Steelcase Currency Enhanced D-Top with Modesty Panel User manual

If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©2021 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
®
Page 1 of 3
Doc # 159428 Rev A
Currency®Enhanced - D-Tops and P-Tops with Modesty Panel
#2

®
Page 2 of 3
Doc # 159428 Rev A
Cam Lock Fastening
(The cam lock screw needs to
be turned 3/4 full turn or 270ofor
complete engagement.)
CAM LOCK
CAM PIN
Shorter offset side
NOTE: The cam pin is
offset and needs to be
installed on the shorter
offset side. If the screw
heads are not visible,
turn the panel 180o.
PANEL
2
1
CAM LOCK NOTE:
If cam lock is installed high on the
surface, tap it down flush with the
surface. If that doesn't work,
replace part.
If cam lock is installed low into
the surface, screw cam pin out
to extend the length of the
cam pin.
Make sure the cam
lock is located parallel
to the side of the
surface as shown
CAM LOCK
(See cam lock note)
in step 2.
Align cam locks
with this edge

®
Page 3 of 3
Doc # 159428 Rev A
Pilot hole
locations
Cam Lock Fastening
(The cam lock screw needs to
be turned 3/4 full turn or 270ofor
complete engagement.)
CAM LOCK
CAM PIN
Shorter offset side
NOTE: The cam pin is
offset and needs to be
installed on the shorter
offset side. If the screw
heads are not visible,
turn the panel 180o.
PANEL
3a
3b
IMPORTANT: The assembly must be attached to an adjacent unit.
Refer to assembly direction 158275 to attach to a Bridge,
or 158276 to attach to a Return.
5
4
Apply stickers on all visible
cam joint faces to cover the
connector faces, after assembly.
Make sure the cam
lock is located parallel
to the side of the
CAM LOCK
(See cam lock note)
CAM LOCK NOTE:
If cam lock is installed high on the
surface, tap it down flush with the
surface. If that doesn't work,
replace part.
If cam lock is installed low into
the surface, screw cam pin out
to extend the length of the
cam pin.
Align end
panel cam
locks with
this edge
surface as shown
in step 3a.
Align modesty
panel cam
locks with
this edge
