protocols protocol transparent for RS-485 interface
Network
topologies
Ring topology, line topology, point-to-point connection
Redundancy automatic switching in case of line
fault
automatic switching in case of line
fault (except 9186/25-12-11)
Connection ST®, BFOC/2.5 connector
Wavelength 850 nm
Transmission
distance
( 2000 m
Recommended
optical fibres
G 50 / 125 multi mode
G 62.5 / 125 multi mode
Integrated diagnosis function with alarm and automatic switching to the backup
path. This enables increased availability.
Electrical interfaces
Protocols PROFIBUS DP, Modbus, HART over RS-485, ServiceBus R. STAHL (IS1+)
Version RS-485-IS (PNO) RS-485
Connection Sub-D socket X1, 9-pole
Bit rate 1.2 kbps ... 1.5 Mbps 9.6 kbps ... 1.5 Mbps
Settings You can select fixed baud rates or automatic baud rate detection
(only for PROFIBUS DP).
Bit refresh Received bit is reset to the original form.
Line length According to PROFIBUS Guideline depends on bit rate and cable
Transmission
method
2-wire, half-duplex
Terminating
resistor
to be connected to an external plug
Indication of data
reception
LED green "RD" ON
Indication of data
transmission
LED yellow "TD" ON
Technical Data

Technical Data
14 918660330020
2016-10-18·HB00·III·en·01
Fibre optic isolating repeater
Series 9186
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Fault control
Power supply
failure
Fault-contact is open
Transmission
level is good
LED green and yellow "FO signal", fault-contact is closed
Transmission
level reduced
(-1,5 dBm)
LED yellow "FO signal", fault-contact is open
Fibre breakage or
transmission level
is too low (-3 dBm)
LED red "FO ERR", fault-contact is open
Switching capacity
of fault-contact
see Ex i values max. 60 V DC, 42 V AC, 0.46 A
Electromagnetic
compatibility
Tested to the following standards and regulations:
EN 61326-1 Use in industrial environment
Ambient conditions
Ambient temperature -20 to +65 °C -20 to +60 °C
The installation conditions affect the ambient temperature.
Storage temperature -40 to +85 °C
Relative humidity
(no condensation)
( 95 %
Use at the height of < 2000 m
Mechanical data
Connectors
Power supply Spring clamp terminal, 0.2 ... 1.5 mm2
(Ex e)
Screw terminal, 0.2 ... 2.5 mm2 green
Fault-contact Screw terminalme, 0.2 ... 2.5 mm2
blue (Ex i)
Screw terminal, 0.2 ... 2.5 mm2 green
Screen connection
to PA
Screw terminal, 0,2 ... 2,5 mm2 blue via DIN rail contact
Serial connection Sub-D socket X1, 9-pole
Shield Using sub-D socket terminal strip
Fibre optic cable BFOC/2.5 for fibre optics 50/125, 62.5/125
Degree of protection
Enclosure IP30
Terminals
Powersupply
IP20 IP30
Terminals IP30
Weight approx. 330 g approx. 200 g
Enclosure material PA 6.6
Fire resistance
(UL-94)
V0
Technical Data

918660330020
2016-10-18·HB00·III·en·01
Engineering
15
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Fibre optic isolating repeater
Series 9186
For further technical data, see www.stahl-ex.com.
6 Engineering
Mounting / Installation
Installation
conditions
Mounting type on DIN rail (NS35/15; NS35/7.5)
Connection diagram
DANGER
Explosion hazard due to too high temperature in the cabinet!
Non-compliance results in severe or fatal injuries!
• Install and adjust the cabinet in such a way that it is always
operated within the permissible temperature range.
Technical Data
9186/12-..-..
05352E00
PIN RS-485-IS
8A-
3B+
6 ISP+
5ISGND
9186/15-..-..
05354E00
PIN RS-485
8A-
3B+
6U+
5GND
9186/25-..-..
06005E00
PIN RS-485
8A-
3B+
6U+
5GND
5
6
x
x

Engineering
16 918660330020
2016-10-18·HB00·III·en·01
Fibre optic isolating repeater
Series 9186
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
6.1 PROFIBUS
Operating in linear structure
Calculate the minimum slot time TSL min according to the rule
TSL min = a + b x L + 2 x N
where:
TSL min: the minimum SLOT time in bit times
N: number of FO converters
L: Network reach in km
• Values a and b are dependent upon the data rate and bus profile used (see table).
Adjust the slot time TSL in the system configuration accordingly.
• Confirm that the minimum protocol processing time MIN TSDR amounts to at least
11 bit times (MIN TSDR ) 11).
Table: Programming parameters for linear structures
Operating in redundant ring
A ring structure is made of at least three type 9186 devices.
Calculate the minimum slot time TSL min according to the rule
TSL min = a + b x L + 2 x N
where:
TSL min: the minimum SLOT time in bit times
N: number of FO converters
L: Network reach in km
The data transmission lines and network components may cause signal
delays. The bus parameters must therefore by adjusted using appropriate
project engineering software. The defined maximum network reach must also
be taken into account.
Data rate
kbps
a b
DP DP/FMS
1500 161 991 15
500 111 371 5
187.5 71 371 1.875
93.75 71 211 0.9375
45.45 411 411 0.4545
19.2 71 76 0.192
9.6 71 71 0.096

918660330020
2016-10-18·HB00·III·en·01
Engineering
17
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Fibre optic isolating repeater
Series 9186
• Values a and b are dependent upon the data rate and bus profile used (see table).
Adjust the slot time TSL of the system configuration accordingly.
• Raise the RETRY LIMIT parameter by at least three.
• Confirm that the minimum protocol processing time MIN TSDR amounts to at least
11 bit times (MIN TSDR ) 11). This is the case as standard.
Table: Project engineering parameters for ring structures
Table: Ring size in PROFIBUS operating mode (various data rates)
Data rate
kbps
a b
DP DP/FMS
1500 161 1971 15
500 211 731 5
187.5 131 731 1.875
93.75 131 411 0.9375
45.45 811 811 0.4545
19.2 131 141 0.192
9.6 131 131 0.096
Number of
devices
Data rate (kbps) of the ring size [km]
9.6 19.2 45.45 93.75 187.50 500 1500
2 Not permitted
3 9.90 9.90 9.90 9.90 9.90 9.90 5.20
4 13.20 13.20 13.20 13.20 13.20 13.20 5.07
6 19.80 19.80 19.80 19.80 19.80 14.40 4.80
8 26.40 26.40 26.40 26.40 26.40 13.60 4.53
10 33.00 33.00 33.00 33.00 33.00 12.80 4.27
12 39.60 39.60 39.60 39.60 39.60 12.00 4.00
14 46.20 46.20 46.20 46.20 29.87 11.20 3.73
16 52.80 52.80 52.80 52.80 27.73 10.40 3.47
18 59.40 59.40 59.40 51.20 25.60 9.60 3.20
20 66.00 66.00 66.00 46.93 23.47 8.80 2.93
22 72.60 72.60 72.60 42.67 21.33 8.00 2.67
24 79.20 79.20 79.20 38.40 19.20 7.20 2.40
26 85.80 85.80 70.41 34.13 17.07 6.40 2.13
28 92.40 92.40 61.61 29.87 14.93 5.60 1.87
30 99.00 99.00 52.81 25.60 12.80 4.80 1.60
32 105.60 105.60 44.00 21.33 10.67 4.00 1.33

Engineering
18 918660330020
2016-10-18·HB00·III·en·01
Fibre optic isolating repeater
Series 9186
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
• Note the maximum ring reach, which depends upon the data rate and number of
devices in use according to the table.
Example:
• Number of FO converters in the ring: 6
• Speed: 500 kbps
• Permitted total reach: 14.4 km
• Total installed length of the FO: 9.98 km => O. K.
Slot time to be set: TSL min = a + b x L + 2 x N = 211 + 9.98 x 5 + 2 x 6 = 273 bits
6.2 Modbus / ServiceBus
Calculate the signal delay dT according to the rule
dT= b x L + 2 x N
where:
Signal delay in bit times for a complete signal cycle
b: Length parameter (table)
L: Network reach in km
N: Number of fibre optic isolating repeaters
For the FO ring to function correctly, dT must be smaller than the shortest frame in bits.
Table: Correlation of data rate and length parameter b
Data transmission lines and network components may cause signal delays.
If necessary, these must be taken into account when adjusting the TIME-OUT
times of the bus system used.
Data rate b
1.5 Mbps 15
500 kbps 5.00
375 kbps 3.75
187.5 kbps 1.88
93.75 kbps 0.94
57.6 kbps 0.58
38.4 kbps 0.38
19.2 kbps 0.19
9.6 kbps 0.10
4.8 kbps 0.048
2.4 kbps 0.024
1.2 kbps 0.012

918660330020
2016-10-18·HB00·III·en·01
Engineering
19
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
Fibre optic isolating repeater
Series 9186
Modbus
For Modbus and similar UART protocols: At a minimum frame length of 44 bits,
the maximum FO ring size is determined based on the number of devices and the
data rate.
Table: FO ring size in Modbus operating mode (various data rates)
Num-
ber of
devices
Data rate (kbps) of the FO ring size [km]
1.2 2.4 4.8 9.6 19.2 38.4 57.6 93.75 187.5 500 1500
2 Not permitted
3 9.90 9.90 9.90 9.90 9.90 9.90 9.90 9.90 9.90 9.90 5.53
4 13.20 13.20 13.20 13.20 13.20 13.20 13.20 13.20 13.20 13.20 5.41
6 19.80 19.80 19.80 19.80 19.80 19.80 19.80 19.80 19.80 15.56 5.19
8 26.40 26.40 26.40 26.40 26.40 26.40 26.40 26.40 26.40 14.88 4.96
10 33.00 33.00 33.00 33.00 33.00 33.00 33.00 33.00 33.00 14.20 4.73
12 39.60 39.60 39.60 39.60 39.60 39.60 39.60 39.60 39.05 13.52 4.51
14 46.20 46.20 46.20 46.20 46.20 46.20 46.20 46.20 34.24 12.84 4.28
16 52.80 52.80 52.80 52.80 52.80 52.80 52.80 52.80 32.43 12.16 4.05
18 59.40 59.40 59.40 59.40 59.40 59.40 59.40 59.40 30.61 11.48 3.83
20 66.00 66.00 66.00 66.00 66.00 66.00 66.00 57.60 28.80 10.80 3.60
22 72.60 72.60 72.60 72.60 72.60 72.60 72.60 53.97 26.99 10.12 3.37
24 79.20 79.20 79.20 79.20 79.20 79.20 79.20 50.35 25.17 9.44 3.15
26 85.80 85.80 85.80 85.80 85.80 85.80 76.04 46.72 23.36 8.76 2.92
28 92.40 92.40 92.40 92.40 92.40 92.40 70.14 43.09 21.55 8.08 2.69
30 99.00 99.00 99.00 99.00 99.00 96.35 64.24 39.47 19.73 7.40 2.47
32 105.60 105.60 105.60 105.60 105.60 87.50 58.33 35.84 17.92 6.72 2.24

Engineering
20 918660330020
2016-10-18·HB00·III·en·01
Fibre optic isolating repeater
Series 9186
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
ServiceBus
The number of devices is limited to a maximum of 24 when operating in ServiceBus
mode.
Table: Ring size in ServiceBus operating mode (9.6 kbps data rate)
6.3 PROFIsafe
The PROFIsafe devices differ from the standard PROFIBUS devices by assigning
4 bytes of the possible payload range of a PROFIBUS frame for the additional PROFIsafe
information (frame ID, CRC, etc.). This additional data is analysed by the master
(F-Host).
To the type 9186 fibre optic isolating repeater, the PROFIBUS frames are transmitted
transparently, irrespective of the contents of the data. All type 9186 fibre optic isolating
repeaters can consequently be operated in PROFIBUS networks with and without
PROFIsafe devices.
Also note the Watchdog monitoring, configured for all PROFIsafe devices in the control
system. In the event of very large fibre optic networks or radio transmission of PROFIBUS
data, Watchdog monitoring can be triggered. In this case the configured Watchdog time
must be adjusted correspondingly.
Number of devices Ring size [km]
2 Not permitted
39.90
4 13.20
6 19.80
8 26.40
10 33.00
12 39.60
14 46.20
16 52.80
18 59.40
20 66.00
22 68.75
24 33.33
Based on the state-of-the-art technology, PROFIsafe devices and
PROFIBUS standard devices can be operated simultaneously in one
PROFIBUS network. It is commonly referred to as PROFIsafe in PROFIBUS
(not to be confused with PROFIsafe in PROFINET). More information on this
topic can be found in the relevant standards of the PNO.
