Steelcase FrameOne User manual

Page 1 of 3
FRAMEONE
Assembly Instruction - 600/800D Intermediate Leg
®
May 2009
Intermediate Leg + Table
1. Align both left and right table together.
2. Position the Intermediate Leg in between both
connecting bracket. Make sure that the leg’s
indicator slot is facing the seating side of the
table.
Intermediate Leg
1
2
Slot is facing
the seating side
of the table

Page 2 of 3
FRAMEONE
Assembly Instruction - 600/800D Intermediate Leg
®
May 2009
Intermediate Leg + Table
3. Lock the Intermediate Leg in position with M10 Socket Screws and washers.
- 4 screw positions
4. Fix the Intermediate Leg only to the 600 depth table top by tightening
4 x M5 screws through the channel bracket.
DO NOT fix the intermediate leg for the 800 depth table as this
would disable the table top sliding feature.
4
3
M10 Socket Screw
Washer
600 Depth Table
Intermediate Leg
DO NOT FIX
INTERMEDIATE LEG
TO 800 DEPTH TABLE

Page 3 of 3
FRAMEONE
Assembly Instruction - 600/800D Intermediate Leg
®
May 2009
Intermediate Leg + Table
5. Completed Intermediate Leg installation
for 600D and 800D desking.
5
800 Depth Intermediate Leg
600 Depth Intermediate Leg
