Steelcase 9000 E.I.P. Corner Work Surface Series User manual

If you have a problem,
question, or request,
call your local dealer
or Steelcase Line 1 at
888.STEELCASE
(888.783.3522)
Outside the U.S.A. call:
1.616.246.4880
Or visit our website
www.steelcase.com
Si vous avez un problème,
question, ou demande,
appeler votre revendeur local
ou ligne 1 de Steelcase à
888.STEELCASE
(888,783,3522)
En dehors des Etats-Unis
appel: 1,616,246,4880
Ou visiter notre website
www.steelcase.com
Si usted tiene un problema,
pregunta, o petición,
llame a su distribuidor local
o línea 1 de Steelcase en
888.STEELCASE
(888,783,3522)
Fuera de los E.E.U.U.
llamada: 1,616,246,4880
O visite nuestro website
www.steelcase.com
c1998 Steelcase Inc.
Rapids Grand, MI 49501
U.S.A.
Les ETATS-UNIS.
Los E.E.U.U.
Printed in U.S.A.
Imprimé aux Etats-Unis.
Impreso en los E.E.U.U.
1
of
3
939501047 Rev B
Series 9000®E.I.P. Corner Work Surfaces
Models: S-98864 thru S-98872 and S-98874 thru S-98881
9/64” Drill Bit

2
of
3
939501047 Rev B
Refer to recommended work surface height
chart below. After selecting the desired
height of work surface,measure up from the
floor and place a pencil mark of piece of
masking tape on panel upright to indicate
where the top of cantilevered end support
assembly must be located.
1.
Hold cantilevered end support assembly in
a vertical position and insert tabs into slots
between panel upright and panel surface.
Push down engaging tabs into slots until
retainer lock snaps into place.
NOTE: The top of cantilevered end support
assembly must be aligned with pencil mark
or bottom of tape.
2.
RECOMMENDED WORK SURFACE HEIGHT
TYPING HEIGHT 26-3/4”
TYPING HEIGHT 27-3/4”
TYPING HEIGHT 28-3/4”
STANDARD DESK HEIGHT 29-3/4”
1-3/8"

3
of
3
939501047 Rev B
Insert tabs on rear corner support bracket
into slots between panel upright and panel
surface.
3.
Mount support brackets to cantilever using
1/4-20 x 1/2” bolts. Position work surface
onto cantilevered supports and secure with
(4) #10 x 7/8” wood screws. DO NOT
TIGHTEN AT THIS TIME! Next, using
holes in rear corner support bracket as a
template. Drill (2) 9/64” dia. holes 1” deep.
Install and tighten (2) #10 x 7/8” wood
screws. Tighten all screws.
4.
