Steelcase Machine and Typewriter unit 41-ATT Firmware update

Steelcase, Inc.
Grand Rapids, MI 49501
U.S.A.
1-888-783-3522
Tools
Assembly Directions Printed In U.S.A.
REV
93-9500974 A
Page 1 of 6
Attaching a 41-ATT Machine and Typewriter unit to a 3200 or 4200 Series Desk
5/16” Socket
3/16” Drill

3/32"
Assembly Directions
93-9500974 REV A Page 2 of 6
NOTES:
1. The following assembly steps apply to either a right or left hand 41-ATT unit. A left hand unit is shown for all instructions.
2. A steel top has been shown. When assembling a wood top, the same instructions apply.
3. If the unit is assembled on a non-carpeted floor, we recommend you cushion the top with cardboard.
4. If your unit has been pre-assembled, begin with Step 4.
ASSEMBLING RETURN UNIT END PANEL TO TOP
Place end panel over pre-drilled holes in end of top
and install (2) 1/4 x 1” hex head screws.
NOTE: Use (2) channel spacers when attaching an end panel
to a 4200 top.
1.
PACKAGE CONTENTS
QTY. DESCRIPTION
1 TOP
1 BACK PANEL
1 END PANEL & LEG ASSEMBLY
1 BOTTOM PANEL PLATE (FIG. C)
1 BOTTOM PANEL PLATE (FIG. D)
1 MOUNTING BRACKET
4 #10-24 HEX NUTS
2 #10-24 X 3/8” MACHINE SCREWS
4 1/4 X 1” HEX HEAD SCREWS (6 REQUIRED FOR WOOD TOP)
1 HANGER BRACKET
1 TWIN SPEEDNUT
2 CLIP ANGLE (NOT REQUIRED FOR WOOD TOP)
2 1/4-20 X 1-1/4” ROUND HEAD MACHINE SCREW (NOT REQUIRED FOR WOOD TOP)
3 #10 X 1/2” SHEETMETAL SCREW
2 #10 X 1/2” HEX HEAD SCREW
1 SLOPE TRAY ASSEMBLY
1 TYPE PAD
2 CHANNEL SPACERS (USED ON 4200 ONLY)
CHANNEL SPACERS
4200 ONLY
ATTACHING BACK PANEL
Fasten back panel to top with (3) #10 x 1/2”
sheetmetal screws. Before tightening screws be
sure to have a 3/32” overhang between the back
panel and end of top.
NOTE: Use (3) “Z” brackets when attaching back panel
to a 4200 top.
2.
Z BRACKET
4200 ONLY

INSTALLATION OF BOTTOM PANEL PLATE
Attach bottom panel plate to pre-drilled holes in each
panel (2) #10 x 1/2” sheetmetal screws. Next, attach
plate to back panel using (2) #10-24 x 3/8” machine
screws and hex nuts.
3.
BOTTOM PANEL PLATE DETERMINATION
Shown below are (2) bottom panel plate templates. Place each plate on
like template to determine proper usage and proceed with instructions.
Assembly Directions
93-9500974 REV A Page 3 of 6
Remove pull from box drawer.4.

Install mounting bracket.5. If you have a drawer with a flush
pull insert mounting bracket.
Assembly Directions
93-9500974 REV A Page 4 of 6
INSTALLATION OF HANGER BRACKET TO DESK
With your top drawer in an open position, center
hanger bracket over drawer front and tilt to engage
rear clamp flange behind top cross brace of desk
pedestal.
6. Close drawer thus engaging hanger bracket to
outer surface of drawer.
7.

DESK TO RETURN UNIT INSTALLATION
Place end of return unit on hanger bracket
and secure with (2) clip angles and (2) 1/4-
20 x 1-1/4” round head sheetmetal screws.
(For wood top, omit clip angle) Drill (2) 3/
16” thru mounting bracket and into top and
secure with (2) 1/4 x 1” hex head screws.
(For wood top, drill (4) 3/16” holes and use
(4) 1/4 x 1” hex head screws)
8.
Assembly Directions
93-9500974 REV A Page 5 of 6

BOTTOM PANEL PLATE RETURN UNIT TO DESK INSTALLATION
Remove bottom drawer from your desk. Then secure bottom panel plate to desk with (2) #10 x 1/2” sheetmetal
screws and (1) twin speednut. Assemble drawer back into desk.
9.
Secure bottom flange of back panel to bottom panel plate with (2) #10-24 x 3/8” machine screws and hex nuts.10.
Assembly Directions
93-9500974 REV A Page 6 of 6
